Histology of the Gastrointestinal Tract'

1
Histology of the Gastrointestinal Tract. Biology
316.
2

• ESOPHAGUS
• Mucosa stratified squamous epithelium,
  nonkeratinized
• Submucosa unremarkable
• Muscularis
• skeletal
• mixed skeletal/smooth
• smooth
• Adventitia

3
Layers of the esophagus
siumed.edu
4
(No Transcript)
5
Esophagus
6
Stomach Mucosa simple columnar
epithelium Submucosa connective tissue
Muscularis 2 layers of smooth muscle
(inner circular, outer
longitudinal ) Serosa
7
Stomach
8
STOMACH

• Mucosa Simple columnar epithelium

9
Schematic of layers of the stomach
10
Stomach mucosa pits and glands
Parietal cells HCl, intrinsic factor Chief
cells Pepsin Mucus-secreting cells on the
surface and in the gastric pits Endocrine cells
ghrelin (stimulates appetite) gastrin
(influences secretion)
11
Histology of the Stomach Low Power View
12
Gastric Mucosa
13
Pyloric Region of the Stomach. Note that the
mucosa looks somewhat different, but it is still
simple columnar epithelium
14
(No Transcript)
15
Small Intestine Duodenum, Jejunum,
Ileum,
Specializations for absorption Folds of
plasma membranes microvilli Folds of mucosa
villi, with glandular
crypts in between
Folds of submucosa plicae circulares Musculari
s inner circular, outer longitudinal
smooth muscle Serosa
16
Small Intestine Duodenum, Jejunum,
Ileum,
17
Small Intestine Duodenum, Jejunum,
Ileum,
Small Intestine Duodenum, Jejunum,
Ileum,
VILLUS Simple Columnar Epithelium Lamina
Propria Crypts
18
Small Intestine Duodenum, Jejunum,
Ileum,
19
Small Intestine Duodenum, Jejunum,
Ileum,
20
Another View of the Jejunum
21
Small Intestine Duodenum, Jejunum,
Ileum,
22
Small Intestine Duodenum, Jejunum,
Ileum,
FUNCTIONS Digestion with pancreatic
enzymes proteins fats
starch Absorption amino acids
fats
glucose
water Secretion disaccharidases
mucus Movement peristalsis
23
(No Transcript)
24
Large Intestine Mucosa simple columnar
epithelium with increasing number of goblet cells
Submucosa Muscularis 3 layers (outer layer
is taenia coli)
Serosa
25
Large Intestine
26
Large Intestine
27
Colon 3 layers of muscularis
TAENIA COLI
28
(No Transcript)
29
OUR FRIEND, THE LIVER the hepatic lobule
30
OUR FRIEND, THE LIVER
31
Portal Triad
Branch of the hepatic portal vein
Branch of the hepatic artery
Branch of the bile duct
32
More of the portal triad..
33
The Hepatocyte, the Sinusoid, and the Bile
Canaliculus
34
Our Friend, the Gall Bladder
35
Pancreas
36
PANCREAS
37
ISLET OF LANGERHANS surrounded by pancreatic
acini
38
(No Transcript)
