Seminar in bioinformatics

1
Seminar in bioinformatics

• Computation of elementary modes a unifying
  framework and the new binary approach

Julien Gagneur and Steffen Klamt
BMC Bioinformatics 2004, 5175
Elad Gerson, Spring 2006, Technion.
2
Agenda

• Quick overview of last weeks lecture.
• Extension of the EP concept.
• Enter EM.
• General framework for EM computation.
• Reversible reactions split.
• Network compression.
• Post processing.
• Some implementation tweaks.

3
Last week on bioinformatics seminar!

• Given a metabolic network we wish to find all the
  possible flux distributions which results in a
  steady state.
• Meaning, the overall flux in a pathway is 0.

4
Last week on bioinformatics seminar!

• This is done by describing the pathway as a
  stoichiometric matrix S, solving the equation

5
Last week on bioinformatics seminar!

• Notice that we are interested only in solutions
  where
• (sign suggests reactions direction).
• Solution space is spanned by linearly independent
  vectors.
• We look for a spanning set s.t. every solution
  can be written as a linear combination of the
  spanning vector where all coefficients are
  non-negative (Genetically independent).
• Those solutions are called
• Extreme pathways (EP).
• Can be found using the Null
• Space Approach (NSA)
• Algorithm.

6
Problem

• Biology suggests some reaction are reversible.
• Consider the following network for instance
• R5 can work in both directions (Not
  simultaneously!)

7
Solution ?

• Remove the restriction, signs suggests
  direction ..
• Bad idea ..
• Not all reactions are reversible.
• Solutions no longer take the form of a polyhedral
  cone.

8
Solution !

• Split the reversible reactions ..
• Find Extreme Pathways using the NSA algorithm.
• Post process found EPs, merge split reactions
  (opposite direction should be set with a
  negative sign).
• Post processed EPs are now called - Elementary
  Modes (EM).

R5a
R5b
9
Compressing the network

• Removing redundancies

Can be united..
10
Compressing the network

• Removing redundancies

R1 is null in any feasible steady state
11
Compressing the network

• Removing redundancies

Contradict each other .. Can be eliminated.
12
Compressing the network

• Removing redundancies

Active in any stead state.
13
Compressing the network

• Removing redundancies
• Some redundancies can be detected as dependent
  linear rows in the kernel matrix.
• Iterative approach, remove redundancies until non
  detected.
• Produce better results.

14
General framework

• Preprocessing -
• Metabolic networks yield deeper insight of
  organisms metabolism.
• Failure modes analysis will provide
• Crucial parts identification.
• Suitable targets for repressing undesired
  metabolic functions.
• Apply NSA algorithm.
• Post process.

15
One more tweak

• The authors offers an efficient implementation to
  the NSA and CBA (Combined basis Schuster et.
  al.) algorithms.
• Using binary representation for vectors.
• Fast bit operators.
• Efficient memory usage (up to 1.6 of original!)

16
Seminar in bioinformatics

• Minimal cut sets in biochemical reaction
• networks

Steffen Klamt and Ernst Dieter Gilles
Bioinformatics Vol. 20 no. 2 2004, pages 226234
Elad Gerson, Spring 2006, Technion.
17
Abstract

• Motivation
• Metabolic networks yield deeper insight of
  organisms metabolism.
• Failure modes analysis will provide
• Crucial parts identification.
• Suitable targets for repressing undesired
  metabolic functions.
• Results
• The biochemical networks minimal cut sets
  concept.
• Algorithm which computes MCS with respect to an
  objective reaction.
• Potential applications includes
• phenotype predictions.
• Network verifications.
• Structural robustness and fragility assessment.
• Metabolic flux analysis.
• Target identification in drug discovery.

18
Introduction

• Assume we wish to prevent the production of
  metabolite X.
• i.e. there is no balanced flux distribution
  possible which involves obR.
• Can be done by gene deletion or enzyme inhibition.

