What is nLight?

1
(No Transcript)
2
What is nLight?

• nLight is a revolutionary digital architecture
  and networking technology that cost-effectively
  integrates time-based, daylight-based,
  sensor-based and manual lighting controls.

3
How does nLight work?
nLight networks together intelligent digital
devices including occupancy sensors, photocells,
power packs, wall switches, dimmers, panels, and
even luminaires creating a system with an
unmatched level of distributed intelligence
4
What is Distributed Intelligence?

• Digitally Addressable
• Locally makes switching dimming control
  decisions
• Self-Commissioning
• Stand-alone Operation

5
nLight Enabled Devices
6
nLight-enabled Device

• Model numbers start with the letter n
• 2 RJ-45 Ports
• All devices consist of one or more of basic
  lighting control components
• sensor
• relay

• manual control station
• dimmer

7
nLight-enabled Device
Basic Devices 1 component
Model Number Lighting Control Components Lighting Control Components Lighting Control Components Lighting Control Components Lighting Control Components
Sensor Sensor Relay Manual Control Station Dimmer
Occupancy Photocell Relay Manual Control Station Dimmer
nCM 9 ?
nCM PC ?
nPP16 ?
nPOD ?
nIO ?
RT LED ?
8
nLight-enabled Device
Advanced Devices 2 or more components
Model Number Lighting Control Components Lighting Control Components Lighting Control Components Lighting Control Components Lighting Control Components
Sensor Sensor Relay Manual Control Station Dimmer
Occupancy Photocell Relay Manual Control Station Dimmer
nCMR 9 ? ?
nCMR 9 P ? ? ?
nCMR 9 ADC ? ? ? ?
nSP5 D ? ?
nPODR ? ?
nPODR D ? ? ?
nWSD ? ? ?
9
Occupancy Sensors
Enclosure Lenses of Relays of Time Delays Options Options
Enclosure Lenses of Relays of Time Delays Photocell 0-10 VDC Dimming1
Ceiling Mount Standard Range Extended Range High Bay 360 High Bay Aisleway 0, 1, 2 1, 2 Yes Yes
Recessed Mount Standard Range Extended Range High Bay 360 High Bay Aisleway 0, 1, 2 1, 2 Yes Yes
Fixture Mount Standard Range Extended Range High Bay 360 High Bay Aisleway 0, 1, 2 1, 2 Yes Yes
Corner/Wall Wide View / Hallway _ 1 Yes No
Wall Switch Wall to Wall 0, 1, 2 1, 2 Yes No

• PIR or Dual Technology2
• Powered over CAT-5, therefore units have no
  neutral wire
• 1 or both relays can be used as a dry contact
  closures
• Sensors that switch two phase power (208/480)
  also available
• Remotely configurable and upgradeable
• Integrated RJ45 connectors

1 Dimming not available with 2 pole or 208/480
devices 2 Dual Technology not available on High
Bay or Hallway sensors
10
Photocell Sensors
Enclosure Control Type of Relays of Dimming Outputs
Ceiling Mount On/Off On/Off/Dimming 0, 1, 2 0, 1, 2
Recessed Mount On/Off On/Off/Dimming 0, 1, 2 0, 1, 2
Fixture Mount On/Off On/Off/Dimming 0, 1, 2 0, 1, 2

• Automatic set-point programming mode
• Device provides light level in foot-candles
• Powered over CAT-5, therefore units have no
  neutral wire
• 1 or both relays can be used as a dry contact
  closures
• Sensors that switch two phase power (208/480)
  also available
• Remotely configurable and upgradeable
• Integrated RJ45 connectors

Dual Technology not available on High Bay or
Hallway sensors
11
Relay Packs
Description Model Load Rating (Amps) Supplies Network Power of Relays of Dimming Outputs
Power Pack nPP16 (SA) 16 Yes 1 0
Secondary Pack nSP16 (SA) 16 No 1 0
0-10 VDC Dimming Pack nSP5 D 5 No 1 1
Line Voltage Dimming Pack nSP5 PCD 5 No 1 1
480/240/208 VAC Pack nSP5 480 5 No 1 0
2-Pole Secondary Pack nSP5 2P 5 No 2 0
Low Voltage Auxiliary Pack nAR40 1 No 1 0

