Module 3: Designing an Active Directory Site Topology

1
Module 3 Designing an Active Directory Site
Topology
2
Agenda

• Sites
• Replication Within Sites
• Replication Between Sites
• Replication Protocols
• Active Directory Branch Office Deployment

3
What Are Sites?

• The First Site Is Set Up Automatically, and Is
  Called Default-First-Site-Name
• Sites Can Consist of Zero, One, or More Subnets
• Sites Are Used to Control Replication Traffic and
  Logon Traffic
• Sites Contain Server Objects and Are Associated
  with IP Subnet Objects

4
Sites Purpose and Function

• Definition
• A set of well-connected subnets
• Contain only Server and Configuration objects
• Sites are used for
• Logging on
• Group Policies
• Replication topology
• Intra-Site
• Inter-Site

5
Site Boundaries

• Sites may span domains
• Domains may span sites
• OUs may span sites

dom.com
Site A
OU
Site B
sub.dom.com
6
Replication

• Intra-Site Replication
• Automatic topology generation
• Pull-only, based on update notification
• Always RPC based
• Inter-Site Replication
• Semi-automatic topology generation
• Scheduled (no update notification)
• RPC or SMTP (Domain NC RPC Only)

7
Intra-Site Replication

• Information that is replicated
• Domain Naming Context (NC)
• Configuration Naming Context (NC)
• Schema Naming Context (NC)
• Replication Topologies
• Domain NC
• Schema/Configuration NC always share the same
  topology

8
Intra-Site Replication

• Same Site - Single Domain One Replication
  Topology
• Each new DC (KCC) inserts itself into the ring
• Replication via RPC is based on pull
• Topology adjusts to ensure a maximum of three
  hops (edges added at 7 servers)
• KCC runs every 15 minutes

9
Intra-Site Replication

• DCs within a site/domain will maintain distinct
  Domain NC connection objects
• Schema/Configuration replication performed
  normally
• Domain NCs topologies are separate for Domain A
  and Domain B

10
Intra-Site Replication

• Global Catalog Servers within a site will source
  from a DC
• Global Catalog will establish a connection object
  to request Domain NC from the other domain(s)

SITE
A
A
1
2
B
2
B
Global Catalog
1
Server Connector
B
3
A
A
4
3
11
Inter-Site Replication

• Site Links
• Two or more sites
• Connected by common transport
• Cost associated with link
• Schedule determines window
• Frequency determines replication
• Site Link Bridges
• Two or more site links
• Transitiveness between site links

12
Site Links

• Transport
• IP (RPC) or SMTP
• Cost
• Smaller number is cheaper
• Based on network characteristics
• Schedule
• Configurable
• Schedule defines windows of replication
• Frequency defines how often replication will
  happen

13
Site Links

• Describe physical network
• Used for message route paths
• Defined by
• Two or more sites
• Cost
• Transport
• Schedule
• Frequency

NYC
A
20
B
FRAME
RED
BOS
128
128
A
A
T-1
B
B
T-1
256
256
SEA
ATL
A
A
B
A
512
512
LAX
B
B
14
Site Link Bridges
NYC
A
20
B

• Provide transitiveness between site links
• Similar to network routers
• All sites bridged by default
• Defined by two or more site links

FRAME
RED
BOS
128
128
A
A
T-1
B
B
256
256
SEA
ATL
A
A
B
A
512
512
LAX
B
B
15
Site Link Bridges
NYC
A
20
B
FRAME
RED
BOS
128
128
A
A
T-1
B
B
256
256
SEA
ATL
A
A
B
A
512
512
LAX
B
B
16
Topology Creation

• Manual
• Disable auto-generation of KCC and manually
  define connection objects
• Automatic
• Allows site link transitiveness
• Bridges all sites
• Influenced
• Add site link bridges to enforce routes

17
Design Considerations

• How big to make a site
• Few Locations Site LAN
• Many Locations Site segments in a certain
  geographic area
• Factors affecting site scope
• Replication latency
• Network impact
• Client performance

