Computational Intelligence

1
Computational Intelligence a Possible Solution
for Unsolvable Problems

• Annamária R. Várkonyi-Kóczy
• Dept. of Measurement and Information Systems,
• Budapest University of Technology and Economics
• koczy_at_mit.bme.hu

2
Contents

• Motivation Why do we need something
  non-classical?
• What is Computational Intelligence?
• How CI works?
• About some of the methods of CI
• Fuzzy Logic
• Neural Networks
• Genetic Algorithms
• Anytime Techniques
• Engineering view Practical issues
• Conclusions Is CI really solution for
  unsolvable problems?

3
Motivation Why do we need something
non-classical?

• Nonlinearity, never unseen spatial and temporal
  complexity of systems and tasks
• Imprecise, uncertain, insufficient, ambiguous,
  contradictory information, lack of knowledge
• Finite resources ? Strict time requirements
  (real-time processing)
• Need for optimization
• Users comfort
• New challanges/more complex tasks to be solved ?
  more sophisticated solutions needed

4
Never unseen spatial and temporal complexity of
systems and tasks
How can we drive in heavy traffic? Many
components, very complex system. Can classical or
even AI systems solve it? Not, as far as we
know. But WE, humans can. And we would like to
build MACHINES to be able to do the same.
Our car, save fuel, save time, etc.
5
Never unseen spatial and temporal complexity of
systems and tasks

• Help
• Increased computer facilities
• Model integrated computing
• New modeling techniques
• Approximative computing
• Hybrid systems

6
Imprecise, uncertain, insufficient, ambiguous,
contradictory information, lack of knowledge

• How can I get to Shibuya?
• (Person 1 Turn right at the lamp, than straight
  ahead till the 3rd corner, than right again ...
  NO better turn to the left) (Person 2 Turn
  right at the lamp, than straight ahead till appr.
  the 6th corner ... than I dont know) (Person 3
  It is in this direction ? somewhere ...)
• It is raining
• The traffic light is out of order
• I dont know in which building do we have the
  special lecture (in Building III or II or ...)?
  And at what time???? (Does it start at 3 p.m. or
  at 2 p.m? And on the 3rd or 4th of October?)
• When do I have to start from home at at what
  time?
• Who (a person or computer) can show me an
  algorithm to find an OPTIMUM solution?

7
Imprecise, uncertain, insufficient, ambiguous,
contradictory information, lack of knowledge

• Help
• Intelligent and soft computing techniques being
  able to handle the problems
• New data acquisition and representation
  techniques
• Adaptivity, robustness, ability to learn

8
Finite resources ? Strict time requirements
(real-time processing)

• It is 10.15 a.m. My lecture starts at 3 p.m.
  (hopefully the information is correct)
• I am still not finished with my homework
• I have run out of the fuel and I dont have
  enough money for a taxi
• I am very hungry
• I have promised my Professor to help him to
  prepare some demo in the Lab this morning
• I can not fulfill everything with maximum
  preciseness

9
Finite resources ? Strict time requirements
(real-time processing)

• Help
• Low complexity methods
• Flexible systems
• Approximative methods
• Results for qualitative evaluations for
  supporting decisions
• Anytime techniques

10
Need for optimization

• Traditionally
• optimization precision
• New definition
• optimization cost optimization
• But what is cost!?
• presition and certainty also carry a cost

11
Need for optimization

• Lets look TIME as a resource
• The most important thing is to go the Lab and
  help my Professor (He is my Professor and I have
  promised it). I will spend there as needed, min.
  3 hours
• I have to submit the homework, but I will work in
  the Lab., i.e. today I will prepare an average
  and not a maximum level homework (1 hour)
• I dont have time to eat at home, I will buy a
  bento at the station (5 minutes)
• The train is more expensive then the bus but
  takes much less time, i.e. I will go by train (40
  minutes)

12
Users comfort

• I have to ask the way to the university but
  unfortunately, I dont speak Japanese
• Next time I also want to find my way
• Today it took one and a half hour to get here.
  How about tomorrow?
• It would be good get more help
• ....

