Lessons Learned with TEVAR

1
Lessons Learned with TEVAR
SAVS 2007 Thoracic Endovascular Aortic Repair
Christopher J. Kwolek, MD FACS Division of
Vascular and Endovascular Surgery Massachusetts
General Hospital
2
Faculty Disclosure

• Christopher Kwolek, MD

• I disclose the following financial relationships
• Receive grant/research support
• Cook, WL Gore, Edwards, Cordis
• Advisory board of
• Medtronic, Boston Scientific

3
THORACIC STENT GRAFT

• SPECTRUM PATHOLOGY

Saccular

• Degenerative aneurysm
• Acute/ ? Chronic Dissection
• IMH
• Penetrating ulcer
• Acute transection
• Pseudoaneurysm
• ? Shaggy aorta syndrome

Focal
Fusiform
vs
Diffuse
4
THORACIC STENT GRAFT

• TIMELY

(J Vasc Surg 2005)
5
Fundamentals of Endovascular Repair of DTA
Aneurysms

• Minimally invasive procedure
• Reliable delivery and deployment
• Hemostatic seal excludes DTA aneurysm from
  circulation
• Exclusion prevents DTA aneurysm rupture

? limited to descending aorta
6
Pivotal Study (TAG 99-01)
Operative Results
30 days or In-Hospital Events

• TAG Device Surgical Control
• Operative Mortality 2
  11.7 ? p .003
• Paraplegia / paraparesis 3 14 ?
  p lt .001
• Stroke 4 4

7
Pivotal Study (TAG 99-01)
Operative Results
140 Patients Enrolled

• 137 successful implantation (98)
• 3 failures due to poor iliac access
• 77 patients (55) required gt1 device
  to bridge the aneurysm
• 21 patients (15) had a conduit to the aortoiliac
  segment for access

8
TAG Device Selection
9
Trauma Arch Anatomy
18 yr. old
60 yr. old
20 yr. old
10
2. Small aortic diameters (stentgrafts lt 20 mm Ø)
11
3. Lesion close to left subclavian artery
Landing Zone lt 10 mm LSA overstenting 70
12
Mid-device MMS
13
Aortic Dissection
PATHOLOGIC ANATOMY
DISTAL DISSECTIONS

• Entry tear typically just distal to left
  subclavian artery. Rupture at entry site is RARE
  in absence of localized aneurysmal dilatation _at_
  entry tear. Anatomic foundation of medical Rx for
  distal dissections.

14
Aortic Dissection

• CONTEMPORARY PERSPECTIVE

• IRAD study group results
• 12 academic medical centers
• nearly 500 patients treated 1996-1998

• Overall mortality ? 27
• Urgent asc. aortic graft ? 26 op mortality
• Distal dissections

(Hagan et al. IRAD, JAMA 2000)
15

• Aortic Dissection

TREATMENT OPTIONS TYPE B

• Intervention indicated only for specific
  complications (for now)

Threatened proximal rupture (rare)
Branch compromise
Open/endovascular methods for directed peripheral
intervention, a complication-specific approach
Open repair
Stent graft
16

• Aortic Dissection

ENDOVASCULAR FENESTRATION

• Minimally invasive alternative to surgical
  fenestration
• Complex endovascular procedure

Role of IVUS/adjuvant stenting

• Local expertise a definite factor!

17
Infrarenal aorta fenestrated and right renal
perfused from true lumen
18

• Aortic Dissection

ENDOVASCULAR FENESTRATION
RESULTS
Series Year pts Mortality Stanford 1999
40 25 Michigan 2001 50
25
CAVEATS Age/vascular beds affected/ mesenteric
ischemia correlates of death
19
STENT GRAFT REPAIR OF ACUTE DISSECTION
ANATOMIC PRINCIPLES
20
STENT GRAFT CONSTRUCT FOR ACUTE DISSECTION
ROLE OF UNCOVERED STENTS
ENTRY TEAR
DISTAL BARE STENTS REMODEL AORTA
21
HYBRID PROCEDURE
Aortic arch debranching
Distal ascending aorta becomes proximal seal zone
for stent graft
22
CASE REPORT
ENLARGING ARCH/DESCENDING TAA

• 18 yrs s/p AAA
• Aneurysm begins mid arch with significant mural
  debris
• Staged hybrid procedure

Sternotomy Asc-Ao ? innominate/left CCA BPG 5
days later stent graft Asc ? distal thoracic aorta
23
VISCERAL AORTIC SEGMENT
HYBRID PROCEDURE

• 73 yr. old female with limiting COPD and
  enlarging extent III TAA small AAA
• Stage one infrarenal graft with
  renals/SMA/celiac re-routing and conduit to left
  groin area
• Stage two stent graft thoracic aorta via conduit

24

• Adopted B/O 20-30 mortality open TAA
• 25pts Rx 2002-05 (80 extent II, III)
• Elective mortality 17 ? no paraplegia

(J Vasc Surg 2006431081-9)
25
Next Generation Devices

• Longer lengths
• Larger and smaller diameters
• More flexible devices and delivery systems
• Improved accuracy of proximal and distal
  deployment
• Mechanism to deal with risk of embolization
• Insitu mechanism to deal with arch and visceral
  branches
• System to integrate with percutaneous aortic
  valve repair
• Pathology specific devices which are more durable

26
Tips and Tricks

• Pre and perioperative imaging is critical
• CTA 3D reconstruction
• Intraoperative angiogram with ability to obtain
  lateral and LAO views to visualize origins of
  visceral vessels, aortic arch
• IVUS for complicated cases (Dissection, complex
  anatomy, minimize contrast load)

27
AXIAL IMAGING

28
Tips and Tricks

• Intraoperative case planning (Set the table)
• Start with the easy cases
• Prepping and positioning, role underneath left
  flank, retroperitoneal access
• Access, Access, Access
• Have proximal and distal extensions, large
  balloons (Gore tri-fold, Coda, Medtronic)
• Z-Med balloon, large Palmaz stents

29
Conduits

• Consequences if being overly aggressive with
  traditional access can lead to
• Femoral and iliac artery dissection or rupture
• Need for iliofemoral bypass grafting
• Having to do a conduit anyway
• Possible conversion to open surgical procedure


• Possibly death

Iliac artery on a stick
30
OPEN VS. TEVAR -- MGH EXPERIENCE
(J VASC SURG 2006)
31
THORACIC STENT GRAFT
POTENTIAL FOR DECREASED SPINAL CORD ISCHEMIA

No cases of spinal cord ischemia were noted
With n105 implants 4 (4.9) patients with
paraparesis/paraplegia
32
ROLE OF ADJUNCTS

• CSF Drainage
• Adequate spinal cord perfusion pressure must be
  maintained
• Difference between mean arterial pressure and CSF
  pressure spinal cord perfusion pressure
• Spinal cord perfusion may be enhanced by lowering
  intrathecal pressure with use of CSF drainage

Is this extension from the surgical paradigm
logical in either a prophylactic or therapeutic
mode?
33
Summary

• Paraplegia following endovascular repair of TAA
  does occur, but likely less risk than open repair
• Patients appearing at greater risk are those
  with
• Increased segmental treatment lengths
• Prior aortic replacement
• Concomitant abdominal aortic surgery
• True benefits of current prevention and treatment
  methods remains to be determined as more
  experience accumulates ? for now CSFD and
  arterial line (pressure) management best strategy
  for at-risk patients

34
Thoracic Stent Graft Procedures-MGH
