Product Line - Belts
2
Carlisle Power Transmission

• Full line of belts, sheaves,pulleys and
  sprockets
• Product constructionswrapped,
  raw-edge,synchronous, v-rib,double angle,
  specialty

3
Carlisle Belts
4
Gold Ribbon Cog-Belt
Product Name Gold Ribbon Cog-Belt
Product Brand
Part No format AX, BX, CX, DX followed by
Inside length
Sizes/classifications Classical profile, raw
edge construction, 23 to 362
Examples CX225 has an inside length or standard
length designation of 225 inches, and an
outside length of 227.2 inches. It has a 7/8
top width and 9/16 depth.
5
Gold Ribbon Cog-Belt

• Up to 20 more cordof hi-modulus
  syntheticfibers carry high loadswith minimal
  stretch
• Compression sectionof exclusive Stiflex
  compound with precision-molded cogs

6
Gold Ribbon Cog-Belt

• More efficient than conventional V-belts
• 30 higher horsepowerrating cuts
  replacementdowntime
• Improved system-wideperformance deliverscost
  savings

7
Super II V-Belt
Product Name Super II V-Belt
Product Brand
Part No format A, B, C followed by inside
length
Sizes/classifications Classical profile,
raw-edge construction, 21 to 200
Examples B94 has an inside length or standard
length designation of 94, and an outside
length of 96.8. It has a 21/32 top width
and a 7/16 depth.
8
Super II V-Belt

• Greater strengthfrom centrally placed polyester
  cord
• Longer life onsevere drives
• Better grip withcontrolled slippage
• Greater flexibility

9
Super Blue Ribbon V-Belt
Product Name Super Blue Ribbon V-Belt
Product Brand
Part No format AP, BP, CP, DP, EP followed by
inside length
Sizes/classifications Classical
profile, wrap molded construction, 23 to 662
Examples BP136 has an inside length or standard
length designation of 136, and an outside
length of 138.8. It has a 21/32 top width
and a 7/16 depth.
10
Super Blue Ribbon V-Belt

• The finest wrapped belt in the industry
• Double wrapped cotton cover
• ChekMate matching
• Longer, more dependable performance
• The work horse of classical v-belts

11
Double Angle V-Belt
Product Name Double Angle V-Belt
Product Brand
Part No format AA, BB, CC followed by inside
length
Sizes/classifications Modified/special
classical, wrap molded construction
Examples BB60 has an inside length or standard
length designation of 60, and an outside
length of 64.6. It has a 21/32 top width and
a 17/32 depth.
12
Dry Can Belts
Product Name Dry Can Belts
Product Brand
Part No format CC followed by Inside length
followed by S
Sizes/classifications Specialty notched version
of CC Double Angle belt
Examples CC480S has an inside length or
standard length designation of 480, and an
outside length of 482.7. It has a 7/8 top
width a 11/16 depth.
13
Power-Wedge Cog-Belt
Product Name Power-Wedge Cog-Belt
Product Brand
Part No format Profile (3VX, 5VX, 8VX)
followed by outside length (X10)
Sizes/classifications Narrow wedge
profile, raw edge construction
Examples 5VX630 has an outside
length of 63 inchesnot 630. The
length in the part number is the outside as
opposed to classical belts that show
inside length. It has a 5/8 top
width and a 17/32 depth.
14
Power-Wedge Cog Belt

• Exclusive Con-Flex design for longer life on
  replacement drives
• High horsepower ratings permit design flexibility
  to reduce cost, space weight

15
Metric Power-Wedge Cog-Belt
Product Name Metric Power-Wedge
Cog-Belt
Product Brand
Part No format SPZ, SPA, SPB, SPC
Sizes/classifications Narrow section wedge
belt
16
Super Power-Wedge V-Belt
Product Name Super Power-Wedge V-Belt
Product Brand
Part No format Profile (3V, 5V, 8V) followed by
outside length (X10)
Sizes/classifications Narrow wedge profile, wrap
molded construction
Examples 5V2120 has an outside length of 212
inches.not 2120 The length in the part
number is the outside as opposed to classical
belts that show inside length. It has a 5/8
top width and a 17/32 depth.
17
RPP PANTHER Synchronous Belt
Product Name RPP Panther
Product Brand
Part No format Pitch length (mm), PTH, tooth
pitch, width (MM)
Sizes/classifications Super high torque
synchronous
Examples A Part number of 2200PTH8M-35 is a
Panther (PTH) with a pitch length of 2200 mm,
a tooth pitch of 8 mm, and a width of 35 MM
18
RPP PANTHER

