Title: Behavioral Robots with various Controls Generalized Braitenberg Vehicles


1
Behavioral Robots with various
ControlsGeneralized Braitenberg Vehicles
2
each sensor connected to the motor on opposite
side
both sensors connected to both the motors.
each sensor is connected to the motor on the same
side,
The simplest Breitenberg Vehicles with analog
control
3
Fear and Aggression
Braitenberg Vehicles represent emotions
4
Signal Inhibiting
  • Inhibiting signals from the sensors cause light
    following.

Sign minus represents inhibiting
5
Signal Inhibiting
  • Inhibiting signals from swapped sensors causes
    light avoidance

6
Signals and logic in Braitenberg Vehicles
  • Signals can be
  • Analog
  • Binary
  • Multiple-valued
  • Fuzzy
  • Quantum

Sensing can be done in quantum world (Hilbert
Space) or in standard macro-world
7
Our Vehicles have various types of drives
8
Choice of Drives
9
Braitenberg Vehicles Sensory and Effectors
Characteristics
  • Our understanding of Braitenberg Vehicles is much
    more general than in literature
  • Sensing,
  • Controls (functions, automata, distributed
    automata),
  • Effectors (Drives and their Control, walking etc)

10
Emotion as synthesized behavior
Serchuk et al discuss emotion as mapping from
internal state to observable output behavior. We
want to design these mappings well, so that they
wil be similar to humans
Physical variables positions, speeds,
accelerations, words,
Emotional state state of all emotion variables
11
Emotion as emergent, evolvable behavior
  • Here emotion is an emergent behavior that
    arises from sensors, drives, effectors and logic.
  • This may look like human, animal behavior but
    also as an entirely new other world behavior,
    behavior at it may be.

Degrees of freedom
Sensors, vision and fusion features and
patterns
Evolved emotional behavior of robot
Drives and effectors
Main input-output mapping (perception, internal
state, behavior)
Precise motion generation (behavior)
12
Part II. Brief Review of Quantum Circuits and
Automata
If S10gt then M2S2
If S11gt then M2U(S2)
  • A general-purpose controlled quantum gate.
  • U is arbitrary one-qubit quantum operator.

13
Analysis of Quantum Circuits and Automata
  • Every quantum circuit is a serial or parallel
    composition of lower level circuits.
  • For serial connection use matrix multiplication
    of unitary matrices
  • For parallel connection use Kronecker product
    of unitary matrices

Kronecker (tensor) Product of matrices
14
Elementary Quantum Gates
  • Hadamard gate notation and its Unitary matrix.

Feynman gate notation and its unitary matrix.
Observe that this is a permutative matrix.
We will analyze this entanglement circuits - EPR
The circuit to produce entanglement that can be
used as a controller of a Braitenberg Quantum
Robot. By making a feedback from P to B a
Braitenberg Quantum Automaton Robot is created.
15
Analysis of Quantum Braitenberg Vehicle
  • Calculation of parallel connection of gates H and
    wire

16
Analysis of Quantum Braitenberg Vehicle
  • Calculation of Kronecker Product of Hadamard and
    wire using their unitary matrices

17
Analysis of Quantum Braitenberg Vehicle
10
inputs
01
11
00
00
01
outputs
10
11
Unitary matrix of Feynman gate in the
entanglement circuit.
18
Analysis of Quantum Braitenberg Vehicle
  • Final calculation of the unitary matrix of the
    entanglement circuit by multiplying matrices of
    Feynman gate and a parallel connection of H and
    wire in reverse order.

19
Analysis of Quantum Braitenberg Vehicle in dark
room
1 0 0 0
1 0 0 1


1/?2 00gt 1/?2 11gt
  • Calculation of entangled state with no light on
    both sensors

0 interpreted as no action on motor
Conclusion in dark room quantum robot can go
straight forward or stop, each step after
measurement
20
Analysis of Quantum Braitenberg Vehicle in fully
lighted room
0 0 0 1
0 1 -1 0


1/?2 01gt - 1/?2 10gt
  • Calculation of entangled state with light on both
    sensors

0 interpreted as no action on motor
Conclusion in fully lightened room quantum robot
turn right or left, each step after measurement
21
Quantum Automata Models
Quantum signal
Quantum signal
Quantum logic
Benioff s Automaton and robot
Quantum memory
  • Quantum Automaton that lives in Hilbert Space.

