Malunions: Principles of Evaluation

1
MalunionsPrinciples of Evaluation Treatment

• Clifford B Jones, MD
• Orthopaedic Associates of Michigan
• Clinical Professor, MSU/CHM
• Grand Rapids, MIMay 2011

2
What is a malunion?

• Bone healed in a nonanatomic position
• Affect function?
• Likely to affect function?
• Consequences with or without treatment

3
What is a malunion?

• Limits of deformity vary by bone and plane
• Somewhat arbitrary
• Merchant and Dietz, JBJS 1989
• No long term effects on knee or ankle function at
  29 years with deformity gt10 degrees after tibia fx

4
(No Transcript)
5
(No Transcript)
6
Planes of deformity

• Articular
• (splits and depressions!)
• Length
• Angulation
• Rotation
• Combined

7
Evaluation

• Length
• Measure
• Blocks
• Scanogram
• CT scanogram

8
Evaluation

• Angulation
• AP/lat X-rays
• Comparison views
• Long leg films
• Standing

9
Evaluation

• Rotation
• Exam (rotational profile)
• CT

10
Evaluation

• Rotation
• Exam (rotational profile)
• CT

11
Correction

• Planning

12
CorrectionClosing wedge

• Single site to heal
• Biomechanically sound
• Soft tissue friendly
• Corrects angulation
• May shorten
• No graft required

13
CorrectionClosing wedge
14
CorrectionClosing wedge
15
Cut
Insert
Compress
Finalize
16
(No Transcript)
17
CorrectionOpening Wedge

• Two sites to heal
• Need graft
• Tension soft tissue
• Pre op plan soft tissue integrity
• Allows lengthening

18
(No Transcript)
19
(No Transcript)
20
Oblique osteotomy

• Single site to heal
• Large surface to heal
• Compression at site
• Can lengthen
• No graft
• Creates some rotation

21
(No Transcript)
22
Oblique osteotomy

• Define plane of deformity

23
Oblique osteotomy

• Define plane of deformity

24
Oblique osteotomy

• Define plane of deformity
• Oblique cut

25
Oblique osteotomy

• Define plane of deformity
• Oblique cut
• Rotate through cut

26
Oblique osteotomy

• Define plane of deformity
• Oblique cut
• Rotate through cut

27
(No Transcript)
28
(No Transcript)
29
(No Transcript)
30
(No Transcript)
31
16 F, 2 years s/p Flex IMN for Proximal Third
Femoral Fracture Short, Varus, Apex Anterior,
Painful Lateral Thigh Deformity
32
PRE OP PLAN
33
(No Transcript)
34
(No Transcript)
35
54 M, 13 years s/p Open tibial Fx
Osteomyelitis Now, complaining of knee and tibial
pain with activities
36
Single Cut Osteotomy Osteotomy Fibula Lag screw
compression Medial Plate Stabilization
37
Multiplanar osteotomies
38
Closed Femur IMN x 3ValgusShort 3.5 cm
39
Planning Reduction
40
1 year post op
41
IMN transverse osteotomy
42
IMN, ORIF, Multiple Intramedullary Osteotomies
Short 2.5 cm Painful Lateral Thigh Deformity IR
Rotation Deformity 45 2 Prior Failed ACL Recon
43
Multiple Intramedullary Osteotomies
Proximal Osteotomy
Mid Mid Osteotomy
Regenerate Recanalization
Distal Osteotomy Translation
44
ER Rotate
Translate
45
Clamshell osteotomyG. Russell, MD
46
Clamshell OsteotomyG. Russell, MD
47
Clamshell osteotomyG. Russell, MD
48
Clamshell osteotomyG. Russell, MD
49
Clamshell osteotomyG. Russell, MD
50
Clamshell osteotomyG. Russell, MD
51
Ilizarov Method
52
Combination MethodOsteotomy, Derotation,
Lengthening
45 M, Fall from ladder 18 mo prior Short Gamma
IMN for Reverse Oblique Fx Pattern Began WBAT at
6 wks Complains of LLD (3.5 cm) and Inability to
walk with his foot straight (45 ER Deformity)
53
Remove IMN Ream CanalIntramedullary
OsteotomyDerotate Leg 45 Internal Rotation
54
Insert IMN No Dist ILApply Uniplanar
Unicortical External FixatorBegin Distraction
Osteogenesis
55
When desired length obtainedReturn to ORInsert
Distal IL ScrewsRemove External Fixator
56
Mid Ending Distraction
57
Final Result
58
End Result
59
Complex problems

• Identify the problem
• Determine the consequences
• (with or without intervention)
• Plan the correction
• Execute the plan
• Lifelong learning