13
Users comfort

• Help
• Modeling methods and representation techniques
  making possible to
• handle
• interprete
• predict
• improve
• optimise the system and
• give more and more support in the processing

14
Users comfort
Human language Modularity, simplicity,
hierarchical structures Aims of the processing
preprocessing
processing
improving the performance of the
algorithms giving more support to the processing
(new)
aims of preprocessing
image processing / computer vision
noise smoothing feature extraction (edge, corner
detection) pattern recognition, etc. 3D
modeling, medical diagnostics, etc. automatic 3D
modeling, automatic ...
preprocessing
processing
15
The most important elements of the solution

• Low complexity, approximative modeling
• Application of adaptive and robust techniques
• Definition and application of the proper cost
  function including the hierarchy and measure of
  importance of the elements
• Trade-off between accuracy (granularity) and
  complexity (computational time and resource need)
• Giving support for the further processing
• These do not cope with traditional and AI
  methods.
• But how about the new approaches, about
  COMPUTATIONAL INTELLIGENCE?

16
What is Computational Intelligence?

• Computer Intelligence

Increased computer facilities
Added by the new methods
L.A. Zadeh, Fuzzy Sets 1965 In traditional
hard computing, the prime desiderata are
precision, certainty, and rigor. By contrast, the
point of departure of soft computing is the
thesis that precision and certainty carry a cost
and that computation, reasoning, and decision
making should exploit whenever possible the
tolerance for imprecision and uncertainty.
17
What is Computational Intelligence?

• CI can be viewed as a corsortium of methodologies
  which play important role in conception, design,
  and utilization of information/intelligent
  systems.
• The principal members of the consortium are
  fuzzy logic (FL), neuro computing (NC),
  evalutionary computing (EC), anytime computing
  (AC), probabilistic computing (PC), chaotic
  computing (CC), and (parts of) machine learning
  (ML).
• The methodologies are complementary and
  synergistic, rather than competitive.
• What is common Exploit the tolerance for
  imprecision, uncertainty, and partial truth to
  achieve tractability, robustness, low solution
  cost and better rapport with reality.

18
Computational Intelligence fulfill all of the
five requirements(Low complexity,
approximative modelingapplication of adaptive
and robust techniquesDefinition and application
of the proper cost function including the
hierarchy and measure of importance of the
elementsTrade-off between accuracy (granularity)
and complexity (computational time and resource
need)Giving support for the further processing)
19
How CI works?1. Knowledge

• Information acquisition (observation)
• Information processing (numeric, symbolic)
• Storage and retrieval of the information
• Search for a structure (algorithm for the
  non-algorithmizable processing)
• Certain knowledge (can be obtained by formal
  methods) closed, open world ABSTRACT WORLDS)
• Uncertain knowledge (by cognitive methods)
  (ARTIFICIAL and REAL WORLDS)
• Lack of knowledge
• Knowledge representation

20
How CI works?1. Knowledge

• In real life nearly everything is optimization
• (Ex.1. Determination of the velocity
  Calculation of the optimum estimation of the
  velocity from the measured time and done
  distance)
• Ex.2. Determination of the resistance the
  optimum estimation of the resistance with the
  help of the measured intensity of current and
  voltage
• Ex.3. Analysis of a measurement result the
  optimum estimation of the measured quantity in
  the kowledge of the conditions of the measurement
  and the measured data)
• Ex. 4. Daily time-table
• Ex. 5. Optimum route between two towns
• In Ex. 1-3 the criteria of the optimization is
  unambiguos and easily can be given
• Ex. 4-5 are also simple tasks but the criteria is
  not unambiguos

21

• Optimum route
• What is optimum? (Subjective, depending on the
  requirements, taste, limits of the person)
• - We prefer/are able to travel by aeroplane,
  train, car, ...
• Lets say car is selected
• the shortest route (min petrol need), the
  quickest route (motorway), the most beautiful
  route with sights (whenever it is possible I
  never miss the view of the Fuji-san ...), where
  by best restaurants are located, where I can
  visit my friends, ...
• OK, lets fix the preferences of a certain
  person
• But is it summer or winter, is it sunshine or
  raining, how about the road reconstructions, ....
• By going into the details we get nearer and
  nearer to the solution
• Knowledge is needed for the determination of a
  good descriptive model of the circumstances and
  goals
• But do we know what kind of wheather will be in
  two months?

