Component Based Automation - SIMATIC iMap V3.0

1
(No Transcript)
2
Working with CBA
Component Based Automation
Using Components SIMATIC iMap
Creating Components Engineering Tool (STEP7)
3
Creating components with SIMATIC
STEP7
Highlights of the new version 3.0(Extracts)
4
Steps to create a component

• Define devices and functions
• Create hardware configuration
• Addressing of singleton component
• PROFINET Components
• Adjusting CPUs scan cycle load from
  communication
• Limit PROFINET communication load for local
  PROFINET IO-Devices
• Set the name for local PROFINET IO-Devices
• Create PROFINET Interface
• Programming of the function
• PN copy blocks (PROFINET System-Library) only
  required when the PN Interfaces will be updated
  by user program
• Generate the component

5
Support of components with several PROFIBUS DP
Master and PROFINET IO-System
6
Adjusting scan cycle load from communication
7
Adjusting PROFINET RT communication load for
local PROFINET IO-Devices
8
Addressing local PROFINET IO-Devices by the
device name
9
Creating a PROFINET Interfaces
10
Intuitive Interface Editor within STEP7
11
Multifunction component
12
Properties of component
13
Defining component type and the PROFIBUS DP
master systems with PROXY functionality
14
Using of componentswithin SIMATIC
iMap
Highlights of the new Version 3.0(Extracts)
15
Basic procedure for configuring the plant

• Structure the plant
• Insert components in SIMATIC iMap library /
  project
• Couple and address devices in the net view
  (IP-address and/or PROFIBUS-address)
• Interconnect technological functions in the plant
  view
• Modifying properties of devices and functions
  (optional)
• Check the project
• Generate the project
• Commissioning of devices
• Download of project data to the devices
• If required rework of devices and technological
  function in vendor specific Engineering-Tool
  (optional)
• Test the plant
• Document and archive the project

16
New look feel of SIMATIC iMap
17
Reduction of rework cycle and consistent data by
project library
18
Multifunction componentn-functions within one
device
19
Higher performance in communication due to
PROFINET Real-Time (RT)
20
Improved plant view by downsizing to process
relevant data
21
Reduced connection by using data type STRUCT
Online status of structured data in variable
table
22
Support of components with several PROFIBUS DP
master systems CPU 319-3 PN/DP
Component withseveral PROFIBUSDP systems
23
Unique addressing of local PROFINET IO-Devices
Device name
24
Simple administration of the project in project
view
25
Delta Download for modified program
26
Improved download of several CPUs withoutPop-Up
windows
27
Shorter commissioning time with improved system
and device diagnosis
Graphical informationin the diagnostic window
28
Unambiguous OPC Tag-File Generationfor each
project
29
Improved project documentation in HTML format and
printout
30
SIMATIC iMap V3.0New functions

• Several functions within one device (based on
  CPU 319-3 PN/DP)
• Comfortable navigation and plan overview through
  new Chart view
• Improvements in diagnostic and better support by
  help on errors
• Support of PROFINET components with integrated
  PROFINET IO-Devices
• Support of CPU 319-3 PN/DP
• Support of several PROFIBUS DP master systems in
  one device (based on CPU 319-3 DP/PN)
• Support of WinCC flexible panels within the
  component

31
SIMATIC iMap V3.0Further new functions

• Hide and show of connectors to get a better
  overview in the plant view
• Support of delta download for program blocks to
  keep the process relevant data
• Comfortable download of several CPUs without
  Pop-Up windows
• Improved project documentation in HTML format and
  printout inclusive cross-reference
• Further language support Italian, French,
  Spanish
• Support of additional operating systems

32
CBA Components
Products for CBA
33
Component Based AutomationThe different levels
of modularity
From decentralized intelligence up to
machine-machine communication
34
