Title: SUBOCCIPITAL TRIANGLE


1
SUBOCCIPITAL TRIANGLE
2
Bony Articulations
  • Occipital bone
  • Occipital condyles.
  • Atlas
  • Posterior tubercle.
  • Posterior arch.
  • Anterior arch.
  • Transverse process with foramina.
  • Lateral masses
  • Articulation with occipital condyles.
  • Articulation with axis.

3
Bony Articulations
  • Axis
  • Dens (odontoid process).
  • Spinous process.
  • Transverse processes with foramina.

4
Vertebral Column Ligaments
  • Anterior longitudinal ligament.
  • Posterior longitudinal ligament.
  • Ligamentum flavum.
  • Ligamentum nuchae
  • Supraspinous interspinous ligaments.

5
Cervical and Craniovertebral Joints
  • Three synovial joints
  • No intervertebral disc.
  • Between dens and anterior arch of the atlas.
  • Between lateral masses of atlas and axis (x2).
  • Ligaments
  • Apical ligament.
  • Alar ligaments.
  • Cruciate ligaments.
  • Tectorial membrane.

6
Suboccipital Triangle Muscles
  • Obliquus capitis superior
  • Weak extensor of the neck.
  • Obliquus capitis inferior
  • Strong rotator of atlas.
  • Rectus capitis posterior major
  • Extension of vertebral column.
  • Rectus capitis posterior minor
  • Extension of vertebral column.

7
Floor and Roof
  • Floor
  • Posterior atlanto-occipital membrane.
  • Roof
  • Semispinalis capitis muscle.

8
Suboccipital Triangle Contents
  • Suboccipital nerve
  • Dorsal ramus of C1.
  • No sensory function and no dorsal root.
  • Motor to muscles of suboccipital triangle.
  • Greater occipital nerve
  • Dorsal ramus of C2.
  • Sensory to back of skull.

9
Suboccipital Triangle Contents
  • Third occipital nerve
  • Dorsal ramus of C3.
  • Vertebral artery.
