Onion, Garlic, Leek: Horticulture

1
Onion, Garlic, Leek Horticulture and Human
Health Irwin Goldman University of
Wisconsin-Madison
2
Garden of Eden
Goldman
3
Goldman
4
Plant-Based Folklore

• Rice deters demons affecting fertility of the
  newlyweds
• Tomato was used to treat eye diseases
• Seeds from Apiaceae species were used to derive
  medicines
• Alliums were used for infections and to improve
  circulation

Goldman
5
Coincidence?
Goldman
6
Monomolecular Drugs
Goldman
7
Functional Foods?
Goldman
8
Functional Foods

• Similar in appearance to conventional food
• Demonstrated physiological benefit beyond
  nutritional value
• Example antioxidant function of carotenoids,
  beyond Vitamin A nutrition
• Therefore, the molecule is multi-functional

Goldman
9
Dysfunctional Foods?
Goldman
10
Snake Oil Steady Work for Over One Century
Harpers Bazaar, 1898
Harpers Bazaar, 1998
Goldman
11
Let your food be your medicine and your medicine
be your food -Hippocrates
Goldman
12

• Egyptian use of Alliums for heart ailments
• Olympic athletes use Alliums for circulation
• Blood clots in horses treated with onion and
  garlic

Goldman
13
Are Alliums functional foods?
?
Goldman
14
Defense Compounds

• Sulfur stored as ACSOs
• Tissue disruption initiates lysis of ACSOs
• Causing formation of thiosulfinates, other OSCs
• Organosulfur compounds deter many pests

Sulfate
ACSOs
Alliinase
Thiosulfinates
Pest resistance
Fenwick and Hanley, 1986
Goldman
15
Chemical Composition of Garlic
mg/g FW
Water 620-680 Carbohydrates 260-300 Fiber
15 Protein 15-21 Amino Acids
10-15 OSCs 11-35 Vitamins 0.15 Minerals
7 Sulfur 2.3-3.7 Nitrogen
6-13 Lipids 1-2 Adenosine 0.1
ACSOs 6-19 g-Glut.Cyst. 5-16
Unique Featues High OSC content Low moisture
(65) High fructans (65 of DW) High AA,
arginine High S content High Se content
Goldman
16
Chemical Composition of Garlic
Presence of Principal OSCs in Garlic
---------mg/g FW------- Whole
Crushed ACSOs 6-17 0 g-GACs 5-15 5-15 Thi
osulfinates 0 3-5
Goldman
17
Cell
bundle sheath cells
Cytoplasm, mesophyll storage cells
Goldman
18
Distribution of Flavor Precursors
Goldman
19
Garlic Sulfur Compound Transformation-Redrawn
from Lawson, 1998
Whole
? Glutamyl-S-allylcysteine Alliin Cycloalliin ?
Glutamyl-S-t-1-propenlcysteine Methiin
No change
Crushed

Alliinase
Sulfenic Acids Allicin Allyl
methanethiosulfinate Pyruvic Acid
Processed
Transpeptidase
aqueous steam distillation
oil or solvent incubation
S-Allylcysteine Diallyl trisulfide 2-Vinyl-4H-1
,3-dithiin S-1-Propenylcysteine Diallyl
disulfide 2-Vinyl-4H-1,2-dithiin Glutamic
acid Allyl methyl trisulfide E-Ajoene Allyl
methyl disulfide
Goldman
20
Flavor and Medicine

• Thiosulfinates confer flavor to food
• Also mask other flavors
• Exhibit a range of unique bioactivities
• Including many of interest to human health

Sulfate
ACSOs
Alliinase
Thiosulfinates
Flavor, Medicine
Block, 1985, Lawson, 1998
Goldman
21
Domestication

• Cluster
• Perennial
• Flower
• each year

• Bulb onion progenitor unknown
• Perennial growth habit
• Selection pressure for apically-dominant bulb
• Large single bulb, biennial cycle

• Single
• Apical
• dominance
• Biennial

Brewster, 1994
Goldman
22
History of Alliums as Medicine

• Recorded by Sumerians and in India
• Inscribed on Great Pyramid of Cheops
• Discussed in Codex Ebers, 1550 B.C.E.
• Eaten by pyramid builders
• Described in China by 500 C.E.
• Incorporated into Ayurvedic medicine by 500 C.E.
• Hippocrates recommended as remedy, 400 B.C.E.
• Dioscorides suggested medicinal properties

