Chapter 16

1

• Chapter 16 Composites Teamwork and Synergy in
  Materials

2
Chapter Outline

• 16.1 Dispersion-Strengthened Composites
• 16.2 Particulate Composites
• 16.3 Fiber-Reinforced Composites
• 16.4 Characteristics of Fiber-Reinforced
  Composites
• 16.5 Manufacturing Fibers and Composites
• 16.6 Fiber-Reinforced Systems and
  Applications
• 16.7 Laminar Composite Materials
• 16.8 Examples and Applications of Laminar
  Composites
• 16.9 Sandwich Structures

3
(No Transcript)
4
(No Transcript)
5
(No Transcript)
6
Figure 16.1 Some examples of composite materials
(a) plywood is a laminar composite of layers of
wood veneer, (b) fiberglass is a fiber-reinforced
composite containing stiff, strong glass fibers
in a softer polymer matrix (? 175), and (c)
concrete is a particulate composite containing
coarse sand or gravel in a cement matrix (reduced
50).
7
Section 16.1
Dispersion-Strengthened Composites

• A special group of dispersion-strengthened
  nanocomposite materials containing particles 10
  to 250 nm in diameter is classified as
  particulate composites.
• Dispersoids - Tiny oxide particles formed in a
  metal matrix that interfere with dislocation
  movement and provide strengthening, even at
  elevated temperatures.

8
(No Transcript)
9
(No Transcript)
10
Section 16.2
Particulate Composites
11
(No Transcript)
12
Figure 16.4 Microstructure of tungsten
carbide20 cobalt-cemented carbide (1300). (From
Metals Handbook, Vol. 7, 8th Ed., American
Society for Metals, 1972.)
13
Figure 16.5 The steps in producing a
silver-tungsten electrical composite (a)
Tungsten powders are pressed, (b) a low-density
compact is produced, (c) sintering joins the
tungsten powders, and (d) liquid silver is
infiltrated into the pores between the particles.
14
Figure 16.6 The effect of clay on the properties
of polyethylene.
15
(No Transcript)
16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
Section 16.4
Characteristics of Fiber-Reinforced Composites

• Many factors must be considered when designing a
  fiber-reinforced composite, including the length,
  diameter, orientation, amount, and properties of
  the fibers the properties of the matrix and the
  bonding between the fibers and the matrix.
• Aspect ratio - The length of a fiber divided by
  its diameter.
• Delamination - Separation of individual plies of
  a fiber-reinforced composite.

22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
Figure 16.11 Effect of fiber orientation on the
tensile strength of E-glass fiber-reinforced
epoxy composites.
26
Figure 16.12 (a) Tapes containing aligned fibers
can be joined to produce a multi-layered
different orientations to produce a
quasi-isotropic composite. In this case, a
0/45/90 composite is formed.
27
Figure 16.10 Increasing the length of chopped
E-glass fibers in an epoxy matrix increases the
strength of the composite. In this example, the
volume fraction of glass fibers is about 0.5.
28
(No Transcript)
29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
Figure 16.13 A three-dimensional weave for
fiber-reinforced composites.
33
(No Transcript)
34
Figure 16.14 Comparison of the specific strength
and specific modulus of fibers versus metals and
polymers.
35
Section 16.5
Manufacturing Fibers and Composites

• Chemical vapor deposition - Method for
  manufacturing materials by condensing the
  material from a vapor onto a solid substrate.
• Carbonizing - Driving off the non-carbon atoms
  from a polymer fiber, leaving behind a carbon
  fiber of high strength. Also known as pyrolizing.
• Filament winding - Process for producing
  fiber-reinforced composites in which continuous
  fibers are wrapped around a form or mandrel.
• Pultrusion - A method for producing composites
  containing mats or continuous fibers.

36
Figure 16.20 A scanning electron micrograph of a
carbon tow containing many individual carbon
filaments (x200).
37
Figure 16.22 Producing composite shapes in dies
by (a) hand lay-up, (b) pressure bag molding, and
(c) matched die molding.
38
(No Transcript)
39
Figure 16.24 Producing composite shapes by
pultrusion.
40
Figure 16.23 Producing composite shapes by
filament winding.
41
(No Transcript)
42
Figure 16.21 Production of fiber tapes by
encasing fibers between metal cover sheets by
diffusion bonding.
43
(No Transcript)
44
Section 16.7
Laminar Composite Materials

• Rule of Mixtures - Some properties of the laminar
  composite materials parallel to the lamellae are
  estimated from the rule of mixtures.
• Producing Laminar Composites - (a) roll bonding,
  (b) explosive bonding, (c) coextrusion, and (d)
  brazing.

45
Figure 16.30 Techniques for producing laminar
composites (a) roll bonding, (b) explosive
bonding, and (c) coextrusion, and (d) brazing.
46
Section 16.8
Examples and Applications of Laminar Composites

• Laminates - Laminates are layers of materials
  joined by an organic adhesive.
• Cladding - A laminar composite produced when a
  corrosion-resistant or high-hardness layer of a
  laminar composite formed onto a less expensive or
  higher-strength backing.
• Bimetallic - A laminar composite material
  produced by joining two strips of metal with
  different thermal expansion coefficients, making
  the material sensitive to temperature changes.

47
Section 16.9
Sandwich Structures

• Sandwich - A composite material constructed of a
  lightweight, low-density material surrounded by
  dense, solid layers. The sandwich combines
  overall light weight with excellent stiffness.
• Honeycomb - A lightweight but stiff assembly of
  aluminum strip joined and expanded to form the
  core of a sandwich structure.

48
Figure 16.32 (a) A hexagonal cell honeycomb
core, (b) can be joined to two face sheets by
means of adhesive sheets, (c) producing an
exceptionally lightweight yet stiff, strong
honeycomb sandwich structure.
49
Figure 16.33 In the corrugation method for
producing a honeycomb core, the material (such as
aluminum) is corrugated between two rolls. The
corrugated sheets are joined together with
adhesive and then cut to the desired thickness.
