Title: Contamination Control


1
Contamination Control
Contamination Control Basics
2
Contents
  • Contamination Control Overview
  • Particle Counting ISO Codes
  • Contamination Control Tooling
  • Cleanliness Targets

3
Why Contamination Control?
  • Customers are demanding .
  • More power
  • Greater breakout forces
  • Faster cycle times

4
Why Contamination Control?
  • Industry trends
  • Electro-hydraulics
  • Higher system pressures
  • Tighter clearances

5
Why Contamination Control?
  • Result Todays fluid systems are more sensitive
    to contamination
  • Hydraulics
  • Transmissions / Final drives
  • Fuel systems
  • Engines

6
Why Contamination Control?
  • Contaminated fluid systems
  • Shorten component and fluid life
  • Reduce productivity
  • Can lead to catastrophic failure and
    costlydowntime and repairs

7
Why Contamination Control?
  • Tests prove clean oil improves life
  • Increased bearing life
  • No contamination-related failures from 6,000 to
    11,000 hours

8
What Is Contamination?
  • Anything in a fluid that doesnt belong
  • The 1 enemy of fluid systems

9
Contamination Sources
  • Built-in
  • New fluids
  • Introduced contamination
  • Cylinder wiper seals
  • Reservoir vent ports
  • Poor maintenance
  • Generated internally

10
Two Types of Contamination
11
Small Particle Contamination
Even Particles Too Small to See are Harmful!
Human Hair
Cat System Clearances
Smallest Visible to the Eye
2
30
40
MICRONS (?m)
80
12
What is a Micron?
1 Millionth of a Meter
100 microns (?m) - grain of table salt 80 microns
(?m) - diameter of a human hair
13
(No Transcript)
14
Effects of Contamination
Hydraulic System experts attribute 75 to 85
of all component failures to particle
contamination in the fluid and not a weakness in
the system components.
-- Hydraulics Pneumatics, June 1998 --
Equipment Today, August 1997
15
Pump Manufacturer
Component Life
----
-----
------------

Clean New Oil
Component Life Over Time
16
Effects of Contamination
  • Erratic steering
  • Cylinder drift
  • Slower performance
  • Unreliable operation
  • Lower productivity
  • Machine downtime
  • Higher operating costs

17
Prevention
  • Housekeeping
  • Oil storage and transfer
  • Change filters carefully
  • Parts handling and storage
  • Hose assembly and storage
  • Care in maintenance and repair
  • Adhere to proper maintenance intervals
  • Particle counting

18
Housekeeping
  • Sweep floors daily
  • Clean up spills immediately
  • Keep work benches uncluttered and free of debris
  • Limit use of floor storage

19
Housekeeping
Floor Dry
Hand Pump
Parts Packaging/Storage
Parts Cleaner
20
Housekeeping
21
Oil Storage and Transfer
  • Use a transfer filter cart
  • Change when warm and agitated
  • Use barrel covers

22
Kidney-loop Filtration System
Shown to increase oil and component life and
reduce costs
23
Change Filters Carefully
  • Change on schedule
  • Remove used filter carefully
  • Do not pre-fill new filter
  • Use high efficiency filters on serviced machines
  • Examine used filters for debris

24
Parts Handling and Storage
  • Keep components packaged until ready to install
  • Return parts to storage in packaging
  • Protect in-process components
  • Wash components before assembly

25
Hose Assembly and Storage
  • Keep hoses plugged capped
  • Use Cat hose cleaner proper process

26
Care in Operation and Maintenance
  • Perform daily inspections
  • Keep hydraulic tank filled
  • Maintain valves
  • Use rod protectors
  • Watch temperature
  • gauges

27
Particle Counting
  • The way to measure your contamination control
    efforts

28
Measuring Contamination
  • Spectrographic Analysis
  • Identifies elements in oil
  • Only up to 10-15 microns in size

29
Understanding Particle Counting
  • ISO codes
  • 28 code ranges
  • Particle Count
  • Quantifies particles 1-200 microns

30
ISO Cleanliness Code
  • Explained in ISO Standard 4406
  • Expressed Amount of Contamination in one mL of
    Fluid

4µm / 6µm / 14µm
31
ISO Codes
  • Expressed in X/Y form
  • X number of particles larger than 6 microns
    (gt6)
  • Y number of particles larger than 14 microns
    (gt14)
  • Example 16/13

32
ISO Code Chart
Number of Particles / mL 40,000 - 80,000 20,000 -
40,000 10,000 - 20,000 5000 - 10,000 2500 -
5000 1300 - 2500 640 - 1300 320 - 640 160 -
320 80 - 160 40 - 80 20 - 40 10 - 20 5 - 10 2 -
5 1 - 2
28 ISO Codes 23 22 21 20 19 18 17 16 15 14 13 12 1
1 10 9 8
NOTE Particle count doubles at each level
33
Compare the Difference
Very Dirty Oil
Hydraulic/ Steering Targets
Minimum Target
Fill Oils
21
18
24
16
160,000 20,000 2,500
640
15
13
19
17
5,000 1,300 320 80

34
Compare the Difference
18/15 (clean)
16/13 (very clean)
35
Contamination Control Tooling
Portable Contamination Kit
Hose Cleaning Kit
S-40
Transfer Cart And Fluid Recovery System
Rear Axle Filter Buggy
Small System Filtration Cart
36
Particle Counter Printouts Patch Kit Results
37
Recommended Cleanliness Targets
Fill Oil ....
ISO16/13 Hydraulic Systems (Implement
Steering)..... ISO18/15 Transmission
Systems Electronic ...
ISO18/15 Mechanical Transmissions.
ISO21/17 Component Rebuild Engines (Roll-off)
....Pending. ISO18/15 Transmission,
Pumps, Governors Etc .... ISO16/13 Fuel
???. ISO18/16/13
Injector Testing Equipment Calibration
Fluid.. ISO15/13
38
Visualizing Contamination
  • How much dirt can be present in a 55-gallon
    drum of oil and still meet ISO 16/13?

39
Visualizing Contamination
  • Half a teaspoon

40
Contamination Control Example
  • How much difference will cleaning oil from ISO
    19/16 to 16/13 really make?

Example 32 GPM pump working 8 hours/day for 200
days
41
Contamination Control Example
Amount of Dirt Flowing Amount of Dirt
in Oil Through Pump in One Year

ISO 19/16 ISO 18/15 ISO 16/13
157.7 lb/yr
78.9 lb/yr
19.7 lb/yr
42
Contamination ControlSupport Available

Tools Equipment Methods
Procedures Available for All
Products (95)
43
Contamination ControlResults
  • Lower Cost
  • Repair Time
  • Preventive Maintenance
  • Component Life Extension
  • Oil Extension
  • Increased Availability
