Enterprise Java Beans

1
Enterprise Java Beans

• Adam, Engels, Josh, Marc, Tim

2
What Are EJBs?

• Enterprise Java Beans
• EJB special kind of JavaBean for performing
  server-side business logic
• More powerful version of the regular beans that
  weve used in class

3
Where they fit in a system
4
EJBs in J2EE
5
Three kinds of EJBs

• Session
• associate client information with a specific
  client
• both stateless and stateful versions
• Entity
• groups associated information in an abstraction
  that provides transaction support
• Message Bean - rarely used, hardly supported

6
What is a Session Bean?

• Represents a single Client inside the J2EE server
• one client at a time/ not persistent
• when the client terminates, the session bean is
  disassociated from the client
• There are two types Stateful and Stateless...

7
Stateful

• These represent a set of interactions between
  client and server.
• Example shopping cart
• Saves information over several method
  invocations.
• There is a lot of overhead associated with using
  stateful beans

8
Stateless Beans

• A stateless bean does not save information
  between method calls.
• Limited application
• Little overhead
• multiple clients can use the same bean instance
  without alteration
• Example fetch from a read-only database or send
  a confirmation email for an order

9
Entity Beans

• Associates pieces of information in a group
• Accessed by multiple clients at a time
• Persistent and Serializable
• The container loads and stores the entity beans
  in the database
• These are more similar to regular beans

10
More on Entity Beans

• Transactions this is what makes an Entity Bean
  special.
• Entity beans rely on the container to enforce
  robust transactions
• example Airline booking if the flight booking
  action fails, then the credit card charge action
  fails, or vice versa.

11
Persistence in Entity Beans

• Container managed persistence
• the container controls when the bean is read from
  or written to the database
• Bean managed persistence
• the beans implementation performs all of the sql
  operations that loads, stores, and updates the
  beans data to or from the database.
• Bean is responsible for connection allocation to
  the database

12
Connection Pooling

• Setting up connections to the database is
  resource intensive
• Connection pooling maintains a pool of database
  connections for the entity beans so that the
  connection is maintained when a bean finishes,
  and is available for other entity beans.
• Specific to database and EJB container
  implementation

13
Message Beans

• A message bean is an enterprise bean that allows
  J2EE applications to process messages
  asynchronously. It acts as a JMS message
  listener, which is similar to an event listener
  except that it receives messages instead of
  events.
• Many systems do not yet support JMS, message bean
  use is currently not widespread

14
Using an Entity bean from a Session bean

• An entity bean can be shared by multiple
  sessions.
• This allows for data encapsulation clients can
  interact with data via session beans within
  transaction boundaries.
• Can do all database interaction from session bean
  as an alternative
• encapsulation is weakened

15
Using EJBs
16
An EJB Example...

• Online Banking Application
• Demonstrates how all the component
  technologies--enterprise beans, J2EE application
  clients, and Web components fit together

17
Online Banking Application

• Two clients
• a J2EE application client used by administrators
  to manage customers and accounts
• Web client used by customers to access account
  histories and perform transactions. The clients
  access the customer, account, and transaction
  information maintained in a database through
  enterprise beans.

18
Online Bank Application Overview
19
Session beans used

• The online bank application has three session
  beans AccountControllerEJB, CustomerControllerEJB
  , and TxControllerEJB. These session beans
  provide a client's view of the application's
  business logic. Hidden from the clients are the
  server-side routines that implement the business
  logic, access databases, manage relationships,
  and perform error checking.

20
Entity Beans used

• For each business entity represented in our
  simple bank, the bank application has a matching
  entity bean
• AccountEJB, CustomerEJB, TxEJB
• The purpose of these beans is to provide an
  object view of these database tables account,
  customer, and tx. For each column in a table, the
  corresponding entity bean has an instance
  variable. Because they use bean-managed
  persistence, the entity beans contain the SQL
  statements that access the tables. For example,
  the create method of the CustomerEJB entity bean
  calls the SQL INSERT command.

21
Database
22
Security in this example

• you can protect an enterprise bean by specifying
  the security roles that can access its methods In
  the bank application, two roles are
  defined--BankCustomer and BankAdmin
• BankAdmin role is allowed to perform
  administrative functions creating or removing an
  account, adding a customer to or removing a
  customer from an account, setting a credit line,
  and setting an initial balance.
• BankCustomer role is allowed to deposit,
  withdraw, transfer funds, make charges and
  payments, and list the account's transactions.
  Notice that there is no overlap in functions that
  users in either role can perform

23
security continued...

