TIMERS

1
TIMERS
2
The 555 Timer

• The 555 Timer is one of the most popular
• and versatile integrated circuits ever
  produced!
• It is 30 years old and still being used!
• It is a combination of digital and analog
  circuits.
• It is known as the time machine as it performs
  a wide variety of timing tasks.
• 555 timer operate in several modes
• 1. Monostable mode
• 2. Astable mode
• 3. Bistable mode
• 4. Buffer Schmitt trigger

3
555 Timer Pin Connection
4
555 Timer Pin Function

• PIN 1 Ground Connect this to ground. Remember
  to connect all grounds in a circuit
  together.
• PIN 2 Trigger A short low (less than 1/3 Vcc)
  pulse on the trigger starts the
  timer. By connecting this to ground we "turn on"
  the 555 timer.
• PIN 3 Output During a timing interval, the
  output stays at VCC. Can source up
  to 200ma.
• PIN 4 Reset Forces pin 3 low if pulled to
  ground.
• PIN 5 Control Can be used to adjust threshold
  trigger voltage. Not used in our
  applications. Connect to ground with a .01uF cap
  to eliminate supply noise from Vcc.
• PIN 6 Threshold When threshold crosses above
  2/3 Vcc timing interval ends.
• PIN 7 Discharge Connects to ground when output
  goes low. Controls timing.
• PIN 8 Vcc Power supply. Typical range 4.5v to
  16v.

5
Applications for the 555 Timer

• The 555 is a general purpose IC that can be used
  for
• Precision timing
• Pulse generators
• Sequential timing
• Time delay generation
• Linear ramp generation.
• Cascaded timers
• Frequency dividers
• Voltage-controlled oscillators
• LED flashers

6
Inside the 555 Timer
7
Inside the 555 Timer

• The voltage divider (blue) has three equal 5K
  resistors. It divides the input voltage (Vcc)
  into three equal parts.
• The two comparators (red) are op-amps that
  compare the voltages at their inputs and saturate
  depending upon which is greater.
• The Threshold Comparator saturates when the
  voltage at the Threshold pin (pin 6) is greater
  than (2/3)Vcc.
• The Trigger Comparator saturates when the voltage
  at the Trigger pin (pin 2) is less than (1/3)Vcc

8

• The flip-flop (green) is a bi-stable device. It
  generates two values, a high value equal to Vcc
  and a low value equal to 0V.
• When the Threshold comparator saturates, the flip
  flop is Reset (R) and it outputs a low signal at
  pin 3.
• When the Trigger comparator saturates, the flip
  flop is Set (S) and it outputs a high signal at
  pin 3.
• The transistor (purple) is being used as a
  switch, it connects pin 7 (discharge) to ground
  when it is closed.
• When Q is low, Qbar is high. This closes the
  transistor switch and attaches pin 7 to ground.
• When Q is high, Qbar is low. This open the
  switch and pin 7 is no longer grounded

9
Monostable Multivibrators

• Monostable multivibrator A switching circuit
  with one stable output state.
• Also referred to as a one-shot.
• The one-shot produces a single output pulse when
  it receives a valid input trigger signal.

10
Monostable Operation
Figure 5 555 Timer Set Up for Monostable
Operation
11

• Stable State
• 1. The output Qbar of the SR flip-flop (also
  called a RS flip-flop) is initially set HIGH
  which turns on the discharge transistor. The
  discharge transistor then grounds the capacitor
  C1. The outputs of both comparators 1 and 2 are
  LOW. See Figure 6.

Initial Timing Chart
Figure 6 C1 Grounded
12

• Unstable State (C1 Charging)
• 2. Comparator 2 serves as the input S (Set) and
  comparator 1 serves as the R input (Reset) into
  the SR flip-flop. With the THRESHOLD grounded in
  the initial stable state, the output of
  non-inverting comparator 1 is LOW. When the
  switch S1 is closed driving the TRIGGER input to
  LOW (more precisely, when it drops below 1/3
  Vcc), the output of lower inverting comparator 2
  is driven HIGH (See Figure 7). From the SR
  flip-flop truth table below (Table 1), when the S
  input is HIGH and R is LOW, the output Qbar of
  the SR flip-flop is driven LOW and the 555 timer
  OUTPUT is HIGH due to the inverting buffer stage.

