DDIDS(Dynamic Distributed Intrusion Detection
System)

• 11/04/04
• Kevin Skapinetz
• Daniel Hanley
• Andrew Thigpen

2
Outline

• IDS History
• IDS Types
• Intrusion Prevention
• Attack Correlation
• Current Technology
• DDIDS

3
What is Intrusion Detection?

• all processes used in discovery of unauthorized
  uses of network or computer devices
• Detection of unusual and abnormal activity/events
  in real-time
• Detects break-ins or attacks through various data
  sources from logs / audits / surveillance and
  network traffic

4
History of IDS

• Early 1970s paper by James P. Anderson
• US Air Force paper first acknowledging the need
  for increased awareness of computer security
  problems
• Erose from unique need of USAF for security with
  different levels of classification
• 1980 Computer Security Threat Monitoring and
  Surveillance, by James P. Anderson
• Notion of automated intrusion detection born
• Outlines ways to improve computer security
  auditing and surveillance
• Must define and understand threats then design
  IDS tailored to these threats
• Risk assessment process -gt security policy

5
History of IDS (cont.)

• 1984 Stanford Research Institute
• Developed means of tracking and analyzing audit
  data for ARPANET
• Navy SPAWAR contract to realize first functional
  IDS (IDES)
• Mid-1980s - Dorothy Denning and Peter Neumann
• Significant research in ID for SRI
• Developed actual model for real-time IDS (IDES)
• Prototype
• First to address break-ins, masquerading, system
  penetrations, Trojan horses, viruses, leakages,
  DNS attacks
• Initially rule based expert system
• Developed into NIDES

6
History of IDS (cont.)

• 1988 University of Davis Lawrence Livermore
  Laboratories
• Haystack project -gt IDS for USAF
• Analyzed audit data by comparing with defined
  patters
• searching through this large amount of data for
  one specific misuse was equivalent to looking for
  a needle in a haystack
• 1989 Haystack Labs
• Last generation called Stalker
• DIDS
• host-based, pattern matching system that
  included robust search capabilities to manually
  and automatically query the audit data

7
History of IDS (cont.)

• 1990 UC Daviss Todd Heberlein
• NSM (Network Security Monitor)
• First Network-based ID
• Major government installations
• Contributions with DIDS with idea of Hybrid ID
• Introduced to commercial world
• Late-1990s commercialization
• CMDS (Computer Misuse Detection System)
• ASIM (Automated Security Measurement System)
• RealSecure ISS product

8
Types of IDS

• Implementation
• Host-based vs. Network-based
• Methodology Models
• Anomaly vs. Signature detection

9
Host-based (HIDS)

• Operate on a host to detect malicious activity
• Load pieces of software on system
• Uses system log files or auditing agents as
  sources of data
• Two primary classes
• Host wrappers/personal firewalls
• Agent-based software
• Effective in detecting trusted-insider attacks
  (anomalous activity)
• Pros
• High level of detail
• Use centralized system to manage multiple hosts
• Can examine encrypted traffic
• Cons
• May decrease network performance
• Foiled by DoS attacks
• Consumes host resources

10
Network-based (NIDS)

• Operate on network data flows
• Monitors traffic on network segment for sources
  of data
• NIC set to promiscuous mode
• Complete knowledge
• Lots of data
• Signature matching
• String
• Port
• Header condition
• Pros
• Can monitor large networks
• Little overhead
• Easy to secure
• Cons
• May overlook attacks peak traffic periods
• Cannot analyze encrypted data
• Cannot report success or failure of attacks

11
Anomaly Detection

• Detects activity that deviates from normal
  activity
• Depends on statistical definition of normal
• Prone to large number of false positives
• Subcategories
• Profile-based
• Protocol-based
• Pros
• If implemented properly, can detect unknown
  attacks
• Offers low overhead (learning vs. development)
• Cons
• Not definitive
• Definition of normal
• High false positive rate

12
Signature Detection

• Matches known patterns of events specific to
  known attacks
• Requires knowledge of attack signatures
• Requires method to compare and match behavior to
  signature
• Types
• Pattern matching
• Stateful pattern matching
• Protocol decode based
• Heuristic based

13
Pattern Matching

• Fixed sequence of bytes in a single packet
• Pros
• Simple to employ
• Highly specific
• Applicable across all protocols
• Cons
• High false positive rate
• Multiple signatures for a single vulnerability

14
Stateful pattern matching

• More sophisticated
• Employs the concept of contextual matches within
  the state of the data stream
• Pros
• Similar to Non-stateful pattern matching
• Makes evasion more difficult
• Cons
• Same as Non-stateful pattern matching

15
Protocol-decode based

• Breaks down elements of protocol
• Applies rules defined by RFCs to look for
  violations
• Pros
• Minimizes chance for false positives if well
  defined and enforced
• More general to allow for catching variations on
  themes
• Reliably alerts on violation of rules
• Cons
• Can lead to high false positives if RFC not well
  defined
• Longer development times

16
Heuristic based

• Uses algorithmic logic to base alarm decisions
• Statistical evaluation of traffic
• Pros
• Certain types of activity can only be detected
  through this type
• Cons
• Algorithms may require tuning and modification to
  conform to traffic and limit false positives