Source Lawson, 1998 Hahn, 1996
Goldman
23
History of Alliums as Medicine

• St. Hildegard of Bingen, 1150
• Suggested as cure for plague of London, 1665
• Sydenham used to cure smallpox, 1650s
• Used to cure cholera in Europe, 1850s
• Pasteur showed antibacterial effect in 1858
• Schweitzer used to cure typhoid in Africa
• Used in WW I in Europe to treat wounds
• Russian Penicillin from use during WW II

Source Lawson, 1998 Hahn, 1996
Goldman
24
Greeks and Romans

• A garlic breakfast will make you hotter for
  fighting (Aristophanes)
• Our fathers and great-grandfathers were rather
  courageous men, though their words had a crude
  odor of garlic and onions. (Varro)
• If you evershould partake of this plant, then
  may your beloved resist your kiss and remain far
  from your hugs and flee to the lowest couch.
  (Horatius)

Goldman
25
Greeks and Romans

• Pliny the elder (23-79 C.E.) commented that
  exposure turns Allium leaves black
• Concluded the plant attracts evil
• Romans believed snakebite transferred evil demons

• Connection made with treating evil
• Pompeiian ruins demonstrate painting of garlic on
  walls to deter evil

Goldman
26
Spread to Europe

• Romans brought Alliums to Celts, Germans
• Benedictine Monks helped to distribute Alliums
• Met with mixed results in England
• Much beloved in Spain
• Balkans enjoyed, Northern Europeans disliked
• Used as curative for plague
• In 1721, looters in Marseille used garlic to stay
  alive
• Vinaigre des quatres voleurs!

Goldman
27
Protection from Evil Spirits

• Many cultures still use Alliums as protection
  from demons
• Royalty in France annointed with garlic oil to
  repel evil spirits
• Farm animals and crops protected with Alliums
• Used to disinfect areas after death to prevent
  haunting by the human spirit
• Connection with vampire lore

Goldman
28
Goldman, World Vegetables
Alliums and Human Well-Being
Goldman
29
Functional Properties of Alliums

• Lipid Lowering
• Most thoroughly studied
• Placebo-controlled, dose-consistent
• 4-30 decrease in cholesterol and triglycerides
  over 3-8 week feeding period
• Highest reduction with fresh cloves
• Meta-analyses reveal 9-12 reduction with 0.5-1
  clove per day
• Equivalent reduction to bezafibrate in Germany
• Mechanism is increased triglyceride catabolism

Goldman
30
Functional Properties of Alliums

• Antithrombotic
• Reduction in platelet aggregation
• In vitro and in vivo studies suggest
  thiosulfinates
• Intake reduces thromboxane
• Thiosulfinate-derived oils also active in vitro
• Very striking effect of fibrinolysis with intake
• Increases in clotting time and flow rate
• Also thiosulfinate-determined
• Surgeons warning to patients

Goldman
31
Functional Properties of Alliums

• Blood Pressure
• Placebo-controlled studies
• Reductions of up to 7 over 6 months
• Meta-analysis useful in hypertension
• Not due to thiosulfinates
• May be associated with fructans and adenosine
• Mechanism may be stimulation of NO synthetase

Goldman
32
Functional Properties of Alliums

• Anticancer
• Significant epidemiological data from 6 countries
• 79 of studies show protective effect for GI
  cancer
• Similar percentage for green veg. and Brassicas
• Shangdong Province study and stomach cancer
• Thiosulfinates kill nitrate-reducing bacteria
• Iowa Womens Health Study colon cancer risk
• Thiosulfinates and other compounds responsible
• Sulfides studied extensively
• Benefits conferred even with cooked Alliums

Goldman
33
Flavonoids in Alliums

• Quercitin at high concentration in onion
  (280-480 mg/kg)
• Hertog et al., Lancet, 342, 1993
• Unique and abundant in red onion
• Fossen et al., Phytochem., 47, 1998
• Variability among accessions
• Patil et al., 1995
• Reduce carcinogen activity
• Leighton et al., 1992
• Inhibit tumorigenesis
• Leighton et al., 1992
• Function as antioxidants
• Arai et al., Lipids, 30, 1995

Quercitin and derivatives
Goldman
34
Functional Properties of Alliums

• Antioxidant
• Decreases in lipid peroxidation
• Increased free radical scavenging
• Increases in glutathione
• Thiosulfinates can be pro-oxidants in vitro
• Appear to be antioxidants in vivo
• Mostly due to thiosulfinates
• Other compounds active at very high doses

Goldman
35
Functional Properties of Alliums

• Antimicrobial
• Perhaps longest-known medicinal effect
• Effective against gram Positive and Gram negative
• More effective against human pathogenic bacteria
• No bacterial resistance reported to
  thiosulfinates
• Due to thiosulfinates and to oils
• Thiosulfinates react with SH groups of cysteine

