Title: Spectrum and Modulation Measurement, Signal Analysis


1
Spectrum and Modulation Measurement, Signal
Analysis
INA Academy Workshop Spectrum Management
Series Workshop 3 "Measurements and Techniques"
  • Prof. Venceslav Kafedziski
  • University "Ss Cyril and Methodius"
  • Skopje, Republic of Macedonia

2
Outline
  • Introduction
  • Review of analog modulation techniques spectra,
    modulation parameters
  • Digital modulation techniques signal space
    representation, demodulation, spectra
  • Elements of digital spectral analysis DSP, FFT,
    digital spectrum analyzers
  • Bandwidth measurement definitions, occupied
    bandwidth measurement, x-dB measurement, effects
    of noise and interference, equipment requirements

3
Introduction
  • Spectrum monitoring is amidst major change
    because of introducing new digital modulation
    techniques, and new and sophisticated measurement
    equipment.
  • There is an increased use of digital modulation
    in GSM, DAB, DVB-T, WLAN etc. These new
    techniques require measurement a number of new
    parameters.
  • There is an increased use of modern digital
    receivers that employ modern DSP for demodulation
    and signal analysis, including spectral analysis.
  • New training procedures are required for smooth
    transition towards monitoring new digital
    modulations and employing new digital receivers.

4
Analog modulation
  • Analog modulation the message is an analog
    signal and is impressed on a carrier.
  • To study analog modulation is still important,
    since
  • AM and FM are still in use in radio broadcasting,
    and AM vestigial side band in TV broadcasting
  • digital modulation techniques also use AM, FM and
    PM.
  • Transition towards digital modulation has already
    happened in mobile telephony.
  • Major shift towards introducing digital
    modulation in broadcasting is happening in
    Europe DAB, DVB-T.

5
Analog modulation AM
  • Amplitude modulation include AM, AM Double Side
    Band Suppressed Carrier (AM-DSB-SC), AM Single
    Side Band (AM-SSB), AM Vestigial Side Band
    (AM-VSB).
  • Spectrum of any AM modulation can be obtained by
    pure translation of the baseband spectrum to
    carrier frequency and filtering.
  • AM bandwidth depends on the particular modulation
    technique, and is at most 2B for AM-DSB-SC and AM
    modulation, and at least B for AM-SSB, where B is
    the bandwidth of the message.
  • AM-VSB is the best trade-off between bandwidth
    and receiver complexity used in conventional
    television.

6
Analog modulation AM
  • AM signal used in AM broadcasting
  • u(t)Ac1m mn(t)cos(2pfctfc)
  • Parameter m is called modulation depth, and mn(t)
    is the normalized message.
  • Total power is computed as PAc2/21m2Pm where
    Pm is the power in the normalized message mn(t).
  • Percentage power loss in carrier is usually
    large, since m is usually small, and Pm is always
    less than one.

7
AM modulation depth
  • AM modulation depth can be measured by measuring
    certain values of the signal envelope.


8
Analog modulation FM and PM
  • Angle modulation u(t)Accos2pfctf(t), where
    for FM
  • and for PM, f(t)kpm(t).
  • Bandwidth of FM can be estimated based on Carson
    formula
  • where B is the maximum frequency in the message
    signal, and Df is the maximum deviation.
  • FM is a modulation technique that expands
    bandwidth in order to improve the output SNR.

9
Stereo FM
  • Two signals, LR, and L-R which is modulated
    DSB-SC at 38 kHz, are transmitted, together with
    a pilot tone of 19 kHz.

10
FM broadcast multiplex
  • Besides the stereo message FM broadcast may
    contain additional signals such as traffic
    information, RDS (Radio Data Signal) at 57 kHz,
    and/or HSDS (High Speed Data System), for
    instance DARC (Data Radio Channel) at 76 kHz.

11
IQ modulation
  • It is possible to increase the efficiency of
    AM-DSB-SC by using two quadrature carriers, and
    transmitting a different signal on each of them.
  • The bandwidth efficiency of IQ is equal to the
    efficiency of AM-SSB, i.e. B per message signal.

