Sex Chromosomes and Nondisjunction Diseases

1
Sex Chromosomes and Nondisjunction Diseases

• A. P. Biology
• Chapter 15
• Mr. Knowles
• Liberty Senior High School

2
Human Chromosomes

• 46 Total (23 pair)
• 22 pair are perfectly matched-autosomes.
• Remaining pair- sex chromosomes.
• Human XX normal female
• XY normal male
• Y chromosome highly condensed with a few dozen
  genes.

3
Chromosomal Basis of Sex

• Two similar Xs human female
• Two dissimilar X and Y human male
• NOT true for all diploid organisms.
• Both sex chromosomes behave like homologues
  during meiosis in the testes and ovary. They may
  cross-over at Pro I.
• Each gamete receives one sex chromo.

4
Spermatogenesis Oogenesis
44 XY
44 XX

22 X
22 X
22 X
22 Y
5
Chromosomal Basis of Sex

• Each ovum contains one X chromosome.
• Sperm have either X OR the Y chromosome.

6
What determines sex in humans?

• Before two months, all fetuses are anatomically
  the same.
• The gonads are generic and can become either
  ovaries or testes.
• Depends upon hormone levels in the embryo.
• Trigger is the SRY gene on the Y.

7
Y Chromo. Encodes Few Genes
8
SRY on the Y Chromosome
9
The Human Y Chromosome

• Encodes a protein called SRY- the
  sex-determining region of Y. SRY is a
  regulator for other genes on other chromosomes.
• Responsible for development of testes.
• Without SRY, the gonads develop into ovaries.
  Female is default sex in humans.

10
SRY Protein Binding to DNA (Gene Regulation)
11
Sex-linked Genes Have a Unique Pattern of
Inheritance

• In 1910, Thomas Hunt Morgan saw a remarkable
  mutation in Drosophila.
• Saw a mutant male with white eyes!
• Followed Mendels techniques- F1 showed that the
  white phenotype was recessive to wild-type red
  eye color.
• F2 - 31 red white but all white eyes were MALE!

12
(No Transcript)
13
Explanation to Morgans Dilemma

• The gene that causes the white eye phenotype is
  on the X chromosome and not found on the Y.
• Proved that inheritable traits do reside on the
  chromosomes.
• Any trait or gene found on the X chromosome- sex
  linked.

14
Mapping the First Chromosome

• In 1913, A. H. Sturtevant located the relative
  positions of 5 recessive genes on the X
  chromosome of Drosophila by estimating their
  frequency of recombination due to X-over.
• This was a linkage map.

15
(No Transcript)
16
Genetic Maps

• Cross-over occurs more frequently between two
  genes farther apart.
• Use x-over rates in progeny to plot relative
  position of genes on chromosomes- Linkage Map.
  Distance is measured in frequency of
  recombination between two genes.
• Genes very close are linked- they do not x-over.

17
Genetic Map

• A linear sequence of genetic loci on a particular
  chromosome. Linkage Maps are based on frequency
  of recombination between two loci.
• What about genes very far apart?
• Linkage maps are NOT a picture of chromosomes.
  NOT physical map of genes.

18
Cytological Maps of Chromosomes

• Locate genes with respect to chromosomal features
  such as banding patterns.
• G-banding (Giemsa staining) stains
• C-banding (Centromere staining) stains
  heterochomatin of the centromere.

19
Cytological Mapping of Chromosome 15
20
Human Genome Project

• Physical sequencing of the DNA on each
  chromosome.
• Shows the distance between loci in DNA
  nucleotides.
• Finished Human Genome Project in Spring 2000.
  Identified 30,000 genes in humans in Winter 2001.
• Other genomes sequenced C. elegans, D.
  melongaster, many prokaryotes.

21
Finished Human Chromosome 22
22
X -linked Traits

• If a sex-linked trait is recessive, female will
  be heterozygous one X comes from the mother and
  the other X from the father. Seldom will be
  homozygous for the genes on the X chromosome.
• Males only inherit X from the mother- called
  hemizygous. More likely to be affected by
  X-linked diseases.

23
gt60 X-linked Human Diseases

• Colorblindness
• Duchenne and Becker Muscular Dystrophies
• Albinism-Deafness Syndrome
• Two proteins (Factor 8 and 9) for blood clotting.
  Mutations here cause Hemophilia, Hemophilia A
  and B.
• SCID (Boy in the Bubble, Johnny T.)

24
SCID

• David Vetter- lacked cytokines for the immune
  system.
• Died at age 12.

25
X Chromosome Genetic Map
26
Some Diseases Mapped to X
27
(No Transcript)
28
(No Transcript)
29
X
30
Duchennes Muscular Dystrophy

• On the X chromosome, the gene for dystrophin- a
  protein found attached to the inner surface of
  the sarcolemma in normal muscle fibers (cells).
• Dystrophin regulates Ca ion channels- mutations
  keep the channels open too long.
• Candidate for gene therapy-successful in rats.