In case of a robot, such robot can live only on
quantum mechanics level of world, but because of
entanglement it interacts with whole universe.
22
Quantum Automata Models
Yellow signals are quantum
Blue signals are standard
Quantum logic
initialization
measurement
initialization
measurement
standard memory
  • Quantum Automaton with standard memory.

This automaton lives in normal macro world.
Several other types of automata/robots can be
proposed.
23
Conclusion on Quantum Vehicles
  • Quantum logic includes binary, multiple-valued
    and fuzzy logic
  • Quantum Automaton includes quantum combinational
    function, probabilistic and deterministic
    automaton
  • Quantum Braitenberg Vehicle includes (for many
    reasons) the standard Braitenberg Vehicle.

24
Part III. Generalized and Quantum Braitenberg
Robots
sensors
actuators
Combinational Block
Generalized Braitenberg Robot
ENVIRONMENT
25
Braitenberg Automaton Robot
sensors
actuators
Combinational Block
memory
ENVIRONMENT
26
Generalized Braitenberg Robot and Braitenberg
Automaton Robot may exist in both quantum and
standard environment.
27
A Hybrid Fuzzy-Quantum system of Automata in
Generalized Braitenberg Robot.
28
Quantum Robot Motion (Behavior) generation
Quantum sensing
Quantum Counter-like automaton
Quantum ROM
Standard sensing
Rough positions in Hilbert Space
M
M
M
Each behavior is a sequence of states
effectors
Precise deterministic positions probabilistically
generated
29
Complete Quantum Robot Architecture
Quantum sensing
Quantum brain
Quantum motion control
Standard sensing
effectors
Quantum associative memory
Every realization of quantum motion is slightly
different because of measurements
30
Quantum Braitenberg Vehicles Simulator
31
01
00
(o1)1/2 , (10) 1/2
(oo)1/2 , (11) 1/2
s1
10
11
(oo)1/2 , (11) 1/2
(o1)1/2 , (10) 1/2
Graphical description of EPR reactive Quantum
Braitenberg Vehicle ( robot )
32
C
Problem 1 Find the unitary matrix and the graph
for this Quantum Braitenberg Vehicle Describe in
English its behavior.
M1
S1
S2
M2
33
Problem 2 Find the unitary matrix and the graph
for this Quantum Braitenberg Vehicle Describe in
English its behavior.
M1
0
M2
0
garbage
S1
S2
garbage
34
Problem 3 Find the unitary matrix and the graph
for this Quantum Braitenberg Vehicle Describe in
English its behavior.
C1
garbage
C2
garbage
M1
S1
H
S2
M2
35
Environment
robot
Lego camera
Light sensors
Lego motors
Touch and other sensors
Feature value creation and normalization
Quantum Combinational Block
Motion generation
measurement
PROJECT 1. Quantum Automaton with standard memory
in a setup where the behavior of walking Lego
robot is observed by Lego Camera
Motion sequence completed
Flip-flops
clock
36
The entire system and subsystems for Project 1
  • Please observe two feedback loops.
  • Small processor (microcontroller on the robot)
    processes sensor information
  • PC processes images
  • Camera looks at the robot

37
Environment
robot
ceilingcamera
Lego camera
PROJECT 1. Components of the entire system. _at_
Lego motors
Light sensors
Touch and other sensors
Micro - controller
Radio transmitter -receiver
Radio transmitter -receiver
Laptop PC
Quantum controller
Execution of stored motions
Transmission of motions and sensor readings
Selection and generation of motions
38
The entire system and subsystems for Project 1
  • Please observe two feedback loops.
  • Small processor (microcontroller on the robot)
    processes sensor information
  • PC processes images
  • Human looks at the robot
  • Camera looks at the human

39
Environment
robot
Human observes a robot
Lego camera
Light sensors
motors
Robot mimicks a human
sensors
Micro - controller
Radio transmitter -receiver
Radio transmitter -receiver
Laptop PC
Quantum controller
Execution of stored motions
Transmission of motions and sensor readings
Selection and generation of motions
40
Two Main Simple Quantum Behavioral Architectures
  • (a) Reactive architecture (mapping with no
    memory)
  • (b) Behavioral architecture with the memory to
    represent emotions, moods, knowledge and stored
    processing information.

