ROADMAP

1
(No Transcript)
2
ROADMAP

• Organization Chart
• A6 Ops/Focus Areas
• Information Management
• Airfield Systems
• Expeditionary Communications
• Base Comm support
• Opportunities
• Conclusion

3
(No Transcript)
4
INFORMATION MANAGEMENT

• Enterprise Information Management
• AMC wide deployment of Sharepoint capabilities
• eStaffing (USTC/J6 AMC/A6)
• Foundation MS Sharepoint, CRM (TMT), TRIM
• Records Management
• Integration w/Sharepoint
• IBM tool suite (centralization vs
  de-centralization)
• Publishing Guidance
• AFSO21
• Opportunities
• Business Intelligence / Command Dashboards
• Tools that make Sharepoint design easier

5
EIM Components
Collaborative Tools Web Ex-USTC
SharePoint
Records Management AFRIMS-AMC
6
EIM PERSONAL DASHBOARD (NOTIONAL)
Workflow
Newsletter
Task Management
Collaboration Workspaces
Email
Network Drivesand ERM Files
Schedule
7
AIRFIELD SYSTEMS

• ATCALS Modernization (AFFSA Lead Cmd)
• 20 yr old systems, expensive parts, specialized
  techs
• Specialized techs maintained 98 uptime in AMC
• Deployable ATCALS
• Systems need immediate replacement
• Network Security
• Securing ATCALS attached to backbone
• This keeps me up at night!
• Training
• Techs not as experienced
• Need more support from MAJCOM specialist
• Opportunities All Above

8
EXPEDITIONARY COMMS

• AMC Open the Base Mission Comms
• Contingency Response Wings (CRWs)
• JTF-PO
• CRW Capabilities
• HUMROs/Natural Disasters/New Bases
• Comm Packages
• Opportunities
• Con

9
Open the Base FM Operational Node Connectivity


TACC at Scott AFB, IL

WX and INTEL Flights

C2 ITV Traffic
DRASH
CRG Deployment
C2 ITV Traffic
SPICE in MARC Van
TDC VSAT
C2 ITV Traffic
Open the Base Aerial Port Operations
CRG-E
10
CRW COMMUNICATIONS CAPABILITIES

• Embedded Communications Capabilities
• UHF/VHF A/G/A Radio Set (HAVE QUICK / Secure)
• UHF SATCOM Voice/Data Radio Sets
• INMARSAT M4 Terminal w/STE Telephone
• Iridium Satellite Phone w/Secure Module
• Handheld Intra-base VHF Radio Sets
• HF Radio Sets
• Augmenting Communications Capabilities
• Handheld UHF Intra-base Radios (AKA LMRs)
• Wideband SATCOM Gap Filler (AKA I-BEST)
• Newest Capabilities
• HF-GCS (SIPRNET E-Mail via HF)
• SPICE
• INMARSAT BGAN

11
DEPLOYED COMM PACKAGES

• Small Package Initial Comm Equipment (SPICE)
  (NEW)
• Supports CRW (Open the Airbase)
• Up to 48 NIPR, 48 SIPR 4 VOSIP (Contains No User
  End Items)
• Light Lean - Services Left in Rear to Reduce
  Manpower Equipment
• Utilizes VOIP, VOSIP, Webmail and Web-Based
  Systems Only
• Customers bring their own laptopsuse CAT 5 to
  plug in
• Deployable Independent Comm Element (DICE)
• AMC version supports Deployed Air Mobility
  Division
• 8-DSN, 8-SIPR 8-NIPR (Expandable to 72-91-45
  with end-user Items)
• Theater Deployable Comm (TDC)
• Supports Deployed Air Wings (C2, Establish
  Airbase, Operate the Airbase)
• NIPR/SIPR/DSN, video, LMR, TACSAT Ground-to-Air
  radio
• Supports up to 1,200 End Users

12
BASE COMM SUPPORT

• Long Haul Comms
• Inmarsat/Iridium Accountability
• Airframe Comms
• PWCS Personal Wireless
• Phone plan optimization - 500K/yr savings
• Telephone Systems
• Operator Consolidation starting with Mid-Shifts
  to Scott
• Telephone Regionalization
• Opportunities
• Inmarsat Provider Re-assessment DITCO
• Telephone system maint

13
Areas Where We Need help

• Network Security
• Deployable ATCALS
• ATCALS Modernization
• EIM
• Business Intelligence
• Cmd Dashboards
• Configuration Mgt
• Standardization
• Records Mgt

• Expeditionary Comms
• JTF-PO
• Using what weve purchased
• Documentation
• Exercise Spt

14
SUMMARY

• Organization Chart
• A6 Ops/Focus Areas
• Information Management
• Airfield Systems
• Expeditionary Communications
• Base Comm support
• Opportunities

15
Questions