• 120/277 VAC unless noted
• Network power supplied 40mA / RJ-45 port
  (current limited)
• Remotely configurable and upgradeable
• Integrated RJ45 connectors, push-button, and LED
• Reversible relay logic
• All relays are latching

12
nIO - Universal Input/Output Device
Model Input Description Output Description
nIO 0-10 VDC Input, Contact Closure 0-10 VDC

• Provides an addressable 0-10 VDC dimming output
  for standard dimming ballasts (non-DALI)
• Enables simple incremental addition of dimming
  zones
• Interfaces 0-10 VDC dimming control signal from
  any non-nLight device
• Interfaces a toggle or momentary contact closure
  input into system
• Available as an inline wired device or in the
  power pack housing

13
3rd Party Touch Screen Interface

• Model Numbers nIO X
• Application
• Enables a non-nLight touch screen (e.g. Crestron,
  AMX) to interface with an nLight network
• nIO X device has both an nLight port and a RS-232
  or RS-485 port for direct digital interface
• Simple protocol commands (programmed into 3rd
  party device)
• On/Off and Raise/Lower Control of any lights in
  local zone
• Triggering of up to 4 local or remote nLight
  scenes
• Scenes created in SensorView

14
Low Voltage Outdoor Photocell Kit

• Model Numbers nIO PC KIT
• Application
• Enables a non-nLight low voltage outdoor
  photocell to communicate with nLight network.
• Change of daylight state directly triggers a
  relay(s), or causes a local/remote scene to run.
• Electrical Specs
• Requires 35 mA _at_ 12-28 VDC power from either an
  nPANEL 4 or PS80.
• Kit Contents
• 1 - Outdoor low voltage photocell with threaded
  mounting to ½ KO
• 1 - Specialized interface device (nIO NLI) that
  reads signal from PC and translates to nLight

15
nLight-enabled Digital Luminaires

16
nIO LED
17
nIO LED
18
Push-Button WallPods Standard

• Key Features
• Traditional soft-click tactile feel
• Integrated LED per button
• Low voltage versions only
• 3-way configurations w/ other WallPods or nWSD
• Buttons are field replaceable
• Custom labeling will be handled by ordering
  replacement buttons (see datasheet)

Model On/Off Control Raise/Lower Controls
nPODM 1 0
nPODM DX 1 1
nPODM 2P 2 0
nPODM 2P DX 2 2
nPODM 4P 4 0
nPODM 4P DX 4 4
19
Push-Button WallPods Scene Control

• Local / Remote Scene Mode
• Runs scenes (profiles without a schedule) that
  are configurable via SensorView
• Scenes can control devices within local zone or
  other remote zones
• Scenes for local zones are stored locally, remote
  scenes are stored on the Gateway
• LED shows which scene is currently active
• WallPod Mode (default)
• Each buttons provides On/Off operation for
  different channel
• LED indicates current state

Model Scenes / Channels
nPODM 1S 1
nPODM 2S 2
nPODM 4S 4
nPODM 4S DX 4 on/off raise lower
20
Touch WallPods
Description Model of On/Off Control of Relays of Raise / Lower Controls of Dimming Outputs of Scene / Preset Control
Single On/Off nPOD 1 0 0 0 0
Single On/Off nPODR 1 1 0 0 0
Single On/Off nPOD DX 1 0 1 0 0
Single On/Off nPODR DX 1 1 1 0 0
Single On/Off nPOD D 1 0 1 1 0
Single On/Off nPODR D 1 1 1 1 0
Dual On/Off nPOD 2P 2 0 0 0 0
Scene Selector nPODS 4 0 0 0 4