12
Introduction to digital modulation
  • The first step to digital transmission is to
    perform A/D conversion which includes the
    following steps
  • taking samples from a continuous (analog) signal
    bandlimited to B by the celebrated sampling
    theorem, perfect reconstruction from samples is
    possible if the sampling rate meets the condition
    fsgtB.
  • quantization, which is practically rounding off
    the signal samples to a finite number L of values
    (quantization with L levels).
  • conversion of quantized samples to bits the
    number of bits used for transmission of a
    quantized sample is log2q, and, thus, the bit
    rate is equal to Rfslog2L bit/s.

13
A/D conversion
  • sampling
  • quantizing Dv2mp/L

14
Introduction to digital modulation
  • In digital transmission we transmit bits. Shannon
    showed that by keeping the transmission rate R
    bits/second below channel capacity C, errorless
    transmission is possible
  • Since channels are analog, bits are transmitted
    by sending waveforms, i.e. analog signals s1(t),
    s2(t),,sM(t). Each waveform carries klog2M bits
    of information.
  • When bits are transmitted on analog waveforms, we
    have a digital modulation.

15
Signal space representation
  • For unified representation of signals, we use a
    signal space approach, representing signals as
    vectors in an N-dimensional vector space.
  • Consider M signals s1(t), s2(t),,sM(t).
  • Any signal can be represented as
  • where yj(t) are basis functions with energy
    equal to 1 (creating an orthonormal basis), and
    NltM.
  • Thus, any signal si(t) can be represented as a
    vector
  • si(si,1,si,2,...,si,N).

16
Example of a signal set in a signal space
17
Pulse Amplitude Modulation-PAM
  • Baseband PAM digital signal is
  • where an can have one of M values sm,1 Am,1,
    m1,2, ... ,M and gT(t) is an arbitrary pulse in
    0,T.
  • PAM is one-dimensional signal with basis function
    gT(t)
  • Similarly, bandpass PAM signal
  • is one-dimensional signal with basis function
    gT(t)cos2pfct.

18
Two dimensional signals
  • Consider a bandpass signal modulated by cosine
    and sine wave, called in-phase and quadrature
    components
  • The signal s(t) can be represented as
  • where is the complex
    information sequence.

19
Two dimensional signals
  • Basis functions are
  • The signal transmitted is sm,1y1(t)sm,2y2(t),
    where sm(sm,1,sm,2) and sm,1AmI, sm,2AmQ,
    m1,2,...,M.
  • We can represent signals as vectors in a two
    dimensional space (AmI,AmQ), i1,2, ... ,M.
  • All the signal points create a constellation
    diagram.

20
QAM and MPSK
  • QAM signal points are positioned on a rectangular
    grid.
  • M-ary PSK signal points are on a circle, i.e. all
    the signals have identical energy.

QAM
PSK
21
Demodulation correlation receiver
  • Assume that signal sk(t) was sent. There exists
    an additive white Gaussian noise n(t) at the
    receiver input.
  • To demodulate, multiply the received signal
    r(t)sk(t)n(t) by basis functions and integrate,
    producing the coordinates rjsk,jnj, where sk,j
    are signal coordinates, and nj are noise
    coordinates, j1,2,...,N.

22
Demodulation matched filter receiver
  • There is a matched filter version of the
    receiver.
  • Correlators are replaced with matched filters.
  • There is yet another version of matched filter
    receiver where filters are matched to signals
    si(t), i1,2, ... ,M, instead to basis functions
    yi(t), i1,2, ... , N.

23
Optimal Detection
  • Optimal detector minimizes the probability of
    error, which results in Bayesian decision rule.
  • Smallest distance receiver results from the
    assumption of Gaussian noise and the
    orthonormality of the basis functions.
  • The detector computes the distance from the
    received vector r(r1,r2, ...,rN) to each signal
    point si, i1,2,...,M, and decides in favor of
    the closest signal point.

24
Power Spectral Density
  • Since signals are carrier modulated, power
    spectral density (PSD) is shifted around the
    carrier frequency
  • where
  • is the PSD of the complex envelope sB(t).
  • Sa(f) is the Fourier transform of the
    autocorrelation Ra(n)Eanmam of the complex
    information sequence an.

