Sports Medicine Imaging

1
Sports Medicine Imaging

• Timothy G. Sanders, MD
• Director of Education and ResearchNational
  Musculoskeletal Imaging Weston,
  FLandProfessor, Part-TimeDepartment of
  RadiologyUniversity of Kentucky

NMSI
2
MR Imaging

• T1-weighted (short TE/TR)
• Anatomy Image
• Muscle intermediate
• Fluid intermediate
• Calcium dark
• Fibrous tissue dark
• Fat (marrow) bright

3
MR Imaging

• T2-weighted (long TE/TR)
• Pathology Image
• Muscle intermediate
• Fluid bright
• Calcium dark
• Fibrous tissue dark
• Fat (marrow) bright
• Fat saturation technique

Look for bright signal in joint Bright Fluid T2
4
Intravenous GadoliniumNephrogenic Systemic
Fibrosis (NFS)

• 1997 a new fibrosing skin disorder was identified
  in patients with renal disease
• Fibrosis of skin and connective tissue
• Skin thickening/ decreased ROM joints
• Progressive disease with reports of death
• 2006 first linked to contrast agents containing
  gadolinium

5
Intravenous GadoliniumNephrogenic Systemic
Fibrosis (NSF)

• No known treatment for NSF
• Reported only in patients with severe renal
  disease
• Often on dialysis, but not all patients
• FDA warning to avoid gadolinium
• Acute or chronic severe renal disease (GFR lt30)
• Hepato-renal syndrome
• Perioperative liver transplant period
• Incidence 3-5 in patients with severe / endstage
  renal disease

6
Intravenous GadoliniumNephrogenic Systemic
Fibrosis (NSF)

• Question all patients to receive gadolinium for
  history of
• Acute or chronic kidney disease
• History of dialysis
• Diabetes
• Liver disease
• Recent chemotherapy
• Avoid gadolinium if GFR lt 30
• Informed consent

7
Computed Axial Tomography (CT scan)

• Improved soft tissue contrast
• Occult fractures
• Complex fractures
• Axial skeleton
• Intra-articular fractures
• Hardware complications

8
Nuclear Medicine
Screening tool -High sensitivity -Entire
skeleton -Poor anatomic detail
Indications -Radiographically occult
lesions -Orthopedic infections -Incidental bone
lesions -Surveillance for additional/multiple
lesions
9
Nuclear Medicine Bone Scan
-Overuse injuries -Bone scan sensitivity near
100 -Radiograph sensitivity 15
10
Nuclear Medicine Bone Scan

• Orthopedic Infections
• Bone scan
• No surgery or trauma
• Labeled white blood cells
• Recent surgery or trauma
• Bone scan and Ga-67
• Spine

