Software Testing Seminar

1
Software Testing Seminar

• Mooly Sagiv
• http//www.math.tau.ac.il/sagiv/courses/testing.h
  tml
• Tel Aviv University
• 640-6706
• Sunday 16-18
• Monday 10-12 Schrieber 317

2
Bibliography

• Michael Young, University of Oregon UW/MSR 1999
• Glenford Myers The Art of Software Testing 1978!

3
Outline

• Testing Questions
• Goals of Testing
• The Psychology of Testing
• Program Inspections and Reviews
• Test Case Design
• Achieving Reliability
• Other Techniques
• A Success Story

4
Standard Testing Questions

• Did this test execution succeed or fail?
• Oracles
• How shall we select test cases?
• Selection generation
• How do we know when weve tested enough?
• Adequacy
• What do we know when were done?
• Assessment

5
Possible Goals of Testing

• Find faults
• Glenford Myers, The Art of Software Testing
• Provide confidence
• of reliability
• of (probable) correctness
• of detection (therefore absence) of particular
  faults

6
Testing Theory (such as it is)

• Plenty of negative results
• Nothing guarantees correctness
• Statistical confidence is prohibitively expensive
• Being systematic may not improve fault detection
• as compared to simple random testing
• So what did you expect, decision procedures for
  undecidable problems?

7
What Information Can We Exploit?

• Specifications (formal or informal)
• in Oracles
• for Selection, Generation, Adequacy
• Designs
• Code
• for Selection, Generation, Adequacy
• Usage (historical or models)
• Organization experience

8
The Psychology of Testing

• Testing is the process of demonstrating that an
  errors are not present
• Testing is the process of establishing
  confidence that the program does what it intends
  to do
• Testing is the process of executing programs
  with the intent of finding errors
• Successful (positive) test exposes an error

9
Black Box Testing

• View the program as a black box
• Exhaustive testing is infeasible even for tiny
  programs
• Can never guarantee correctness
• Fundamental question is economics
• Maximize investment
• Example Partition test

10
White Box Testing

• Investigate the internal structure of the program
• Exhaustive paths testing is infeasible
• Does not even guarantee correctness
• Specification is needed
• Missing paths
• Data dependent paths
• Becomes an economical question

if (a-b lt epsilon)
11
Testing Principles

• Test case must include the definition of expected
  results
• A program should not test her/his own code
• A programming organization should not test its
  own programs
• Thoroughly inspect the results of each test
• Test cases must be also written for invalid
  inputs
• Check that programs do not do unexpected things
• Test cases should not be thrown a way
• Do not plan testing assuming that there are no
  errors
• The probably of error in a piece of code is
  proportional to the errors found so far in this
  part of the code

12
Program Inspections and Reviews

• Conducted in groups/sessions
• A well established process
• Modern programming languages eliminate many
  programming errors
• Type errors
• Memory violations
• Uninitialized variables
• But many errors are not currently found
• Division by zero
• Overflow
• Wrong precedence of logical operators

13
Test Case Design

• What subset of inputs has the highest probability
  of detecting the most errors?
• Combine black and white box testing

14
Higher Order Testing

• Show that the program does not so what the
  end-user expects
• Different testing levels
• Unit test (procedure boundaries)
• Module test
• Function test (discrepancies external spec.)
• System test (discrepancies with original
  objectives)
• Facility test
• Volume test
• Usability test
• Security test
• Performance test
• ...

15
Black box
White box

• Coverage/Adequacy
• Data flow analysis
• Cleanness
• Correctness
• Mutation
• Slicing

• Equivalence partitioning
• Boundary-value analysis
• Cause-effect graphing
• Error guessing
• State space exploration

16
Partition Testing (Equivalence Partitioning)

• Basic idea Divide program input space into
  (quasi-) equivalence classes
• Underlying idea of specification-based,
  structural, and fault-based testing

17
Specification-Based Partition Testing

• Divide the program input space according to
  identifiable cases in the specification
• May emphasize boundary cases
• May include combinations of features or values
• If all combinations are considered, the space is
  usually too large
• Systematically cover the categories
• May be driven by scripting tools or input
  generators
• Example Category-Partition testing Ostrand

18
Adequate testing

• Ideally adequate testing ensures some property
  (proof by cases)
• Origins in Goodenough Gerhart, Weyuker and
  Ostrand
• In reality as impractical as other program
  proofs
• Practical adequacy criteria are really
  inadequacy criteria
• If no case from class XX has been chosen, surely
  more testing is needed ...

19
Structural Coverage Testing

• (In)adequacy criteria
• If significant parts of program structure are not
  tested, testing is surely inadequate
• Control flow coverage criteria
• Statement (node, basic block) coverage
• Branch (edge) and condition coverage
• Data flow (syntactic dependency) coverage
• Various control-flow criteria
• Attempted compromise between the impossible and
  the inadequate

20
Basic structural criteria (ex.)
a
Edge ac is required by all-edges but not by
all-nodes coverage
b
Typical loop coverage criterion would require
zero iterations (cdf), one iteration (cdedf), and
multiple iterations (cdededed...df)
c
d
e
f
21
Data flow coverage criteria (ex.)
x 7
Rationale An untested def-use association
could hide an erroneous computation
y x
2 reaching definitions (one is from self)
y y1
z xy
2 reaching definitions for x, and 2 reaching
definitions for y
22
The Infeasibility Problem

