Indian Remote Sensing Programme

1
Indian Remote Sensing Programme
Dr J Krishnamurthy Indian Space Research
Organisation Bangalore
Training programme on Participatory GIS for
Remote and Hilly Areas University of
Agricultural Sciences, Bangalore
January 16, 2008
2
Operational Earth Observation satellites
1979/81
1988/91
Experimental
Operational
IRS-1A 1B LISS-12 (72/36m)
2003
BHASKARA 1 /2 VIDICON, SAMIR
2001
1999
2005
1996
2007
TES PAN (1M)
IRS-P4 (OCEANSAT-1) OCM, MSMR
IRS-P3 WiFS, MOS, X-Ray
RESOURCESAT-1 LISS-3 (23.5) LISS-4 (5.8 M,) AWiFS
(55 M)
1995/1997
CARTOSAT - 1 PAN (2.5 M)
CARTOSAT - 2 PAN (1 M)
IRS-1C/1D LISS-3 (23/ 70 M), STEERABLE PAN (5.8
M), WiFS (188 M)
3
Indian Earth observation imaging capabilities
Delhi and Environs
4
FASAL Nationwide in-season Crop Forecasting
EO Applications in India
Towards Food Security Building Social
Infrastructure Building Physical
Infrastructure Building NR Assets Disaster
Management Support
Potential Fishing Zones
Drinking water Mission
Wasteland Inventory Watershed Development
Agriculture Soils Forest, Environment
Bioresources Land Water Resources Geology
Minerals Weather Climate Ocean
resources Disaster Support
Urban Info System Road / Rail/ Pipeline
Alignment
5
Forecasting Aof Agricultural outputs using Space,
Agrometeorogy and Land based observations (FASAL)
- Pre-harvest Crop Inventory
(Funded by Ministry of Agriculture and
Co-operation)
Acreage and production estimates for principle
crops such as wheat, rice, sorghum, cotton,
mustard and groundnut
Pre-harvest estimates
NCFC / DAC, GOI
Indias Wheat belt
STATE
COTTON PADDY
State Dept. of Planning
DISTRICT
Wheat ( 2006-7 27.30 Mha 72.25 Mt) Kharif
rice (2006-7, final forecast 36.16 Mha 73.37
Mt) (2007-8, first forecast 33.69 Mha
72.19 Mt) Winter potato ( 2007-8 1.04 Mha
18.84 Mt)
6
Wasteland Inventory, Development Monitoring
Phase 3 2005-06

• Ecologically Degraded Land - 64 MHa
• - 45 Mha culturable with interventions

• Categorisation for development in terms of
• A Sands, Barren(High capital investment)
• B Marginal Agril. (Intervention needed)
• C Saline, Aklaline.. (Second Generation Issues)

• Targeting Poverty Eco-degradation
• Creation of Rural Employment/Assets
• Watershed Development Programme

7
Watershed Monitoring Evaluation
(World Bank Assisted Sujala Watershed Development
Project)
77 Sub-watersheds ( 5 Districts, Karnataka)

• GIS MIS Design for Monitoring Evaluation
• Concurrent Monitoring of Implementation
• Social and Environmental Impact Assessment
• Dev. Activity

Remote Sensing GIS Utilisation at Village
level
Use of RS and GIS for midcourse and final
impact evaluation
a model of excellence and should be promoted
widely for other projects to follow World
Bank Review Team (Nov 2003 June 2004)
8
Potential Fishing Zones
Information Dissemination through INCOIS, DoD
9
Natural Resources of India
Geog. area 329 M ha Net sown area 143 M
ha Gross cropped area 193 M ha Gross
irrigated area 75 M ha Food grains
211 MT
LTA rainfall 88 cm Glaciers 8500
km3
Coast line 7500 km Coral
reefs, Mangroves EEZ
2 M km2 Fisheries Coastal 2.8
MT Inland 2.8 MT
Forest area 64 M ha Grasslands
12 M ha Wetlands 7.6 M ha Bio
diversity Flora 46000 (7.0 of
worlds) Fauna 81000 (6.5 of worlds)
10
Environmental Issues

• Land degradation
• E/S/WL 183/4.8/11.6 M ha
• Low Productivity (1635 kg/ha)
• Wastelands
• 63 Mha
• Forestry
• Decrease in closed forest
• Loss of species
• Water
• Depletion of ground water table
• Inequitable distribution of surface water
• Rainfall ( 880 /- 85 mm)
• Glacier retreat gt10 meters/year
• Degrading Coast
• Disasters
• Demographic pressure

11
NNRMS NR Repository Major elements
Create and maintain a systematic archive of all
the digital spatial data of thematic and base
maps generated using remote sensing data
NSDI Server
NRR Data generation
Other NNRMS Projects
12
NNRMS Standards
Fundamental requirement for national spatial
database infrastructure

• Standards provide common method to manage,
  access, and display information
• Exchange of Geospatial information demand common
  data format
• Integration of multiple data sets to derive
  action plan/decision making
• Generation of seamless GIS database

13
NNRMS Standards

• NNRMS Repository Design Standards
• Image standards image resolution
  (scale)national spatial framework datum
  projection image position accuracy band-to-band
  registration
• Thematic Cartographic mapping standards
  National spatial framework minimum map frame
  size datum projection position accuracy
  minimum mappable unit DEM Z-spacing DEM
  Z-Accuracy .
• GIS database standardNational spatial framework
  Tie-point interval for spatial framework
  coordinate units datum Coordinate Movement
  Tolerance Weed Tolerance Sliver Polygon
  Tolerance
• Output Standard Output formats output frame
  work output media output symbology.
• Quality standard National Spatial Framework
  Accuracy Position accuracy accuracy of
  classification ..

