Introduction to Challenges in System and SoC Debug

1
Introduction to Challenges in System and SoC
Debug

• DAC System and SoC Debug Workshop, June 8, 2008
• Dr. Neal Stollon, HDL Dynamics
• neals_at_hdldynamcs.com

2
First the good news

• Lots of Design for Debug standards activity
• OCP-IP has released Debug Interface spec
• Power.org has released Debug spec
• SPRINT has released Debug API spec
• Nexus, 1149.7 set to release specs by COB
  2008
• Lots of DfD industry activity
• More on-chip debug IP and interfaces are now
  the
• norm for higher end embedded parts

3
3 Challenges

• Challenge 1 - User Perception
• Debug capabilities as key features
• Challenge 2 Intra-Domain Integration
• Better multi-vender SoC debug Interoperability
• Challenge 3 Inter-Domain Integration
• Closer integration with EDA, test,
  software worlds for win-win SoC solutions

4
Challenge 1

• DfD perception as a necessary evil vs. value
  added feature
• Debug features are only needed by engineers
  who make errors!
• Limited users for HW debug Why waste
  silicon ??
• Debug infrastructure bar goes up with
  complexity
• - RAM vs. IO Bandwidth tradeoffs

5
Challenge 1

• More painless solutions (automation)
• Software is king
• Better visualization
• Localizing problems
• HW should be interoperable
• Migration from JTAG
• 3rd party value vs. in-house solutions

6
SoC On Chip Debug Evolution
JTAG (Scan, BIST Run Ctrl)
Embedded Processor / Logic Trace
Multi-Core Embedded System Debug
Debug- Innovation
ICE
BDM
Platform SoC (Multi-Core)
50K 20K 8K 2.5K 1K
Debug- Difficulty Metric (total gates/pins)
SoC (RISCIP RAM)
ASICS
System FPGA (PLDRISC IP)
Embedded Systems
Single processor
FPGAs
1980s
1990s
2000s
The New Frontier

• Embedded Debug Complexity increasing on log scale
• Gates increase geometrically - Pins increase
  linearly
• Significant debug difficulties for complex
  architectures
• More complex debug needs new Instrumentation
  approaches

7
The Debug Landscape

• Tool Level of Integration
• SW/EDA Tool level APIs
• HW tools level APIs

Debug Software
SPIRIT

• IO Level of Integration
• JTAG different flavors
• Nexus 5001
• MIPI NIDnT

CJTAG
Probe
MIPI
TAP
IJTAG

• Protocol Level of Integration
• Nexus 5001
• Multicore IP probe APIs
• Other Proprietary

Nexus Power.org
System Level Debug Communications (SoC level run
control, Cross-triggers, etc.)
Multicore Trace formats
SPRINT
OCP

• Instrument Level
• Many vendor/IP solutions
• CoreSight
• MIPS EJTAG
• MCDS
• Nexus

Bus Analyzers
Bus Fabric
Core Analyzers
Core A
Core B
8
Challenge 2

• The DfD community is still internally fractured
• Many groups reinventing the same wheels
• Little to no inter-company commonality on
  instrument interface/tool feature/API
  infrastructure
• What is driving incentives to common interfaces??

MIPI Roadmap
Does this converge to a DfD Industry Roadmap ?
Nexus Roadmap
OCP-IP Roadmap
Will design community adopt Without an Industry
Roadmap ?
POWER.ORG Roadmap
SPIRIT Roadmap
. . .
9
Challenge 2

• Many Roadmaps vs Industry roadmap
• Diverging IO parallel, Serdes
• Differing processor trace capabilities,
  formats
• Differing bus debug capabilities
• Emerging debug solutions for multicore
• Common, low cost debug solutions for low end MCUs

• Basic MCU in 3-5 years will differ from today

10
The Target Hitting Range of Debug Solutions
11
Challenge 3

• System and SoC Debug is still an island to the
  greater EDA/Test community
• Integration with other aspects of design and
  verification flow are limited and adhoc.
• Why SW centric focus, need for IP, lower
  margins
• Debug breakthroughs will occur in conjunction
  with EDA community
• EDA venders are starting to see the opportunity
  beyond emulation
• Synplicity Identify
• Novas - Verdi

12
Challenge 3

• SoC Debug is Test issue
• SoC Debug is Design Optimization issue
• SoC Debug is Verification issue
• How to we annotate simulation analysis with debug
  data?
• How can we reuse testbenches and assertions to
  automate debug?
• Ex. GDB is used for debug. GDB is used in ESL.
• Who has a common GDB mechanism to integrate ESL
  and Debug?