18
Scoping Sites

• Small Organizations will base sites on LANs
• Organizations with many sites will want to
  maximize site boundaries
• Factors affecting traffic
• Differential replication
• Schedule
• Compression
• Replication Scope
• Topology is configurable

19
Site Scopes

• Scope Sites to
• Increase performance of client logon
• Map replication traffic to the network
• Use SMTP replication between sites when
• Domain Site
• Spanning very slow links

20
Replication Within Sites

• Replication Within Sites
• Occurs Between Domain Controllers in the Same
  Site
• Assumes Fast and Highly Reliable Network Links
• Does Not Compress Replication Traffic
• Uses a Change Notification Mechanism

21
Replication Between Sites

• Replication Between Sites
• Occurs on a Manually Defined Schedule
• Is Designed to Optimize Bandwidth
• One or More Replicas in Each Site Act As
  Bridgeheads

ISTG
Bridgehead Server
Replication
IP Subnet
IP Subnet
Site
Replication
Replication
Bridgehead Server, ISTG
IP Subnet
IP Subnet
Site
22
Replication Protocols
23
ISM and KCC/ISTG

• Inter-Site Messaging Service (ISM)
• Creates cost matrix for Inter-Site replication
• Sends and receives SMTP messages if SMTP
  replication is used
• Runs only when
• ISM service starts up
• Changes happen in site configuration (new sites,
  site-links, site-link-bridges)
• Information is used by
• Netlogon for auto-site coverage
• Load-Balancing tool
• Universal Group Caching
• DFS
• KCC/ISTG
• Computes least cost spanning tree Inter-Site
  replication topology
• Inter-Site component of KCC
• Runs every 15 minutes by default

24
Bridgehead Server Selection

• Windows 2000
• On a per site basis, for each domain, one DC per
  NC used as Bridgehead
• Windows Server 2003
• On a per site basis, for each domain, all DCs per
  NC used as Bridgehead
• KCC picks DC randomly when connection object is
  created
• For both incoming and outgoing connection objects

25
Bridgehead Server Selection
A
B
A1
A2
B1
A3
B2
B3
B4
A13
B13
B12
A12
B11
A11
26
Bridgehead Server Selection Windows 2000
A
B
A1
A2
B1
A3
B2
B3
B4
A13
B13
B12
A12
B11
A11
27
Bridgehead Server SelectionPreferred Bridgehead
Server List

• Some servers should not be used as Bridgeheads
• PDC FSMO
• Weak hardware
• Solution Preferred Bridgehead Server List
• Allows administrator to restrict what DCs can be
  used as Bridgehead Servers
• If Preferred Bridgehead Server List is defined
  for a site, KCC/ISTG will only use members of the
  list as Bridgeheads
• Warning
• If Preferred Bridgehead Server List is defined,
  make sure that there are at least DCs per NC in
  the list
• If there is no DC for a specific NC in the list,
  replication will not occur out of site for this NC

28
Bridgehead Server Selection Preferred
Bridgehead Server List
A
B
A1
A2
B1
A3
B2
B3
B4
A13
B13
B12
A12
B11
A11
29
Bridgehead Server Selection Bad Bad Preferred
Bridgehead Server List
A
B
A1
A2
B1
A3
B2
B3
B4
Replication to B NC broken
A13
B13
B12
A12
B11
A11
30
Bridgehead Server SelectionRecommendations for
Branch Office Deployments

• Always use Preferred Bridgehead Server List in
  hub sites
• Make sure that there are enough DCs in the list
• Make sure that there are enough DCs that are not
  included in the list
• Do not add PDC Operations Master
• Do not add DCs used for user logons
• Do not add DCs used by Exchange servers
• Make sure that all NCs are covered in the
  Preferred Bridgehead Server List
• If there are GCs in the branches, make all
  Bridgehead Servers GCs

