Navy Ships Recognition

1
Navy Ships Recognition
2
Destroyers and frigates

• Destroyers and frigates are the workhorses of the
  fleet.
• Destroyers - air defence
• Frigates - surface and subsurface warfare.
• They are equally at home in large task groups or
  on independent operations which may include
  sanctions enforcement, humanitarian relief or
  anti-drug patrols.

3
Destroyers

• Air defence
• Pennant number begins with D

Sea Dart missile launcher
Radar domes
114 m gun
D pennant
4
Types of Destroyer
Type 42
Type 45
Batch 1/2
Batch 3
5
(No Transcript)
6
(No Transcript)
7
(No Transcript)
8
Frigates

• Anti-sub defence
• Frigate fridge cold water ?
• Pennant number begins with F

Vertical Launch sea wolf missiles
114m gun
F pennant
9
Types of Frigate
Type 22
Type 23
10
(No Transcript)
11
Aircraft carriers

• Aircraft carriers are the largest ships in the
  fleet.
• They are very versatile, and can be used for
  various different purposes on expedition
  operations.
• Their main armament is provided by their aircraft
  they carry, which enables carriers to deploy
  rapidly around the world to local points of
  crises.

12
What is the purpose of the Ski Jump at the front
of aircraft carriers?

• The ski jump is an ingenious British invention.
• It is used by fixed wing aircraft, such as the
  harrier, to take off in short distances.
• It helps the aircraft take off by giving it a
  "push" in an upward direction at the moment of
  launch.

13
LPH

• Landing platform (helicopter)
• Only one of these HMS Ocean
• Looks exactly like an aircraft carrier except
  without the ramp.

14
Submarines
Future Submarines
SSBN
SSN
Astute Class
Vanguard Class
Trafalgar Class Swiftsure Class
15
(No Transcript)
16
LPDs

• The Albion Class, Landing Platform Dock Ships
  (LPD's) primary function is to embark, transport,
  and deploy and recover (by air and sea) troops
  and their equipment, vehicles and miscellaneous
  cargo, forming part of an Amphibious Assault
  Force.

17
Test!

• Dont forget
• Destroyers have a D pennant number
• Frigates have a F pennant number
• Type 23 Frigates are different to type 22s
  because of the hull line being continuous.
• Type 42 Destroyers batch 3 are different to batch
  1 and 2 because of the reinforced hull line near
  the middle.
• You can also tell Destroyers by their radar
  domes.
• Aircraft carriers are different to the assault
  ship (Ocean) because of the ski jump.
• LPDs have a section at the back for landing on

18
1
19
2
20
3
21
4
22
5
23
6
24
7
25
8
26
9
27
10
28
11
29
12
30
13
31
14
32
15

• Name
• An assault ship
• A LPD
• A Trafalgar class submarine
• A Swiftsure class submarine
• A Vanguard class submarine
• An Aircraft Carrier

33
Answers

• Type 22 Frigate HMS Cornwall
• Type 22 Frigate HMS Cumberland
• Type 23 Frigate HMS St Albans
• Type 42 Destroyer HMS Exeter
• Type 42 Destroyer - HMS Nottingham
• Type 42 Destroyer HMS Westminster
• Aircraft carrier HMS Illustrious
• Aircraft carrier HMS Ark Royal
• Assault ship HMS Ocean
• Type 23 Frigate
• Landing Platform Dock ship (LPD) HMS Albion
• Vanguard class submarine, SBN
• SSBN Trafalgar class
• SSBN - HMS Superb Swiftsure class submarine
• HMS Ocean,
• Albion/Bulwark,
• Trafalgar/Talent/Triumph/Turbulent/Trenchant/Torb
  ay/Tireless,
• Vanguard/Vigilant/Vengeance/Victorious,
• Sovereign/Superb/Sceptre/Spartan,