25
Power Spectral Density
  • When the complex symbols an are uncorrelated
  • where sa2 is the variance, and ma is the mean of
    the information sequence an.
  • When the symbols are uncorrelated, then the PSD
    becomes

26
Power Spectral Density of QAM and M-ary PSK
  • If there is a DC component in the information
    sequence, there exist discrete components at n/T
    in the PSD.
  • PSD of M-ary PSK and QAM signals depend on the
    pulse shape of gT(t) and on the correlation of
    information sequence. For sa21 and rectangular
    pulse gT(t) with energy 2, we get

27
QPSK and OQPSK
  • Offset QPSK (OQPSK) is QPSK where in-phase and
    quadrature components are offset for T, and the
    duration of gT(t) is 2T. This results in phase
    changes of K90 degrees, as opposed to K180 and
    K90 for QPSK.
  • This can eliminate phase ambiguity, and can also
    decrease envelope changes.

28
Nyquist Condition
  • When the pulse is rectangular, the resulting
    spectrum is infinite. Since all transmission
    systems are bandlimited, there is an inter-symbol
    interference (ISI) at the receiver.
  • To avoid ISI, Nyquist condition for the signal
    x(t)gT(t)c(t)gR(t) after the channel c(t) and
    receive filter gR(t) has to be met
  • In frequency domain, Nyquist condition translates
    to

29
Nyquist Condition
  • So called raised cosine pulses meet Nyquist
    condition

Nyquist pulse in time domain
Nyquist pulse in frequency domain
30
Eye Diagram
  • The amount of ISI and noise present in the
    received signal can be viewed on an
    oscilloscope.
  • Eye diagram is obtained by displaying the signal
    on the vertical input with the horizontal sweep
    rate at 1/T.
  • Eye opening shows how big is ISI and the margin
    against noise. Eye width shows the margin against
    timing errors.

31
M-ary FSK
  • M-ary FSK is an M-dimensional modulation with
    signals
  • and basis functions
  • i1, ,M. Minimum distance between carriers
    that provides orthogonality is 1/2T. Required
    bandwidth is M/2T.
  • Signal power does not depend on M, since
    different signals are equal to the basis
    functions, scaled by Es.

32
M-ary FSK
  • Vector representation is smoEsym, for m1,2,
    ... ,M.
  • Distance between any two signal points is

s1(oEs,0,0) s2(0,oEs,0) s3(0,0,oEs)
33
QAM versus M-ary FSK
  • Bit rate for both QAM and M-ary FSK is
  • Rb1/T log2M
  • Bandwidth for QAM is W1/T, and for M-ary FSK is
    WM/2T.
  • Bandwidth efficiency is defined as the ratio
    between bit rate and bandwidth and is measured in
    bit/s/Hz.
  • Bandwidth efficiency for QAM is log2Mbit/s/Hz
    and for M-ary FSK is (2log2M)/M bit/s/Hz.

34
Power versus bandwidth
  • By increasing M in QAM, the average signal power
    has to also increase, since the probability of
    error depends on the distance between signal
    points. By increasing M with M-ary FSK, the
    average power does not increase.
  • There is a trade-off between signal power and
    bandwidth necessary for transmission.
  • QAM is bandwidth efficient, but power inefficient
    modulation.
  • M-ary FSK is power efficient, but bandwidth
    inefficient modulation.

35
Power versus bandwidth
  • Comparison of different modulation methods at
    10-5 symbol probability of error is given.
  • Bandwidth limited region is for Rb/Wgt1.
  • Power limited region is for Rb/Wlt1.
  • Signal to noise ratio is equal to energy per bit
    divided by the noise PSD.

36
Continuous Phase Modulation - CPM
  • Continuous Phase Modulation (CPM) was introduced
    to avoid abrupt changes in envelope and to save
    bandwidth. To obtain CPM, PAM signal
  • where gT(t) is a pulse of duration T, is used
    to frequency modulate a carrier
  • The resulting frequency modulated signal is phase
    continuous and, hence, is called CPM.

