Ladder Safety

1
Ladder Safety

• University Safety and Assurances
• 229-6339
• www.safety.uwm.edu

2
Choosing Right Equipment -- Ladder or Scaffold?
Ladder
Scaffold

• Will the job take only a short amount of time?
• Does work require side-to-side movement?
• Does the work require using tools with both hands?

3
Types of Ladders

• Max 30
• Max 20
• Max 60
• Combined lengths of section not longer than
  specified for equivalent non-sectional types
• Max 30
• Max 20
• Max 20
• Max 40

• Straight Ladder
• Step Ladder
• Extension Ladder
• Sectional Ladder
• Trestle Ladder
• Trolley Ladder
• Side Rolling
• Masons Ladder

4
Duty Ratings

• Type IAA Special-duty -- 375 lbs
• Type IA Extra heavy-duty -- 300 lbs
• Type I Heavy-duty -- 250 lbs
• Type II Medium-Duty -- 225 lbs (not recommended
  at UWM)
• Type III Light-Duty -- 200 lbs (not allowed at
  UWM)

5
Load Limits

• Select a ladder designed to hold the necessary
  load, including worker and equipment
• Do not assume that a longer ladder has a higher
  duty rating. There is no relationship between
  length and duty rating.
• The American National Standards Institute (ANSI)
  requires that a duty rating sticker be placed on
  the side of every ladder so users can determine
  if they have the correct type ladder for each
  task/job.

6
Advantages/Disadvantages

• Fiberglass
• Strong, lightweight, electrically non-conductive
• More expensive than wood or metal

Fiberglass Ladder
7
Advantages/Disadvantages

• Metal
• Must not be used when working on or near
  electrical wires
• lightweight

8
Advantages/Disadvantages

• Wood
• Heavier than aluminum or fiberglass
• Can rot
• Electrically non-conductive

9
Fixed Ladders
Prior to ascending or descending a fixed ladder,
examine connections to assure that ladder is
properly secured
Fixed ladders are located in the Fine Arts
Complex -- Theatre and Recital Hall
10
Ladder Safety Checklist

• Check for damage prior to using
• Make sure feet are not broken or malfunctioning
  and that the slip-resistant pads are secure.
• Inspect for cracks, bends splits on the side
  rails, rungs steps.
• Make sure both rung locks are working properly.
• Test the rope pulley. Examine rope for any
  signs of fraying. Make sure the pulley is
  operating smoothly.
• Ensure all bolts and rivets are secure.
• Make sure ladder is free of foreign materials
  such as oil grease.
• Make sure the spreader braces are secure
  working properly.
• Aluminum or steel ladders should be inspected for
  rough burrs and sharp edges.

11
Immediately remove ladder from service if
inspection finds

• Broken or missing steps, rungs or cleats
• Broken or damaged side rails
• Other faulty equipment such as missing feet,
  damaged connections, broken rivets

12
Ladder Set-Up

• Always place ladders on a stable surface
• Clear debris
• Level uneven ground

13
Ladder Set-Up

• Always assure secure footing
• Keep ladder free from mud, grease and other
  substances which could cause you to slip
• Keep area around ladder free from traffic.

14
Ladder Set-Up

• Always lock or guard door if ladder blocks doorway

15
Ladder Set-Up

• Base of straight ladder should be 1 foot away
  from the surface for every 4 feet to the top
• (14)

4 feet
1 foot
16
Ladder Set-Up

• Dont place ladder on boxes, barrels or other
  unstable surfaces to extend height

17
Extension Ladders

• Always raise extension ladders so that the upper
  section overlaps and rests on the bottom section.
• The upper section must always overlap on the
  climbing side of the extension ladder.

18
Extension Ladder Overlap

• Extension Ladders should have the proper overlap
• Three foot overlap for 32-foot ladder
• Four foot overlap for 32- to 36-foot ladder
• Five foot overlap for 36- to 48-foot ladder
• Six foot overlap for 48-foot ladder

19
Straight Ladder

• If a straight ladder is used to climb onto an
  elevated work station, it will extend at least 3
  1/2 feet above the working level.

This ladder is not sufficiently extended
20
Safe Ladder Use

• Face the ladder when ascending or descending
• Both hands should be placed on ladder rails, not
  on rungs, when ascending and descending
• Maintain 3 point contact at all times -- This
  means both feet and one hand or one foot and both
  hands

21
Safe Ladder Use

• Use extra caution while climbing in windy weather

22
Safe Ladder Use

• Always climb completely past the landing before
  stepping over

23
Safe Ladder Use

• Dont walk a ladder (rocking from side to side
  to move)
• Dont use a stepladder as a straight ladder

24
Safe Ladder Use

• Dont carry tools in your hands. (A tool pouch
  or belt should be used or tools should be hoisted
  up)
• Dont overreach to either side or lean too far
  forward or backward

25
Safe Ladder Use

• Dont use a ladder without locking spreader or
  other device in place

26
Safe Ladder Use

• Dont climb using bracing on back legs of step
  ladder
• Dont attempt to straighten or use a bent ladder
  made of metal or reinforced plastic--repairs
  should be made by qualified personnel

27
Safe Ladder Use

• Dont Climb using two highest steps or top of
  platform

28
Safe Ladder Use

• Dont use a defective ladder
• Dont block a fire exit
• Dont use a ladder as a platform
• Dont use a ladder by more than one person

29
Safe Ladder Use

• Dont use a ladder if you are feeling dizzy,
  light-headed, are excessively tired, on
  medication, have recently consumed alcohol or are
  otherwise temporarily impaired.

30
Ascending and Descending

• Always face ladder when ascending, descending and
  performing work

31
Safe Ladder Use

• Keep between the side rails when working --your
  body should be centered on the ladder so your
  belt buckle is between the side rails

32
Ladder Storage

• Store ladders for easy access and inspection.
• Store vertically if possible. If not possible,
  store horizontally supporting ladder at several
  points to avoid sagging
• Protect ladder from heat, weather and corrosive
  materials

33
Ladder Storage

• Do not leave ladders where they may create a
  tripping or fall hazard for others

34
Lifting and Carrying

• Lift ladder using legs muscles, not back
• Carry holding ladder close to body

35
Lifting and Carrying

• When carrying ladder
• Balance center of ladder on your shoulder
• Position so front end of ladder is above your
  head and back end is near the ground

36
Lifting and Carrying
When ascending and descending stairs, carry
ladder with one hand and hold stair rail with the
other hand
37
Lifting and Carrying

• Set ladder down when opening and closing doors
• Take special care when negotiating corners or
  turning around

38
Lifting and Carrying

• When it is necessary for two people to carry a
  ladder, both should be on the same side of ladder
  and both people should walk in step.
• Spikes, hooks or ladder feet should face toward
  the rear when ladder is being carried

39
Whats Wrong in this Picture?
40
Whats Wrong in this Picture?

• Climb only as high as the 2nd tread from the top
  on a step ladder and the 3rd rung from the top on
  a straight ladder.

41
Whats Wrong in this Picture?

• Do not sit on the ladder and never sit or stand
  on the top cap of a step ladder it is not
  designed to carry your weight.

42
Whats Wrong in This Picture?
Ladder should be opened fully and locking
mechanism engaged prior to ascending