Input
Database
Output
14
Natural Resources Census
To provide a snap-shot of the countrys status of
natural resources with a repeat cycle will depict
changes and modifications

• At 1250,000 scale using IRS-AWiFS
• Periodic National level Land-use/ Land cover
  inventory for 3 seasons

• At 150,000 scale using IRS-LISS - 3
• National level Land-use/ Land cover inventory for
  3 season
• Pilot study for Geomorphology in 5 different
  Geomorphic Provinces initiated with GSI
• Snow and Glaciers mapping taken up with Min of En
  F
• Land degradation mapping launched with Department
  of Agriculture and co-operation

15
Large Scale Mapping
Preparation of 110,000 scale Cartographic
quality maps using space borne imagery and GPS
control

• Pilot Stage
• Studying efficacy of large scale mapping for
  different terrain types
• Standardization of mapping procedures including
  accuracies
• Designing Geospatial database
• Operational Stage
• Generation of large scale maps using Cartosat-I
  II satellite data.
• Generation of operational Geospatial database.

• OUTPUT
• Vector Map data layers
• Digital Elevation Model
• Ortho Image/Geo-rectified image
• Value Added Products

Dubrugarh, Imphal, Nowgong, Tezpur
16
Cadastral Referencing Database
Digital database of Cadastral maps overlaid on
Geo-referenced satellite data
State level seamless Cadastral database

• Land Information System
• Monitoring of implementation of developmental
  activity
• Social and Environmental Impact Assessment

Maharashtra, Chhattisgarh Karnataka Gujarat
17
CartoDEM

• Objective of the project is to prepare seamless
  digital elevation model for Indian land mass and
  to generate corresponding ortho-image using
  Cartosat-1 data

• CartoDEM deliverables
• Digital Elevation Model with Height accuracy of
  8m (LE90) Plan accuracy of 15 m (CEP90)
• Orthoimage with resolution of 2.5m

• Augmented Stereo-Strip Triangulation (ASST)
  software being developed by SAC is the backbone
  software for generating CartoDEM deliverables
• WGS 84 for both planimetry and elevation of
  CARTODEM data

18
NRDB Operational Setup
CENTRALIZED MASTER DATA BANK
METADATASERVER
APPLICATION SERVER_PRIMARY
MEDIA PRODUCTS SERVER
TOGGLE SERVER
SAN DATABASE STORAGE
APPLICATION SERVER_SECONDARY
QC SYSTEM
SPACENET
REGIONAL SERVER CONFIGURATION
RS_1
DAS DATABASE STORAGE
APPLICATION SERVER
RRSSCs, NESAC, NRSA, SAC
FTP SERVER
DATABASESERVER
TOGGLE SWITCH
TOGGLE SWITCH
TOGGLE SWITCH
ftp SERVER
ftp SERVER
19
NATURAL RESOURCES DATABASE

• Major Tasks
• Design and organisation of databases and
  meta
• data at MDS and RDS
• Development of software tools for data base
• organisation, meta data generation, network
• monitoring, user access portal services
• Configuration, procurement, installation,
  and operationalization of systems and network
• Portal development and operationalization for
• services to user
• Development of Indigenous GIS package
• ALL THE ABOVE TASKS COMPLETED. NRDB
  HAS BEEN OPERATIONALISED. PORTAL AVAILABLE ON
  24Hrsx7 DAYS TO USERS

20
NEW FRONT END
21
INFORMATION UPDATED
22
METADATA EXPLORER
23
METADATA SEARCH ENGINE
24
SEARCH RESULTS
25
DETAILS OF SELECTED SEARCH RESULT
26
DETAILS OF SELECTED SEARCH RESULT
27
GENERATING WORK ORDER
28
GENERATING WORK ORDER
29
SELECTED REQUEST
30
REQUEST-ID SENT BY E-MAIL
31
Indigenous GIS (IGIS) software
IGIS KEY STRENGTHS

• Indigenous Software development using object
  oriented languages
• Single Software for GIS and Image Processing
  Functionalities
• Compliant with OGC Standards and OGC Open Geo
  Data Model
• Automatic loading of all Indian Remote Sensing
  Satellite Data
• Inbuilt RDBMS (PostGRE) and support any RDBMS
  using ODBC
• Seamless Data handling capability
• Creating, Viewing, Querying Spatial data
  Output as Maps and Reports
• Easy Customization / User friendly GUI
• Supports all the Raster Vector file formats

TE of Module Integration level by
Inter-center team of ISRO
32
IGIS GRAPHIC USER INTERFACE
MAIN GUI
33
Theme Menu
34
Image Menu
35
Dr J Krishnamurthy kris_at_isro.gov.in
36
Indian Space Endeavor
BORN IN THE 60S VISION FOR NATIONAL DEVELOPMENT
APPLICATIONS DRIVEN AND SELF-RELIANT
APPLICATIONS LEADERSHIP
INTERNATIONAL COOPERATION
SPACE ASSETS
HUMAN RESOURCES EXPERTISE
Remote sensing telecom satellite constellations
STATE OF THE ART TECHNOLOGY
INDUSTRY
INFRA STRUCTURE
Strategic alliances
End- to- end capability