37
CPFSK, MSK and GMSK
  • When gT(t) is a rectangular pulse of amplitude
    1/2T and duration T, CPM is called CPFSK.
  • Minimum shift keying (MSK) is a special form of
    CPFSK in which the modulation index is h1/2. It
    can be also viewed as OQPSK with cosine pulse
    shape.
  • Gaussian MSK (GMSK) is used in DECT and GSM. The
    pulse is a convolution of Gaussian pulse and
    rectangular pulse, i.e. is described by
    difference of two Q functions. Parameter BT is
    used to characterize GMSK, where B is the
    equivalent pulse bandwidth.
  • CPM and CPFSK are modulations with memory.

38
Partial response CPM
  • Partial response CPM is obtained when an
    arbitrary pulse gT(t) which extends beyond the
    time interval 0lttltT, is used.
  • The primary reason for this is to further reduce
    the bandwidth of the transmitted signal.
  • When the duration of the pulse extends over
    0lttltLT, where Lgt1, additional memory is
    introduced in the CPM signal, and the number of
    states increases.
  • Notation LRC is used if gT(t) is a raised cosine
    pulse of duration LT.

39
PSD of MSK and OQPSK
  • MSK can be viewed as OQPSK with sinusoidal
    shaping.
  • The sidelobes of MSK fall off faster than those
    of OQPSK, but its main lobe is 50 wider than
    that of OQPSK.

40
PSD of GMSK and CPM
  • (a) PSD of GMSK compared to PSD of MSK.
  • (b) PSD of LRC CPM compared to PSD of MSK.

(b)
(a)
41
OFDM
  • OFDM has attracted lot of interest recently for
    use on frequency selective channels, i.e.
    channels that introduce intersymbol interference.
  • Applications include ADSL, DAB, DVB-T, WLAN
    802.11a.
  • Digital TV broadcasting will replace the analog
    systems in coming years
  • TV production environment has become digital
  • improved picture quality (transmission of HDTV
    signal)
  • saves frequency spectrum (4 digital channels
    versus 1 analog channel in 8 MHz slot)

42
OFDM
  • The idea of FDM is to subdivide the available
    channel bandwidth in N sub-channels, such that
    each sub-channel is nearly ideal.
  • Then, each sub-channel is modulated with a
    separate symbol sequence and the N obtained
    signals are frequency multiplexed.

43
OFDM
  • OFDM uses the idea that more efficient use of
    bandwidth can be obtained if the spectra of the
    individual sub-channels are permitted to overlap,
    with specific orthogonality constraints imposed
    to facilitate separation of the sub-channels at
    the receiver.

44
OFDM
  • An input sequence with a symbol rate 1/T is
    subdivided into N parallel information sequences
    with rate 1/NT. Each sequence modulates one of N
    subcarriers, with frequency fk of the subcarrier.
  • Symbol interval is TuNT, and subcarrier spacing
    is 1/Tu. Inside interval Tu, signals overlap, but
    are orthogonal.

45
OFDM
  • The discrete time implementation of OFDM
    modulator is by inverse FFT on block of symbols.
  • The collection of N received samples is FFT
    transformed to obtain N received symbols.

46
OFDM
  • N complex QAM symbols are IDFT transformed at
    transmitter
  • The received block of samples is DFT transformed
  • The effect of channel is as if Xk were multiplied
    by the channel transfer function at the same
    frequencies and adding AWGN to obtain N complex
    symbols
  • RkCkXkNk

47
PSD of OFDM
  • PSD of OFDM is obtained by summing the PSD's of
    all the carriers.
  • Increasing N, PSD decreases more rapidly (Figure
    (a)).
  • The use of windows can also shape the spectrum
    raised cosine windows with roll-off factor a in
    Figure (b).

(a)
(b)
48
Signal analysis
  • Radio monitoring is changing, due to introducing
    new digital signals, and transmitting additional
    information in the existing, more conventional
    signals.
  • Signal analysis is the art of extracting every
    possible bit of information from a signal, in our
    case a radio signal.
  • Includes modulation characteristics (symbol
    rate, frequency shift, linear/nonlinear
    modulation, kind of modulation, constellation),
    time characteristics (burst waveforms), spectrum
    characteristics (narrow/wide band, single carrier
    or multicarrier), traffic measurements,
    extraction of information from the demodulated
    data stream including hidden information.

