HOLOGRAPHIC VERSATILE

1

• HOLOGRAPHIC VERSATILE
• DISC

2
Outline

• What is HVD?
• Collinear Holography.
• Basic structure
• How it work?
• Compare with other devices.
• Advantages/Disadvantages
• Conclusion

3
What is HVD ?

• Holographic Versatile Disc (HVD) is an optical
  disc technology which would hold up to 3.9
  terabytes (TB) of information.
• It employs a technique known as collinear
  holography.

4
Collinear Holography

• In collinear holography there are two type of
  laser beam.
• Red beam(Information beam)
• Green beam(Refrence beam)
• This two beams are collimated in a single beam.
• The green laser reads data encoded as laser
  interference fringes from holographic layer near
  the top of the disc.

5

• while the red laser is used as the reference
  beam and to read servo information from a regular
  CD-style aluminum layer near the bottom.
• A dichroic mirror layer between the holographic
  data and the servo data reflects the green laser
  while letting the red laser pass through.


6
Basic structure

• It has similar to CD-DVD structure. It is differs
  to use laser beams its pulse speed.
• The Components are like
• blue or green laser(532 nmwl),
• red laser ,beam splitter, mirrors
• special lights modulator(SLM),
• C-MOS sensor ,photo polymer
• recording medium.

7
(No Transcript)
8
How it works?

• Current optical storage saves one bit per pulse
  the HVD hopes to improve this efficiency with
  capability of around 60,000 bits/pulse.
• Truncated cone shape that has 200 micrometer
  diameter at the bottom
• 500 micrometer diameter at top.

9
(No Transcript)
10

• Data-SLM-Binary
• Data is created to fire laser beam into the beam
  splitter to produce 2 beam.
• 1.Reference beam ( Directed to away
• from the SLM).
• 2.Information beam ( Direct toward
• the SLM ).

11

• The 0s 1s data pages are translated into the
  pixel of the special light modulator that either
  block or tr-
• ansmit light.
• A memory system isn't very useful if you can't
  access the data you've stored.

12
Capacity, Speed, Cost Comparison
    Capacity Writing/ Reading Speed Discs Approx. Cost Recordable Player Approx. Cost
Holographic Versatile Discs (HDSS) HVD 300 GB 1.6 TB 1 GB/s 120 3000
Blu-ray Discs BD 25 GB 50 GB 36.5 Mb/s 18 2000
Digital Versatile Discs DVD HD-DVD 5 GB 30 GB 36.5 Mb/s 10 2000
Compact Discs CD 783 MB 1.3 GB 36.5 Mb/s 4 200
13
Advantages

• HVD have the capacity to hold up to 3.9 terabytes
  (TB) of information, which is approximately 5,500
  times the capacity of a CD-ROM,830 times the
  capacity of a DVD,160 times the capacity of
  single-layer Blu-ray Discs, and about 4 times the
  capacity of the largest computer hard drives as
  of 2007.

14

• The HVD also has a transfer rate of 1 Gbit/s (128
  MB/s).
• It has been estimated that the books in the U.S.
  Library of Congress, one of the largest libraries
  in the world, would contain a total of about 20
  terabytes if scanned in text format. Not
  including images from the books, the content
  could be stored with capacity to spare on six 3.9
  TB discs.

15

• Using MPEG4 ASP encoding, a 3.9 TB HVD could hold
  4,60011,900 hours of videojust over one year of
  uninterrupted video at usual encoding rates.
• Using typical satellite radio encoding
  (CT-aacPlus at 40 kbit/s), a 3.9 TB HVD could
  hold over 26.5 years of uninterrupted stereo
  audio.

16
Disadvantages

• Holography memory has
• been around for more than 40 years
• but several characteristic made it difficult
  to implement , now progras
• of HVD make it easy to implement.
• It is not available in market.

17
References

• Ashley, J. et al. Holographic Data Storage IBM
  Journal of Research and Development, Vol 44, No
  3, 2000, pp 341-368
• Ferri, Vic. Holographic Video Storage TechTrax,
  http//pubs.logicalexpressions.com/Pub0009/LPMArti
  cle.asp?ID118
• Orlov, Sergei S. et al. High-transfer-rate
  high-capacity holographic disk data-storage
  system Applied Optics, Vol 43, No 25, Sept. 1
  2004, pp 4902-4914
• Psaltis, Demitri and Mok, Fai. Holographic
  Memories Scientific American, Nov. 1995, pp
  70-76
• Schwartz, Karen D. HVD Coming to a Storage
  Device Near You eWeek, Feb. 3, 2005,
  http//www.eweek.com/article2/0,1759,1759907,00.as
  p
• Blue laser media offers terabytes on a disc
  Mar. 12, 2004. http//www.ferret.com.au/articles/4
  9/0c01d949.asp
• Ecma International creates TC44 to standardize
  Holographic Information Storage systems
  http//www.ecma-international.org/news/TC44_PR_Jan
  2005.htm
• Holographic Disk is Quickly Searchable Laser
  Focus World, Feb. 2003, p 17
• Holographic Storage Takes a Step Toward
  Viability Photonics Technology World Oct. 1998
  http//www.photonics.com/spectra/tech/XQ/ASP/techi
  d.422/QX/read.htm
• Technology http//www.optware.co.jp/english/tec
  h.htm
