Well Control Expert Team

1
ADCO DRILLING DIVISION

• Well Control Expert Team
• Case Study

By S.A.Turki ADCO Drilling Division September
2003
2
CONTENTS

• Summary
• WCET Objectives
• List of Training Providers
• Typical Course Content
• Course Contents Comparison
• Case Study
• Conclusion

3
SUMMARY

• In order to provide extra support in non
  conventional well control situations, ADCO has
  decided to form Well Control Expert Team or WCET
• Main criteria to formulate such team is to
• Select drilling personnel with good experience in
  drilling engineering
• Understand well control methods

4
SUMMARY

• To this end, Drilling Division has requested an
  advanced well control course to enhance the
  competency of the team
• Several proposals were received from various
  training providers available in the market
• Two courses were run in January and March 2003
  and will be discussed in the following slides

5
WCET OBJECTIVES

• The main objectives of the Well Control Expert
  Team are as follows

• Ensure that the team is familiar with all
  available well control methods and scenarios
• Ability to intervene whenever needed for well
  control incidents
• Ability to evaluate and analyze any well control
  situation
• Identify the potential problems along with the
  most effective way to bring the well under
  control
• Demonstrate learning curve and lesson learned

6
LIST OF TRAINING PROVIDERS

• Some of the available training providers are

• Shell-Holland
• Randy Smith International
• Aberdeen Drilling School
• Wild Well Control
• Boots Coots
• ENSPM France
• GSM

• Cudd Well Control
• Well Control School
• John Wright Co
• Moduspec
• Fires Safety Eng. Oman
• G.T.S.C
• PetroSkills-OGCI

7
TYPICAL COURSE CONTENTS

• The course is divided into theoretical and
  practical sessions and include the following
  contents

• Reservoir consideration
• Kick detection prediction techniques
• Well control methods
• Well control equipment
• Drilling fluid behaviour (water, oil and air)

• H2S well control operations
• Relief Wells
• Underground blowouts
• Off bottom well control
• Volumetric, dynamic momentum kill techniques

8
TYPICAL COURSE CONTENTS

• Continued

• Consideration for
• HPHT
• Underbalanced drilling
• Horizontal wells
• Multi-lateral wells
• Deep water drilling
• Slime hole drilling

• Stripping snubbing techniques
• Hands-on Simulator
• Well cap test
• Case studies

9
COURSE CONTENTS COMPARISON
Course Content Company A Company B Company C Company D Company E Company F
Reservoir Consideration ? ? ?
Kick Detection Techniques ? ? ? ? ? ?
Well Control Methods ? ? ? ? ?
Well Control Equipment ? ? ? ? ? ?
Drilling Fluids Behavior ? ? ? ? ?
HPHT Wells Consideration ? ? ?
Horizontal Wells Consideration ? ? ?
Underbalance Drilling Consideration ? ? ?
Multi-Lateral drilling Consideration
Slim-Hole Drilling Consideration ? ? ? ?
10
COURSE CONTENTS COMPARISON
Cont'd
Course Content Company A Company B Company C Company D Company E Company F
Deep Water Drilling ? ? ? ? ? ?
H2S Well control Operations ?
Relief Wells ? ? ?
Underground Blowouts ? ? ? ?
Volumetric, Dynamic Momentum Techniques ? ? ? ?
Stripping Snubbing Techniques ? ? ? ? ?
Off-Bottom Well Control ? ?
Hands-on Simulator ? ? ?
Case Studies ? ?
Well Cap Test ?
11
CASE STUDY

• Introduction

• Due to several well control incidents, that
  occurred in ADCOs fields. Well Control Expert
  Team concept was suggested
• The team is responsible for the intervention and
  control of the said wells whenever an incident
  occurs
• The team should have enough drilling experience
  to conduct the necessary analysis
• The analysis requires more advance courses in
  well control so that all issues are covered

12
CASE STUDY

• Introduction (contd)

• Advanced Well Control Course proved to be the
  best solution
• He decision was taken t contact all available
  training providers. Proposals were received from
  the following
• Aberdeen Drilling School (via BP)
• Randy Smith
• GSM
• Wild well Control
• Boots and Coots

13
CASE STUDY

• Introduction (contd)

• ENSPM PetroSkills were not directly contacted
  but the information was obtained via their course
  catalogue (by the author of this presentation)
• Members of ADCO Drilling Division have visited
  Shell Training Center in the Hague
• One of the observations noted that Shell provides
  an Advanced Well Control Course. The practical
  application is contacted using a real life well
  in the North West of Holland

14
CASE STUDY

• Introduction (contd)

• Based on this, a request was made to Shell to run
  the said course in their Training Center
• To run the said course, Shell has requested that
  a minimum of 8 candidates has to attend. This
  request was difficult to fulfill at that time due
  to the individuals work pressure
• Since there was no other training provider than
  Shell who uses real life well. ADCO has decided
  to run the anyway and COMPANY B was the candidate

15
CASE STUDY

• Course Overview
• 5-Day duration consisting of the following

• Well control basics
• Kick prevention, detection prediction
  techniques
• Pressure limits on casing kick tolerance
• Well control methods
• Handling gas in the wellbore

• Recognizing problems during well control
• Student hands-on (simulator practice)
• Stripping
• Well intervention
• Well control equipment

16
CASE STUDY

• Course Overview
• Contd

• Underbalanced drilling
• Student hands-on (simulator practice)
• Extendedreach horizontal well control
• HPHT well control consideration
• Case studies

• Slimhole well control consideration
• Student hands-on (simulator practice)
• Final exercise on simulator

17
CASE STUDY

• Dual Course Evaluation
• Course objectives achieved

18
CASE STUDY

• Dual Course Evaluation
• Improved job performance

19
CONCLUSION

• Considering the importance of formulating WCET,
  following the concluding remarks

• Ensure that course objectives are covered by the
  training providers
• List course content that serve ADCO needs
• Ensure the course is divided into
• Refreshment sessions (to fill the gap)
• Advanced theoretical session

20
CONCLUSION

• Contd

• Case studies related to advanced well control
• Advanced Simulator sessions
• End of course exam covering objectives
• Possibility to run the course on a real life well
  is highly recommended to enhance individuals
  skills

21
CONCLUSION

• Recommended course contents for ADCO purposes

• Refreshment Session (to fill the gap)
• Reservoir consideration
• Kick detection techniques
• Well control operations
• Well control equipment
• Advanced Theoretical Session
• Drilling fluids behavior (water, oil and air)
• HPHT wells consideration
• Horizontal well consideration

22
CONCLUSION

• Recommended course contents for ADCO purposes

• Advanced Theoretical Session (contd)
• Underbalanced drilling consideration
• Multi-lateral consideration
• Slim hole drilling consideration
• H2S well control operations
• Relief wells
• Underground blowouts
• Volumetric, dynamic momentum kill techniques

23
CONCLUSION

• Recommended course contents for ADCO purposes

• Advanced Theoretical Session (contd)
• Stripping snubbing techniques
• Off bottom well control
• Case Studies
• Advanced Simulation
• Preferably on a real life well
• End of Course Exam Covering Course Objectives
• Well cap for example or an alternative (for
  accreditation purpose)

24
ADCO DRILLING DIVISION

• Thank You