49
DTFT
  • Fourier transform of a signal x(t) is computed as
  • If the signal is a discrete sequence x(nTs), the
    Discrete Time Fourier Transform (DTFT) is
    computed as
  • where Ts is the sampling period. The DTFT is a
    periodic function with a period fs1/Ts.

50
DFT
  • Assume that we have N samples of discrete time
    signal x(nTs), with Ts the sampling period.
    Signal is time limited to NTs. Denote this
    sequence by x(n), n0, ... ,N-1.
  • We define Discrete Fourier Transform
  • Since X(k) is a discrete function, time signal
    becomes a periodic function with period NTs.
  • Inverse DFT is defined as

51
Comparison of FT, DTFT, FS, DFT
  • Fourier transform of a continuous and aperiodic
    signal
  • DTFT of a sampled and aperiodic signal
  • Fourier series of a continuous and periodic
    signal
  • DFT of a sampled and periodic signal

52
DFT resolution
  • Note that the DFT is a sampled version of DTFT
    when a block of samples is observed. When N
    increases to infinity, it coincides with the
    DTFT.
  • The DFT resolution can be increased by increasing
    the number of samples (block length) used for
    computation.
  • Since real signals are non-stationary, long
    blocks of samples should not be used. Using short
    blocks of samples is called Short Term Fourier
    Transform (STFT).
  • There is a trade-off between increased spectral
    resolution and the requirement of using short
    blocks of samples for non-stationary signals.

53
DFT spectral leakage
  • Since N samples of the signal are used to compute
    the DFT, this corresponds to multiplying the
    signal with a rectangular window of duration N
    samples (NTs seconds).
  • Multiplication in time domain is convolution in
    frequency domain, so the spectrum of the signal
    is convolved with sin(pfNTs)/pfNTs function. This
    causes spectral leakage.
  • The window spectrum from f0 to the first null is
    called main lobe.
  • The window spectrum between any two consecutive
    nulls is called side lobe.

54
DFT windows
  • In order to decrease spectral leakage, various
    time windows are used. The requirements from a
    window are to have low first sidelobe and the
    power in the sidelobes to decrease as fast as
    possible.
  • Windows that produce low side lobes, produce wide
    main lobe. This is a trade-off between resolution
    (the width of the main lobe) and spectral leakage
    (the amplitude of the side lobes).
  • Rectangular window has the narrowest main lobe,
    but the largest side lobes Blackman window has
    the widest main lobe, but the lowest side lobes.

55
DFT windows
  • (a) Rectangular window
  • (b) Hamming window
  • (c) Blackman window

(b)
(a)
(c)
56
FFT
  • FFT is just an algorithm for fast computation of
    DFT, when the block length is a power of 2.
  • This criterion can be met in one of three ways
    sampling a sequence in a way that block length is
    a power of 2, interpolating the sampled sequence
    to obtain a length that is a power of 2, or,
    putting zeros at the end and beginning of the
    sampled sequence (zero padding).
  • There are different algorithms for computing FFT.
    The complexity is proportional to Nlog2N, as
    opposed to N2 for DFT.

57
Equipment for spectrum analysis
  • Digital technologies, such as analog to digital
    converters (ADCs) and DSP have become more common
    in spectrum analyzers, gradually moving from data
    display functions toward the analyzers' inputs.
  • In modern analyzers, this digital technology is
    concentrated in the stages following the final
    IF, i.e. resolution bandwidth (RBW) filtering.
  • Modern spectrum analyzers use an all digital IF
    section. Using DSP instead of series of analog
    gain and filtering stages eliminates or vastly
    reduces many sources of error including IF gain
    uncertainty, RBW switching error, RBW filter
    bandwidth uncertainty, etc.

58
FFT versus swept spectrum analyzers
  • Modern spectrum analyzers use both swept and FFT
    analysis techniques for spectrum measurements.
  • In a swept spectrum analyzer the amplitude
    accuracy of the RBW filters can be quite high
    because they are all centered at the same
    frequency.
  • In the case of FFTs, the flatness of the IF
    preceding A/D process is a factor in determining
    accuracy.
  • The primary advantage of FFT analysis is
    measurement speed in measurements that require a
    narrow RBW and a relatively wide frequency span.
    FFT processing can be viewed as the operation of
    many RBW filters in parallel.