11
Ultrasonography
-Widely used as an imaging tool since the 1970s
-Popularized for imaging of the musculoskeletal
system mid-1980s -Primary Indications -Muscles
and tendons -Soft tissue masses and foreign
bodies -Dynamic evaluation
12
Ultrasonography
-Mechanical pressure waves rather than ionizing
radiation -No known adverse biological effects
-Highly operator dependent -Time consuming for
the physician
-The probe functions as a transducer/
receiver -Sound wave sent into body -As wave
encounters different interfaces -Portion of wave
reflected back -Computer generates image
13
Ultrasound
-Muscles, tendons, dynamic evaluation -Operator
dependent
Normal Achilles Tendon
Chronic Tendinopathy
14
Muscles
-Gastrocnemius with hematoma
-Torn Rectus Femoris muscle
-Dynamic evaluation of Rectus Femoris -Complete
disruption of fibers
15
S.T. Masses
Bakers Cyst
Subdeltoid Bursitis
Cyst versus solid Complex S.T. mass (MFH)
16
Shoulder Imaging
Radiographs
CT
MR
17
Osteolysis of Distal Clavicle
Post-traumatic osteolysis -Acute trauma (occurs
within 2 months of injury, self
limiting) -Repetitive stress (wt.
lifters) -X-ray loss of normal cortical line-
distal clavicle -MR high signal in distal
clavicle -Acromion normal abnormality isolated
to distal clavicle
18
Anterior Dislocation
Diagnosis?
-Hill-Sachs defect
-Osseous Bankart lesion
West Point View
19
Normal Labrum
Anterior/ Posterior Labrum Axial Plane
LABRUM -Dark on all Pulse Sequences -Triangular
20
Bankart Lesions
Osseous
Fibrous
21
Hill-Sachs Lesion
-Impaction Humeral Head against Anterior-inferior
Glenoid -Associated with Bankart Lesion -Top 3
Images Round -Hill-Sachs Flattening or Concavity
22
Normal Superior Labrum
Coronal Plane
Superior Labrum -Dark on all pulse
sequences -Triangular -Extends off of Superior
Glenoid
23
SLAP Lesion
-Normal Superior Labrum -Black
-SLAP tear -Signal within superior labrum
24
Middle Glenohumeral Ligament
-Prevents external rotation of humeral head when
arm is between 45º and 60º of abduction
-Originates at superior glenoid tubercle
-Courses obliquely superficial to the anterior
labrum -Blends with the deep fibers of
subscapularis
25
Normal Anatomic Variant
-Buford Complex -1.5 of Patients -Can Mimic
Anterior Labral Tear
-Thick Cord-like MGHL
-Absent or Diminutive Anterior-Superior Labrum
26
Inferior Glenohumeral Ligament
-Redundant when the Arm is in Neutral Position
27
HAGL Lesion
Humeral avulsion of glenohumeral ligament
Disrupted IGHL at humeral attachment site
28
Locked posterior dislocation

• Reverse Hill Sachs
• Widening of GH joint
• Locked in internal rotation

29
MRI Performed 3 weeks following original injury
Locked posterior dislocation Reverse Hill Sachs
30
Rotator Cuff Imaging

• Normal cuff
• Dark on T1 and T2

31
Rotator Cuff Imaging

• Tendonopathy
• Intermediate signal on T1 and T2
• Thickened tendon

• Calcific Bursitis/ tendonitis
• Globular low signal
• Blooming artifact- Gradient echo

32
Rotator Cuff Imaging

• Tear
• Bright (fluid) signal on T2

Fluid Tear
Fatty atrophy
33
Subscapularis tendon tear with medial dislocation
of the LHBT
34
Axillary Nerve Neuropraxy
Axillary Nerve can be stretched at time of
anterior dislocation resulting in denervation
atrophy Deltoid and Teres Minor muscles
Denervation atropy -Acute edema -Chronic fatty
35
Paralabral Cysts
-Suprascapular nerve entrapment -Denervation
edema

• SLAP tear
• Paralabral cyst
• Suprascapular notch

• Supraspinatus
• Infraspinatus

36
Case 1
What is the most likely diagnosis?
Rotator cuff tear
37
Case 2
MRI of a patient with shoulder weakness. What is
the most likely diagnosis?

• Quadrilateral space syndrome
• Axillary nerve
• Deltoid
• Teres minor

38
Imaging of the Elbow
39
Biceps Tendon Tear with Retraction
40
UCL ligament Injury
T sign Partial thickness UCL tear
20 y.o. pitcher
41
OCD of the Capitellum
Gymnast
Professional Baseball player
42
Olecranon Stress Fracture
18 y.o. pitcher with posterior elbow pain
43
Posterior Elbow Dislocation
-FOOSH -Fractures Adult coronoid/ radial head
Child Avulsion of medial epicondyle
44
Radiographically Occult Fractures of the Elbow
The Sail Sign
45
Radiographically Occult Elbow Fracture

• Adult radial head/neck fracture-
• Fracture line dark on T1
• Dark or fluid signal on T2

