Normal ECG: Rate and Rhythm

1
Normal ECG Rate and Rhythm

• Read chapters 4 and 22

2
ECG Interpretation

• Standardization
• Rate
• RR interval
• Heart rate
• Rhythm
• PP interval
• P wave
• width, height, shape, etc.
• PR interval
• QRS
• width (and height)
• axis
• R wave progression
• abnormal Q waves
• ST segment
• T waves
• QT interval
• U waves

See Chapter 22
3
(No Transcript)
4
ECG Interpretation

• Univ. of Wisconsin Medical School
• http//www.fammed.wisc.edu/pcc/ecg/

5
The Normal ECG

• Normal normal sinus rhythm

6
Rate

• R-R interval
• Is it regular?
• What is the heart rate?
• 300, 150, 100, 75, 60, 50
• 300 / ( of large boxes)
• 1500 / ( of small boxes)
• Count the number of cardiac cycles in 10 seconds
  and multiple by 6.

7
(No Transcript)
8
Rate

• Bradycardia
• less than 60 bpm
• Tachycardia
• greater than 100 bpm

9
Rate

1. P-P interval

10
Rhythm

1. P wave
2. PR interval
3. QRS

11
4. P Wave

• Lead II and aVR
• Positive in II
• Negative in aVR
• lt 2.5 mm in amplitude
• lt 0.12 sec. in width

12
Normal P Wave
Normal direction of atrial depolarization
aVR?
II?
Figures 4-2 and 4-3
13
Abnormal P Wave
Direction of atrial depolarization with junction
rhythm
aVR?
II?
This is an example of a retrograde conduction
14
(No Transcript)
15
P wave

• The same direction as QRS
• Only one P wave in front of QRS
• Do all the P waves look alike?

16
5. PR interval

• 0.12 - 0.20 seconds

17
6. QRS Complex

• What is the width? (less than 0.10 seconds)
• Do all the QRS waves in the same lead look alike?
• R wave progression
• Axis
• Abnormal Q waves (infarction)

18
(No Transcript)
19
(No Transcript)
20
QRS Complex
Q waves
21
Normal QRS

• Two phases
• brief phase depolarization of ventricular septum
• longer phase depolarization of both ventricles
  but the left is larger

22
First Phase

• Depolarization of ventricular septum

23
Second Phase

• Depolarization of both ventricles but the left is
  larger

24
Precordial Leads
V6
V1
25
Normal QRS
V6?
V6?
V1?
V1?
Fig. 4-6
26
Normal QRS
V1
V6
27
Normal QRS

• Septal r wave

• Septal q wave

28
6. QRS Complex

• R wave progression

29
Normal R Wave Progression
Transition Zone?
30
R Wave Progression
Transition Zone?
31
Transition Zone

• Figure 4-7

32
Early Delayed Transition
V1 V2 V3 V4
V5 V6

• Figure 4-7

33
6. QRS Complex

• What is the electrical axis?
• normal
• left axis deviation
• right axis deviation
• extreme axis deviation

34
7. St Segment

• ST segment elevation or depression
• (see chapters 8 9)

35
8. T Wave

• Normally positive where QRS wave is positive
• V3- V6 and II, but negative in aVR
• Abnormally tall T waves

36
Practice

• ECG Library
• http//www.ecglibrary.com/ecghome.html
• ECG The Art of Interpretation
• http//www.12leadecg.com/full/

37
Normal
38
Not normal PR interval - Mobitz Type II block
39
Not normal LAD, R wave progression RBB w/inferior
MI
40
Not normal - First degree block, left atrial
enlargement, left bundle branch block, inferior
MI
41
Not normal Atrial fibrillation
42
Normal
43
Not normal Junctional rhythm
44
Not normal LAD, late R wave progression Acute MI
45
Not normal Premature ventricular contractions
46
Not normal Ventricular tachycardia note fast
rate and wide bizarre QRS.
47
Normal
48
Not normal Second degree AV block - type II
49
Not normal RAD, R wave progression
50
Not normal Third degree AV block
51
Not normal Right bundle branch block. Note the
wide QRS waves
52
Normal
53
Not normal Left bundle branch block. Note the
wide QRS waves
54
a. yes b. vertical c. V3 d. yes e. yes f. yes
55
2. No. Although there are P waves, they are
negative. negative P waves indicate a retrograde
conduction likely coming from the AV junction.