19
Introduction

• Definition - We call a set of reactions a cut set
  (with
• respect to a defined objective reaction) if after
  the removal
• of these reactions from the network no feasible
  balanced flux
• distribution involves the objective reaction.

20
Introduction

• Thats easy .. Consider C0 obR
• One might wish to cut the reaction at the
  beginning.
• What if there are numerous obRs ?
• Simultaneous failure might be achieved more
  efficiently.

21
Introduction

• Take two Remove all reactions except for oBR.
• Not efficient.
• Not intelligent.

22
Introduction

• Consider C1 R5, R8
• Sufficient.
• Neither the removal of R5 nor R8 is sufficient.
• No subset of C1 is a valid cut set ? C1 is
  minimal.

23
Introduction

• Definition - A cut set C (related to a defined
  objective reaction)
• is a minimal cut set (MCS) if no proper subset of
  C is a
• cut set.
• Can you spot all the MCS in the network ?

24
Introduction
Is C2 R2, R4, R6 minimal ?
25
Introduction
Is C3 R2, R5, R7 ?
26
Introduction
How about C1 R1 ?
27
Introduction

• OK, what about Graph disconnectivity algorithms ?
• No good, They dont take the hypergraph nature of
  metabolic pathways into account.

28
The algorithm

• Initialization
• Calculate the EMs in the given network
• Define the objective reaction obR
• (3) Choose all EMs where reaction obR is
  non-zero and
• store it in the binary array em_obR
  (em_obRij1
• means that reaction j is involved in EM i)
• (4) Initialize arrays mcs and precutsets as
  follows (each
• array contains sets of reaction indices)
  append j to mcs if reaction j is
• essential (em_obRij1 for each EM i),
  otherwise to precutsets

29
The algorithm

• (5) FOR i2 TO MAX_CUTSETSIZE
• (5.1) new_precutsets
• (5.2) FOR j 1 TO q (q number of reactions)
• (5.2.1) Remove all sets from precutsets where
  reaction j participates
• (5.2.2) Find all sets of reactions in
  precutsets that do not cover at least one EM in
  em_obR where reaction j participates combine
  each of these sets
• with reaction j and store the new preliminary
  cut sets in temp_precutsets
• (5.2.3) Drop all temp_precutsets which are a
  superset of any of the already determined
  minimal cut sets stored in mcs
• (5.2.4) Find all retained temp_precutsets which
  do nowcover all EMs and
• append them to mcs append all others to
  new_precutsets
• ENDFOR
• (5.3) If isempty(new_precutsets)
• (5.3.1) Break
• ELSE
• (5.3.2) precutsetsnew_precutsets
• ENDIF
• ENDFOR
• (6) result mcs contains the MCSs

30
Running example

• Initialization Calculate EM

We are only interested in EM containing obR
31
Running example

• Initialization
• mcs 1, precutsets 2,3,4,5,6,7
  ,8

R8 R7 R6 R5 R4 R3 R2 R1 em_obR
1 1 1 0 0 0 0 1 1 (EM2)
0 0 0 1 0 1 1 1 2 (EM3)
0 0 0 1 1 0 0 1 3 (EM4)
32
Running example

• I 2, j 1
• mcs 1, precutsets 2,3,4,5,6,7
  ,8
• new_precutsets
• temp_precutsets

R8 R7 R6 R5 R4 R3 R2 R1 em_obR
1 1 1 0 0 0 0 1 1 (EM2)
0 0 0 1 0 1 1 1 2 (EM3)
0 0 0 1 1 0 0 1 3 (EM4)
33
Running example

• I 2, j 1
• mcs 1, precutsets 2,3,4,5,6,7
  ,8
• new_precutsets
• temp_precutsets 1 2

R8 R7 R6 R5 R4 R3 R2 R1 em_obR
1 1 1 0 0 0 0 1 1 (EM2)
0 0 0 1 0 1 1 1 2 (EM3)
0 0 0 1 1 0 0 1 3 (EM4)
34
Running example