22
2. Model

• Known model e.g. analithic model (given by
  differential equations) - too complex to be
  handled
• Lack of knowledge - the information about the
  system is uncertain or imperfect
• We need new, more precise knowledge
• The knowledge representation (model) should be
  handable and should tolerate the problems

23
Learning and Modeling

• New knowledge by learning
• Unknown, partially unknown, known but too complex
  to be handled, ill-defined systems
• Model by which we can be analyze the system and
  can predict the behavior of the system
• Criteria (quality measure) for the validity of
  the model

24
u
Input
d
c
Measure of the quality of the model
y
Parameter tuning
1. Observation (u, d, y), 2. Knowledge
representation (model, formalism), 3. Decision
(optimizasion, c(d,y)), 4. Tuning (of the
parameters), 5. Environmental influence,(non-obser
ved input, noise, etc.) 6. Prediction ability
(for the future input)
25
Iterative procedure

We build a system for collecting information
We improve the system by building in the
knowledge
We collect the information
We improve the observation and collect more
information
26
Problem
Knowledge representation, Model
Represented knowledge
Independant space, coupled to the problem by the
formalism
Non-represented part of the problem
27
3. Optimization

• Valid where the model is valid
• Given a system with free parameters
• Given an objective measure
• The task is to set the parameters which mimimize
  or maximize the qualitative measure
• Systematic and random methods
• Exploitation (of the deterministic knowledge) and
  exploration (of new knowledge)

28
Methods of Computational Intelligence

• fuzzy logic low complexity, easy build in of the
  a priori knowledge into computers, tolerance for
  imprecision, interpretability
• neuro computing - learning ability
• evalutionary computing optimization, optimum
  learning
• anytime computing robustness, flexibility,
  adaptivity, coping with the temporal
  circumstances
• probabilistic reasoning uncertainty, logic
• chaotic computing open mind
• machine learning - intelligence

29
Fuzzy Logic

• Lotfi Zadeh, 1965
• Knowledge representation in natural language
• computing with words
• Perceptions
• Value imprecisiation ?meaning precisiation

30
History of fuzzy theory

• Fuzzy sets logic Zadeh 1964/1965-
• Fuzzy algorithm Zadeh 1968-(1973)-
• Fuzzy control by linguistic rules Mamdani Al.
  1975-
• Industrial applications Japan 1987- (Fuzzy
  boom), KoreaHome electronicsVehicle
  controlProcess controlPattern recognition
  image processingExpert systemsMilitary systems
  (USA 1990-)Space research
• Applications to very complex control problems
  Japan 1991-e.g. helicopter autopilot

31
Areas in which Fuzzy Logic was succesfully used

• Modeling and control
• Classification and pattern recognition
• Databases
• Expert Systems
• (Fuzzy) hardware
• Signal and image processing
• Etc.

32

• Universe of discourse Cartesian (direct) product
  of all the possible values of each of the
  descriptors
• Linguistic variable (linguistic term) Zadeh
  By a linguistic variable we mean a variable
  whose values are words or sentences in a natural
  or artificial language. For example, Age is a
  linguistic variable if its values are linguistic
  rather than numerical, i.e., young, not young,
  very young, quite young, old, not very old and
  not very young, etc., rather than 20, 21, 22, 23,
  ...
• Fuzzy set It represents a property of the
  linguistic variable. A degree of includance is
  associated to each of the possible values of the
  linguistic variable (characteristic function)
• Membership value The degree of belonging into
  the set.

33
An Example

• A class of students (e.g. M.Sc. Students taking
• the Spec. Course Computational Intelligence)
• The universe of discourse X

• Who does have a drivers license?
• A subset of X A (Crisp) Set
• ?(X) CHARACTERISTIC FUNCTION

• 1 0 1 1 0 1 1

• Who can drive very well?
• ?(X) MEMBERSHIP FUNCTION

• 0.7 0 1.0 0.8 0 0.4 0.2

FUZZY SET
34
Definitions

• Crisp set
• Convex setA is not convex as a?A, c?A,
  butd?a(1-?)c ?A, ??0, 1.B is convex as for
  every x, y?B and??0, 1 z?x(1-?)y ?B.
• Subset

35
Definitions

• Relative complement or differenceABx x?A
  and x?BB1, 3, 4, 5, AB2, 6.C1, 3, 4,
  5, 7, 8, AC2, 6!
• Complement where X is
  the universe.Complementation is
  involutiveBasic properties
• UnionA?Bx x?A or x?B
• For

(Law of excluded middle)
36
Definitions

• IntersectionA?Bx x?A and x?B. For

• More properties Commutativity A?BB?A,
  A?BB?A. Associativity A?B?C(A?B)?CA?(B?C)
  , A?B?C(A?B)?CA?(B?C). Idempotence
  A?AA, A?AA. Distributivity A?(B?C)(A?
  B)?(A?C), A?(B?C)(A?B)?(A?C).