17
Intrusion Prevention

• Evolution of IDS to IPS
• Incorporates other network devices
• Passive gt Active detection
• Proactive defense mechanisms
• Stops offending traffic prior to damage
• Host IPS
• Direct system installation
• Binds close to kernel to intercept system calls
  (Audits)
• Not very upgradeable (change controls,
  availability)
• Network IPS
• Combines IDS, IPS, and a firewall
• In-line IDS or Gateway IDS
• Discards malicious packets
• Unable to compete with current speed of networks

18
IDS Correlation

• What is Correlation with respect to IDS systems?
• The process of transforming raw threat data into
  prioritized and actionable data.
• Need for Correlation technology
• Low accuracy rates in current IDS (reduces false
  positives)
• Decision support in real-time incident response
• Sheer volume of information can overwhelm human
  operators
• Ability to detect distributed attacks
• Opportunity to take advantage of multiple data
  sources for more accurate detection
• Allows the security management team to focus on a
  subset of higher priority alerts
• Increases IDS productivity and effectiveness

19
IDS Correlation

• Good IDS correlation systems will
• Separate and highlight events that are more
  likely to cause damage
• Distinguish successful intrusions from
  unsuccessful ones
• Identify widely distributed attacks
• Track events in real-time in an automated fashion
• Have an automated response capability that can
  help protect against serious threats
• Offer user-defined and configurable signatures to
  adapt to the customer environment

20
IDS Assessment Correlation

• Lowers or Increases the priority of an event if
  the target is vulnerable or not vulnerable to the
  threat.
• Requires assessment scanning of network resources
  and storage of the results.
• Assessment scanning determines the following
• Type of resource (OS / Version information).
• Services running on that resource.
• If the resource is vulnerable to a known exploit.
• May be done remotely or from an agent installed
  directly on the host.
• Central point of Correlation.

21
IDSVA Correlation Diagram

• Scanner profiles servers to build Vulnerability
  information on IDS Server.
• Sensor picks up attack aimed at First Server,
  sends event to IDS Server.
• IDS Server determines if the Server is vulnerable
  to the attack. If there is a high probability
  that the attack will be successful, the priority
  of the event raised in the IDS Console is
  increased.

22
IDSVA Correlation

• Limitations of IDSVA Correlation
• Requires Vulnerability Assessment scans to be
  performed on a regular basis.
• Does not do a good job with handling roaming
  hosts (WLAN, DHCP, environments).
• Does not assist in Intrusion Prevention, only
  alters the way the threat is presented in the
  management console.

23
Attack Pattern Correlation

• Combines different events/attacks into a single
  incident.
• Events may originate from the a single or
  multiple sensors on the network.
• The ability to correlate Host and Network
  intrusion information for an added level of
  verification.

24
Attack Pattern Correlation (ex 1)
25
Attack Pattern Correlation (ex 1)
26
Attack Pattern Correlation (ex 1)
27
Attack Pattern Correlation (ex 1)
28
Attack Pattern Correlation (ex 1)
29
Attack Pattern Correlation (ex 1)
30
Attack Correlation from different Sensors

• Successful buffer overflow attack against DNS
  server followed by login and attempt to install
  Trojan backdoor.
• Correlate across network engines and system
  agents
• DNS buffer overflow attack (network)
• Login with admin privileges (system)
• Audit disable attempt (system)
• netbus install (system)
• Same source (network, system)
• lttime framegt
• Probable successful system compromise

31
Current IDS Correlation Technology

• ISS Security Fusion Module (APVA)
• Qualys QuIDScor (VA)
• Cisco Threat Response (VA)
• Symantec Incident Manager (AP VA)
• Juniper Networks Netscreen (AP)

32
Internet Security Systems Solution
33
Current Correlation Prevention Architecture

• Sensors send events to a separate device in the
  IDS system.
• Correlation engine in a centralized location.
• Correlation engine only affects notification
  responses (i.e. increasing the priority of an
  alert in the management console).
• Preventative response have no relation with event
  correlation.

34
Project Motivation

• Mean Time to Diagnose (MTTD)
• Current IDS Limitations
• Intrusion Detection
• Capabilities
• Network view
• Intrusion Prevention
• Active response
• Compartmentalized response

35
DDIDS Architecture

• Solution Distributed Dynamic IDS

36
DDIDS Architecture
37
DDIDS Host Components

• IDS
• SNMP Agent
• Correlation Engine
• Response Engine

38
DDIDS Host Components
39
DDIDS Responses

• Prevention
• Integrated -- network device with DDIDS
  functionality
• Remote -- configuration of network device
  remotely
• Autonomous -- direct modification of traffic
• Notification
• Email
• SNMP Trap

40
DDIDS Implementation

• Snort
• SnortSNMPPlugin
• Attack Generation
• Simulated Traffic
• Satan, nmap, Nessus
• DDIDS Daemon
• iptables

41
DDIDS Future Work

• Large-scale DDIDS
• Variable trust levels of DDIDS hosts

42