• 3-way configurations w/ other WallPods or nWSD
• Remotely configurable and upgradeable
• Integrated RJ45 connectors
• Capacitive Touch Controls
• Audible Clickers

21
Graphic WallPod

• nPOD-GFX
• Full-color touch screen control
• Provides functionality of 16 On/Off/Dim WallPods
• Facilitates creation of up to 8 lighting presets
  with on/off/dim settings
• Enables programming of switch tracking channel of
  all devices in local zone
• Low voltage device mounts to a single gang switch
  box or ring
• Micro-USB connector (behind cover plated) for
  simple laptop connectivity with zone
• Requires separate PS-150 power supply

22
Virtual WallPods

• On-screen icon version of WallPods
• Available as taskbar or iPhone application

Multiple
Single
23
iPhone Virtual WallPod App.
24
nLight Control Zone
25
nLight Control Zone

• Zones are daisy-chain wired (in any order)
• May have a single device
• May have several different device types
• May have multiple devices of the same type
• Can be sub-divided into 16 channels of occupancy,
  photocell, and switch control
• Functions stand-alone if disconnected from
  Gateway/SensorView

26
Zones and Channels

• Every nLight zone has 16 occupancy channels, 16
  photocell channels, and 16 switch channels on
  which to communicate information

• Any device with a sensor, photocell, and/or
  switch can broadcast each type of information on
  one respective channel (2 pole devices can
  broadcast of two channels simultaneously)
• Any device with a relay and/or dimming output can
  listen (track) on one or more of each information
  types channels simultaneously

27
Zones and Channels - Example

• Example
• Classroom with 4 circuits of lights (3 main rows
  of lights, 1 accent light)
• Two occupancy sensors each broadcasting on
  occupancy channel OC-1
• One dimming photocell broadcasting on photocell
  channel PC-1
• Four WallPods broadcasting on switch channels
  SC-1, SC-2, SC-3, and C-4 respectively
• Four Power Packs tracking on occupancy channel
  OC-1, each tracking a different switch channel
  (SC-1, SC-2, SC-3, SC-4), and two tracking
  photocell channel PC-1

28
Zones and Channels - Example
Physical Connections
29
Zones and Channels - Example
Logical Connections
30
Example Zone Designs
1 Circuit - Relay in Power Pack
31
Example Zone Designs
2 Circuits - Relays in Power Pack
32
Example Zone Designs
2 Distribution Circuits Relays in both Power
Pack and Sensor
33
Example Zone Designs
Multi-zone Dimming
34
(No Transcript)
35
(No Transcript)
36
nLight Network Backbone
37
nLight Network Backbone

• Backbone devices include
• Bridges
• Gateways

38
nLight Bridge

• Functions
• Routes Information between upstream Gateways up
  to 8 downstream sensor zones
• Increases number of lighting zones (128 devices
  per port)
• Acts as both a hub and router of information
  between zones and Gateway
• Redistributes power between zones

• Physical Specs
• 4 or 8 ports (RJ-45)
• Mounts to 4x4 junction box
• Powered via dedicated Power Supply
• Optional Wireless interconnectivity

39
Gateway

• Functions
• Local Control Point
• Two gang low voltage device located in space
• Discovers and maintains database of all network
  devices
• Capable of managing 400 devices indirectly or 32
  devices directly
• Typically one per floor

• Network Access Point
• Links Ethernet to nLight network
• Contains one Ethernet port and 3 SensorNet ports
• Maintains time clock

• Profile management
• Stores all profiles created by SensorView that
  include a device connected to Gateway
• Sends out new settings to all devices in the
  Group bound to a particular Profile at the times
  specified by that Profile
• Enables profiles to be run on-demand

40
Gateway

• Network connection
• IP address can be fixed or DHCP
• Derives time from network
• Ethernet port connects to buildings LAN (Local
  Area Network)
• Security
• Gateway password (set via SensorView) prevents
  outside SensorViews from accessing network
• Once password is set for one Gateway it is
  automatically configured as the password for all
  current and future Gateways on the network
• 4 Digit Pin Code is available to enable locking
  of Gateway manual interface

