Title: NEUROMUSCULAR JUNCTION


1
NEUROMUSCULAR JUNCTION
  • Dr. Sidra Hamid
  • Physiology Department

2
CASE 4 35 year old woman with progressive muscle
weakness
  • A 35 years old woman resident of Rawalpindi
    presented in foundation OPD with progressive
    weakness for the last 2 months. She has also
    noticed intermittent drooping of both of her eye
    lids, and progressive facial muscles weakness
    while speaking. She also complaints of weakness
    and tiredness while climbing the stairs of her
    office has difficulty while typing a lengthy
    official replies to their clients.

3
  • Her general physical examination revealed a pulse
    of 82/min. B.P 120/80 mm of Hg. Temp. 98 F and
    Resp. rate 16/min. with drooping of both eyelids
    ( Ptosis ive). Her laboratory investigations
    revealed positive anti-choline receptor
    antibodies. Rest of laboratory workup was
    unremarkable.

4
LEARNING OBJECTIVES
Describe the physiological anatomy of
Neuromuscular Junction (NMJ). Terminal
button. Motor end plate. Motor End Plate
potential and how action potential is generated
in muscle. Synaptic trough/ gutter/
cleft. Chemicals/ drugs/ diseases effecting
neuromuscular transmission
5
  • ANIMATION

6
DEFINITION
  • The place where the motor neuron makes a
    functional contact with the skeletal muscle cell
    is called NEUROMUSCULAR JUNCTION or MYONEURAL
    JUNCTION

7
Neuromuscular Junction
  • Neuromuscular Junction
  • A neuromuscular junction exists between a
    motor neuron and a skeletal muscle.
  • - Synapse
  • A junction between two neurons

8
(No Transcript)
9
(No Transcript)
10
(No Transcript)
11
(No Transcript)
12
(No Transcript)
13
(No Transcript)
14
(No Transcript)
15
INNERVATION OF SKELETAL MUSCLE FIBERS
  • Large, myelinated nerve fibers
  • Originate from large motor neurons in the
    anterior horns of the spinal cord
  • Each nerve fiber, branches and stimulates from
    three to several hundred skeletal muscle fibers
  • The action potential initiated in the muscle
    fiber by the nerve signal travels in both
    directions toward the muscle fiber ends

16
(No Transcript)
17
(No Transcript)
18
How myelinated fiber becomes unmyelinated
19
MOTOR END PLATE
  • The nerve fiber forms a complex of branching
    nerve terminals that invaginate into the surface
    of the muscle fiber but lie outside the muscle
    fiber plasma membrane
  • Entire structure - motor endplate.
  • Covered by one or more Schwann cells that
    insulate it from the surrounding fluids.

20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23
AXON TERMINAL
  • SYNAPTIC VESICLES
  • Size 40 nanometers
  • Formed by the Golgi apparatus in the cell body
    of the motor neuron in the spinal cord.
  • Transported by axoplasm to the neuromuscular
    junction at the tips of the peripheral nerve
    fibers.
  • About 300,000 of these small vesicles collect in
    the nerve terminals of a single skeletal muscle
    end plate.

24
(No Transcript)
25
  • MITOCHONDRIA
  • Numerous
  • Supply ATP
  • Energy source for synthesis of excitatory
    neurotransmitter, acetylcholine
  • DENSE BARS
  • Present on the inside surface of neural
  • membrane

26
(No Transcript)
27
  • VOL TAGE GATED CALCIUM CHANNELS
  • Protein particles that penetrate the neural
    membrane on each side 0f dense bar
  • When an action potential spreads over the
    terminal, these channels open and calcium ions
    diffuse to the interior of the nerve terminal.
  • The calcium ions, exert an attractive influence
    on the acetylcholine vesicles, drawing them to
    the neural membrane adjacent to the dense bars.