-adult
-Supracondylar fracture child
46
Radiographically Occult Elbow Fracture
Child supracondylar fracture
-Supracondylar fracture child
47
Posterior Elbow Dislocation in Child
-Associated with medial epicondyle avulsion in
50 of cases -Up to 30 become entrapped in the
joint following reduction
48
Imaging of the Hand and Wrist
49
Tendonopathy
-Fluid in Tendon Sheath -Thickening/ High Signal
in Tendon -T2 Axial Images
-Flexor Carpi Radialis Longus
50
De Quervains Syndrome
-Tenosynovitis -Extensor Pollicis
Brevis -Abductor Pollicis Longus
-Sporting activity requiring repetitive ulnar
deviation of wrist Mechanical -Canoeists
-Weightlifters
51
Scapholunate Ligament
-Perforation -Visualize Fluid Extending Through
Ligament -Traumatic Tear Vs. Age Related
Perforations
Coronal T1 Arthrogram/ fatsat
52
Ulnar Impaction Syndrome
-Positive ulnar variance -Perforation of
TFCC -Cartilage defects distal ulna and proximal
lunate -Subchondral cystic change
53
14 y.o. gymnast with bilateral wrist pain
54
Carpal Dislocations
Triangular appearance
Dislocations

• Lunate
• Lunate dislocates in volar direction

55
Diagnosis?
Scaphoid fracture with Avascular Necrosis
56
Scaphoid Fracture Complications
-AVN complication of scaphoid fracture -Recurrent
blood supply -Risk factors delayed diagnosis,
displacement, proximal fracture site
Scaphoid fracture complication rate is
high -AVN -Delayed/ nonunion -Osteoarthritis
57
What soft tissue structure is injured?
Mallet Finger (Baseball Finger)
Avulsion of extensor digitorum tendon
58
Volar Plate Avulsion
What soft tissue structure is injured?
--Hyperextension avulsion injury -MCP or PIP
joint dorsal dislocation
59
What soft tissue structure is injured?
-Avulsion of flexor digitorum profundus -Forced
hyperextension -Osseous fragment displaced
proximally Jersey Finger
60
Imaging of the Hip and Pelvis
Double Line Sign Avascular Necrosis
-T2 -AVN -Zone of healing interface -80 of AVN
cases
61
Stress Fracture of Hip

• Plain film
• Sclerotic line
• Perpendicular to normal trabeculae

62
Stress Fracture of Hip
-MRI dark line on all pulse sequences -Line
incomplete -Surrounding edema
63
Avulsion Injuries of the Pelvis
Sartorius
Rectus Femoris
Gluteus Medius
Hamstring
Iliopsoas
64
Anterior Superior Iliac Spine
Sartorius/ tensor fascia lata attachment site
65
Anterior Inferior Iliac Spine
Rectus Femoris
66
Old Rectus Femoris Avulsion
67
Rectus Femoris Avulsion Injury

• MR
• If x-ray is normal or equivocal

68
Ischial Tuberosity Hamstring/ Adductor Magnus
Attachment Site
-Large avulsion fragment -Mimic
neoplasm -Sprinters
69
Beware Avulsion Fracture Lesser Tuberosity in
Aduts
-Pathologic fracture until proven otherwise in an
adult
70
FAICam Type
-Results from prominence of femoral neck -Labral
tear -Subchondral cysts lateral aspect of femoral
neck
71
FAIPincher Type
Pincher Impingement -Results from acetabular
abnormalities
72
Sports Imaging of the Knee
73
Imaging of the ACLThings you must know!

• Normal MR appearance (all 3 imaging planes)
• Primary signs of ACL disruption (all 3 imaging
  planes)
• Secondary signs of ACL disruption
• Commonly associated soft tissue injuries
  (meniscal tears, posterolateral corner injuries)

74
The Anterior Cruciate Ligament Normal MR
Appearance
-High signal striations between strands of distal
ACL
-2 separate bundles distal ACL -Anteromedial/
Posterolateral
75
The Empty Notch Sign
Normal proximal ACL attachment
Fluid signal at normal attachment site of ACL
proximal avulsion
76
Primary signs of disruption
Abnormal morphology
Disrupted fibers
77
Secondary signs of ACL disruption

• Deep sulcus sign
• Impaction lateral femoral condyle against
  posterior tibia
• Normal sulcus lt1.5mm

ACL Tear
78
Secondary signs of ACL Tear

• Pivot shift edema pattern
• Posterolateral femoral condyle
• Posterior lateral tibia