31
Best Practices
32
Agenda

• Sites
• Replication Within Sites
• Replication Between Sites
• Replication Protocols
• Active Directory Branch Office Deployment

33
Characteristics Of A Branch Office Deployment

• Large number of locations
• Small number of users per location
• Hub and spoke network topology
• Slow network connections and dial on demand
  links
• WAN availability
• Bandwidth available for Active Directory
• Other services relying on the WAN
• Large number of domain controllers in remote
  locations

34
AD Branch Office Scenario
35
Design Considerations For Branch Offices

• User management and Group Policies
• Structural Planning
• Forest planning
• Domain planning
• DNS considerations
• Replication planning
• DNS configuration for branch offices
• Replication planning

36
Centralized User Management

• Advantages
• Good security control and policy enforcement
• Easy automation of common management tasks from a
  single source point
• Problems can be fixed quickly
• Changes flow from hub to branch
• Disadvantages
• Success varies directly with the availability and
  speed of the local area network (LAN) or WAN
• Propagation changes are time-consuming, depending
  on the replication infrastructure and the
  replication schedules
• Time to react and to fix issues might be longer
• IT organization tends to be further away from
  customer
• Recommendation
• Use centralized model

37
Group Policy Management

• Management of Group Policies focuses on PDC
• Group policies use both Active Directory and
  sysvol replication (NTFRS replication)
• Sysvol replicates on a per file level
• Changes are performed on PDC
• Always use centralized Group Policy model for
  Branch Office deployments
• Watch applications that change Group Polices
  (account security settings)
• Restrict administration of policies to group that
  understands impact of changes
• Avoid last writer win overwrite issues

38
SYSVOL Replication

• Follows AD replication topology
• Uses connection objects
• Different conflict resolution algorithm
• Replicates on a per file level
• Last writer wins
• Avoid applications that create excessive sysvol
  replication
• Do not create file system policy against
  replicated content
• Check anti-virus software
• Diskeeper

39
Forest Planning

• Deploy single forest for Branch Offices
• Reasons for having multiple forests
• Political/organizational reasons
• Unlikely in branch office scenarios
• Too many locations where domain controllers must
  be deployed
• Complexity of deployment
• Too many objects in the directory
• Should be partitioned on domain level
• GCs too big?
• Evaluate not deploying GCs to branch offices
• Whistler No-GC-logon feature

40
Domain Partitioning

• Recommendation for Branch Office Deployment
• Use single domain
• Typically only one security area
• Central administration (users and policies)
• Replication traffic higher, but more flexible
  model (roaming users, no GC dependencies)
• Database size no big concern
• If high number of users work in central location
• Create different domains for headquarters and
  branches
• If number of users very high (gt 50,000)
• Create geographical partitions

41
Design Considerations For Domain Controller
Placement

• Required services
• File and Print, e-mail, database, mainframe
• Most of them require Windows logon
• Logon requires DC and GC availability
• Logon locally or over the WAN
• WAN logon requires acceptable speed and line
  availability
• Cached credentials only work for local
  workstation logon

42
Design Considerations For Domain Controller
Placement

• Replication versus client logon traffic
• Replication traffic more static and predictable
• Affected by domain design and GC location
• Applications using the GC can demand local GC
• Logon traffic affected by number of users in the
  branch and services
• Less predictable
• Security
• Management
• Alternative solutions
• Terminal Servers
• Local accounts

43
Design Considerations For Global Catalog Placement

• No factor in single domain deployment
• Multiple Domain deployments
• GC needed for logon in native mode
• Disable GC requirement
• Whistler has Universal Group caching feature
• Services might require GC
• Exchange 2000
• Recommendation
• If WAN unreliable or more than 50 users in
  branch, deploy GC to branch
• Always put GC next to services that require GC
• I.e., if there are Exchange 2000 servers in the
  branch, deploy GC to branch

44
DNS Planning Considerations

• DNS AD root domain
• Distributing forest wide locator records
• Island problem
• Domain controller SRV record configuration
• Auto Site Coverage
• NS records

