Logical Time

1
Logical Time

• M. Liu

2
Introduction

• The concept of logical time has its origin in a
  seminal paper by Leslie Lamport Time, Clocks,
  and the Ordering of Events in a Distributed
  System, Communications of ACM, July 1978.
• The topic remains of interest a recent paper
  appeared in Computer Capturing Causality in
  Distributed System by Raynal and Singhal (see
  handout).

3
Application of Logical Time

• Logical Time in Visualizations Produced by
  Parallel Computations
• Banker system algorithm.
• Efficient solutions to the Replicated Log and
  Dictionary problems by Wuu Bernstein.

4
Background 1 source Raynal and Singhal

• A distributed computation consists of a set of
  processes that cooperate and compete to achieve a
  common goal. These processes do not share a
  common global memory and communicate solely by
  passing messages over a communication network.

5
Background 2 source Raynal and Singhal

• In a distributed system, a process's actions are
  modeled as three types of events internal,
  message send, and message receive.
• An internal event affects only the process at
  which it occurs, and the events at a process are
  linearly ordered by their order of occurrence.
• Send and receive events signify the flow of
  information between processes and establish
  causal dependency from the sender process to the
  receiver process.

6
Background 3 source Raynal and Singhal

• The execution of a distributed application
  results in a set of distributed events produced
  by the process.
• The causal precedence relation induces a partial
  order on the events of a distributed computation.


7
Background 4 source Raynal and Singhal

• Causality among events, more formally the
  causal precedence relation, is a powerful concept
  for reasoning, analyzing, and drawing inferences
  about a distributed computation. Knowledge of the
  causal precedence relation between processes
  helps programmers, designers, and the system
  itself solve a variety of problems in distributed
  computing.

8
Background 5 source Raynal and Singhal

• The notion of time is basic to capturing the
  causality between events. Distributed systems
  have no built-in physical time and can only
  approximate it. However, in a distributed
  computation, both the progress and the
  interaction between processes occur in spurts.
  Consequently, logical clocks can be used to
  accurately capture the causality relation between
  events.
• This article presents a general framework of a
  system of logical clocks in distributed systems
  and discusses three methods--scalar, vector, and
  matrix--for implementing logical time in these
  systems.
• .

9
Notations

• A distributed program is composed of a set of n
  independent and asynchronous processes p1, p2, ,
  pi, , pn. These processes do not share a global
  clock.
• Each process can execute an event spontaneously
  when sending a message, it does not have to wait
  for the delivery to be complete.
• The execution of each process pi produces a
  sequence of events ei0,ei1,.,eix,ei x1, .
• The set of events produced by pi have a total
  order determined by the sequencing of the events
  eix ? ei x1
• We say that eix happens before ei x1.
• The happen-before relation ? is transitive eii
  ? eij for all i lt j.

10
Notations - 2

• Events that occur between two concurrent
  processes are generally unrelated, except for
  those that are causally related as follows
• for every message m exchanged between two
  processes Pi and Pj, we have eix send(m),
  ejyreceive(m), and
• eix ? ejy
• Events in a distributed execution are partially
  ordered
• Local events are totally ordered.
• Causal events are totally ordered.
• All other events are unordered.
• For any two events e1 and e2 in a distributed
  execution, either
• (i) e1?e2, (ii) e2?e1, or (iii) e1e2 (that is,
  e1 and e2 are concurrent).

11
Which of these events are ? related? Which ones
are concurrent?
12
Clock conditions

• In a system of logical clocks, every
  participating process has a logical clock that is
  advanced according to a protocol.
• Every event is assigned a timestamp in such a
  manner that satisfy the clock consistency
  condition
• if e1?e2 then C(e1 ) lt C(e2 )
• where C(ei ) is the timestamp assigned to
  event ei
• If the protocol satisfies the following condition
  as well, then the clock is said to be strongly
  consistent
• if C(e1 ) lt C(e2 ) then e1?e2

13
A logical clock implementation - the Lamport
Clock

• R1 Before executing an event(send, receive, or
  internal), pi executes the following
• Ci Ci d (d gt 0, usually d 1)
• R2 Each message carries the clock value of its
  sender at sending time. When pi receives a
  message with the timestamp Cmsg, it executes the
  following
• Ci max(Ci , Cmsg )
• Execute R1.
• Deliver the message.
• The logical clock at any process is
  monotonically increasing.

14
Fill in the logical clock values
15
Correctness of the Lamport Clock

• Does the Lamport clock satisfy the clock
  consistency condition?
• Does the Lamport clock satisfy the strong clock
  consistency condition?

16
Logical Clock Protocols

• The Lamport Clock is an example of a logical
  clock protocol. There are others.
• The Lamport Clock is a scalar clock it uses a
  single integer to represent the clock value.