Table 1 SR Flip-Flop Truth Table
13
Figure 7 C1 Charging Through R1
3. Since the Qbar is LOW, the discharge
transistor is turned off and C1 begins
charging through R1. See Figure 7.
14

• 4. The switch S1 is opened driving the TRIGGER
  back to HIGH (Figure 8). The output of the lower
  comparator 2 changes to LOW (Vcc gt 1/3 Vcc)
  comparator 1 remains unchanged at LOW. The
  trigger pulse must be shorter than the output
  pulse width allowing time for the timing
  capacitor to charge and then discharge fully.

Figure 8 C1 Continues Charging Through R1
5. From the SR flip-flop truth table, the output
Qbar of the SR flip-flop does not change
(S0 R0), thus remaining in a LOW state.
15

• Unstable State (C1 Discharging)
• 6. C1 continues to charge until the voltage
  across C1 exceeds 2/3 Vcc. At this point, the
  upper comparator 1 is driven HIGH (Figure 9).
  From Table 1, the SR flip-flop is driven to HIGH
  (S0 R1) which turns on the discharge
  transistor and grounds C1 again.

Figure 9 When the Voltage across C1 gt 2/3 VCC,
C1 Is Grounded
16

• Return to the Stable State
• 7. The voltage across C1 is greater than 2/3 Vcc
  for only a moment before dropping below 2/3 Vcc
  driving the upper comparator 1 to LOW (Figure 10).

Figure 10 555 Timer Returns to Stable State
8. From the SR flip-flop truth table, the output
Qbar of the SR flip-flop does not change
(S0 R0), thus remaining in a HIGH state and
discharge transistor continues to ground C1.
The 555 will remain in the stable state
until another LOW trigger pulse is detected.
17
Astable Multivibrators

• Astable multivibrator A switching circuit that
  has no stable output state.
• The astable multivibrator is a rectangular-wave
  oscillator.
• Also referred to as a free-running multivibrator.

18
Astable Operation
Figure 3 555 Timer Set Up for Astable Operation
19

• Charging
• 1. When the power is turned on, capacitor C1 is
  not charged and pin 2 (TRIGGER) and pin 6
  (THRESHOLD) voltage (Vin) is at 0 V.
• 2. The output of lower comparator 2 (inverting)
  is therefore HIGH (Vin lt 1/3 Vcc) and the output
  of the upper comparator 1 (non-inverting) is LOW
  (Vin lt 2/3 Vcc).
• 3. Comparator 2 serves as input S (Set) and
  comparator 1 serves as the R input (Reset) for
  the SR flip flop (also called a RS flip-flop).
  From the truth table below for a SR flip-flop, S
  input is HIGH and R is LOW, therefore the output
  Qbar of the SR flip-flop is LOW and the 555 timer
  OUTPUT is HIGH due to the inverting buffer stage.

Table 1 SR Flip-Flop Truth Table
20

• 4. Since Qbar is LOW, the discharge transistor
  is turned off and C1 begins charging through R1
  and R2. While the capacitor C1 is charging, the
  OUTPUT of the 555 timer is HIGH while the
  capacitor C1 is discharging, the OUTPUT of the
  555 timer is LOW.

Figure 5 C1 Charging Through R1 and R2
21

• 5. When the voltage across C1 (Vin) reaches 1/3
  Vcc, the output of the lower comparator 2 changes
  to LOW comparator 1 remains unchanged.
• 6. From the SR flip-flop truth table, the output
  Qbar of the SR flip-flop does not change (S0
  R0), thus remaining in a LOW state.
• 7. C1 continues to charge until it reaches 2/3
  Vcc. At this point, the upper comparator 1
  changes to a HIGH state.
• 8. Since the input R is HIGH and input S is LOW,
  the output Qbar of the SR flip-flop goes to HIGH.

22

• Discharging
• 9. The HIGH output from the SR flip-flop turns
  on the discharge transistor which creates a
  discharge path for C1 through R2.

Figure 8 C1 Discharging Through R2
23

• 10. The discharge of C1 causes the output of the
  upper comparator 1
• to change to LOW.
• 11. The output Qbar of the SR flip-flop does not
  change (S0 R0), thus remaining in a HIGH
  state.
• 12. When C1 discharges to 1/3 Vcc, the lower
  comparator 2 output changes to HIGH causing the
  output Qbar of the RS flip-flop to go LOW (S is
  HIGH and R is LOW). The LOW output Qbar from the
  SR flip-flop turns off the discharge transistor
  and C1 begins to recharge.
• 13. The output of lower comparator 2 then changes
  to a LOW state, but the RE flip-flop remains LOW
  continuing to charge the capacitor C1. The
  capacitor continues the new recharge cycle.

