Title: STAIRS


1
STAIRS
2
STAIR PARTS
Drop newel
Kite winder
Wall string
Landing nosing
Cut out for joist trimmer
Riser board
nosing
Well string
Split landing
Newel post
Balustrade
Baluster and handrail
Tread
Landing bearer
skirting
¼ space landing
3
MORE STAIR PARTS
4
CUT AND BRACKETED STRINGS
BRACKETS
CUT STRING
5
CUT AND BRACKETED STRINGS
  • CUT BRACKETED STRINGS.
  • STRING

2. RISER
3. TREAD
  1. BRACKET

5. SCOTIA
6. CORNER BLOCK
7. MITRE
8. MITRE
9. RETURN NOSING
6
Filling in below stairs
SOFFIT PANEL OR LINING
SPANDREL PANEL OR LINING
7
STAIR TYPES
  • Straight flight No more than 18 rises without a
    change in direction.

8
STAIR TYPES
  • Quarter turn with landing.

9
STAIR TYPES
  • Half turn with landing.

10
STAIR TYPES
  • Quarter turn with kite winders

11
STAIR TYPES
  • Half turn with winders

12
STAIR TYPES
  • Circular and spiral stairs