• Access to these functions was restricted to the
  appropriate role by setting method permissions on
  selected methods of the CustomerControllerEJB,
  AccountControllerEJB, and TxControllerEJB
  enterprise beans. For example, by allowing only
  users in the BankAdmin role to access the
  createAccount method in the AccountControllerEJB
  enterprise bean, you have denied users in the
  BankCustomer role or any other role permission to
  create bank accounts.
• Set method permissions in the container with the
  deploy tool for each role

24
BankCustomer Role Mapped to Customer Group
25
Underlying TechnologiesRMI

• RMI - Remote Method Invocation
• instead of invoking a method on another Java
  object running in the same JVM, you invoke a
  method in a Java object in another JVM on the
  same computer or another one.
• Using an interface, RMI hides the fact that you
  are invoking a method remotely
• The Remote and Home interfaces for an EJB must be
  RMI interfaces

26
Underlying TechnologiesJNDI

• JNDI - Java Naming and Directory Interface
• JNDI provides a uniform way to access naming and
  directory services
• You use JNDI to locate EJBs and JDBC connection
  pools from within your EJB container
• When a client needs to access a beans Home
  interface, it uses JNDI to locate the Home
  interface. After you locate an object, you
  communicate directly with it instead of going
  through JNDI
• You dont need to know much about JNDI for EJBs
  except for a few setup calls.

27
Underlying TechnologiesJDBC

• JDBC - Java Database Connectivity
• gives you a standard API in which to communicate
  with different types of databases
• If you use CMP (Container Managed Persistence)
  theres a chance that you wont use JDBC at all.
  However there are still a few cases in which CMP
  doesnt handle all the different ways that you
  can access data.

28
Bean DesignThe Home interface

• The 2 main functions of the home interface are
  creating beans and locating beans
• Only entity beans need methods to locate beans

import java.rmi. import javax.ejb. public
interface HelloWorldHome extends EJBHome public
MyBean create() throws RemoteException,CreateExcep
tion MyBean findByPrimaryKey(String
myEntityKey) throws RemoteException,CreateExce
ption
29
Bean designThe Remote Interface

• Consists of the remote methods you can call on a
  bean after the bean has been created and located.

import java.rmi. public interface
HelloWorld public String getGreeting() throws
RemoteException
30
Bean DesignBean Implementation

• import java.rmi.
• import java.util.
• import javax.ejb.
• public class HelloWorldImpl implements
  SessionBean
• protected String greeting
• private SessionContext context
• / An EJB must have a public, parameterless
  constructor /
• public HelloWorldSessionImpl()
• / Called by the EJB container when a client
  calls the create() method in
• the home interface /
• public void ejbCreate() throws
  CreateException
• greeting "Hello World!"
• / Returns the session's greeting /
• public String getGreeting()

31
/ Called by the EJB container to wake this
session bean up after it has been put to
sleep with the ejbPassivate method. / public
void ejbActivate() public void
ejbPassivate() public void
ejbRemove() / Called by the EJB container to
set this session's context / public void
setSessionContext(SessionContext aContext)
context aContext
32
Bean DesignClient to access bean

• import java.util.
• import javax.naming.
• import javax.rmi.
• public class TestHello
• public static void main(String args)
• try
• / Creates a JNDI naming context for location
  objects /
• Context context new
  InitialContext()
• / Asks the context to locate an object named
  "HelloWorld" and expects the
• object to implement the HelloWorldSessionHome
  interface /
• HelloWorldSessionHome home
  (HelloWorldSessionHome)portableRemoteObject.narrow
  (
• context.lookup("HelloWorld"),Hell
  oWorldSessionHome.class)
• / Asks the Home interface to create a new
  session bean /
• HelloWorldSession session
  (HelloWorldSession) home.create()
• System.out.println(session.getGreeting
  ())
• / Destroy this session /
• session.remove()

33
Some Restrictions

• EJBs cannot
• create or manage threads
• access files using java.io
• create a ServerSocket or change the socket and
  stream handler factories
• load a native library
• use the AWT to interact with the user

These restrictions keep EJBs from making too
many assumptions or interfering with its
environment.
34
OpenEJB

• OpenEJB is an open source EJB container and EJB
  server
• Allows use of EJBs in your apps with little
  configuration
• Why use it?
• Can be combined to work with Tomcat
• A web app in Tomcat will become an OpenEJB client
  in a fully J2EE compliant way

35
Server-Container Contract

• Defines responsibilities between app server and
  OpenEJB container
• Container manages EJBs at runtime according.
  Container provides transaction, authorization,
  and connector support for beans servicing
  requests from the server.

36
The Major Steps

• Install OpenEJB
• Deploy an EJB from OpenEJB
• Configure Tomcat
• Create and Deploy the Web app

37
Configuring Tomcat

• Tomcat is a servlet container. OpenEJB is an EJB
  container.
• Open EJB creates a runtime environment to run
  EJBs and let other access them by JNDI.
• Tomcat allows EJBs to be bound to names so JSPs
  and servlets can access them, but there must be a
  bridge...

38
JNDI Object Factory

• Bridge between Tomcat and OpenEJB runtime
  environment
• The OpenEJB class, TomcatEJBFactory interprets
  bean requests and passes them to OpenEJB
• OpenEJB processes this and responds back
• Installation of the factory also requires some
  classes be available for Tomcat, a simple web app
  provided with OpenEJB loads the jars into
  Tomcats class path

39
Configure server.xml

• EJB name bindings appear between ltContextgt of the
  web app using the bean
• ltEjb name"ejb/hello"
• type"Session"
• home"org.acme.HelloHome"
• remote"org.acme.Hello"/gt
• ltResourceParams name"ejb/hello"gt
• .
• .
• .
• .
• .
• lt/ResourceParamsgt

40
Wrap-up

• Questions?