24

• 14. The 555 timer repeats the charge/discharge
  cycle between 1/3 Vcc and 2/3 Vcc producing an
  output periodic square wave (Figure 12).

Figure 12 Relationship between Vin and the
Output of the 555 Timer
25
Output Pulses and Formulas for Astable Operation
555 Timer Output Pulses for Astable Operation
Figure 15 Astable Operation Circuit
Formulas
Discharging time is given by (time of output in
HIGH state) T1 TH 0.693 (RA RB)
C Discharge time is given by (time of output in
LOW state) T2 TL 0.693 RB C Total period
is- T TH TL 0.693(RA 2RB)C
26
Output frequency
Duty cycle D ( ratio of high state to period
of pulse)
27
Example

• A 555 timer connected as a astable multivibrator,
  if given a RA 2.2KO, RB 3.9KO and C C1
  0.1µF. Draw the waveforms at pin 6 or pin 2 and
  pin 3. calculate the TH, TL output frequency, f,
  and duty cycle, DT.
• A 555 timer circuit is connected in astable mode
  with the values of the following components -
• RA 2kO, RB 4kO and C 0.1µF. Calculate
• TH, TL and T, frequency, f, Percentage of duty
  cycle, DT. Draw the output waveform.
• 3. A 555 timer connected in the unstable mode and
  given RA 2.3kO, RB 4.6kO and C 0.1µF.
  Calculate TH, TL, frequency, f and percentage of
  duty cycle of output waveform.

28
Bistable Multivibrator

• The circuit is called a bistable because it is
  stable in two states output high and output low.
  It is also known as a 'flip-flop'.
• It has two inputs
• Trigger (555 pin 2) makes the output high.
  Trigger is 'active low', it functions when
  lt 1/3 Vs.
• Reset (555 pin 4) makes the output low. Reset is
  'active low', it resets when lt 0.7V.

29
Circuit diagram of 555 timer bistable mode
555 bistable circuit
30
Circuit operation

• The circuit is two basic inverters, each taking
  its input from the other's output. When power is
  first applied, Q1 turns on, its output will be a
  logic 0. This will be applied to Q2's input
  resistor, keeping Q2 turned off so that its
  output will be a logic 1. This logic 1 will be
  applied back to Q1's input resistor, keeping Q1
  turned on and holding the entire circuit locked
  into this stable state.

On the other hand, if Q1 stays off at power-up,
it will apply a logic 1 to Q2's input, thus
turning Q2 on. The resulting logic 0 output from
Q2 will in turn hold Q1 off. The circuit will
then remain in this stable state indefinitely.
31
Waveforms of bistable multivibrator

• Notice that the circuit is symmetrical that is,
  each transistor amplifier has the same component
  values. When power is first applied, the voltage
  divider networks place a negative voltage at the
  bases of Q1 and Q2. Both transistors have forward
  bias and both conduct.

32
(No Transcript)
33
Buffer Schmitt trigger

• It is an inverting buffer or NOT gate because
  the output logic state (low/high) is the inverse
  of the input state
• Input low (lt 1/3 Vs) makes output high, Vs
• Input high (gt 2/3 Vs) makes output low, 0V

NOT gate symbol
Schmitt trigger symbol
34
555 inverting buffer circuit (a NOT gate)

• When the input voltage is between 1/3 and 2/3 Vs
  the output remains in its present state. This
  intermediate input region is a deadspace where
  there is no response, a property called
  hysteresis, it is like backlash in a mechanical
  linkage. This type of circuit is called a Schmitt
  trigger.
• If high sensitivity is required the hysteresis is
  a problem, but in many circuits it is a helpful
  property. It gives the input a high immunity to
  noise because once the circuit output has
  switched high or low the input must change back
  by at least 1/3 Vs to make the output switch
  back.

35
(No Transcript)
36
556 TIMER

• The 556 consists of a pair of 555 timers in one
  package. The two timers work independently and
  only share common power supply connections.

556 timer pin configuration
