Computer Animation with Flash CS3

1
Computer Animationwith Flash CS3 ActionScript
3.0

• National Polytechnic Institute of Cambodia
• Bachelor of IT, Year III, Semester 1
• 2007-2008
• by
• Oum Saokosal, Head of IT Department

2
Chapter 22Interactivity

• Computer Animationwith Flash CS3 ActionScript
  3.0

3
Interactivity

• Event basics
• Mouse events
• Keyboard events

4
Event Basics (1)

• To add an event to an event target
• eventTarget.addEventListener(typeString,
  listenerFunction)
• E.g.
• var ballmvBall new mvBall()
• ball.addEventListener(MouseEvent.MOUSE_CLICK,
• onClickEvent)
• function onClickEvent(eMouseEvent)void
• trace(ball is hit)
• Note addEventListener is from EventDispatcher
  which DisplayObject inherits from.

5
Event Basics (2)

• To remove the event from an event
  targeteventTarget.removeEventListener(
  typeString, listenerFunction)
• E.g.
• var ballmvBall new mvBall()
• ball.addEventListener(MouseEvent.MOUSE_CLICK,
• onClickEvent)
• function onClickEvent(eMouseEvent)void
• trace(ball is hit)
• ball.removeEventListener(MouseEvent.MOUSE_CLICK,
• onClickEvent)
• Note The types and the listeners function MUST
  be the same.

6
Mouse events (1)

• Mouse-Input events
• Device mouse, trackball, a laptop touchpad, a
  laptop pointing stick, and a stylus.
• Event Class MouseEvent.
• MouseEvents class
• MOUSE_DOWN - ROLL_OVER
• MOUSE_UP - ROLL_OUT
• MOUSE_CLICK - MOUSE_OUT
• DOUBLE_CLICK - MOUSE_MOVE
• MOUSE_OVER - MOUSE_WHEEL

7
Mouse events (2)

• MOUSE_DOWN Happened when pressing left mouse
  button down
• MOUSE_UP Happened when pressing release mouse
  button
• MOUSE_CLICK Happened after pressing mouse down
  and release.
• DOUBLE_CLICK Happened after double click
• ROLL_OVER Happened only ONCE when rolling mouse
  over a target
• ROLL_OUT Happened only ONCE when rolling mouse
  over a target
• MOUSE_MOVE Happened every time whenever moving
  mouse over a target
• MOUSE_OVER Similar to ROLL_OVER.
• MOUSE_OUT Similar to ROLL_OUT.
• MOUSE_WHEEL Happened when scrolling mouse wheel
  up or down over a target.

8
Keyboard Events (1)

• Event class KeyboardEvent.
• KeyboardEvent class
• KEY_DOWN Happened when pressing a key down.
• KEY_UP Happened when releasing up a key.
• E.g.
• stage.addEventListener(KeyboardEvent.KEY_DOWN,
  keyDownOnStage)
• function keyDownOnStage(eKeyboardEvent)void
• trace(Any key is hit)
• Note Because some keys are short-cut in Flash
  Pro CS3, please run SWF file in Flash players
  and try to type keys again.

9
Keyboard Events (2)

• To specify a key, using keyCode from
  KeyboardEvent. E.g.
• stage.addEventListener(KeyboardEvent.KEY_DOWN,
  keyDownOnStage)
• function keyDownOnStage(keKeyboardEvent)void
• if(ke.keyCode 32)
• trace(Spacebar key is hit)
• Note trace() can use only in Flash Professional,
  not in Flash Players. So some key like Enter,
  Escape etc. shouldnt be tested with trace().

10
Keyboard Events (3)

• To set Key Code
• Using KeyboardEvent class.
• altKey Boolean
• ctrlKey Boolean
• shiftKey Boolean
• Using Keyboard class.
• capsLock Boolean
• numLock Boolean
• BACKSPACE
• CONTROL
• F1 -gt F15
• RIGHT, LEFT, UP, DOWN etc.

• Setting them manually
• Some keys like 1...9 or a ... Z dont have
  defined key codes.
• So we have to set them by ourselves.
• final var KEY_1uint 49
• final var KEY_Auint 65
• final var KEY_auint 97
• Note if you dont know which number is a key,
  please use trace(e.keyCode)

11
Keyboard Events (4)

• Example
• stage.addEventListener(KeyboardEvent.KEY_DOWN,
  keyDownOnStage)
• function keyDownOnStage(eKeyboardEvent)void
• trace(e.keyCode) // To see key code
• if(e.keyCode Keyboard.LEFT)
• trace("Left")
• if(e.keyCode Keyboard.RIGHT)
• trace("Right")