45
DNS Configuration Of Root Domain

• If DNS already exists
• Delegate AD root domain to Windows 2000 DNS
  server (i.e., corp.microsoft.com)
• Use Active Directory integrated DNS zones
• If not
• Use Windows 2000 DNS server on domain controllers
• Use Active Directory integrated DNS zones
• Create internal root, or Configure forwarders

46
Distributing Forest Wide Records

• CNAME records for replication and GC records are
  forest wide records
• Stored in _msdcs domain in the AD root domain
• I.e., two domains, corp.microsoft.com and
  sales.corp.microsoft.com
• A records for DCs in corp.microsoft.com are
  stored in the corp.microsoft.com DNS domain
• A records for DCs in sales.corp.microsoft.com are
  stored in sales.corp.microsoft.com
• CNAMEs for replication for DC in
  corp.microsoft.com are stored in the
  _msdcs.corp.microsoft.com DNS domain
• CNAMEs for replication for DC in
  sales.corp.microsoft.com are stored in the
  _msdcs.corp.microsoft.com DNS domain
• By default, this domain exists only on root
  domain controllers
• Create separate zone for _msdcs.ltForestRootDomaingt
  and transfer zone to all DCs in child domains

47
The Island Problem

• A domain controller that is also a DNS server can
  isolate itself from replication
• Can only happen if
• DC points to itself as preferred or alternate DNS
  server
• DC has writeable copy of _msdcs.ltforestRootDomaingt
  DNS domain
• Recommendation
• Domain controllers that are DNS servers AND are
  domain controllers in the forest root domain
  should point to another DC as preferred and
  alternate DNS server
• All other domain controllers (especially child
  domain controllers) can point to themselves as
  preferred or alternate DNS server

48
Managing Service Records

• SRV records are published by netlogon in DNS
• On site level and domain level
• Clients search for services in the client site
  first, and fall back to domain level
• Branch Office deployments require specific
  configuration
• Large number of domain controllers creates
  scalability problem for domain level
  registration
• If more than 850 branch office DCs want to
  register SRV records on domain level,
  registration will fail
• Registration on domain level is in most cases
  meaningless
• DC cannot be contacted over WAN / DOD link
  anyways
• If local look-up in branch fails, client should
  always fallback to hub only
• Configure netlogon service to register SRV
  records for Branch Office DCs on site level only
• Follow Q267855
• HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Servic
  es\Netlogon\Parameters
• Registry value DnsAvoidRegisterRecords
• Data type REG_MULTI_SZ

49
Mnemonic Type DNS record
Dc SRV _ldap._tcp.dc._msdcs.ltDnsDomainNamegt
DcAtSite SRV _ldap._tcp.ltSiteNamegt._sites.dc._msdcs.ltDnsDomainNamegt
DcByGuid SRV _ldap._tcp.ltDomainGuidgt.domains._msdcs.ltDnsForestNamegt
Pdc SRV _ldap._tcp.pdc._msdcs.ltDnsDomainNamegt
Gc SRV _ldap._tcp.gc._msdcs.ltDnsForestNamegt
GcAtSite SRV _ldap._tcp.ltSiteNamegt._sites.gc._msdcs.ltDnsForestNamegt
GenericGc SRV _gc._tcp.ltDnsForestNamegt
GenericGcAtSite SRV _gc._tcp.ltSiteNamegt._sites.ltDnsForestNamegt
GcIpAddress A _gc._msdcs.ltDnsForestNamegt
DsaCname CNAME ltDsaGuidgt._msdcs.ltDnsForestNamegt
Kdc SRV _kerberos._tcp.dc._msdcs.ltDnsDomainNamegt
KdcAtSite SRV _kerberos._tcp.dc._msdcs.ltSiteNamegt._sites.ltDnsDomainNamegt
Ldap SRV _ldap._tcp.ltDnsDomainNamegt
LdapAtSite SRV _ldap._tcp.ltSiteNamegt._sites.ltDnsDomainNamegt
LdapIpAddress A ltDnsDomainNamegt
Rfc1510Kdc SRV _kerberos._tcp.ltDnsDomainNamegt
Rfc1510KdcAtSite SRV _kerberos._tcp.ltSiteNamegt._sites.ltDnsDomainNamegt
Rfc1510UdpKdc SRV _kerberos._udp.ltDnsDomainNamegt
Rfc1510Kpwd SRV _kpasswd._tcp.ltDnsDomainNamegt
Rfc1510UdpKpwd SRV _kpasswd._udp.ltDnsDomainNamegt
50
AutoSite Coverage