59
FFT versus swept spectrum analyzers
  • Sweep time for an FFT analyzer increases linearly
    as RBW is reduced, rather than as the inverse
    square of the RBW (as it would for a single swept
    RBW filter).
  • For wider bandwidths the FFT computational
    overload becomes more significant and begins to
    exceed the gains from parallel processing. As a
    consequence, FFT analysis can actually be
    substantially slower than swept techniques in
    analyzing wide frequency spans.

60
FFT versus swept spectrum analyzers
  • (a) resolution bandwidth (RBW) in swept analyzers
    is narrow
  • (b) conceptual comparison of measurement speeds
    for swept and FFT analysis
  • (c) practical measurement speeds for an existing
    spectrum analyzer

(b)
(a)
(c)
61
Swept spectrum analyzers
  • For the measurement of narrowband emissions, a
    spectrum analyzer having a high degree of
    resolution is desirable. A typical instrument has
    a maximum resolution of 10 Hz and provides a
    swept range adjustable from 1 kHz to 100 kHz,
    together with a sweep rate adjustable from 1 to
    30 sweeps per second.
  • For the analysis of wideband emissions, available
    instruments cover frequency range up to 44 GHz
    with a sweep width continuously variable up to
    100 MHz (at the higher frequencies). The sweep
    rate is adjustable from 1 to 60 sweeps per
    second.

62
Digital receivers
  • Receivers are also becoming all digital. That
    means that following the A/D conversion at IF,
    they process samples instead of analog waveforms.
    Demodulation is performed by DSP.
  • DSP techniques used in modern digital receivers
    digital down conversion, digital filtering
    (including FIR and IIR filtering), downsampling.
  • It is much easier to realize digital filter than
    analog filter. Digital filters use mathematical
    algorithms, as opposed to analog filters, that
    are directly attributable to the physics of the
    devices implementing them.

63
Digital receivers
  • First step is conversion of the RF signal to IF
    signal.
  • Second step is the IF digitizing using A/D
    converter.
  • Then the DSP performs filtering and demodulation.
  • A/D converter performs analog signal
    reconstruction.

64
Digital receivers
  • The performance of digital receivers does not
    vary with regard to time and temperature.
  • Digital receivers have improved flexibility, and
    can accommodate complex modulation formats,
    including digital modulation formats.
  • Additional IF bandwidth, demodulation modes or
    other functions can be made in a DSP based
    circuit by a software change.
  • Modern digital monitoring receivers include a
    display with a control unit, typically a PC with
    computer software.
  • The receiver also has a remote interface,
    including LAN.

65
Bandwidth definitions
  • baseband bandwidth The width of the band of
    frequencies occupied by one signal, or a number
    of multiplexed signals, which is intended to be
    conveyed by a line or a radio transmission
    system.
  • necessary bandwidth For a given class of
    emission, the width of the frequency band which
    is just sufficient to ensure the transmission of
    information at the rate and with the quality
    required under specified conditions.
  • out-of-band emission Emission on a frequency or
    frequencies immediately outside the necessary
    bandwidth which results from the modulation
    process, but excluding spurious emissions.

66
Bandwidth definitions
  • out-of-band spectrum (of an emission) The part of
    the power density spectrum of an emission, which
    is outside the necessary bandwidth and which
    results from the modulation process, with the
    exception of spurious emissions.
  • spurious emission Emission on a frequency or
    frequencies which are outside the necessary
    bandwidth and the level of which may be reduced
    without affecting the corresponding transmission
    of information. Spurious emissions include
    harmonic emissions, parasitic emissions,
    intermodulation products and frequency conversion
    products, but exclude out-of-band emissions.

67
Bandwidth definitions
  • unwanted emissions Consist of spurious emissions
    and out-of-band emissions.
  • out-of-band power (of an emission) The total
    power emitted at the frequencies of the
    out-of-band spectrum.
  • occupied bandwidth The width of a frequency band
    such that, below the lower and above the upper
    frequency limits, the mean powers emitted are
    each equal to a specified percentage b/2 of the
    total mean power of a given emission. Unless
    otherwise specified by the Radiocommunication
    Assembly for the appropriate class of emission,
    b/20.5.

