Visual Grouping and Recognition

1
Visual Grouping and Recognition

• David Martin
• UC Berkeley

2
UCB Collaborators

• Prof. Jitendra Malik
• Prof. Dave Patterson
• Charless Fowlkes
• Doron Tal
• See http//www.cs.berkeley.edu/dmartin/papers/icc
  v01.pdf

3
From images to objects
Labeled sets tiger, grass etc
4
Recognition

• Object classes are hierarchical (e.g. leopard vs.
  clouded leopard vs. my pet clouded leopard
  Leopold)
• Must be tolerant to changes in pose and
  illumination

5
Framework for Recognition Three stages

• Segmentation Images ? Regions
• Association Regions ? Super-regions
• Matching Super-regions ? Prototype views

6
Segmentation Images ? Regions

• Slight over-segmentation of objects is OK
• Under-segmentation is BAD

7
Association Regions ? Super-Regions

• Simple enumeration of connected components
• Number of super-regions of size k in image with n
  regions is approximately (4k)n/k
• For typical images, number is 1K-10K
• Plausibility ordering could reduce effective
  number substantially

8
Matching Super-regions ? Prototype Views

• Objects are represented by a set of prototypical
  views (10 per object)
• For each super-region S, calculate probability
  that it is an instance of view V
• Determine most probable labeling of image into
  objects
• Tolerant to
• pose and illumination changes
• intra-category variation
• error in segmentation and association steps

9
Focus on Segmentation

• Segmentation Recognition (?!)
• Need quantitative measures A benchmark!
• MNIST for handwritten digits
• SPEC for CPUs
• WinStone for PCs
• TPC-C for transaction processing DBs
• Segmentation / Recognition on ISTORE

10
Step 1 Establish Ground-truth

• We want high-level Gold Standard segmentations.
• Range of granularities
• Segmentation tool in Java
• Explicit partition of image into pixel sets
• Ease of deployment
• 10 UCB grad students
• 60 images, 180 total segmentations
• Up to 5 segmentations/image by different people
• Goal 1K images, 5K segmentations

11
Human Segmentations (1)
12
Human Segmentations (2)
13
Step 2 Similarity / Error Measures
14
Segmentation Refinement
B
A
C
D
15
Local Refinement Error

• How much is segmentation S1 a refinement of
  segmentation S2 at pixel pi?

E(S1,S2,pi) (R(S1,pi)\R(S2,pi)
R(S1,pi)
16
Segmentation Error Measures

• Global Consistency Error (GCE)
• Refinement in same direction at all pixels
• GCE 1/n min ?i E(S1,S2,pi), ?i E(S2,S1,pi)
• Local Consistency Error (LCE)
• Refinement in either direction at each pixel
• LCE 1/n ?i min E(S1,S2,pi), E(S2,S1,pi)

17
Measure Results
GCE (human vs. human)
LCE (human vs. human)
GCE (NCuts vs. human)
0.11
0.07
0.28
SAME
0.39
0.30
0.38
DIFFERENT
18
NCuts Per-Image Error
Red NCuts vs. Human
Blue Human vs. Human
19
Future Work Dataset

• Obtain 1000-5000 segmentations
• Hire undergrads
• Vision groups at other schools
• More widespread deployment on web?
• Release dataset to community
• Informal public forum for segmentation algorithm
  comparison
• e.g. MNIST

20
Future Work Segmentation Algorithms

• Cue combination is the key
• luminence, color, texture, motion, stereoscopic
  depth, familiar configuration
• Feedback between segmentation and matching
• Distributed computational framework for exploring
  these issues
• Millennium or ISTORE

21
Visual Recognition on ISTORE

• Sequential code
• Segmentation 5 minutes / image
• Association Negligible
• Matching 0.5 sec / match
• Memory requirements are very low
• 10K object categories 10 views/category 100
  100 pixels/view 1 byte/pixel 1 GB.
• Computation on 104 node ISTORE
• Segmentation
• 50 embarrassingly parallel (many convolutions)
• 50 sparse eigenvalue problem
• ? Frame rate throughput, but not latency

22

• Matching Embarrassingly parallel
• 1K candidate super-regions
• 20K matches/sec at full resolution
• Consider only 1 of matches at full resolution
  (10 pass color/texture filter, 10 of those pass
  low resolution shape filter)
• If half time spent in pruning and half in full
  resolution matching, we get 10K matches/sec
• Worst case 100 object categories
• Best case depends on how well one can exploit
  context, hierarchy and hashing.
• Humans can recognize 10K-100K objects

23
ISTORE Applications Summary

• Segmentation algorithm development
• Much compute, little storage
• Real-time recognition of image/video stream
  content
• Plus storage for subsequent retrieval
• Content-based indexing of all the images/video on
  the Internet!
