Designed Metal Connections

1
Designed Metal Connections

• PermaLite

2

• DMC - Gardena, CA
• PSAS - France

3
The DMC Companies

• DMC Dagan - Israel
• Nihon - Japan
• Companie DMC GMBH - Germany
• DMC Rep. - Australia

4
DMC Facilities

• Designed Metal Connections is housed in 160,200
  sq./ft.
• Four Buildings
• Located at 14800 S Figueroa St., Gardena, CA

5
DMC Products

• DMC products are used today in the following
  industries -
• Aircraft Systems
• Marine Industry
• Electric Utilities
• Petrochemical Industry - Offshore platforms
  Refineries

6
DMC Products - DeutschLite

• PermaLite - utilizes Axial swage tools - Was
  introduced in the last six years and today it is
  used in major programs.

7
DMC Products - Permaswage

• Permaswage the most commonly used product in the
  Aerospace Industry

8
DMC Products - DME

• DMC Miniature End Fitting (DME)-The latest in End
  Fitting Technology. The Lightest and most cost
  effective system in the industry today.

9
DMC Products - Swivels

• DMC fluid pivot connectors that permits relative
  movement and / rotation for hydraulic media. This
  25 year old product line is a name in Quality and
  Reliability.

10
DMC Products - Forgings

• Complete in-house die making capability
• Six presses from 250 Ton to 1300 Ton
• Heat treatment
• Chemical processing
• Penetrant Inspection

11
DMC Processes
DMC Forge Shop
We are proud to be the only fitting manufacturer
that controls the process from the raw matl
stage to completion
12
Latest Technologies
ABC Index
Large investment in latest technologies and
machining centers
Okuma
13
What is PermaLite?

• PermaLite is a tube fitting that is mechanically
  attached to the tube by axial swaging. The
  movement of the ring along the fitting body
  results in deformation of the tube with a
  leak-tight joint

14
PermaLite Titanium

• PermaLite Titanium for 3AL-2.5V
• Qualified on tube material both per AMS4944
  AMS4945
• Qualified on 3000 psi, 4000 psi 5000 psi
• Qualification test data on both pressure and
  return lines

15
PermaLite Aluminum

• PermaLite Aluminum for 6061T6 5052-O
• The only permanent fitting qualified on soft
  tubing (5052-0)
• All configurations, available for Aluminum system
  applications

16
PermaLite Stainless Steel

• Also known as the PermaLite Repair Fitting
• Can be swaged on -
• Al. 6061T6
• Stainless Steel 21-6-9
• Ti. 3AL-2.5V
• Pressure rating up to 5000 psi

17
PermaLite Technical Points

• Composite rings on the Ti. Product reduces stress
  in swaging ring
• Flexure performance at higher level
• Low scatter on S/N curve
• No ovality
• Metal to metal seal
• Lower shipset weight

18
PermaLite tooling benefits

• Designed with Finite Element Analysis
• Made from forgings in-house
• Push/pull features
• Easy installation
• Swivel and extension hydraulic hose

19
PermaLite Installation

• Mark both insertion mark inspection mark
• Insert the fitting to the tube insertion mark
• Place tool between the shoulder and the ring
• Actuate pump - Swaging complete

20
PermaLite benefits -

• Easy to install
• Push Pull feature
• Faster to install
• Easy to inspect
• Easy to train - Short training
• No cost training by DMC
• Completely round (no oval deformation)

21
PermaLite benefits -

• Metal to metal seal
• Smaller / Lighter tools
• Low tool maintenance - small number of components

22
PermaLite Family

• Boeing - Long-Beach C17 Hyd. System
• Sikorsky - Comanche, Hyd. Sys.
• Sikorsky - S92, Hyd. Sys., Pneumatic Sys.,
  Drain Sys.
• Cessna - Sovereign, Hyd. Sys., Fuel
• Gamesa - S92
• Lockheed - F22, Hyd. Sys., Pneumatic Sys.

23
PermaLite Family

• Boeing - 717 (MD95), Hyd. Modifications
• deHavilland - Global Express, Fuel, Fuel
  Vent
• Airbus - A3-XX, Hyd. System
• deHavilland - Dash 8/400, Fuel Sys. Fuel
  Vent
• Boeing 777 - Oxygen system

24
Permalite Family

• LearJet - Lear 45, Oxygen Sys. Pitot Sys.
  Fire Sys. Pneumatic, Hyd. Sys. Return.
• Shorts Ireland - Lear 45
• Shorts Ireland - RJ700, Fuel
• MHI Japan - RJ700
• Auburn Tec. - RJ700
• CanadAir - RJ700
• Raytheon - Hawker