(Law of contradiction)
37
Membership function
Crisp set Fuzzy set
Characteristic function Membership function
?AX?0, 1 ?AX?0, 1
38
Some basic concepts of fuzzy sets
Ele-ments Infant Adult Young Old
5 0 0 1 0
10 0 0 1 0
20 0 .8 .8 .1
30 0 1 .5 .2
40 0 1 .2 .4
50 0 1 .1 .6
60 0 1 0 .8
70 0 1 0 1
80 0 1 0 1
39
Some basic concepts of fuzzy sets

• Support supp(A)x ?A(x)gt0.
  supp?Infant0, so supp(Infant)0.If
  supp(A)lt?, A can be defined A?1/x1 ?2/x2
  ?n/xn.
• Kernel (Nucleus, Core) Kernel(A)x
  ?A(x)1.

40
Definitions

• Height
• height(old)1 height(infant)0
• If height(A)1 A is normal
• If height(A)lt1 A is subnormal
• height(0)0
• (If height(A)1 then supp(A)0)
• a-cut
• Strong Cut
• Kernel
• Support
• If A is subnormal, Kernel(A)0

41
Definitions

• Fuzzy set operations defined by L.A. Zadeh in
  1964/1965
• Complement
• Intersection
• Union

?(x)
42
Definitions
This is really a generalization of crisp set ops!
A B ?A A?B A?B 1-?A min max
0 0 1 0 0 1 0 0
0 1 1 0 1 1 0 1
1 0 0 0 1 0 0 1
1 1 0 1 1 0 1 1
43
Fuzzy Proportion

• Fuzzy proportion X is PTina is young,
  whereTina Crispage, young fuzzy
  predicate.

Fuzzy sets expressing linguistic terms for ages
Truth claims Fuzzy sets over 0, 1

• Fuzzy logic based approximate reasoning
• is most important for applications!

44
? CRISP RELATION SOME INTERACTION OR
ASSOCIATION BETWEEN ELEMENTS OF TWO OR MORE
SETS. ? FUZZY RELATION VARIOUS DEGREES OF
ASSOCIATION CAN BE REPRESENTED A B A B
? ? ? ? ? ? ? ? ? ? ?
? ? ? CRISP RELATION FUZZY
RELATION ? CARTESIAN (DIRECT) PRODUCT OF TWO
(OR MORE) SETS X, Y X ? Y (x,y) ?
x ? X, y ? Y X ? Y ? Y ? X IF X ? Y
! MORE GENERALLY ? xi (x1,
x2, , xn) ? xi ? Xi , i ? Nn
0.5
0.8
1
0.9
0.6
CR
FR
n
i 1
45
Fuzzy Logic Control

• Fuzzification converts the numerical value to a
  fuzzy one determines the degree of matching
• Defuzzification converts the
• fuzzy term to a classical numerical value
• The knowledge base contains the fuzzy rules
• The inference engine describes the methodology to
  compute the output from the input

46
Fuzzyfication
µ
1
8,4
X
The measured (crisp) value is converted to a
fuzzy set containing one element with membership
value1
µ(x) 1 if x8,4 0 otherwise
47
DefuzzificationCenter of Gravity Method (COG)
48
Specificity of fuzzy partitions
Fuzzy Partition A containing three linguistic
terms
Fuzzy Partition A containing seven linguistic
terms
49
Fuzzy inference mechanism (Mamdani)

• If x1 A1,i and x2 A2,i and...and xn An,i
  then y Bi

The weighting factor wji characterizes, how far
the input xj corresponds to the rule antecedent
fuzzy set Aj,i in one dimension
The weighting factor wi characterizes, how far
the input x fulfils to the antecedents of the
rule Ri.
50
Conclusion
The conclusion of rule Ri for a given x
observation is yi
51
Fuzzy Inference