• Chain horsepowerwithout the mess
• Horsepower ratingscomparable to urethane,PLUS
  backside idler capacity, better heatresistance,
  lower drive noise
• Now with Ultra-Cord and Able compound

19
RPP PANTHER

• Performs at 98operating efficiencyfor reduced
  energy consumption
• Patented graphite-loaded,self-lubricating,
  nylon cover - resists ozone, friction wear and
  abrasion

20
RPP Plus Synchronous Belt
Product Name RPP Plus
Product Brand
Part No format Pitch length (MM) Tooth Pitch
Belt width (mm)
Sizes/classifications High torque synchronous
Examples A part number of 966-14M-170 is an RPP
Plus with a pitch length of 966 mm, a tooth
pitch of 14 mm and a width of 170 mm.
21
RPP Plus Synchronous Belt

• Provides up to 50 morehorsepower
  capacitycompared to standardhigh-torque belts
• Ideal for replacingchain and gear drives

22
Fin-Fan Belts
Product Name Fin-Fan Belts
Product Brand
Part No format Same as RPP Plus, but add F to
the end
Sizes/classifications Specialty
synchronous. The belt looks the same as a
standard RPP but has a special cord process
made for fin-fan drives. Only 8 sizes
available.
Examples 3500-14M-85F would be 3500 mm pitch
length, 14 mm tooth pitch and 85 mm wide. The
F designates fin-fan type.
23
Long Length RPP
Product Name Long Length RPP Belts
Product Brand Branded with part
number and date code.
Part No format LL, Tooth pitch (8m), width
in MM
Sizes/classifications Specialty synchronous.
Open ended RPP belting in 150 foot reels. Can
splice to any length.
Example LL8M020 would represent a 150 ft
reel of 8m tooth pitch belting in a 20 mm
width.
24
Dual RPP
Product Name Dual RPP
Product Brand Branded with part number and date
code. Brands conform to tooth shape.
Part No format D, Pitch length (mm), tooth
pitch (mm), width (mm)
Sizes/classifications Specialty synchronous belts
Examples D1120-8M-50 would be a dual sided,
1120 MM pitch length, 8 mm tooth pitch, 50 mm
wide belt.
25
Synchro-Cog Timing Belt
Product Name Synchro-Cog Timing Belt
Product Brand
Part No format Pitch Length (in10), tooth
pitch design, top Width (in)
Sizes/classifications Standard synchronous
Examples 700H050 would be a 70 inch pitch
length, ½ (H) tooth pitch, and a ½ (050/100)
top width.
26
Cotton Cleaner Timing Belt
Product Name Cotton Drive Timing Belt
Product Brand
Part No format Pitch Length (apprx), CCB,
Drive Center Distance10
Sizes/classifications Specialty synchronous for
cotton cleaner drives 1 tooth pitch, only 5
part numbers available.
Examples A Part Number of 63CCB165 is a belt
with 63 Pitch Length and fits a drive with a
Center distance of 16.5 inches.
27
Long Length Timing Belting
Product Name Long Length Timing Belting
Product Brand Unbranded
Part No format LL, Top Width (in/100), Tooth
Pitch Designation
Sizes/classifications Specialty synchronous
product
Examples A Part number of LL150H is long length
belting, 1.5 (150/100) top width, ½ (H)
tooth pitch. This product is sold in 100 foot
reels (can be spliced to any length).
28
Synchro-Cog Dual Timing Belt
Product Name Synchro-Cog Dual Timing Belt
Product Brand Branded with date code. Brands
conform to tooth shape.
Part No format D, Pitch length10 (in), tooth
pitch, top width (in)
Sizes/classifications Specialty synchronous
Examples A part number of D300L075 is a dual
sided belt, 30 pitch length, 3/8 (L) tooth
pitch, and a top width of ¾ (075/100).
29
Synchro-Cog Dual Timing Belt

• For maintenance-freesynchronizationfrom both
  sidesof the belt onpositive driveapplications
• Delivers excellentperformance onserpentine
  drives

30
Durapower FHP V-Belt
Product Name Durapower FHP (light duty) V-Belt
Product Brand
Part No format Profile (3L, 4L, 5L), outside
length (inches)
Sizes/classifications Light duty/ fractional
h.p., wrapped construction
Examples A 5L750 is an FHP belt with an outside
length of 75, A top width of 5/8 and a depth
of 11/32.
31
Durapower II FHP V-Belt
Product Name Durapower II FHP (light duty)
V-Belt
Product Brand
Part No format Profile (3L, 4L, 5L), outside
length (inches)
Sizes/classifications Light duty/fractional
h.p., raw edge construction
Examples A 5l750 is an FHP belt with an
outside length of 75, A top width of 5/8 and
a depth of 11/32.
32
Durapower ll Construction Features

• 1. Stress-relieved bias-cut cover fabric
  provides maximum flexibility.
• 2. Hi-Modulus polyester cord is specially
  treated to maintain belt loads without
  stretching.
• 3. Raw Edge belt side walls grip pulleys,
  minimizing belt slip, noise and drive vibration.
• 4. Special Neoprene compounds support cords
  evenly and resist flex fatigue.