41
sensors
Quantum Combinational Block
actuators
Measurements
(a)
ENVIRONMENT
sensors
Quantum Combinational Block
actuators
Measurements
Standard memory
(b)
ENVIRONMENT
42
Combinational logic with probabilistic entangled
results
Calculations in Hilbert Space
measurements
M1
m1
S1
H
M2
m1
S2
C
Mood
md
memory
Behavioral Quantum Robot with Memory of moods
43
S1 S2 C M1 M2 Mood
0 0 0 0 0 0 nice
0 0 1
0 1 0 0 1 0
0 1 1
1 0 0 1 1 1 angry
1 0 1
1 1 0 1 0 1
1 1 1
(000)1/2 or (111) 1/2
Problem 4. Complete this table for the Quantum
Robot with Memory from the previous slide.
44
Hybrid Architectures
  • Modern Behavioral robots are hybrid
  • They combine various components (agents)
  • Reactive
  • With memory
  • Fuzzy
  • Neural
  • Multi-valued
  • Learning
  • Knowledge-based
  • Quantum
  • ..

45
Fuzzy Combinational Block
actuators
Fuzzy Memory
sensors
F/Q
Quantum Combinational Block
Q/F
Quantum memory
Hybrid Behavioral Robot with Fuzzy and Quantum
Subsystems
ENVIRONMENT
46
You can find many good Lego designs on Internet
  • New Lego Kits

47
Mindstorms NXT
  • It has a 32-bit processor,
  • proper servo motors,
  • new sensors (including color vision and hearing)
  • bluetooth connectivity
  • it can be controlled by a cellphone

48
(No Transcript)
49
  • powered by LabVIEW from National Instruments.
    when I got the Space Monorail, I thought it was
    the absolute height of coolness that Lego could
    hope to attain.  Now Lego kits have Bluetooth and
    their own programming language, LegOS.

50
  • The inclusion of Bluetooth technology also
    extends possibilities for controlling robots
    remotely, for example, from a mobile phone or
    PDA.

51
  • Projects with new Lego

52
  • when I got the Space Monorail, I thought it was
    the absolute height of coolness that Lego could
    hope to attain.  Now Lego kits have Bluetooth and
    their own programming language, LegOS.

53
(No Transcript)
54
(No Transcript)
55
(No Transcript)
56
(No Transcript)
57
(No Transcript)
58
  • Lego Heads

59
(No Transcript)
60
(No Transcript)
61
(No Transcript)
62
(No Transcript)
63
(No Transcript)
64
(No Transcript)
65
(No Transcript)
66
  • Lego Bipeds

67
(No Transcript)
68
(No Transcript)
69
(No Transcript)
70
(No Transcript)
71
(No Transcript)
72
Lego robot biped google
73
  • Lego Hands

74
(No Transcript)
75
(No Transcript)
76
(No Transcript)
77
(No Transcript)
78
(No Transcript)
79
Homework 2
  • Design a simulator of two Braitenberg Vehicle in
    an environment
  • The environment may be an arbitrary maze, sports
    field or battlefield. It can be a plan of a
    house.
  • The robots can turn right 90 degree, left 90
    degree and rotate. They can move one step forward
    or one step backwards. These are the all basic
    moves from which other moves are composed.