• AutoSite coverage allows DCs to advertise for
  sites without DCs, if they are in the closest
  site to the DC
• Not practical for Branch Office deployments
• Root DCs would advertise for all sites
• If client cannot connect to a local DC, it will
  fall back to hub site anyways (configuration of
  SRV records)

51
Name Server Records

• DNS servers use NS records to advertise that they
  are authoritative for a zone
• Hidden name servers are not advertised
• Clients find DNS server through DNS client
  configuration (preferred and alternate DNS
  servers)
• Configure Branch Office DNS Servers to not add
  NS records
• Two registry keys
• HKLM/System/CCS/Services/DNS/Parameters REG_DWORD
  DisableNSRecordsAutoCreation
• Server automatically adds NS record (0 / 1)
• HKLM/System/CCS/Services/DNS/Parameters/Zones/Zone
  name REG_SZ AllowNSRecordsAutoCreation
• Recommended, single point of administration
• List is a list of space separated IP addresses of
  the DNS servers that are allowed to add the NS
  records to the zone

52
Planning For Replication

• Concepts
• Connection objects
• KCC
• Site-links
• Site-link bridges
• Sysvol replication
• Planning steps
• Planning for Bridgehead Servers
• Determine number of Sites
• Decide whether to use the KCC or create
  replication topology manually
• Define site structure of hub site
• Define replication schedule
• Create Site-Links
• Create connection objects (if KCC disabled)

53
Planning For Bridgehead Servers

• How many bridgehead servers do I need?
• How to configure bridgehead servers
• Things you need to know
• Centralized or decentralized change model
• Data update requirements formulated by customer
• How many times a day do we need to replicate?
• How many changes happen in a branch per day
• Total number of domain controllers
• Time needed to establish dial-on-demand network
  connectivity

54
Inbound Versus Outbound Replication

• Different threading model
• Outbound replication is multi-threaded
• Bridgehead server can have multiple replication
  partners
• Bottleneck is most likely CPU (monitor!)
• Inbound replication is single-threaded
• Replication of changes from branches to hub is
  serialized
• Bottleneck is most likely the network

55
Replication Traffic

• Documented in Notes from the Field, Building
  Enterprise Active Directories
• Replication overhead for branch office
  deployments
• Overhead if there are two domain controllers 21
  KB
• 13 KB to setup the replication sequence
• 5 KB to initiate replication of the domain naming
  context, including the changed password
• 1.5 KB for each schema and configuration naming
  context (where no changes occurred)
• Each DC will add 24 Bytes
• Overhead for 1,002 DCs 162 KB

56
Number Of Hub-Outbound Replication Partners

• Use formula OC (H O) / (K T)
• H Sum of hours that outbound replication can
  occur per day
• O of concurrent connections per hour of
  replication (a realistic value is 30 on the
  reference server specified below)
• K Number of required replication cycles per day
  (This parameter is driven by replication latency
  requirements.)
• T Time necessary for outbound replication
  (Depending on assumed replication traffic, this
  should be one hour or a multiple of one hour.)

