Emergency Release Snowboard Bindings

1
Emergency Release Snowboard Bindings
Presenting Michael Allen Michael
Weidner David Call
University of Utah Department of Mechanical
Engineering
2
Introduction

• Schedule
• Budget
• Team Groups
• Focus Of The Different Groups
• Final Design

3
Schedule
Emergency Release Snowboard Binding Year Schedule
Source ERSB Final Report Fall 06
4
Budget
Budget of Emergency Release Snowboard Binding Team
Source ERSB Final Report Fall 06
5
Group Division

• Why
• Based on schedule and interest
• Ensure each area is complete
• Make sure everyone is busy and is communicating
  with others about progress

6
Group Division

• Groups
• Finalizing Design
• David Call, Michael Weidner
• Manufacturing and Analysis
• Michael Allen, Jason Wendel
• Remote Control
• Blake Anderson, Gavin Mehraban, Matthew Sartori

7
Current Work

• Design Team
• Manufacturing and Analysis Team
• Remote Team

8
Current Work

• Design Team
• How to make design universal
• No large forces on small parts
• Strength Analysis

9
Current Work

• Manufacturing and Analysis Team
• Material Selection
• Manufacture of top plate
• Calculate expected forces of snowboarding

10
Current Work

• Remote Team
• Benchmarking remote switches
• Researching design with lithium batteries

11
Final Concept

• What it is
• How it works
• Interface with board and binding
• Attach
• Emergency Release
• Why we chose it

12
Concept - Background
Snowboard Setup

• Concept replaces disk
• Holds binding to board
• Used in all setups

Binding
Disk
Snowboard
Photo David Call
13
Concept
ERSB Disk Concept (Exploded)
Current Disk
Top Plate
Lock Fins (4)
Rotating Disk
Latch
Bottom Plate
Snowboard
Photo and sketch David Call
14
Securing the Binding
Top Plate Cross-Section

• Rotating disk extends/ retracts fins
• Fins hold down top plate
• Top plate holds binding to board

Internal Ledge
Against Binding
Binding
Lock Fins
Disk Ledge
Extended
Retracted
Photo and sketches David Call
15
Releasing the Binding
Release Mechanism

• Shape Memory Alloy (SMA) wire contracts at 70 C
• Lithium battery provides current
• Remote Control Activated

Shape Memory Alloy Wire
Spring Load (White)
Latch
Rotating Disk
Image David Call
16
Concept Evolution
Various concepts

• Combined best features from 50 concepts
• Best serves customer needs

Sketches (Clockwise from top) Matthew Sartori,
Michael Allen, David Call, Jason Wendel
17
Additional Appeal

• Ambitious
• All moving parts contained (away from elements)
• What members of group would want to buy

18
ERSB

• Schedule and budget
• Split our team into groups
• Current work
• Final design

19
Contact Info

• TEAM EMAIL
• ERSNOWBINDING_at_gmail.com
