Glaciation of Canada

1
GlaciationofCanada
2
Glaciers

• Definition large, moving mass of ice that
  shapes the landscape by eroding, transporting,
  and depositing huge volumes of rocks and sediments

3
Glaciers and the Great Lakes
COVERING ALL OF CANADA! (Except highest peaks)
4
(No Transcript)
5
How Glaciers Move

• Pressure underneath glacier gravity moving
  glacier

6
Formation

• ice moves like a very thick liquid
• Three Zones
• Zone of Accumulation (more new snow than melting
  evaporation)
• Balance Area or Equilibrium Line (No change)
• Zone of Ablation (more melting than new snow)

7
(No Transcript)
8
(No Transcript)
9
There are two types of Glaciers
ALPINE
CONTINENTAL

• Their movement is mainly due to gravity
• Some still exist in the western mountains

• They move due to their own weight
• The northern ice cap is one of these

10
U-Shaped Valley
Glaciers pass through jagged mountain valleys
making them smooth and u-shaped after the ice
retreats.
11
Striations
Rocks are carried in the bottom of a glacier act
like cutting tools. The direction of these
grooves shows which way the glacier traveled.
12
Till
This is the material picked up and carried by the
glacier. It is made up of everything from very
fine particles of sand, to huge boulders.
13
Till Plain
When the ice melts and leaves a layer of till
behind, it is called a till plain. It is flat or
gently rolling. They are very useful as
farmland, due to the rich deep soil left behind.
14
Moraines
These are ridges of till left either at the front
or sides of a glacier as it retreats.
Oak Ridges Moraine
15
Drumlin
These are egg shaped hills of deposited material
from a glacier.
16
Erratic Large rock carried by the ice.
17
Esker
A long sinuous ridge of sand and gravel deposited
by water flowing under a glacier or ice sheet.
18
Kettle Lakes Former ice blocks that have melted
19
Kame Material deposited through holes in the ice
