Compound Eyes Of

1
Topic
Compound Eyes Of
2
Contents

• Receptors in Insects
• Photoreception in Insects
• Compound Eyes
• Ommatidia
• Components of Ommatidia
• Photochemistry of Insect vision
• Forms of Compound Eyes
• Significance of Compound Eyes
• Color vision in SomeOrders Of Insects
• Summary
• References

3
Receptors in Insects

• Mechanoreceptors
• Auditory receptors
• Stretch receptors
• Chemoreceptors
• Olfactory receptors
• Gustatory receptors
• Thermo receptors
• Photo receptors

4
Vision is the perception of light.Roles of
vision in insects

• Photoreception in Insects

5
Photoreception in Insects

• Photoreceptors1. Ocelli. 2. Stemmata3.
  Compound eyes

6
Dorsal ocelli

• In larvae of hemimetabolous insects and in nearly
  all adults.
• Poor perception of form.
• Active in orientation to a light source.

Ref.02
7
Stemmata

• In larvae of holometabolous insects
• Do not produce clear images
• Most caterpillars can discriminate some shapes
  and they can orientate themselves with respect to
  boundaries.

8
Compound Eyes

• Most adult insects have a single pair of compound
  eyes.
• Reduced or absent in parasitic forms, many soil
  insects, and in some species that live in very
  dark places.

9
Compound Eyes and ocelli
10
Facet
Hexagonal Components of Compound Eye.
11
Ommatidia

• Basic unit of compound eyes
• Vary in size and number.
• Honey bee has 4900 Ommatidia in Queen, 6300 in
  workers and 13000 in donors.
• Pomera punctatissima have only one ommatidium
  in each eye.
• The sizes of Ommatidia vary from about
• 5 to 40 microns in diameter .

Ref.02
12
Components of Ommatidia

• Optical parts
• 1. Corneal lens
• 2. Crystalline cone
• Sensory parts
• 1. Retinula cells
• 2. Rhabdom
• A nerve axon projects
• from each retinula cell.
• Optic nerve
• (YADAV. M)

Ref.01
13
Compound Eyes and Brain
14
Photochemistry of Insect vision

• Photons are caught on the rhabdome by retinal.
• Retinal is connected to opsin, forming
  rhodopsin.
• On absorption of photon, retinal changes its form
  from bent to straight.
• When retinal changes its form, it separates from
  the rhodopsin and the opsin triggers a nerve
  cell.
• The nerve cells conduct the signal to the brain.

15
Forms of Compound Eyes

• Apposition eyes
• 2. Superposition eyes.

Ref.01
16
(No Transcript)
17
Significance of Compound Eyes

• Flicker effect
• The compound eye is excellent at detecting
  motion.
• As an object moves, ommatidia are turned on
  and off.

18
Significance of Compound Eyes

• 2. Distance Perception
• Most insects must be able to judge distance.
• As in prey catching insects, in Grass hoppers
  jumping, and when they are landing.
• Simultaneous stimulation of ommatidia.

Ref.01
19
Colors
20
Significance of Compound Eyes

• 3. Color vision
• Some insects are able to distinguish colors
• Most flower visiting insects exhibit
  preferences for blue and yellow.
• Important in feeding and in court ship behavior

21
3. Color vision

• Bichromatic Insects.
• One pigment absorbs green and yellow light (550
  nm) the other absorbs blue and ultraviolet light
  (lt480 nm).
• Trichromatic Insects.
• Absorption maxima at 360 nm (UV), 440 nm
  (blue-violet), and 588 nm (yellow)

22
Human Vision Vs. Insect Sight

• Colors visible to insects is higher in frequency
  (lower in wave length)
• Violet light is the highest frequency of color
  humans can detect, but many insects can see a
  higher frequency of light invisible to us,
  ultraviolet light.

23
Ultraviolet vision
24
Color vision in SomeOrders Of Insects
25
1. Vision in Order Hymenoptera

• Eastern honey bee (Apis cerana).
• Family Apidae
• The bees are red-blind.
• orange, yellow, and green are the same color
  yellow.
• Sensitive to UV light.
• They see blue colors best.
• Sense of polarization of visible light in the sky.

Ref.05
26
2. Vision in Order Odonata

• Dragonfly(C. aenea) or Downy emerald
• Family Corduliidae
• Compound eyes with wide-angle vision
• Their eyes do not move.
• 30,000 eye ommatidia
• Orange to ultraviolet (UV) light.
• Able to estimate distance based on the
• distance between their eyes.

Ref.06
27
3. Vision in Order Diptera

• House flies (Musca domestica)
• Family Muscidae
• The vision of the housefly is blurred
• Compound apposition eyes
• Can sense rapid motion approaching 200
• cycles per second.

Ref.06
28
Vision in Mosquito

• Mosquito (Culiseta longiareolata)
• Family Culicidae
• Mosquitoes are attracted to black and to dark
  colors. (Howlett 1910)
• Prefer the corners of a three-dimensional target.
  (Brown Bennett)

Ref.07
29
4. Vision in Order Coleoptera

• Beetle (Tetraopes tetrophthalmus)
• Family Cerambycidae
• Have infrared detection systems
• for night vision, fire detection, and other
  functions as to sense forest fires.
• Beetles have refraction superposition eyes

Ref.06
30
5. Vision in Order Blattaria

• American cockroach (Periplaneta americana),
• Family Blattidae
• 2000 individual lenses
• Has receptors for UV light and green light.

Ref.08
31
6. Vision in Order Homoptera AphidsSuper
family Aphidoidea Contains green, blue, and
ultraviolet photoreceptors
Ref.09
32
7. Vision in Order Lepidoptera

• Butterfly(Papilio rutulus)
• Family Papilionidae
• Can See simultaneously in every direction.
• Trichromatic vision
• It can distinguish night from the day
• Can perceive colors in a high frequency
• (from 310 nm to 700)

Ref.10
33
Vision in Order Lepidoptera

• Gipsy Moth (Lymantria dispar).
• Family Lymantriidae
• Can see in the back of their heads.
• Neural summation
• Have three types blue, green, and ultraviolet.
• Ultraviolet light reflection.

Ref.12
34
Summary

• Compound Eyes of Insects

35
References

1. YADAV. M, "Physiology of Insects," Discovery
   Publishing House New Delhi-110002, pp. 322-345
2. http//entomology.unl.edu/ent801/ent801home.html
3. http//users.rcn.com/jkimball.ma.ultranet/BiologyP
   ages/C/CompoundEye.html
4. www.cals.ncsu.edu/course/ent425/tutorial/colorvisi
   on.html
5. http//www.sewanee.edu/Chem/ChemArt/Detail_Pages/
   ColorProjects_2003/Crone
6. www.eyedesignbook.com/index.html
7. http//www.ent.iastate.edu/dept/research/vandyk/ho
   stseek.htm

36
References

• 8.http//www.sciencemag.org/cgi/content/abstract/1
  71/3977/1254
• 9.http//www.ncbi.nlm.nih.gov/pmc/articles/PMC1945
  073/figure/pbio-0050187-g003
• 10. http//www.butterflyzone.org/butterfly-article
  s/butterfly-uv-vision.shtml
• 11.http//indianapublicmedia.org/amomentofscience/
  insect-color-vision
• 12.http//www.animalcorner.co.uk/insects/moths/mot
  h.html
