Application of Metal Forming in Manufacturing Engineering

1
Application of Metal Forming in Manufacturing
Engineering

• Jenn-Terng Gau, Ph.D.
• Assistant Professor of Mechanical Engineering
• Northern Illinois University

2
Research Interests
3
Importance of Metal Forming in Manufacturing
Engineering

• Net Shape or Close to Net Shape
• High Production Rate
• High Profit Margin
• Low Scrap Rate
• Improving Material Properties
• Etc.

4
Applications and Products of Metal forming in
Macro Scale

• Automotive
• Aerospace
• Appliance
• Cookware
• Etc.

5
Current Issues of Metal Forming Industry

• Lack of Experienced Metal Forming Engineer
• Short Product Life Cycle
• New Metallic Materials
• Developing New Hybrid Process
• High Accuracy and Small Feature Products
• Etc.

6
OVERVIEW OF METAL FORMING

• Bulk Deformation Processes
• Compressive deformation force
• Significant deformations
• Massive shape changes
• Starting work shapes include billets and
  rectangular bars
• Sheet metal working
• Also called Pressworking
• Cold working processes
• Use set of punch and die
• Performed on metal sheets, strips and coils

Surface Area / Volume is small
Surface Area / Volume is large
7
Metal Forming Processes
Cup Drawing
Rolling
Forging
Bending
Shearing
Wire Drawing
Extrusion
Sheet Metal Working
Bulk Deformation Processes
8
Examples of PrecisionCold Forged Products
9
Precision Hot Forging of Complex Shapes
10
Precision Hot Forging of Complex Shapes
11
Sheet Metal Forming

• Stamping and Deep Drawing

12
Importance of Stamping

• Stamping is an efficient and low cost process for
  high volume manufacturing.
• In automotive Industry, 70 of parts are formed
  by stamping process

13
Stamping Process Flow in Automotive Industry
14
Binder Wrap Simulation (CAE)
15
Forming Simulation (CAE)
16
Product Change and Draw Development Modification
17
Rerun Forming Simulation
18
CAE and Tryout Comparison
19
CAE and Tryout Comparison
20
Draw Die
21
Micro Metal Forming

• Sheet and bulk metals

22
Applications and Products of Micro Forming

• Cellular Telephones
• IC Leadframes
• Electronics
• Healthcare
• Miniature Fasteners
• Hard Disc Drives
• National Security Defense
• Automobiles
• Sensors
• Etc.

23
Finished Micro Press Design
24
NIU Micro Dies
25
Skills Needed for Metal Forming Engineering

• Mechanics
• Material Science
• Manufacturing Process
• Design and Control
• Machinery
• Computer Skills
• FEA

26
Students Need

• To know the current and future needs of metal
  forming industry.
• To be taught on a series of classes to meet
  challenges of current and future metal forming
  industry.

27
UEET 101 Problem Domain

• According to your imagination, what is the best
  process to make beverage can?

28
Homework

• Is metal forming the most cost effective
  manufacturing process?
• Why metal forming is the best process for mass
  production?