17
Lamport clock paper

• PODC Influential Paper Award 2000,
  http//www.podc.org/influential/2000.html
• Time, clocks, and the ordering of events in a
  distributed system by Leslie Lamport, obtainable
  from the ACM Digital Library.

18
An application of scalar logical time bank
system algorithm

• See bank system algorithm slides

19
Vector Logical Clock

• Developed by several persons independently.
• Each Pi of n participating processes maintains a
  integer vector (array) of size n
• vti1,n, where vtii is the local logical
  clock of pi,
• vtij represents pis latest knowledge of Pjs
  local time.

20
Vector clock protocol

• At process Pi
• Before executing an event, Pi updates its local
  logical time as follows
• vtii vtii d (d gt 0)
• Each sender process piggybacks a message m with
  its vector clock value at sending time. Upon
  receiving such a message (m, vt), Pi updates its
  vector clock as follows
• For 1 lt k lt n vtik max(vtik , vtk)
• vtii vtii d (d gt 0)

21
Vector clock

• The system of vector clocks is strongly
  consistent
• Every event is assigned a timestamp in such a
  manner that satisfies the clock consistency
  condition
• if e1?e2 then vt(e1 ) lt vt(e2 ), using vector
  comparison
• where vt(ei ) is the timestamp assigned to
  event ei
• If the protocol satisfies the following condition
  as well, then the clock is said to be strongly
  consistent
• if vt(e1 ) lt vt(e2 ) then e1?e2 , using vector
  comparison

22
Vector comparison

• Given two vectors V1 and V2, both of size n
• V1 lt V2 if V1i lt V2i for i 1, , n
• And there exists some k, 0 lt k lt n1, such that
  V1k lt V2k
• Example V1 1, 2, 3, 4 V2 2, 3, 4, 5
• V1 lt V2
• Example V1 1, 2, 3, 4 V2 2, 2, 4, 4
• V1 (not) lt V2
• Example V1 1, 2, 3, 4 V2 2, 3, 4, 1
• V1 (not) lt V2

23
Vector clock

• Because vector clocks are strongly consistent, we
  can use them to determine whether two events are
  causally related by comparing their vector time
  stamps, using vector comparison.

24
Matrix Time

• Proposed by Michael and Fischer in 1982.
• A process Pi maintains a matrix
• mti1n, 1n where
• mtii, i denotes the logical clock of Pi
• mtii, j denotes the latest knowledge that Pi
  has about the local clock, mtjj, j of Pj (row i
  is the vector clock of Pi .
• mtij, k represents what Pi knows about the
  latest knowledge that Pj has about the local
  logical clock mtkk, k of Pk.

25
Matrix Time Protocol

• At process Pi
• Before executing an event, Pi updates its local
  logical time as follows
• mtii, i mtii, i d (d gt 0)
• Each sender process piggybacks a message m with
  its matrix clock value at sending time. Upon
  receiving such a message (m, vt) from Pj, Pi
  updates its matrix clock as follows
• for 1 lt k lt n mtii, k max(mtii, k ,
  mtj, k )
• for 1 lt k lt n
• for 1 lt q lt n
• mtik, q max(mtik, q , mtk, q )
• 3. mtii, i mtii, i d (d gt 0)

26
matrix clock consistency

• The system of matrix clocks is strongly
  consistent
• Every event is assigned a timestamp in such a
  manner that satisfy the clock consistency
  condition
• if e1? e2 then mt(e1 ) lt mt(e2 ), using matrix
  comparison
• where mt(ei ) is the timestamp assigned to
  event ei
• If the protocol satisfies the following condition
  as well, then the clock is said to be strongly
  consistent
• if mt(e1 ) lt mt(e2 ) then e1?e2 , using matrix
  comparison

27
Matrix comparison

• Given two matrixes M1 and M2, both of size n by
  n
• M1 lt M2 if M1i, j lt V2i, j
• for i 0, 1, , n, j 0, 1, , n
• And there exist some k, 0 ltk ltn1, and some p, 0
  ltp ltn1, such that M1k, p lt V2i, j
• Because matrix clocks are strongly consistent, we
  can use them to determine whether two events are
  causally related by comparing their vector time
  stamps

28
An application of matrix time Wuu and Bernstein
paper

• The dictionary problem a dictionary is
  replicated among multiple nodes. Each node
  maintains a view of the dictionary independently
  by performing operations on the dictionary
  independently.
• The network may be unreliable.
• The dictionary data must be consistent among the
  nodes.
• Serializability (using locking) is the database
  approach to address such a problem.
• The paper (as did other papers preceding it)
  describes an algorithm which does not require
  serializability.