• Installation
• Discovery of network is automatic, rediscovery
  can be forced via MDI
• Mounts to 2-gang low voltage ring

41
Example Network Design
42
Additional Network Design Topics
43
System Powering

• All device and communication power is delivered
  via the CAT-5 bus that interconnects zones and
  Bridges.
• Power is supplied by power packs (nPP16), power
  supplies (nPS 80), and Bridges (via their
  external power supply)

Typical Power Consumption
Power Generation
3mA
3mA
3mA
Note WallPod Scene Selectors require 5 mA
Wall Switch Sensors with the NL option
require 3.5 mA
44
System Powering

• Bridges combine system power from zones that are
  net contributors of power and distribute it to
  zones that are net consumers of power

45
Design Rules

• Design Rule 1 Every zone requires either a power
  pack/supply or a connection to a Bridge in order
  to power all devices and the zones communication
  bus.
• Design Rule 2 Only one device with a photocell
  should broadcast on each channel per zone. No two
  photocells should be able to see the lights being
  controlled by another photocell
• Virtually any combination of nLight Devices
  can exist in a zone that conforms to these design
  rules.

46
Design Tips

• Recommended that the power pack be directly
  connected to the Bridge
• Any zone connected to a Bridge should have
  exactly one open port
• Any zone designed to run stand-alone should have
  exactly two open ports
• Leave extra Bridge ports unused for expansion
• Use a Gateway per logical building division
  (floor, suite, wing, etc.)

47
Design Tips

• Minimize Bridge-to-Bridge hops

48
System Capacity

• 400 nLight Devices per Gateway
• 40 Active Profiles (Schedules) per Gateway
• Unlimited Bridges per network
• gt40 Gateways per SensorView
• 40 concurrent SensorView web sessions
• Gateway support 32 locally connected devices
  total
• Bridges support 128 devices connected per port
• 500 ft total cable length per zone
• Bridges are counted in 400 device limit per
  Gateway

49
Wide Area Networking of nLight

• Multiple Gateways can be linked together to form
  larger networks
• SensorView auto-discovers all Gateways in its
  local network subnet
• Remote Gateways can be linked in by inputting IP
  address to SensorView
• Application Branch locations of a bank connected
  via corporate WAN network
• Device level permissions will allow for
  partitioning of users to certain Gateways
• Application Multi-tenant buildings with one
  overall nLight/SensorView network

50
(No Transcript)
51
SensorView
52
SensorView Properties
53
SensorView Settings
54
SensorView Status
55
SensorView Groups
56
SensorView Profiles
57
SensorView Updates
58
SensorView Green Screens

• Key Features
• Downloadable plug-in to SensorView
• Logs and displays nLight network information
  including
• Occupancy sensor time delay status
• Daylight levels
• Dim levels
• Relay state
• Provides data in time scaled graphs or in .CSV
  file for exporting to Excel
• Calculates savings both in Time, kWhr and if
  given load and/or energy rates
• Requires Gateway and SensorView

59
SensorView Green Screens Network Totals
60
SensorView Green Screens Zone Details
61
SensorView Green Screens Zone Details
Relay State
Occupancy Time Delays
Total Light Levels
62
SensorView Green Screens Admin
Savings units (kWH, , CO2)
Peak/Off Peak Hrs.
Savings units (kWH, , CO2)
Baseline Operating Hrs.
63
BACnet IP

• Key Features
• Downloadable plug-in to SensorView
• Enables interfacing with BMS systems via an IP
  connection
• Communicates information gathered by nLight to
  other building systems (such as HVAC)
• Translates and forwards lighting relay and other
  select control commands from BMS system to nLight
  control devices.
• Demonstrated compatibility to date with Siemens
  Apogee, Johnson Controls Metasys, and Tridium.
• Interoperability with other systems will be added
  as required.