• Mamdani Type

52
Fuzzy systems an example
TEMPERATURE
MOTOR_SPEED
Fuzzy systems operate on fuzzy rules IF
temperature is COLD THEN motor_speed is LOW IF
temperature is WARM THEN motor_speed is MEDIUM IF
temperature is HOT THEN motor_speed is HIGH
53
Inference mechanism (Mamdani)
Temperature 55
Motor Speed
RULE 1
RULE 2
RULE 3
Motor Speed 43.6

54
Planning of Fuzzy Controllers

• Determination of fuzzy controllers
  determination of the antecedents consequents of
  the rules
• Antecedents
• Selection of the input dimensions
• Determination of the fuzzy partitions for the
  inputs
• Determination of the parameters for the fuzzy
  variables
• Consequents
• Determination of the parameters

55
Fuzzy-controlled Washing Machine (Aptronix
Examples)

• Objective
• Design a washing machine controller, which
  gives the correct wash time even though a precise
  model of the input/output relationship is not
  available
• Inputs
• Dirtyness, type of dirt
• Output
• Wash time

56
Fuzzy-controlled Washing Machine

• Rules for our washing machine controller are
  derived from common sense data taken from typical
  home use, and experimentation in a controlled
  environment.
• A typical intuitive rule is as follows
• If saturation time is long and transparency
  is bad,then wash time should be long.

57
Air Conditioning Temperature Control

• Temperature control has several unfavorable
  features non-linearity, interference, dead time,
  and external disturbances, etc.
• Conventional approaches usually do not result in
  satisfactory temperature control.
• Rules for this controller may be formulated using
  statements similar to
•  If temperature is low then open heating valve
  greatly

There is a sensor in the room to monitor
temperature for feedback control, and there are
two control elements, cooling valve and heating
valve, to adjust the air supply temperature to
the room.
58
Air Conditioning Temperature Control Modified
Model

• There are two sensors in the modified system one
  to monitor temperature and one to monitor
  humidity. There are three control elements
  cooling valve, heating valve, and humidifying
  valve, to adjust temperature and humidity of the
  air supply.

Rules for this controller can be formulated by
adding rules for humidity control to the basic
model. If temperature is low then open
humidifying valve slightly. This rule acts as a
predictor of humidity (it leads the humidity
value) and is also designed to prevent overshoot
in the output humidity curve.
59
Smart Cars 1 - Rules

• The number of rules depends on the problem. We
  shall consider only two for the simplicity of the
  example
• Rule 1 If the distance between two cars is short
  and the speed of your car is high(er than the
  other ones), then brake hard.
• Rule 2 If the distance between two cars is
  moderately long and the speed of your car is
  high(er than the other ones), then brake
  moderately hard.

60
Smart Cars 2 Membership Functions

• Determine the membership functions for the
  antecedent and consequent blocks
• Most frequently 3, 5 or 7 fuzzy sets are used (3
  for crude control, 5 and 7 for finer control
  results)
• Typical shapes (triangular most frequent)

61
Smart Cars 3 Simplify Rules using Codes

• Distance between two cars X1 speed X2Breaking
  strength YLabels- small, medium, large S, M, L
• In the case of X2 (speed), small, medium, and
  large mean the amount that this car's speed is
  higher than the car in front.
• Rule 1
• If X1S and X2M, then YL Rule 2
• If X1M and X2L, then YM

PL - Positive LargePM - Positive MediumPS -
Positive SmallZR - Aproximately ZeroNS -
Negative SmallNM - Negative MediumNL - Negative
Large
62
Smart Cars 4 - Inference

• Determine the degree of matching
• Adjust the consequent block
• Total evaluation of the conclusions based on the
  rules
• To determine the control amount at a certain
  point, a defuzzifier is used (e.g. the center of
  gravity). In this case the center of gravity is
  located at a position somewhat harder than medium
  strength, as indicated by the arrow

63
Advantages of Fuzzy Controllers

• Control design process is simpler
• Design complexity reduced, without need for
  complex mathematical analysis
• Code easier to write, allows detailed simulations
• More robust, as tests with weight changes
  demonstrate
• Development period reduced

64
Neural Networks

• (McCullogh Pitts, 1943, Hebb, 1949)
• Rosenblatt, 1958 (Perceptrone)
• Widrow-Hoff, 1960 (Adaline)
• It mimics the human brain