• I 2, j 1
• mcs 1, precutsets 2,3,4,5,6,7
  ,8
• new_precutsets
• temp_precutsets 1 2, 1 3, 1 4, 1 5 1
  6

R8 R7 R6 R5 R4 R3 R2 R1 em_obR
1 1 1 0 0 0 0 1 1 (EM2)
0 0 0 1 0 1 1 1 2 (EM3)
0 0 0 1 1 0 0 1 3 (EM4)
35
Running example

• I 2, j 1
• mcs 1, precutsets 2,3,4,5,6,7
  ,8
• new_precutsets
• temp_precutsets 1 2, 1 3, 1 4, 1 5 1
  6 1 7 1 8

R8 R7 R6 R5 R4 R3 R2 R1 em_obR
1 1 1 0 0 0 0 1 1 (EM2)
0 0 0 1 0 1 1 1 2 (EM3)
0 0 0 1 1 0 0 1 3 (EM4)
36
Running example

• I 2, j 1
• mcs 1, precutsets 2,3,4,5,6,7
  ,8
• new_precutsets
• temp_precutsets 1 2, 1 3, 1 4, 1 5, 1
  6, 1 7, 1 8

R8 R7 R6 R5 R4 R3 R2 R1 em_obR
1 1 1 0 0 0 0 1 1 (EM2)
0 0 0 1 0 1 1 1 2 (EM3)
0 0 0 1 1 0 0 1 3 (EM4)
37
Running example

• I 2, j 2
• mcs 1, precutsets 2,3,4,5,6,7
  ,8
• new_precutsets
• temp_precutsets

R8 R7 R6 R5 R4 R3 R2 R1 em_obR
1 1 1 0 0 0 0 1 1 (EM2)
0 0 0 1 0 1 1 1 2 (EM3)
0 0 0 1 1 0 0 1 3 (EM4)
38
Running example

• I 2, j 2
• mcs 1, precutsets 3,4,5,6,7,8

• new_precutsets
• temp_precutsets

R8 R7 R6 R5 R4 R3 R2 R1 em_obR
1 1 1 0 0 0 0 1 1 (EM2)
0 0 0 1 0 1 1 1 2 (EM3)
0 0 0 1 1 0 0 1 3 (EM4)
39
Running example

• I 2, j 2
• mcs 1, precutsets 3,4,5,6,7,8

• new_precutsets
• temp_precutsets 2 4

R8 R7 R6 R5 R4 R3 R2 R1 em_obR
1 1 1 0 0 0 0 1 1 (EM2)
0 0 0 1 0 1 1 1 2 (EM3)
0 0 0 1 1 0 0 1 3 (EM4)
40
Running example

• I 2, j 2
• mcs 1, precutsets 3,4,5,6,7,8

• new_precutsets
• temp_precutsets 2 4,2 6,2 7,2 8

R8 R7 R6 R5 R4 R3 R2 R1 em_obR
1 1 1 0 0 0 0 1 1 (EM2)
0 0 0 1 0 1 1 1 2 (EM3)
0 0 0 1 1 0 0 1 3 (EM4)
41
Running example

• I 2, j 2
• mcs 1, precutsets 3,4,5,6,7,8

• new_precutsets 2 4
• temp_precutsets 2 6,2 7,2 8

R8 R7 R6 R5 R4 R3 R2 R1 em_obR
1 1 1 0 0 0 0 1 1 (EM2)
0 0 0 1 0 1 1 1 2 (EM3)
0 0 0 1 1 0 0 1 3 (EM4)
42
Running example

• I 2, j 2
• mcs 1, precutsets 3,4,5,6,7,8

• new_precutsets 2 4,2 6,2 7,2 8
• temp_precutsets

R8 R7 R6 R5 R4 R3 R2 R1 em_obR
1 1 1 0 0 0 0 1 1 (EM2)
0 0 0 1 0 1 1 1 2 (EM3)
0 0 0 1 1 0 0 1 3 (EM4)
43
Running example

