Title: Magnetorheological (MR) Brake System


1
Magnetorheological (MR) Brake System
  • Dr. Khisbullah Hudha

2
Problems with Conventional Hydraulic Brake System
  • High energy consumptions
  • Bulky
  • Problems with leakage in hydraulic line
  • Brake noise due to metal-with-metal friction
  • Brake pad need to be replaced periodically
  • Response delay due to pressure build up
  • Require auxiliary components such as hydraulic
    pump, fluid transfer, brake valve fluid
    researvoir)

3
2 Types of Hydraulic Brake System
4
Why Magnetorheological Brake
  • Low power requirement (only several ampere)
  • Simple design construction
  • Hydraulic free no hydraulic line need less
    space requirement
  • No metal-with-metal friction
  • No brake pad needed
  • Easy to control (potential to be used for
    brake-by-wire (BBW) system)
  • Fast response (0.02 second)

5
Components of MR Fluid
  • Iron Particle micron or nano size
  • Carrier fluids synthetic oil, silicone or water
  • Binder Material (to prevent the iron particles
    from settling down) special grease

6
Behavior of MR Fluid
7
MR Fluid
  • MR fluids are created by adding micron-sized iron
    particles to an appropriate carrier fluid such as
    oil, water or silicon.
  • Their rheological behavior is almost the same as
    that of the carrier when no external magnetic
    field is present.
  • When exposed to a magnetic field, the iron
    particles acquire a dipole moment aligned with
    the applied magnetic field to form linear chains
    parallel to the field

8
Basic design of MR Brake
9
Prototype of MR Brake developed in Autotronics
Lab - UTeM
10
(No Transcript)
11
MR Brake Test Rig available in Autotronics Lab -
UTeM
12
System Modeling
13
Equations of Motion
  • Case 1 Belt tensioner on (Speed Control)
  • - Torque of the motor will be transferred to
  • the driven shaft via belt-pulley system

Where Tm torque of the motor Ts torque of
the shaft h efficiency of belt-pulley system
(96 - 98)
14
Where b viscous damping of the bearing Tmr
brake torque J load moment of inertia
15
Torque of MR Brake (Tmr)
  • MR Fluid behavior
  • MR Brake Torque Calculation

16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
Speed control
20
Case 2 Belt Tensioner off (torque control or
stopping time control)
Belt off Ts 0
21
Equations of Motion
Omega dot negatif deceleration
22
(No Transcript)
23
Motor Torque (belt tensioner off at t 4 sec)
24
Current applied starting from t4sec)
25
Stopping time