65
Neural Networks

• Neural Nets are parallel, distributed information
  processing tools which are
• Highly connected systems composed of identical or
  similar operational units evaluating local
  processing (processing element, neuron) usually
  in a well-ordered topology
• Possessing some kind of learning algorithm which
  usually means learning by patterns and also
  determines the mode of the information processing
• They also possess an information recall algorithm
  making possible the usage of the previously
  learned information

66
Application area where NNs are succesfully used

• One and multidimentional signal processing (image
  processing, speach processing, etc.)
• System identification and control
• Robotics
• Medical diagnostics
• Economical features estimation

67
Application area where NNs are succesfully used

• Associative memory content addresable memory
• Classification system (e.g. Pattern recognition,
  character recognition)
• Optimization system (the usually feedback NN
  approximates the cost function) (e.g. radio
  frequency distribution, A/D converter, traveling
  sailsman problem)
• Approximation system (any input-output mapping)
• Nonlinear dynamic system model (e.g. Solution of
  partial differtial equation systems, prediction,
  rule learning)

68
Main features

• Complex, non-linear input-output mapping
• Adaptivity, learning ability
• distributed architecture
• fault tolerant property
• possibility of parallel analog or digital VLSI
  implementations
• Analogy with neurobiology

69
The simple neuron
Linear combinator with non-linear activation
70
Typical activation functions
step linear sections tangens
hyperbolic sygmoid
71
Classical neural nets

• Static nets (without memory, feedforward
  networks)
• One layer
• Multi layer
• MLP (Multi Layer Perceptron)
• RBF (Radial Basis Function)
• CMAC (Cerebellar Model Artculation Controller)
• Dynamic nets (with memory or feedback recall
  networks)
• Feedforward (with memory elements)
• Feedback
• Local feedback
• Global feedback

72
Feedforward architectures
One layer architectures Rosenblatt perceptron
73
Feedforward architectures
One layer architectures
Input
Output
Tunable parameters (weighting factors)
74
Feedforward architectures
Multilayer network (static MLP net)
75
Approximation property

• universal approximation property for some kinds
  of NNs
• Kolmogorov Any continuous real valued N
  variable function defined over the 0,1N compact
  interval can be represented with the help of
  appropriately chosen 1 variable functions and sum
  operation.

76
Learning

• Learning parameter estimation
• supervised learning
• unsupervised learning
• analytic learning

77
Supervised learning
estimation of the model parameters by x, y, d
n (noise)
x
d
Input
CC(e)
y
Parameter tuning
78
Supervised learning

• Criteria function
• Quadratic
• ...

79

• Minimization of the criteria
• Analytic solution (only if it is very simple)
• Iterative techniques
• Gradient methods
• Searching methods
• Exhaustive
• Random
• Genetic search

80
Parameter correction

• Perceptron
• Gradient methods
• LMS (least means square algorithm)
• ...

81
LMS (Iterative solution based on the temporary
error)

• Temporary error
• Temporary gradient
• Weight update

82
Gradient methods

• The route of the convergence

83
Gradient methods

• Single neuron with nonlinear acticvation
• Multilayer network backpropagation (BP)

84
Teaching an MLP network The Backpropagation
algorithm
85
Design of MLP networks

• Size of the network (number of layers, number of
  hidden neurons)
• The value of the learning factor, µ
• Initial values of the parameters
• Validation, learning set, test set
• Teaching method (sequential, batch)
• Stopping criteria (error limit, number of
  cycles)

86
Modular networks

• Hierarchical networks
• Linear combination of NNs
• Mixture of experts
• Hybrid networks

87
Linear combination of networks
88
Mixture of experts (MOE)
Gating network
experts
89
Decomposition of complex tasks

• Decomposition and learning
• Decomposition before learning
• Decomposition during the learning (automatic task
  decomposition)
• Problem space decomposition
• Input space decomposition
• Output space decomposition

90
Example Automatic recognition of numbers (e.g.
Postal code)

• Binary pictures with 16x16 pixels
• Preprocessing (idea the numbers are composed of
  edge segments) 4 edge detections
• normalization ? four 8x8 pictures (i.e. 256
  input elements
• Classification by 45 independant networks, each
  classifying only two classes of the ten figures
  (1 or 2, 1 or 3, ..., 8 or 0, 9 or 0)
• The corresponding network output are connected to
  an AND gate, if its output equals to 1 then the
  figure is recognized