57
Example Outbound Replication Partners

• Requirements
• Replication twice a day ( K)
• WAN 8 hours available ( H)
• High performance hardware ( 30 concurrent
  connections) ( O)
• Outbound replication will always finish within 1
  hour ( T)
• Applying the formula
• OC (H O) / (K T) (8 30) / (2 1) 120
• Each bridgehead server can support 120 branch
  office DCs (outbound)
• If number is too high/low, change parameters
• I.e., WAN available for 12 hours 180 branches
• I.e., replicating only once a day 240 branches

58
Number Of Inbound Replication Partners

• Use formula IC R / N
• R Length of replication window in minutes
• N of minutes a domain controller needs to
  replicates all changes
• Use replication window defined for outbound
  replication
• Example was WAN available for 8 hours
• If customer wants to replicated hub-inbound only
  once a day, then R 480 minutes
• If customer follows hub-outbound model (twice a
  day), then R 240 minutes

59
Example Inbound Replication Partners

• Lets assume slow WAN with DOD lines
• Factors
• Replication traffic (time to submit changes like
  password changes)
• Time to setup DOD connections
• 4 minutes per branch is conservative
• IC R / N 480 / 4 120 Branches

60
Example Inbound Replication Partners

• Number of branches supported by one bridgehead
  servers is lower value of results
• Outbound 120 branches
• Inbound 120 branches
• Result One bridgehead can support 120 branches
• If you have 1,200 branches, you need 10
  bridgehead servers
• Plan for disasters and special cases!
• Leave headroom for hub outbound replication
• Have spare machine available
• Create multiple connections from branch to hub DCs

61
Bridgehead Server Overload

• Symptoms
• Bridgehead cannot accomplish replication requests
  as fast as they come in
• Replication queues are growing
• Some DCs NEVER replicate from the bridgehead
• Once a server has successfully replicated from
  the bridgehead, its requests are higher
  prioritized than a request from a server that
  has never successfully replicated
• Monitoring
• Repadmin /showreps shows NEVER on last successful
  replication
• Repadmin /queue ltDCNamegt

62
Bridgehead Server Overload

• Can be caused by
• Unbalanced site-links (if ISTG is enabled)
• Unbalanced connection objects
• Replication schedule too aggressive
• Panic trouble-shooting
• Like changing replication interval on all
  site-links to a drastic shorter interval to
  accommodate applications
• Solution
• If ISTG is enabled
• Turn off ISTG (prevent new connections from being
  generated)
• Delete all inbound connection objects
• Correct site-link balance and schedule
• Enable ISTG again

63
Bridgehead Server Hardware

• Processor
• Dual/quad Pentium III or Xeon recommended for
  bridgehead servers and servers supporting large
  numbers of users
• Memory
• Minimum of 512 MB
• Disks
• Configure the operating system and logs on
  separate drives that are mirrored. Configure
  directory database on Redundant Array of
  Independent Disks (RAID) 5 or RAID 01
• Use larger number of smaller drives for maximum
  performance
• Drive capacity will depend on your specific
  requirements

64
Determine Number Of Sites

• Rule for creating sites
• For each physical location that has WAN
  connection (less than 10 MBit) to hub
• If there is a DC in the location
• Create a new site
• If not, if there is a service that uses the site
  model (DFS shares)
• Create a new site
• If not, create subnet for the location and add
  subnet to hub site (or next closest site)

65
Use Of KCC For Inter-Site Replication Topology
Generation

• Always disable transitiveness
• Windows 2000
• Less than 500 sites Use KCC
• But test your hardware first
• Follow guidelines in KB article Q244368
• More than 500 sites Create connection objects
  manually
• Branch Office deployment guide recommends manual
  topology for more than 100 sites
• Windows Server 2003 Use KCC

66
Define Site Structure Of Hub Site

• If KCC is disabled, create single site
• If KCC is enabled, create one site per Bridgehead
  Server
• KCC has no concept of Inter-Site load balancing
  between servers in one site
• Create artificial sites in hub site to spread
  load between Bridgehead Servers
• Create Site-Links with staggered schedules
  between branches and hub sites