13
Next Stage Debug ChallengesIntegrating ESL and
Debug
Eclipse Framework
ESL Virtual SoC
SW-level Debug
HW-level Debug
Data Transaction Debug Transaction
Triggers
HW Analyzers
Simulation
RISC
JTAG
DB Reader
Soft Trace DB
IP Assertions
DB Writer
Mem
SW Debuggers
Trace
DSP
SPIRIT IP_XACT
XML
Bus Monitors
XML
Embedded SW
XML
Correlation Inferences
SoC Bus Sockets
JTAG TRACE
DB Reader
S
M
D
S
M
D
S
M
D
S
D
D
D
D
Hard Trace DB
DB Writer
Mem
DSP
RISC
IP Assertions
Trace
JTAG
Bus Monitor
Triggers
JTAG DFT
SCAN
JTAG /Nexus
RTL/Physical SoC
Adopted from Alan Su Springsoft
14
ESL/Instrumentation Flows
Eclipse GUI Framework

• SystemC
• Analysis (DUST)
• Model Frameworks
• GreenBus

• GDB
• Trace
• Breakpoints
• Run Control

• GCC IDEs
• processor only
• ISS Simulation

MDI, GDI, RDI
Instrumentation Tools - Probe Config, Display
JTAG, Trace Port Interfaces
Instrumentation IP (RTL HW)

• Processor
• Debug block

• System
• Bus, Memory Debug
• Rest of the chip

15
Integrating Nexus
Of some interest DSNOC08 Diagnostic Services
in Network-on-Chips (DSNOC) Workshop, June 9
TLM Modeling Workshop June 9 Breakfast See Mark
Burton, GreenSoCs
16
OCP-IP Debug Status and Plans

• DAC System and SoC Debug Workshop, June 8, 2008
• Dr. Neal Stollon, HDL Dynamics
• neals_at_hdldynamcs.com

17
OCP Debug Working Group

• OCP is neutral On Chip Protocol for SoC IP
  connection
• WG focus on defining debug related signaling
  between cores and other embedded subsystems
• Leverage other work for IOs (JTAG, Nexus), APIs,
  etc.
• Defined subset architecture for on chip debug

Baseline Sockets 1149.1 JTAG Debug
resets Generic Processor debug
handshakes Cross Trigger Interfaces Synchronize
Trace/Debug Trace Triggers TimeStamp Interfaces
Power Management Debug Security
OCP 2.1 Socket
OCP Debug Socket
OCP Fabric b
OCP Fabric
RISC
RISC
Mem Ctrlr
Mem Ctrlr
DSP
DSP
RAM
RAM
Other IP
Other IP
Other IP
Other IP
Standardized transfer socket Master or slave,
with optional bursting, thread signals
not be same Debug
Features For all sockets are optional
18
Debug Socket for Multi-Core Debugging
OCP-IP Debug WG announces the release of its
Debug Standard.  The new standard identifies
Basic and Extended sets of socket level signals
for debugging of multiple processor cores
connected with the OCP interface.  The standard
represents a breakthrough allowing designers to
distribute debug signals as part of the system
interface scheme rather than wired separately
from the data path as had been previously been
the case. This innovative new approach greatly
enhances system providers ability to prepare
multi-core debug hardware and software.
19
What is in the Debug Specification?

• OCP Interface for Basic Debug Signals
• Debug Control and Run Control for Cores
• Consistent (multiple) processor software debugger
  interfaces
• Cross-Triggering between Multiple Cores and
  Events
• Scalable to on-chip/off-chip cross triggering
• Trace Interface
• Bus traffic observation (system trace) and
  control (triggering)?
• New classes of debug errors (different from
  system errors)?
• OCP Interface for Extended Signals (Special
  features)
• Performance Monitor
• Time-stamping
• Power Monitoring voltage islands, gated clock
  islands
• Security islands

Of huge valuein final silicon
20
Debug Hardware Environment
21
NEW OCP Debug Standard
Basic OCP Debug Interface
Standard Debug API (SPRINT)?
Extended OCP Debug Interfaces
OCP Debug Compatible fabric
CPU
B U S F A B R I C
Target Description IP-XACT, XML
Access HW
Debug HW
HWIP
Target Server
DSP
The SPRINT software standard is related to our
work as a general debug functionality description
for multiple processors.
22
System Debug Instrumentation OCP Example

• On-Chip Analysis
• Bus Trace OCP analysis
• Complex Cross-Triggering
• Performance Monitoring (PM)
• Debug Control (DC)
• Bus Master Transactors
• Integrated processor debug
• OCP Debug Spec is in process of release

23
OCP Debug Standard Advantages
Simplifies debug - Standardized Basic OCP core
Debug Socket Facilitates Debug Hardware and
debugging Software offered as standard IP Opens
implementation and support of (heterogenious)
processors Proprietary Debug solutions supported
- Need just OCP Debug wrapper Fixed OCP debug
interface, compatible to multitude of debug
interconnects (I.e. Nexus, serial buses, cross
bar, NoC, etc)? High initial uptake of the new
standard in the OCP-IP community
24
OCP Debug Information

• OCP public white papers are at
  www.ocpip.org/socket/whitepapers/
• OCP members get the standard at
  www.ocpip.org/members/ocpspec/
• OCP membership admin admin_at_ocpip.org
• Non-members can access this standard using an
  on-line, click-through research License