91
Example Automatic recognition of handwritten
figures (e.g. Postal codes)
Edge detection
normalization
horizontal
input
diagonal \
Edge detection masks
vertical
diagonal /
92
Example Automatic recognition of handwritten
figures (e.g. Postal codes)
93
Genetic Algorithms

• John Holland, 1975
• Adaptive method for searching and optimization
  problems
• Copying the genetic processes of the biological
  organisms
• Natural selection (Charles Darwin The Origin of
  Species)
• Multi points search

94
Successful applicational areas

• Optimization (circuit design, scheduling)
• Automatic programming
• Machine learning (classification, prediction,
  wheather forecast, learning of NNs)
• Economical systems
• Immunology
• Ecology
• Modeling of social systems

95
The algorithm

• Initial population ? parent selection ? creation
  of new individuals (crossover, mutation) ?
  quality measure, reproduction ? new generation ?
  exit criteria?
• If no continue with the algorithm
• If yes selection of the result, decoding
• Like in biology in real word

96
Problem building

• Selection of the most important features, coding
• Fitness function quality measure (optimum
  criterium)
• Exit criteria
• Selection of the size of the population
• Specification of the genetic operations

97
Simple genetic algorithms

• Representation features coded in a binary
  string (chromosome, string)
• Fitness function representing the viability
  (optimality) of the individual
• Selection selecting the parent individuals from
  the generation (e.g. random but fitness based,
  i.e. better chance with higher fittness value)

98
Simple genetic algorithms

• Crossover from 2 parents two offsprings (one
  point, two point, N-point, uniform)

?
99
Simple genetic algorithms

• Mutation (of the bits (genes)) (one or
  independant)
• Reproduction who will survive and form the next
  (new) generation
• Individuals with the best fitness function
• Exit after a number of generation or depending
  on the fitness function of the best individual or
  average of the generation, ...

?
100
Example for GAs

• Maximize the f(x)x2 function where x can take
  values between 0 and 31
• Lets start with a population containing 4
  elements (generated randomly by throwing a coin).
  Each element (string) consists of 5 bits (to be
  able to code numbers between 0 and 31)

101
Example for GAs
number Initial population x value f(x) f(xi)/? f(x) ranking
1 01101 13 169 0.14 1
2 11000 24 576 0.49 2
3 01000 8 64 0.06 0
4 10011 19 361 0.31 1
Sum 1170 1170 1.00 4
Average 293 293 0.25 1
Maximum 576 576 0.49 2
102
Example for GAs
The pairs Sequence of the selection Position of the crossover New population x value f(x)
0 1 1 0 1 2 4 01100 12 144
1 1 0 0 0 1 4 11001 25 625
1 1 0 0 0 4 2 11011 27 729
1 0 0 1 1 3 2 10000 16 256
Sum 1754
Average 439
Maximum 729
103
Conclusions

• The fitness improved significantly in the new
  generation (both the average and the maximum)
• Initial population randomly chosen
• Selection 4 times by a roulette wheel where
  better individuals had bigger sectors having
  bigger chance (the 3rd (worst) string has died
  out!)
• Pairs the 1-2, 3-4 selections
• Position of the crossover randomly chosen
• Mutation bit by bit with p0.001 probability
• (the generation contains 20 bits, in average 0.02
  bit will be mutated in this example none)

104
Anytime Techniques Why do we need them?

• Larger scale signal processing (DSP) systems,
  Artificial Intelligence
• Limited amount of resources
• Abrupt changes in
• Environment
• Processing system
• Computational resources (shortage)
• Data flow (loss)
• Processing should be continued
• Low complexity ? lower, but possibly enough
  accuracy or partial results (for qualitative
  decisions)
• ? Anytime systems

105
Anytime Systems What do they offer?

• To handle abrupt changes due to failures
• To fulfill prescribed response time conditions
  (changeable response time)
• Continuos operation in case of serious shortage
  of necessary data (temporary overload of certain
  communication channels, sensor failures, etc.)
  /processing time
• To provide appropriate overall performance for
  the whole system
• guaranteed response time, known error
• Flexibility available input data, available
  time, computational power, balance between time
  and quality(quality accuracy, resolution, etc)