67
Load Balancing With Sites
Site-link Schedule 2am 4am, cost 100
Site-link Schedule 4am 6am, cost 100
Site-link Schedule Always (Notification
enabled), cost 1
Hub Site-Link
BranchC2
BranchA1
68
Load Balancing Manually(With Redundancy)

• Replicate on alternating schedule

Hub Site
Branch6
Branch1
Branch5
Branch2
Branch4
Branch3
69
Creating Connection Objects Manually

• Considerations
• Connection objects must be balanced between
  Bridgehead Servers
• Schedule on connection objects must be balanced
• Branches should have multiple connection objects
  to Bridgehead Servers for fault tolerance
• Connection objects need to be created and managed
  on the local DC
• Sounds complex?
• Use our set of scripts to create a manual
  replication topology (details later)

70
Building The Hub Site

• Building the root domain
• Availability of root domain
• Only needed for special configuration tasks
• Adding new domains
• Schema changes
• Kerberos trusts and dynamic registration of
  forest wide resource records might depend on root
  domain
• Operations Masters
• Typically not critical for root domain
• Server Sizing
• Empty root domain does not require high-end
  hardware
• Kerberos referrals and dynamic DNS updates
• Disaster Recovery
• Root is critical for forest
• Make sure that you perform regular backups

71
Building The Hub Site

• Building the Branch Office Domain
• Operations Master
• Off-load PDC operations master
• Move Infra-structure master off GC
• RID master is the most critical operations master
  monitor this machine very closely
• Bridgehead Servers
• If Branch Office DC are GCs, then Bridgehead
  Servers should be GCs
• If DNS runs on Branch Office DCs, dont run DNS
  on Bridgehead Servers
• Disaster recovery
• State on Bridgehead server not very interesting
  not an ideal candidate for backup
• Leave headroom on Bridgehead, or have spare
  machine in place

72
Staging Site

• Most companies use outsource partners to build
  servers and domain controllers
• Machines are built at the factories
• Server usually build from image and promoted
  later
• Where to promote domain controllers
• Staging site Less network traffic, better
  control of process, opportunity to run QA scripts
  while machine is accessible
• In branch Configuration less complex (domain
  controller finds its site)

73
Building The Staging Site

• Staging Site needs to be permanently connected
  to production environment
• New DCs must be advertised
• New DCs need RID pool
• Fully control replication topology in the staging
  site
• Only case where KCC should be disabled for
  Intra-Site replication topology generation
• Reason is that once machines are moved out,
  domain controllers that have not learned that
  will try to replicate or re-route (DOD lines)
• Capacity planning for domain controller used as
  source
• Usually not a high-end machine
• Depends on how many DCs are installed in parallel
• Software installation
• Add Service Packs and QFEs to image
• Include Resource Kit, Support Tools and scripts
  for management and monitoring
• Document what is loaded on DC before machine is
  shipped

74
Domain Controller Build Process

• Use dcpromo answer file to promote the domain
  controllers
• Do not turn off DCs before shipping them
• Best practice is to build DCs when they are
  needed, not months before
• If they are off-line for too long, they get
  out-of-sync with production
• Tombstone lifetime
• Domain controller passwords
• Install monitoring tools and make sure that
  monitoring processes are in place
• Configure domain controller for new site
• Clean-up old connection objects before shipping
  the machine
• React if you find issues with domain controllers
  during the deployment
• Dont keep processes in place if they are broken

75
General Considerations For Branch Office
Deployments

• Ensure that Your Hub is a Robust Data Center
• Do Not Deploy All Branch Office Domain
  Controllers Simultaneously
• Monitor load on Bridgehead servers as more and
  more branches come on-line
• Verify DNS registrations and replication
• Balance Replication Load Between Bridgehead
  Servers
• Keep Track of Hardware and Software Inventory
  and Versions
• Include Operations in Your Planning Process
• Monitoring plans and procedures
• Disaster recovery and troubleshooting strategy
• Personnel assignment and training
• Personnel Assignment and Training

76
Branch Office Deployment Guide

• Prescriptive documentation
• Planning, deploying, monitoring
• Includes scripts for all tasks

