Outdoor Lighting Design

1
Outdoor Lighting Design REALLY?! Andrew
Bloomfield CANEW Regina SK Monday 29
September 2014
2
The Presentation

• Vision
• Outdoor Lighting Design Metrics
• Light Source Options
• Business Case
• Specifications
• Construction
• Maintenance

3
Vision
4
Vision
5
Lighting Design Metrics
Candle Power
Foot Candle
CRI
Lumen
Lux
CCT
Illuminance
Efficacy
Luminance
Lv
Emax/min
Uniformity
Candela
Luminous Flux
6
Outdoor Lighting Design Metrics
ANSI/IES RP-8-00
7
Outdoor Lighting Design Metrics

• Considerations
• Luminaire Mounting Height
• Luminaire Over Hang
• Roadway Width
• Optimized Luminaire Cycle
• Pole Conflicts
• Unit Power Density
• Luminaire Photometric Parameters
• Adaptive controls

8
Light Source Options

• MV
• LPS
• HPS
• MH
• Induction

9
Light Source Options

• LED

10
Light Source Options

• Plasma

11
Business Case

• Capital Cost
• Stranded Assets
• Operating Savings
• Energy
• Maintenance
• CDM, GHG Benefits
• Cost-Benefit Analysis
• NPV
• ROI gt hurdle rate
• Payback

Treasury Board of Canada Secretariat
12
Specifications

• LED
• Electrical
• Photometric
• CCT
• Driver current
• Junction temperature
• Ingress Protection rating
• Lumen depreciation L70
• Rated life, warranty

13
Construction
14
Maintenance
15

• Thanks For Your Time
• Andrew Bloomfield
• abloomfield_at_enersource.com
• 905-283-4058