Goldman
36
Functional Properties of Alliums

• Boosting Immune Function
• Immune system stimulation with Allium intake
• Increased lymphocytes, antibody production
• Antidiabetic
• Reduce blood glucose, increase insulin
• 4 week intake, reductions of 13
• Antiaging
• Studies with senescence-accelerated mice

Goldman
37
Toxicological / Negative Effects

• Anemia in animals
• Abdominal hemorrhage
• Internal bleeding in animals?
• Acid reflux and heartburn
• Erratic opening of stomach-esophagus valve
• Blockage of COX and LIPOX in Arachidonic acid
  met.
• LF, reduction by NADPH in nerve cell membrane
• Breath OSCs in blood to lungs

Goldman
38
Cardiovascular Health
Lipid lowering Blood pressure lowering Antioxidant
Antithrombotic or Antiplatelet
AHA, 2000
Goldman
39
Cardiovascular Health
Healthy coronary artery
Goldman
40
Plaque in coronary artery
Goldman
41
Platelets in coronary artery
Goldman
42
Platelet aggregate in coronary artery
...Heart attack and stroke
Goldman
43
Aggregating Platelets

• A major cause of heart attack and stroke
• Approximately 25 of US public has some form of
  cardiovascular disease
• Preventive measures aspirin
• Preventive measures diet?
• Preventive measures onion?

Goldman
44
Collaborative Effort

• Medicine John Folts, Cardiology
• Medicine Bradford Schwartz, Hematology
• Food Science Kirk Parkin, Chemistry
• Horticulture Mike Havey, Genetics
• Horticulture Irwin Goldman, Plant Biology

Goldman
45
Whole Blood Aggregometry
Electrical wires
Cuvette Blood
Saline Collagen
As platelets aggregate after collagen is added,
resistance is measured across wires
Goldman
46
CorrelationsPhenotypic / GeneticFrom F3
families derived from BYG x Ailsa Craig
crossTraits measured at 90 days postharvest
Goldman et al., 1996
Galmarini and Havey, 2000
Goldman
47
S FertilityGreenhouse-grown onion, 4 accessions
Orvis, 1997
Goldman
48
S FertilityField-grown onion, 4 accessions
Orvis, 1997
Goldman
49
Postharvest

• Bulb storage for long periods common
• Certain genotypes show OIAA increases
• All generally increase from 0-90 days

Debaene, 1999
Goldman
50
Life Cycle
Umbel Flower Stalk
Leaves Bulb
Goldman
51
Life Cycle

• Bulb, no inhibition
• Scape, no inhibition
• Umbel inhibits
• Sprout inhibits

Pro
Anti
0 10 12 14 16
18 20 Weeks
postharvest
Briggs, 2000
Goldman
52
Life Cycle
Umbel Flower Stalk
Leaves Bulb
ACSO cycling Lancaster et al., 1986
Goldman
53
You are what you eat -mom You are what you
dont excrete -modern medical science
Goldman
54
Cooking

• gt1 minute of boiling eliminates all in vitro OIAA
• Suggests volatility of OSCs, heat-killing of
  alliinase

Kopelberg and Goldman, 1995
Goldman
55
Fresh vs. Cooked Bunching Onion

• Chen et al. (2000) reduction in platelet
  aggregation with feeding of Welsh onion juice
• Rats fed 28 days
• Boiled Welsh onion juice had no effect, and in
  some cases promoted aggregation

Goldman
56
Pungency Paradox

• More pungent more efficacy
• More pungent more difficult to eat raw
• But cooking eliminates OIAA
• So the best onion is the weakest onion

Goldman
57
More Potent than Aspirin in Vitro
Impedance (ohms)
Briggs, 2000
Goldman
58
Folts in vivo Coronary Thrombosis Model
Canine
Measure blood flow through constricted coronary
artery
Goldman
59
Onion Inhibits Platelet Aggregation in vivo
A dosage of 1cc juice given intravenously
inhibited CFRs within 5 minutes
EKG -
Aortic BP -
CCA Flow -
X
X
1cc onion juice
Also inhibited intragastrically at 2 g/kg
Briggs, 2000
Goldman
60

• French Paradox
• 1991 piece on CBS 60 Minutes
• French eat up to 15 of calories from saturated
  fat, yet 40 lower incidence of heart disease
  than U.S.
• Has been explained by French wine consumption,
  among other things

Goldman
61
Spawned herbal supplements containing grape seed
/ grape skin extracts Reflects magic bullet
approach to health
Goldman