80
Homework 2 cont
  • Each vehicle has a minimum of two sensors. You
    design and locate the servos. They can see no
    more than 3 cells from the robot cell in any
    direction.
  • Each robot may have weapons that shoot one cell
    in any direction.
  • There may be a ball or other item for play and
    interaction.
  • The vehicles can have some friendly or unfriendly
    relation, to be defined by you.
  • The environment (space) for robots is a square
    with external walls North, East, West and South.
    If one robot escapes to one of these external
    walls then the robot is safe from shooting but he
    cannot shoot.
  • The space is a grid of cells. The walls are
    marked by number X. The empty cells are empty.
    All other symbols may be used to denote the
    position, orientation and internal state of each
    robot.
  • Your program should either make printouts or
    display the snapshots of robot behavior with
    written explanation what happens (possibly what
    are their internal states), collisions,
    intentions, etc.

81
Example of space encoding
North

X
X
X gt
X
X
X X X X X X X X
X X
X X X
X X
X
X X
West
East
South
82
Examples of programming of simple standard
Braitenberg Vehicles in Java
We used Basic, LISP, Pascal, C, Robot C, etc
83
MotorTest.java
  • import josx.platform.rcx.
  • class MotorTest
  • static final int STOP 0
  • static final int RUN 1
  • static final int FLOAT 2
  • static int mode STOP
  • static int power 0
  • public static void main(String args)
  • setupButtonListeners()
  • while (true)
  • if (mode RUN)
  • Motor.A.setPower( power ) // power in
    range 0, 7. incremented with each press of View
    button.
  • Motor.A.forward()

84
LightTest.java
import josx.platform.rcx. class LightTest
implements SensorConstants public static void
main(String args) throws InterruptedException
Sensor.S1.setTypeAndMode (SENSOR_TYPE_LIGHT,
SENSOR_MODE_PCT) Sensor.S1.activate() while
(true) int lightReading if
(Button.VIEW.isPressed()) lightReading
Sensor.S1.readRawValue() else
lightReading Sensor.S1.readValue()
LCD.showNumber( lightReading )
85
Complete Example Aggressive.java
  • import josx.platform.rcx.
  • class aggressive implements SensorConstants
  • public static void main(String args)
  • int minBrightness 100
  • final int gain 12
  • Sensor.S1.setTypeAndMode (SENSOR_TYPE_LIGHT,
    SENSOR_MODE_PCT)
  • Sensor.S1.activate()
  • Sensor.S3.setTypeAndMode (SENSOR_TYPE_LIGHT,
    SENSOR_MODE_PCT)
  • Sensor.S3.activate()
  • for (int i 0 i lt 100 i)
  • if (Sensor.S1.readValue() lt minBrightness)
  • minBrightness Sensor.S1.readValue()
  • else if (Sensor.S3.readValue() lt
    minBrightness)
  • minBrightness Sensor.S3.readValue()

86
Aggressive.java (continued)
protected static void setMotorSpeed(Motor m, int
motorSpeed) if (motorSpeed lt 1)
m.flt() // important LCD.showNumber(-1
) else if (motorSpeed gt 7)
motorSpeed 7 m.forward() m.se
tPower(motorSpeed) LCD.showNumber(motorSpeed)

87
Observations
  • Closed loop control lessens importance of
    mechanical imperfections (e.g. pulley slip).
  • The map is not the territory.
  • Make your ownrobots and observations!

88
Change the vehicle behavior?
// Sensor output goes directly to wheel on same
side void doSenseLogic()
setASpeed(sA.getSense()) setBSpeed(sB.getSens
e()) // Sensor output crossed to wheel on
opposite side / void doSenseLogic()
setASpeed(sB.getSense()) setBSpeed(sA.getSense
()) / // Each sensor goes to wheel on
same side with an inhibitory connection / void
doSenseLogic() setASpeed(sA.getInverseSense()
) setBSpeed(sB.getInverseSense()) /
// Each sensor goes to wheel on opposite side
with an inhibitory connection / void
doSenseLogic() setASpeed(sB.getInverseSense()
) setBSpeed(sA.getInverseSense()) /
// Sensors are hooked up to opposite motors, with
threshhold sensing. / void doSenseLogic()
setASpeed(sB.getNonlinearSense())
setBSpeed(sA.getNonlinearSense()) /
  • Make a subclass of vehicle and cut-and-paste the
    version of doSenseLogic() that you want
  • Consult Lecture slides for overview of various
    behaviors
Write a Comment
User Comments (0)
About PowerShow.com