77
AD Branch Office Scenario
78
AD Branch Office Deployment Process

• Build the Forest Root Domain and Central Hub Site
• Build the Branch Office Domain and Bridgehead
  Servers
• Pre-Staging Configuration at the Hub
• Create and Configure the Staging Domain
  Controller
• Stage a Branch Office Domain Controller
• Pre-shipment Configuration of the Branch Office
  Domain Controller
• Quality Assurance of the Domain Controller at the
  Branch Office

79
Active Directory Branch Office Scripts

• Four Types of scripts are included with the
  Branch Office guides
• Configuration scripts
• Configure the environment in preparation for
  deploying branch office domain controllers
• Branch Office Domain Controller Deployment
  scripts
• Make implementation easier
• Connection Object scripts
• Create connection objects between the hub site
  bridgehead servers and branch office domain
  controllers
• Quality Assurance scripts
• Monitor an Active Directory environment

80
Connection Object Scripts

• Build the Hub and Spoke Topology
• Create Connection Objects between Branch DCs and
  Bridgehead Servers
• 4 Core Files
• Topo.dat
• Mkhubbchtop.cmd
• Mkdsx.dat
• Mkdsx.cmd

81
Creating Connection Objects
82
Mkdsx.cmd

• Creates the Connection Objects for the Hub and
  Spoke Topology Specified in the Mkdsx.dat File
• Connects to
• The bridgehead server in Topo.dat to create Hub
  connection objects
• Connects to the branch office DC to create the
  connection objects on it

83
Quality Assurance Scripts

• Used to Validate a Domain Controller
• Not Specific to a Branch Office Deployment
• Must be Scheduled to Run Daily on Every DC
• Used through out the AD Branch Office Deployment
  guide
• Three Core Scripts
• QA_Check.cmd
• QA_Parse.vbs
• CheckServers.vbs

84
Running QA Scripts
85
QA_Check.cmd

• Main Script of the Quality Assurance Process
• Records the Current State of a DC in a series of
  log files
• Log files stored in C\ADResults

86
QA_Check.cmd

• Uses the Following Reskit Tools
• DCDiag.exe, NetDiag.exe, Ntfrsutl.exe,
  Regdmp.exe, Repadmin /showreps, and Repadmin
  /showconn
• Uses the Following Scripts
• Gpostat.vbs - verifies that each Group Policy
  object is in sync
• Connstat.cmd - processes the output of the
  ntfrsutl sets command to generate a summary of
  the FRS connections for a given domain controller

• QA_Parse.vbs

87
Results Of QA_Check.cmd
88
QA_Parse.vbs

• Called by the QA_Check.cmd Script
• Parses the Log Files to Locate Errors and
  Potential Issues
• Any Errors or Issues are Written to a Summary
  File
• Summary File is
• Stored in C\ADResults\ltcomputernamegt
• Copied by the QA_Check.cmd script to a central
  server so there is a single location to examine
  the state of all DCs

89
Results Of QA_Parse.vbs
90
Contents Of QAShare
91
CheckServers.vbs

• Run on the Central Server that has the Summary
  Files from each DC
• Provides a Status Report File with the Health of
  the DCs
• The Status Report Consists of Three Lists of DCs
• DCs that are healthy and did not report any
  errors
• DCs that reported errors and require further
  investigation
• DCs that did not report and should be
  investigated

92
Results Of CheckServers.vbs
93
QA Using The Scripts

• Schedule Scripts to Run Every Night
• Check ServerReport.txt Every Morning
• If Any Errors are Reported in ServerReport.txt,
  Examine the DCs Summary File
• If Error in Summary File Requires Further
  Investigation, Examine Logs on the DC

94
Best Practices DNS ModelServer Configuration
corp.ellipsis.dot
noam

• Forest root also hosts _msdcs.ltfrgt zone

• Child domain hosts secondary copy of _msdcs.ltfrgt
  zone through incremental zone transfer