106
Anytime systems How do they work?

• Conditions on-line computing, guaranteed
  response time, limited resources (changing in
  time)
• Anytime processing coping with the temporarily
  available resources to maintain the overall
  performance
• correctmodels, treatable by the limited
  resources during limited time, low and changeable
  complexity, possibility of reallocation of the
  resources, changeable and guaranteed response
  time/ computational need, known error
• tools iterative algorithms, other types of
  methods used in a modular architecture

107

• optimization of the whole system (processing
  chain) based on intelligent decisions (expert
  system, shortage indicators)
• algorithms and models of simpler complexity
• temporarily lower accuracy
• data for qualitative evaluations for supporting
  decisions
• coping with the temporal conditions
• supporting early decision making
• preventing serious alarm situations

108

• Shortage indicators
• Intelligent monitor
• Special compilation methods during runtime
• Strict time constraints for the monitor
• The number and the complexity of the executable
  task can be very high
• ?
• add-in optimization

109
Missing input samples

• Temporary overload of certain communication
  channels, sensor failures, etc. Þ the input
  samples fail to arrive in time or will be lost
• ß
• prediction mechanism (estimations based on
  previous data)
• example resonator based filters

110
Temporal shortage of computing power

• Temporary shortage of computer power Þ the signal
  processing can not be performed in time
• ß
• Trade-off between the approximation accuracy and
  the complexity
• complexity reduction techniques, reduction of the
  sampling rate, application of less accurate
  evaluations

111
Temporal shortage of computing power

• Examples
• application of lower order filters or
  transformers (in case of recursive discrete
  transformers to switch off some of the channels,
  obvious req. to maintain e.g. the orthogonality
  of the transformations
• Singular Value Decomposition applied to fuzzy
  models, B-spline neural networks, wavelet
  functions, Gabor functions, etc. - fuzzy filters,
  human hearing system, generalized NNs

112
Temporal shortage of computing time

• Temporary shortage of computer time Þ the signal
  processing can not be performed in time
• Examples
• block-recursive filters and filter-banks
• overcomplete signal representations

113
Anytime algorithms iterative methods

• Evaluate 734/25! (after 1 second appr. 30 ?
  after 5 seconds better 29,3 ? after 8 seconds
  exactly 29,36

We build a system for collecting information
We improve the system by building in the
knowledge
We collect the information
We improve the observation and collect more
information
114
Anytime algorithms modular architecture

• Units Distinct/different implementations of a
  task,with the same interface but different
  performance characteristics
• characteristics
• complexity
• accuracy
• error transfer characteristic
• ? selection

115
Engineering view Practical issues

• Well defined mathematical fundation but there is
  a gap between the theory and the implementation
• When and which is working better? (the theory can
  not give any answer or is lazy to think over?)
• How to choose the sizes/parameters/shapes/definiti
  ons/etc.?
• What if the axioms are inconsistant/incomplete?
  (the practical possibility can be 0)
• Handling of the exceptions, e.g. the rule for
  very young overwrites the rule young
• Good advises Modeling, a priori knowledge,
  iteration, hybrid systems, smooth
  systems/parameters (as near to the real world as
  possible)

116
Accuracy problems

• How can we handle accuracy problems if we e.g.
  dont have any input information?
• What if in time critical applications not only
  the stationary responses are to be considered?
• How can the different modeling/data
  representation methods interprete the others
  results?
• New (classicalnonclassical) measures are needed

117
Transients

• Dynamic systems
• Change in the systems Þ transients
• Depending on the transfer function and on the
  actual implementation of the structure
• Strongly related to the energy distribution of
  the system
• Effected by the steps and the reconfiguration
  route

118
Transients

• Must be reduced and treated
• careful choosing of the architecture (orthogonal
  structures have better transients)
• multi step reconfiguration selection of the
  number and location of the intermediate steps
• estimation of the effect of transients

119
Is CI really solution for unsolvable problems?

• Yes The high number of succesful applications
  and the new areas where automatization became
  possible prove that Computational Intelligence
  can be a solution for otherwise unsolvable
  problems
• Although With the new methods new problems have
  arised to be solved by you
• Future engineering is unthinkable without
  Computational Intelligence

120
Conclusions

• What is Computational Intelligence?
• What is the secret of its success?
• How does it work?
• What kind of approaches/concepts are attached?
• New problems with open questions