28
  • The vesicles then fuse with the neural membrane
    and empty their acetylcholine into the synaptic
    space by the process of exocytosis
  • Calcium acts as an effective stimulus for causing
    acetylcholine release from the vesicles
  • Acetylcholine is then emptied through the neural
    membrane adjacent to the dense bars and binds
    with acetylcholine receptors in the muscle fiber
    membrane

29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
MUSCLE FIBER MEMBRANE
  • SYNAPTIC TROUGH
  • The muscle fiber membrane where it is invaginated
    by a nerve terminal and a depression is formed
  • SYNAPTIC CLEFT
  • The space between the nerve terminal and the
    fiber membrane is called the synaptic space or
    synaptic cleft

33
(No Transcript)
34
  • SUBNEURAL CLEFT
  • Numerous smaller folds of the muscle membrane at
    the bottom of the gutter
  • Greatly increase the surface area.
  • ACETYLCHOLINE RECEPTORS
  • Acetylcholine-gated ion channels
  • Located almost entirely near the mouths of the
    sub neural clefts lying immediately below the
    dense bar areas

35
(No Transcript)
36
ACETYLCHOLINE RECEPTORS
  • Acetylcholine-gated ion channels
  • Molecular weight -275,000

37
(No Transcript)
38
  • SUBUNITS
  • Two alpha, one each of beta, delta, and gamma
  • Penetrate all the way through the membrane
  • Lie side by side in a circle- form a tubular
    channel
  • Two acetylcholine molecules attach to the two
    alpha subunits, opens the channel
  • RESTING STATE
  • 2 Ach molecules not attached to the alpha subunit
  • Channel remains constricted

39
(No Transcript)
40
(No Transcript)
41
(No Transcript)
42
  • OPENED Ach CHANNEL
  • 2 Ach molecules attached to the alpha subunit of
    receptor
  • Diameter- 0.65 nanometer
  • Allows important positive ionsSODIUM, potassium,
    and calcium to move easily through the opening.
  • Disallows negative ions, such as chloride to
    pass through because of strong negative charges
    in the mouth of the channel that repel these
    negative ions.

43
(No Transcript)
44
  • SODIUM IONS
  • Far more sodium ions flow through the
    acetylcholine channels to the inside than any
    other ions
  • The very negative potential on the inside of the
    muscle membrane, 80 to 90 mili volts, pulls the
    positively charged sodium ions to the inside of
    the fiber
  • Simultaneously prevents efflux of the positively
    charged potassium ions when they attempt to pass
    outward

45
  • END PLATE POTENTIAL
  • Opening the acetylcholine-gated channels allows
    large numbers of sodium ions to pour to the
    inside of the fiber
  • Sodium ions carry with them large numbers of
    positive charges
  • Creates a local positive potential change inside
    the muscle fiber membrane, called the end plate
    potential.
  • End plate potential initiates an action potential
    that spreads along the muscle membrane
  • Causes muscle contraction

46
(No Transcript)
47
Events of Neuromuscular Junction
  • Propagation of an action potential to a terminal
    button of motor neuron.
  • Opening of voltage-gated Ca2 channels.
  • Entry of Calcium into the terminal button.
  • Release of acetylcholine (by exocytosis).
  • Diffusion of Ach across the space.
  • Binding of Ach to a receptor on motor end plate.

48
Examples of Chemical Agents and Diseases that
Affect the Neuromuscular Junction
  • Mechanism Chemical Agent or Disease
  • Alters Release of Acetylcholine
  • Cases explosive release of acetylcholine
    Black widow spider venom
  • Blocks release of acetylcholine
    Clostridium botulinum toxin
  • Block acetylcholine Receptor
  • Bind reversibly Curare
  • Auto antibodies inactivate acetylcholine
    Myasthenia gravis
  • receptors
  • Prevents inactivation of acetylcholine
  • Irreversibly inhibits acetylcholinesterase
    Organophosphates
  • Temporary inhibits acetylcholinesterase
    Neostigmine

49
(No Transcript)
50
(No Transcript)
51
THANKS