33
Durapowerll Laboratory Test Results
Resists Stretch! Sleeve curing yields a
product that stretches less requires less
tension maintenance.
Longer Life! Premium materials provide the key
to longer belt life.
34
XDV Xtra Duty Lawn Garden Belt
Product Name XDV Xtra Duty V-Belt
Product Brand
Part No format Belt profile (38X,48X,58X),
outside length (inches10)
Sizes/classifications FHP Light Duty, Wrap
molded - premium construction
Examples A 48-500 represents an XDV belt with
an outside length or circumference of 50, and
a 48X or 4L top width of ½ and a depth of
9/32.
35
XDV Xtra Duty Lawn Garden Belt

• Easy release jacketfor superior declutching
• High tenacity Aramidfiber cord providessuperior
  shock resistance
• Premium base cushion
  stock is
  ideal
  for backside idlers
• For mowers, tillers and other tough uses

36
Gold Ribbon Cog-Band
Product Name Gold Ribbon Cog-Band
Product Brand
Part No format R, Profile (BX,CX,DX), Inside
Length (inches)
Sizes/classifications Banded classical belt, raw
edge construction
Examples A typical part number of RCX210-3 is a
3 ribbed banded belt with an inside length of
210, an outside length of 215.3 with each
rib having a C profile.
37
Power-Wedge Cog-Band
Product Name Power-Wedge Cog-Band
Product Brand
Part No format R, profile (3VX, 5VX,
8VX), Inside or std length design.
Sizes/classifications Banded wedge /
narrow profile, raw edge construction
Examples A typical part number of R5VX950-4
is a 4 ribbed banded belt with an inside
length of 95, an outside length of 96.1,
with each rib having a 5VX profile.
38
Power-Wedge Chipper Band
Product Name Wedge-Band Chipper Drive V-Belt
Product Brand
Part No format R5VL, inside length (inches),
-5
Sizes/classifications Specialty banded belt for
wood chipper application raw edge laminated
construction, only in 5V profile and only in 5
rib configuration (only 10 sizes avail.)
Examples A Part Number of R5VL900-5 is a
chipper band with an inside length of 90,
and an outside length of 91.1. All CPT
Chipper bands are 5V and 5 Ribs.
39
Super Vee-Band
Product Name Super Vee-Band
Product Brand
Part No format R , Profile (BP, CP, DP),
inside length, - of ribs
Sizes/classifications Classical profile, wrap
molded const., Banded belt
Examples A typical part number of RBP210-4 is a
4 ribbed banded belt with an inside length of
210, an outside length of 214, with each
rib having a B profile.
40
V-Ribbed Belt
Product Name Vee-Rib
Product Brand
Part No format Effective length 10 (Inches),
profile, of ribs
Sizes/classifications Multi ribbed v-belt, raw
edge construction
Examples Part Number 2400L8 has an effective
length of 240, an L pitch (.185 tooth,
.38 depth) and has a total of 8 ribs.
41
Variable Speed Cog-Belt
Product Name Variable Speed Cog-Belt
Product Brand
Part No format Top Width, intended pulley
angle, v, length 10
Sizes/classifications
Examples A 2530V890, would have a top
width of 25/16 or 1-9/16, an intended pulley
angle of 30 degrees, and a length of 89
(890/10)
42
Snowmobile Belts

• Double cog performance
• Tough aramid cord
• Made with the best rubber compounds
• Increased belt life
• 1 selling snow belts

43
ATV Belts

• Exacting belt length tolerances
• Durable, aggressive operation
• Enhance efficiency of the variable speed drive
• Increased belt life

44
Thoro-Twist V-Belting
Product Name Thoro-Twist V-Belting
Product Brand Unbranded, comes in boxed rolls,
100 ft lengths
Part No format Profile (3L, A, B, C) twist
Sizes/classifications Specialty laminated
polyurethane (black) belting used for
emergency replacement of std belts. Can be
assembled by hand with no tools to any length.
Examples An order for 1 unit of b twist would
be a box containing a 100 foot roll of b
profile belting.
45
U.S. Customer Service 866-773-2926
Canada 866-797-2358
www.CarlisleBelts.com info_at_CarlisleBelts.com