29
Wuu and Bernstein protocol

• A replicated log is used to achieve mutual
  consistency of replicated data in an unreliable
  network.
• The log contains records of invocations of
  operations which access a data object.
• Each node updates its local copy of the data
  object by performing the operations contained in
  its local copy of the log.
• The operations are commutative so that the order
  in which operations are performed does not affect
  the final state of the data.

30
The problem environment

• n nodes N1, N2, , Nn are connected over a
  network.
• Each node maintains a data dictionary V a set
  of words s1, s2, , sn, stored in stable
  storage impervious to crashes.
• Vi denotes the local view of the dictionary at
  Ni.
• Two types of operations may be issued by any node
  to perform on the dictionary
• insert(x)
• delete(x)
• delete(x) can be invoked at Ni only if x is in Vi
  note that the operation may be issued by
  multiple nodes.
• insert(x) can only be issued by one node.

31
The problem environment - 2

• The unique event which inserts x is denoted ex.
• An event which deletes x is called an x-delete
  event
• If V(e) is the dictionary view at a node after
  the occurrence of event e, then x is in V(e) iff
  ex -gt e and there does not exist an x-delete
  event, g, such the g -gt e.

32
The log

• Each node maintains a log of events L and a
  distributed algorithm is employed to keep the
  dictionary views up to date.
• An event is recorded in the log as a
  record/object containing these fields operation,
  time, nodeID. For example
• (add a, 3, 2) if Node 2 issued add a at its
  local time 3.
• The event record describing event e is denoted
  eR
• eR.node is the node that issues the event, eR.op
  is the operation eR.time is the value of time
  that the operation was issued.

33
The log

• Nodes exchange messages containing appropriate
  portions of the individually maintained log in
  order to achieve data consistency.
• L(e) denotes the contents of the log at a node
  immediately after the event e completes.
• The log problem
• (p1) f-gte iff fR is in L(e)

34
A trivial solution

• Each node i that generates an event e adds a
  record for the event, eR, to its local log Li.
• Each time the node sends a message, it includes
  its log Li in the message.
• Upon receiving a message, a node j looks at the
  log enclosed in the message, and applies the
  event in each record to its dictionary view Vj
• The logs are maintained indefinitely. If a node
  j is cut off from the network due to failures,
  its dictionary view may fall behind other nodes,
  but as soon as the network is repaired and
  messages can be sent to node j again, then the
  events logged by other nodes will be made known
  to j eventually.

35
Trivial solution

• The trivial solution
• is fault-tolerant.
• satisfies the log problem and the dictionary
  problem.
• The log maintained by each node i, Li, grows
  unboundedly, which has these ramifications
• The entire log is sent with each message
  excessive communication costs
• A new view of the dictionary is repeatedly
  computed based on the log received in each
  message excessive computational costs
• The entire log is stored at each node excessive
  storage costs.

36
Wuu and Bernstiens improved solutions

• Uses matrix time to purge event records that have
  already been seen by all participants.
• Each node i maintains a matrix clock Ti
• When i receives a log which contains a record for
  event e, eR, initiated by node eR.node, it
  determines if process k has already seen this
  record by this predicate (boolean function)
• boolean hasrec(Ti , eR, k)
• return (Tik, eR.node gt eR.time)

37
Wuu and Bernstiens improved solutions pp.236-7

• Kept at each node are
• Vi the dictionary view, e.g .a, b, c
• Pli a partial log of events
• Initialization
• Vi Pli // set both empty,
• set matrix clock to all 0

38
Wuu and Bernstiens improved solutions pp.236-7

• When node i issues insert(x)
• Update matrix clock
• Add the event record to the partial log Pli
• Add x to Vi
• When node i issues delete(x)
• Update matrix clock
• Add the event record to the partial log Pli
• delete x from Vi

39
Wuu and Bernstiens improved solutions pp.236-7

• When node i sends to node k
• Create a subset of the partial log Pli,, NP,
  consisting of those entries such that
• Hasrec((Ti , eR, k) returns false.
• Send the NP and Ti to node k.

40
Wuu and Bernsteins improved solutions pp.236-7

• When node i receives from node k
• Extract from the log received a subset, NE,
  consisting of those entries such that
• Hasrec((Ti , eR, i) returns false.
• These entries have not already been seen by i.
• Update the dictionary view Vi based on NE.
• Update the matrix clock Ti
• Add to the partial log Pli (note not NE) those
  records in the log received such that
• Hasrec((Ti , eR, j) returns false for at least
  one j
• Such a record has not been seen by at least one
  other node.

41
Wuu and Bernsteins improved solutions pp.236-7

• The size of the log sent with each message is
  minimized based on the matrix clock.
• The number of log entries based on which the
  local dictionary view is updated is minimized,
  again based on the matrix clock.
• The algorithm will allow each log record to be
  maintained by at least one node, so that
  eventually that knowledge will be propagated to a
  recovered node.
