HYDRONEPHROSIS

1
HYDRONEPHROSIS

• Donna C. Queyquep, M.D.
• PGY II, Pediatrics
• November 19, 2004

2
Definition

• The dilation of the renal pelvis and calyces.
• May be considered a physiologic response to the
  interruption of urine.
• Not always caused by obstruction.

3
(No Transcript)
4
Incidence

• Pre-natal ultrasound
• detects fetal anomaly in 1 of pregnancies, of
  which 20-30 are genitourinary in origin and 50
  manifest as hydronephrosis

5
Causes

• Can be intrinsic, extrinsic or functional and can
  be classified as to level within the urinary
  tract
• Ureter
• Intrinsic
• congenital ureteropelvic junction stricture
• papillary necrosis
• iatrogenic
• blood clot
• ureteral tumor

6
Causes

• Extrinsic
• retroperitoneal cancer
• aortic aneurysm
• retrocaval ureter
• inflammatory bowel disease
• retroperitoneal hemorrhage
• lymphocele

7
Causes

• Functional
• gram-negative infection
• neurogenic bladder
• Bladder
• Intrinsic
• calculi
• bladder neck contracture
• Functional
• VUR
• neurogenic bladder

8
Causes

• Urethra
• Intrinsic
• urethral stricture
• Extrinsic
• BPH

9
Antenatal Period

• The most common cause is physiologic dilation.
• Metanephric urine production begins at 8 weeks,
  even before ureteral canalization is complete.
• Transient obstruction with hydronephrosis occurs.

10
Embryology
11
(No Transcript)
12
(No Transcript)
13
Pathophysiology

• Anatomic and functional processes interrupts the
  flow of urine.
• There is a rise in ureteral pressure causing
  stretching and dilation if pressures continue to
  rise, leads to decline in renal blood flow and
  GFR.
• When significant obstruction is persistent, it
  affects nephrogenic tissue and results in varying
  degrees of cystic dysplasia and renal impairment.

14
Grading of Severity of Hydronephrosis
15
(No Transcript)
16
(No Transcript)
17
Most Common Causes in Neonates

• Ureteropelvic Junction Obstruction
• Ureterovesical Junction Obstruction
• Posterior Urethral Valves
• Eagle-Barrett Syndrome (a.k.a. Prune Belly
  Syndrome)
• Vesicoureteral Reflux
• Ureterocele

18
Ureteropelvic Junction Obstruction

• UPJ is the most common cause of hydronephrosis in
  children.
• May be the result of incomplete racanalizaton of
  the proximal ureter, abnormal development of
  ureteral musculature, abnormal peristalsis,
  ureteral valves or polyps.
• Causes functional obstruction.

19
Ureteropelvic Junction Obstruction

• Malefemale ratio is 21.
• Prior to prenatal screening, about 25 were
  diagnosed in the first year of life.
• Decreasing frequency with age.

20
Clinical Details of UPJ Obstruction

• Anatomically indistinct segment of the upper
  collecting system where the renal pelvis funnels
  into the ureter.
• In 25-40 of kidneys, a supernumerary artery
  crosses the collecting system on its course into
  the kidneys lower pole causing mechanical
  obstruction.
• Occurs more often on the left side than on the
  right with a 32 ratio.

21
(No Transcript)
22
Other facts on UPJ

• Often associated with other congenital renal
  anomalies
• ectopic or horseshoe kidneys
• duplication of the collecting system
• contralateral renal dysplasia
• MCDK
• renal agenesis
• VUR (lt40), often low grade
• VATER Syndrome

23
Diagnostic Modality for UPJ

• Ultrasonography is the initial modality of
  choice.
• IVP
• Retrograde pyelography
• Radionuclide renogram

24
Assessments on UTS

• Renal length/size
• Degree of caliectasis and parenchymal thickness
• Presence of ureteral dilatation

25
Treatment for UPJ Pyeloplasty
26
Posterior Urethral Valves

• Abnormal congenital mucosal folds that are thin
  membranes impeding bladder drainage.
• Most common obstructive urethral lesion in male
  newborns found at the distal prostatic urethra.
• Incidence is approxly 1 in 8,000 males.
• Approxly 50 have reflux.
• VCUG is the modality of choice.

27
Radiographic signs of PUV

• distended prostatic urethra
• valve leaflets
• bladder and/or bladder neck hypertrophy
• diverticula
• narrow stream in the penile urethra
• incomplete emptying of the bladder

28
(No Transcript)
29
Treatment of PUV

• Transurethral valve ablation, vesicostomy or
  upper tract diversion
• Urethral stricture is a common complication
• Fetal intervention carries a high risk with
  mortality rate of 43
• ESRD, renal insufficiency and chronic renal
  failure are long-term consequences

30

• 30 of boys with posterior urethral valves whose
  symptoms present in infancy are at risk for
  progressive renal insufficiency.