ACL Tear
79
Secondary signs of ACL tear

• Segond fracture
• Avulsion of the lateral capsule

ACL Tear
80
Diagnosis?
Tibial Avulsion Fracture of ACL Most commonly
seen in the adolescent patient
81
Meniscal Tears Associated with ACL Tears
-Most common acute meniscal injury associated
with ACL tear -Vertical tear of the PHLM -Most
commonly missed meniscal tear on MR imaging
82
Meniscal Tears Associated with ACL Tears

• ODonahues Triad
• ACL tear
• MCL injury
• MM tear

83
Normal PCL
-Curvilinear dark structure -Usually seen on 1-2
images
84
PCL Disruption Dashboard Bone contusion pattern
85
Iliotibial Band Friction Syndrome

• Long distance runners
• Friction injury

• MRI Findings
• Edema deep to iliotibial band
• Thickened band

86
Posterolateral Corner Injuries

• Injury of the arcuate ligament and of the
  popliteofibular ligament associated with edema of
  medial fibular head
• Associated with ACL disruption resulting from
  hyperextension or pivot shift injury

87
Medial Collateral Ligament Injury
Grading MCL Injuries Grade 1 Superficial
edema Grade 2 Partial tear Grade 3 Complete tear
Grade 1
Grade 2
88
Grade III- Complete Disruption
Proximal disruption
Distal disruption
89
Diagnosis?
Transient Lateral Patellar Dislocation
-Anterolateral aspect of lateral femoral
condyle -Inferomedial patella
90
Associated Injuries
Osteochondral Injury of Patella
Osteochondral Injury of Lat Femoral Condyle
Disruption of medial patellofemoral ligament
91
Patellar Tendon
Patellar tendonitis Thickening of tendon
Partial tear of tendon Fluid signal on T2 images
92
Quadriceps Tendon
Complete disruption
93
MRI Normal Meniscus
-Normal DARK Signal -T1 Sensitive -T2
Specific
94
MRI Normal Meniscus
Peripheral
Central
1.5 2 bow ties
95
Direct Signs of Meniscal Tear
-Grade 3 Signal -Extending to articular surface
Vertical tear
Horizontal
Complex tear
96
Direct Signs of Meniscal Tear
Missing fragment
Displaced fragment
97
Diagnosis?
Double PCL Sign Bucket Handle Tear Medial
Meniscus
98
Diagnosis?
Bucket Handle Tear Lateral Meniscus
Posterior horn flips anteriorly
Double anterior horn sign lateral meniscus
99
What is the arrow pointing to?
- Anterior transverse meniscal ligament -Attaches
to the anterior horn lateral meniscus -Mimic
meniscal tear
100
Meniscofemoral Ligament
-Attaches to the PHLM

• Mimic meniscal tear
• Humphry/ Wrisberg

101
Popliteus Tendon Sheath
-Fluid tracking in popliteal tendon sheath
-Mimic meniscal tear PHLM
102
Discoid Meniscus
-More than 2 Bow Ties -Lateral
meniscus -Increased risk of meniscal tear
Coronal image meniscus extends beyond1/2 way
point of condyle
103
Diagnosis?
-Meniscal Cyst and meniscal tear -Horizontal
cleavage tear -DDX cruciate ganglia, bursitis,
other ganglia
104
Imaging of the Ankle
105
Achilles Tendonitis/ Tear

• Gap in Achilles tendon with high signal

• Thickened
• Increased signal
• Convex anterior boarder

106
Flexor Tendons
Tom, Dick, and Harry Tibialis Posterior Flexor
Digitorum Longus Neurovascular Bundle Flexor
Hallucis Longus
107
Diagnosis?

• Posterior tibialis tendonosis
• Thickened tendon
• Fluid in tendon sheath

108
Diagnosis?
Split Peroneal Brevis
109
Diagnosis?
-Disruption of Superior Peroneal Retinaculum
Peroneal tendons subluxation
110
Commonly Missed Fracture Following Ankle
Inversion Injury
111
Osteochondral Lesions
Type I- marrow edema, cortex intact Type II-
partial disruption of overlying cortex Type III-
complete separation, fragment in situ Type IV-
displaced fragment
Type III
112
Thank you!