• I 2, j 5
• mcs 1, precutsets 5,6,7,8
• new_precutsets 2 4,2 6,2 7,2 8, ..
• temp_precutsets

R8 R7 R6 R5 R4 R3 R2 R1 em_obR
1 1 1 0 0 0 0 1 1 (EM2)
0 0 0 1 0 1 1 1 2 (EM3)
0 0 0 1 1 0 0 1 3 (EM4)
44
Running example

• I 2, j 5
• mcs 1, precutsets 6,7,8
• new_precutsets 2 4,2 6,2 7,2 8, ..
• temp_precutsets 5 6,5 7,5 8

R8 R7 R6 R5 R4 R3 R2 R1 em_obR
1 1 1 0 0 0 0 1 1 (EM2)
0 0 0 1 0 1 1 1 2 (EM3)
0 0 0 1 1 0 0 1 3 (EM4)
45
Running example

• I 2, j 5
• mcs 1, precutsets 6,7,8
• new_precutsets 2 4,2 6,2 7,2 8, ..
• temp_precutsets 5 6,5 7,5 8

R8 R7 R6 R5 R4 R3 R2 R1 em_obR
1 1 1 0 0 0 0 1 1 (EM2)
0 0 0 1 0 1 1 1 2 (EM3)
0 0 0 1 1 0 0 1 3 (EM4)
46
Running example

• I 2, j 5
• mcs 1, 5 6, precutsets 6,7,8
• new_precutsets 2 4,2 6,2 7,2 8, ..
• temp_precutsets 5 7,5 8

R8 R7 R6 R5 R4 R3 R2 R1 em_obR
1 1 1 0 0 0 0 1 1 (EM2)
0 0 0 1 0 1 1 1 2 (EM3)
0 0 0 1 1 0 0 1 3 (EM4)
47
Running example

• I 2, j 5
• mcs 1, 5 6, 5 7, precutsets
  6,7,8
• new_precutsets 2 4,2 6,2 7,2 8, ..
• temp_precutsets 5 8

R8 R7 R6 R5 R4 R3 R2 R1 em_obR
1 1 1 0 0 0 0 1 1 (EM2)
0 0 0 1 0 1 1 1 2 (EM3)
0 0 0 1 1 0 0 1 3 (EM4)
48
Running example

• I 2, j 8
• mcs 1, 5 6, 5 7, 5 8, precutsets
• new_precutsets 2 4,2 6,2 7,2 8, ..
• temp_precutsets

R8 R7 R6 R5 R4 R3 R2 R1 em_obR
1 1 1 0 0 0 0 1 1 (EM2)
0 0 0 1 0 1 1 1 2 (EM3)
0 0 0 1 1 0 0 1 3 (EM4)
49
Running example

• I 3, j 2
• mcs 1, 5 6, 5 7, 5 8, precutsets
  2 4,2 6,2 7,2 8,4 6,
• new_precutsets
• temp_precutsets

R8 R7 R6 R5 R4 R3 R2 R1 em_obR
1 1 1 0 0 0 0 1 1 (EM2)
0 0 0 1 0 1 1 1 2 (EM3)
0 0 0 1 1 0 0 1 3 (EM4)
50
Running example

• I 3, j 2
• mcs 1, 5 6, 5 7, 5 8, precutsets
  4 6,
• new_precutsets
• temp_precutsets

R8 R7 R6 R5 R4 R3 R2 R1 em_obR
1 1 1 0 0 0 0 1 1 (EM2)
0 0 0 1 0 1 1 1 2 (EM3)
0 0 0 1 1 0 0 1 3 (EM4)
51
Running example

• I 3, j 2
• mcs 1, 5 6, 5 7, 5 8, precutsets
  4 6,
• new_precutsets
• temp_precutsets 2 4 6,