31
X-Section of Duchenne MD
32
Muscle X-Section of Duchenne MDNormal Duchenne
MD
33
Anti-Dystrophin Antibody StainingNormal Duchenn
e MD
34
Female Mammals are like Floor Tile!

• Males and females have the same amount of
  proteins encoded by the X-linked genes! HOW?
• One X chromosome in each female cell becomes
  inactive during embryonic development- X
  -inactivation.
• Males Female X-linked gene activity.

35
X inactivation
36
Barr Bodies
37
X - Inactivation

• The inactive X chromo. Becomes condensed and
  attaches to the inside of the nuclear envelope-
  Barr Body.
• Most genes are NOT expressed.
• Barr Body Chromosomes are reactivated in ovary
  cells--gt ova.

38
X - Inactivation

• Mary Lyon - showed that the selection of which X
  will become the Barr body is random and
  independent in each embryonic cell present at the
  time of X-inactivation.
• After the X is inactive in a particular cell, all
  the mitotic descendents of that cell have the
  same X inactivated.

39
Females are Protein Mosaics!

• Mosaics- half of her cells have the active X
  derived from the mother, half of her cells have
  the active X from the father.
• If heterozygous, the same tissue will express one
  allele from one X chromosome and another allele
  from the other X chromosome

40
Calico Cats- An Example of Mosaicism
41
What would a carrier with X-linked disease look
like?

• Diseased Phenotype? Normal?

42
Anti-Dystrophin Antibody LabelingNormal Carrie
r
43
Mechanism of X-Inactivation

• Attachment of CH3 groups to cytosines.
• A gene is active only on the Barr body
  chromosome-XIST (X-inactive specific transcript)-
  encodes an RNA. These RNA molecules bind to the
  chromosome from which they were made.
• But which X will have an active XIST gene?
  Unknown!

44
Alteration of Chromosome Numbers

• Primary Nondisjunction- members of a pair of
  homologous chromosomes do not move apart
  properly during anaphase of meiosis I.
• Unequal distribution of chromosomes in the
  daughter gametes.

45
Nondisjunction Leads to Abnormal Chromo. in
Zygote

• If the aberrant gamete units with a normal
  gamete, the offspring will have an abnormal of
  chromosomes- aneuploid.
• Aneuploid
• 2n 1 Trisomy
• 2n - 1 Monosomy

46
Monosomics

• Organisms which have lost one copy of a
  chromosome.
• Do Not Survive Development!
• Lethal Error!

47
Trisomics

• Most do not survive either.
• Some trisomies do survive for a time
• Trisomy 13, 15, 18-severe developmental defects,
  die within a few months.
• Trisomy 21- Down Syndrome.
• Trisomy 22- mentally retarded.

48
Trisomy 13 Facies- Bilateral Cleft Lip
49
Trisomy 18 Syndrome
50
Trisomy 21 Karyotype
51
Chromosome 21 Genetic Map
52
Mapping of Chromosome 21
53
Diseases Mapped to Chr. 21
54
Tiffany with Downs- Trisomy 21
55
Downs Syndrome (Trisomy 21) and Special Olympics
56
Trisomy 21 Phenoytpe

• Slower skeletal development- short stature.
• Below normal I.Q.
• 11 X more likely for leukemia. Cancer gene
  located on 21.
• Often have Alzheimer-like dimentia. Alzheimer
  gene located on 21.
• Usually die prematurely.
• Caused by a nondisjunction event during
  oogenesis.

57
(No Transcript)
58
Nondisjunction of the Sex Chromosomes

• Two Types
• Nondisjunction of the X Chromosome.
• Nondisjunction of the Y Chromosome.

59
X X
NONDISJUNCTION
X X
X
XXX
X
X Y
XXY
Y
Y
60
Nondisjunction of the X

• Super Females XXX- Female with one functional X
  and two Barr bodies sterile but appears normal.
• XXY- Klinefelter Syndrome- sterile male with
  female characteristics, some mental retardation
  underdeveloped male characteristics occurs in 1/
  500 male births.

61
Klinefelter Syndrome (XXY)
62
Without an X Chromosome!

• OY- zygote is inviable all humans require at
  least one copy of the X chromosome.
• XO - Turner Syndrome- sterile female, short
  stature, webbed neck, and immature sex organs,
  lower I.Q. occurs in 1/ 5,000 female births.

63
Turner Fetus with Cystic Hygroma
64
Amber (age 4) with Turners Syndrome
65
Nondisjunction Also Occurs in Males!

• Super Males XYY- fertile males of normal
  appearance occurs in 1/ 1,000 male births.
• Historically thought to be 20 X higher in
  institutionalized males. Not true.