31
Eagle-Barrett Syndrome

• More commonly known as Prune Belly Syndrome
• Characterized by
• deficiency of abdominal wall musculature
• a dilated, non-obstructed urinary tract
• bilateral cryptorchidism
• talipes equinovarus and hip dislocation
• Incidence is 1/35-50,000
• gt95 occur in males

32
(No Transcript)
33
(No Transcript)
34

• Believed to be caused by in-utero urinary tract
  obstruction and a specific mesodermal injury
  between the 4th and 10th week of gestation.
• Associated with renal dysplasia or agenesis.
• Often presents with a large-capacity, poorly
  contractile bladder.
• Heart, pulmonary, GI and orthopedic anomalies
  occur in a large percentage of PBS patients.

35
(No Transcript)
36
Management

• Neonatal Period
• Optimize urinary tract drainage
• Monitor and treat renal insufficiency
• Antibiotic prophylaxis if reflux is present
• Children
• Surgical repair of reflux
• Orchiopexy
• Reconstruction of the abdominal wall
• Renal transplant

37
Vesicoureteral Reflux

• Retrograde propulsion of urine into the upper
  urinary tract during bladder contraction.
• Primary reflux is caused by attenuation of the
  trigone and the contiguous intravesical ureteral
  musculature.
• May be caused by the ectopic insertion of the
  ureter into the bladder wall resulting in a
  shorter intravesicular ureter, which acts as an
  incompetent valve during urination.

38

• The ratio of the submucosal tunnel length to the
  ureteral diameter is the primary factor
  determining the effectiveness of the normal valve
  mechanism.
• It is normally 51, and in those with reflux it
  is 1.41.
• The intramural length increases from 0.5 cm at
  birth to 1.3 cm by 12 years of age.
• Duplication of the collecting system and
  ureteroceles should also be considered.

39
(No Transcript)
40
(No Transcript)
41
Some clinical facts about VUR

• It is genetic.
• Occurs in about 30 of first-degree relatives.
• 1/3 of children with a urinary tract infection
  has reflux on VCUG.
• Primary reflux tends to resolve over time as
  intravesical segment elongates with growth.

42
Grading of Vesicoureteral Reflux
43
Prognosis

• Kidney is most susceptible to scarring in the
  first year of life and at the time of first upper
  tract infection.
• Scars less frequently develop after the age of 5.
• VUR and scarring lead to hypertension,
  progressive renal insufficiency and failure.

• Resolves spontaneously before adolescence in
• 90 of Gr. 1 reflux
• 80 of Gr. 2
• 50 of Gr. 3
• 10 of Gr. 4
• 0 in Grade 5 reflux

44
Treatment

• Observation
• Medical treatment of infections
• Surgical treatment
• significant hydroureteronephrosis
• indicated if impossible to keep urine sterile and
  reflux persists
• acute pyelonephritis occurs
• evidence of increasing renal damage

45
On Presentation, how do we manage?

• Antenatal diagnosis of HN
• Enlarged palpable kidneys on PE
• Incidental finding on UTS done for
  other anomalies.

46

• Management would depend on the clinical condition
  of the patient and the suspected nature of the
  lesion.
• More common to have a unilateral HN that is not
  associated with systemic or pulmonary
  complications.
• Postnatal UTS confirmation at about 1 month of
  life, depending on severity.
• Bilateral HN
• urgent work-up especially when accompanied by
  oligohydramnios and pulmonary disease
• if male infant, postnatal VCUG and UTS

47

• Prophylactic antibiotics (Amoxicillin 20mg/kg PO
  daily) before VCUG is performed, as
  hydronephrosis may be due to reflux.
• DMSA scan to evaluate renal function.
• Definitely
• Check presence and regularity of voiding.
• Mild HN UA, BMP
• Moderate UA, BMP, VCUG
• Refer to specialist

48
References

• Tanagho and McAninch. Smiths General
  Urology.16th ed 2004, McGraw-Hill Companies,
  USA.
• Zitelli and Davis. Atlas of Pediatric Physical
  Diagnosis. 4th ed2002, Mosby, Inc., USA.
• Resnick and Novick. Urology Secrets. 3rd ed2003,
  Hanley and Belfus, Inc., USA.
• Edmondson, J.D. Antenatal Hydronephrosis. Mar
  2004, Emedicine article.
• Wiener, J.S. Ureteropelvic Junction Obstruction,
  Congenital. Aug 2004, Emedicine article.
• Maniam, P. Hydronephrosis and Hydroureter. Aug
  2004, Emedicine article.
• Div of Urology, Childrens Hosp, Boston, MA.
  Neonatal Hydronephrosis. Digital Urology Journal.
  Internet download.

49
References

• McCarthy, K. Vesicoureteral Reflux. Mar 2004,
  Emedicine article.
• Behrman, et al. Nelson Textbook of Pediatrics.
  17th ed Saunders Co., USA.
• Lloyd-Davies, et al. Color Atlas of Urology. 2nd
  edMosby-Year Book Europe Limited, London,
  England.
• Gillenwater, et al. Adult and Pediatric Urology.
  4th ed, Vol. I 2002, Lippincott Williams and
  Wilkins, USA.
• Cloherty, et al. Manual of Neonatal Care. 5th ed
  2004, Lippincott Williams and Wilkins, USA.
• Gonzales and Bauer. Pediatric Urology Practice.
  1999 Lippincott Williams and Wilkins, USA.

50
THANK YOU!And HAPPY THANKSGIVING!