R8 R7 R6 R5 R4 R3 R2 R1 em_obR
1 1 1 0 0 0 0 1 1 (EM2)
0 0 0 1 0 1 1 1 2 (EM3)
0 0 0 1 1 0 0 1 3 (EM4)
52
Running example

• I 3, j 2
• mcs 1, 5 6, 5 7, 5 8, 2 4 6,
  precutsets 4 6,
• new_precutsets
• temp_precutsets

R8 R7 R6 R5 R4 R3 R2 R1 em_obR
1 1 1 0 0 0 0 1 1 (EM2)
0 0 0 1 0 1 1 1 2 (EM3)
0 0 0 1 1 0 0 1 3 (EM4)
53
Running example

• I 3, j 8
• mcs 1, 5 6, 5 7, 5 8, 2 4 6,,
  precutsets
• new_precutsets
• temp_precutsets

R8 R7 R6 R5 R4 R3 R2 R1 em_obR
1 1 1 0 0 0 0 1 1 (EM2)
0 0 0 1 0 1 1 1 2 (EM3)
0 0 0 1 1 0 0 1 3 (EM4)
54
Complexity

• Let q be the number of reactions.
• Assuming EM ltlt q.
• In initialization q singletons are generated and
  tested.
• In the i-th iteration
• Overall number of temp_precutsets generated
• O(p) comparisons are made.
• Hence, (All subsets of q items)
• Yes .. exponential..
• Maximal MCS size ltlt q bounds polynomial
  approximation.

55
MCS in central metabolism of E. coli

• MCS calculated with biomass synthesisas
  objective reaction (growth).
• Network comprises 110 reactions and 89
  metabolites.
• Catabolic (material breakdown) part modeled in
  details.
• Enables excretion of 5 metabolites.
• Uptake of glucose, acetate, glycerol and
  succinate.
• Growth on each substrate was tested separately.

56
MCS in central metabolism of E. coli
57
Possible applications

• Structural fragility and robustness
• MCS can be used for risk assessment in
  metabolic pathways.
• More EMs suggested a more robust and less fragile
  pathway.
• EMs number and MCSs size are strongly correlated.
  (More elements must fail).
• We seek a better criteria.

Glucose is known to be the least fragile growth
substrate having most EMs and apparently longest
MCSs
Dangerous MCSs
58
Possible applications
Structural fragility and robustness
Definition Reaction fragility factor
Fi is the reciprocal of the average size of all
the MCSs the reaction i participates.
59
Possible applications
Structural fragility and robustness
Definition Reaction fragility factor
Fi is the reciprocal of the average size of all
the MCSs the reaction i participates.
May suggest reactions importance.
60
Possible applications
Structural fragility and robustness
Definition Reaction fragility factor
Fi is the reciprocal of the average size of all
the MCSs the reaction i participates.
Is there a correlation between Fi and the number
of EMs the reaction participates?
61
Possible applications
Structural fragility and robustness

62
Possible applications
Structural fragility and robustness D
efinition Network fragility F is defined
as where q is then number of reactions.
63
Possible applications

• Network verification and mutant phenotype
  predictions.
• Cutting an MCS is predicted to leave a metabolic
  pathway dysfunctional.
• Apply the algorithm with growth as obR.
• If a set of gene deletions (or mutants) contains
  an MCS a non-viable phenotype is expected.
• Viable phenotype would be a false negative.
• Proof for incorrect or incomplete network.
• Otherwise growth is possible.
• Non-viable phenotype would be a false positive.
• May suggest a false assumption in the network
  structure.
• One of the reactions in the MCS might be of
  regulatory nature.

64
Possible applications

• Target identification and repressing cellular
  functions.
• MCS offers a theoretical tool for target
  identification in drug discovery.
• An irreducible set of interventions needed for
  pathway dysfunction.
• Usually we will look for minimal size of MCS.
• Other pathways should be weakly affected.
• Can be checked easily set of untouched EMs.
• MCS 0, 2, 3, 4 will not affect EM1