• Syntactically indicated behaviors (paths, data
  flows, etc.) are often impossible
• Infeasible control flow, data flow, and data
  states
• Adequacy criteria are typically impossible to
  satisfy
• Unsatisfactory approaches
• Manual justification for omitting each impossible
  test case (esp. for more demanding criteria)
• Adequacy scores based on coverage
• example 95 statement coverage, 80 def-use
  coverage

23
Challenges in Structural Coverage

• Interprocedural and gross-level coverage
• e.g., interprocedural data flow, call-graph
  coverage
• Regression testing
• Late binding (OO programming languages)
• coverage of actual and apparent polymorphism
• Fundamental challenge Infeasible behaviors
• underlies problems in inter-procedural and
  polymorphic coverage, as well as obstacles to
  adoption of more sophisticated coverage criteria
  and dependence analysis

24
Structural Coverage in Practice

• Statement and sometimes edge or condition
  coverage is used in practice
• Simple lower bounds on adequate testing may even
  be harmful if inappropriately used for test
  selection
• Additional control flow heuristics sometimes used
• Loops (never, once, many), combinations of
  conditions

25
Testing for Reliability

• Reliability is statistical, and requires a
  statistically valid sampling scheme
• Programs are complex human artifacts with few
  useful statistical properties
• In some cases the environment (usage) of the
  program has useful statistical properties
• Usage profiles can be obtained for relatively
  stable, pre-existing systems (telephones), or
  systems with thoroughly modeled environments
  (avionics)

26
Arbitrary ? Random

• A common error in naïve attempts to obtain
  statistical confidence measures
• Arbitrary distributions may be modeled by
  adversary functions, not by uniform distributions
• Example
• If failures were distributed randomly through the
  execution space of a database program, it would
  fail at a uniform rate over time.
• In reality, it may never fail until a critical
  table overflows, and then always fail thereafter.

27
Certifying Ultra-High reliability

• Problem How can I show that system X has an
  expected failure rate of 10-9/hour?
• example probability that software will ever
  bring down an Airbus A320
• Butler Finelli estimate
• for 10-9 per 10 hour mission
• requires 1010 hours testing with 1 computer
• or 106 hours (114 years) testing with 10,000
  computers
• ACM Sigsoft 91, Conf. on SW for Critical Systems

28
Glimmers of Hope for Measuring High Reliability

• Random distribution of faults or failures would
  enable statistical reasoning and classic
  redundancy techniques
• A whole more reliable than its parts
• Randomization approaches
• Blum Self-checking programs
• Lipton Redundant computations
• Podgurski Kolmogorov complexity
• Grail or illusion?
• Difficult to generalize beyond simple functions

29
Process-Based Reliability Testing

• Rather than relying only on properties of the
  program, we may use historical characteristics of
  the development process
• Reliability growth models (Musa, Littlewood, et
  al) project reliability based on experience with
  the current system and previous similar systems

30
Fault-based testing

• Given a fault model
• hypothesized set of deviations from correct
  program
• typically, simple syntactic mutations relies on
  coupling of simple faults with complex faults
• Coverage criterion Test set should be adequate
  to reveal (all, or x) faults generated by the
  model
• similar to hardware test coverage

31
Fault Models

• Fault models are key to semiconductor testing
• Test vectors graded by coverage of accepted model
  of faults (e.g., stuck-at faults)
• What are fault models for software?
• What would a fault model look like?
• How general would it be?
• Across application domains?
• Across organizations?
• Across time?
• Defect tracking is a start

32
The Budget Coverage Criterion

• A common answer to when is testing done
• When the money is used up
• When the deadline is reached
• This is sometimes a rational approach!
• Implication 1 Test selection is more important
  than stopping criteria per se.
• Implication 2 Practical comparison of approaches
  must consider the cost of test case selection

33
Test Selection Standard Advice

• Specification coverage is good for selection as
  well as adequacy
• applicable to informal as well as formal specs
• Fault-based tests
• usually ad hoc, sometimes from check-lists
• Program coverage last
• to suggest uncovered cases, not just to achieve a
  coverage criterion

34
The Importance of Oracles

• Much testing research has concentrated on
  adequacy, and ignored oracles
• Much testing practice has relied on the eyeball
  oracle
• Expensive, especially for regression testing
• makes large numbers of tests infeasible
• Not dependable
• Automated oracles are essential to cost-effective
  testing

35
Sources of Oracles

• Specifications
• sufficiently formal (e.g., Z spec)
• but possibly incomplete (e.g., assertions in
  Anna, ADL, APP, Nana)
• Design models
• treated as specifications, as in protocol
  conformance testing
• Prior runs (capture/replay)
• especially important for regression testing and
  GUIs hard problem is parameterization

36
What can be automated?

• Oracles
• assertions replay from some specifications
• Selection (Generation)
• scripting specification-driven replay
  variations
• selective regression test
• Coverage
• statement, branch, dependence
• Management

37
Design for Test 3 Principles
Adapted from circuit and chip design

• Observability
• Providing the right interfaces to observe the
  behavior of an individual unit or subsystem
• Controllability
• Providing interfaces to force behaviors of
  interest
• Partitioning
• Separating control and observation of one
  component from details of others

38
Problems Opportunities

• Compositionality
• for components for regression
• Specifications
• low entry barrier, incremental payoff
• Synergy with Analysis
• conformance test w/ verified models
• backstop for unsafe assumptions
• (your idea here)

39
A recent success story

• The Prefix program analysis tool
• Analyzes C/C sources
• Scans for cleanness bugs, e.g., dereferences to
  NULL pointers
• Symbolically executes the program on some paths
• May miss some errors and generate false alarms
• Tried on Windows 2000
• Located 65,000 potential bugs28,000 out of which
  are real bugs