68
Bandwidth definitions
  • x-dB bandwidth The width of a frequency band such
    that beyond its lower and upper limits any
    discrete spectrum component of continuous
    spectral power density is at least x-dB lower
    than a predetermined 0 dB reference level.
  • assigned frequency band The frequency band within
    which the emission of a station is authorized
    the width of the band equals the necessary
    bandwidth plus twice the absolute value of
    frequency tolerance.

69
Measurement of occupied bandwidth
  • Digital signal processing techniques can be used
    to calculate the occupied bandwidth from the PSD.
  • First, the noise floor of the PSD is estimated.
    The PSD values are set to zero if the power is
    less than Y dB above the noise floor. For most
    signals Y6dB is adopted.
  • The total signal power, P, is computed by summing
    the values of the PSD bins containing the signal
    energy. The integral of the PSD is computed and
    the data are interpolated to find the lower and
    upper frequencies, f1 and f2, where the
    integrated power equals Pb/2. The occupied
    bandwidth is f2f1. This is the power-ratio
    method.

70
Measurement of occupied bandwidth
  • Emission is considered optimum when its occupied
    bandwidth coincides with the necessary bandwidth
    for the class of emission concerned.

71
Measurement of occupied bandwidth
  • A relationship between the errors in the occupied
    bandwidth and the errors in the power comparison
    is obtained from the spectrum envelope
    approximation
  • where S(fm) is the power on a given frequency,
    g0.33Nfm and N is a number of dB by which the
    spectrum envelope is reduced within an octave of
    band widening.
  • For N12-20 dB/octave, power comparison at
    accuracy of about 15-20 ensures an occupied
    bandwidth measurement accuracy of 3 to 7.

72
Method using a spectrum analyzer
  • PSD evaluated by spectrum analysis is used. The
    relevant power values are determined by summing
    the powers of the individual spectral components.
  • When the PSD is continuous, PSD samples with
    equidistant separation are used.
  • A spectrum analyzer with a digitally controlled
    synthesizer scans the spectrum in frequency
    steps, and a digital memory sends the measured
    values to a computer, which in turn performs the
    calculations.
  • Since a conventional spectrum analyzer performs a
    sequential measurement, it is advisable to make a
    number of scans.

73
Method relying on FFT
  • FFT based power-ratio measuring methods require
    little or no knowledge about the detailed
    parameters of the modulation and are able to
    interpret the part of the signal spectrum that
    emerges out of the noise floor.
  • effect of windowing a window must be selected
    that generates an overall low side lobe power
    content, so as to operate in conditions as close
    as possible to the definition, which requires
    rectangular filters.
  • FFT resolution 99 power method does not depend
    much on the resolution chosen to compute the FFT.
    It gives very accurate results as soon as more
    that a 100 to 200 bins cover the occupied
    bandwidth of the signal.

74
Method relying on FFT
  • effect of the duration of signal sample the
    observation window must be long enough to cover
    the entire signal. Simulation tests with
    stationary signals show that reliable results are
    obtained for about 1000 symbols (for digital
    modulation).
  • effect of noise under noisy conditions, it is
    essential to filter the signal emerging from
    noise the importance of filtering increases when
    the SNR is low. If the observed bandwidth
    significantly exceeds the occupied bandwidth, the
    99 bandwidth of the signalnoise will be
    measured instead that of the signal alone.

75
x-dB method
  • The x-dB method computes bandwidth by taking
    frequencies where the PSD drops for x-dB compared
    to reference 0 dB level
  • Method with single band-pass filter sweeping
    narrow-band filter, i.e. spectrum analyzer. The
    x-dB bandwidth is considered to include discrete
    components attenuated less than 26 dB below the
    peak value of the emissions.
  • If the signal contains numerous low-level
    components, the result might be different from
    power-ratio result. Also, it is not possible to
    have both high resolution and rapid sweep rates.

76
x-dB method
  • The problem with this approach is how to
    determine the reference level, especially in
    cases where the PSD at carrier frequency is not
    maximum for instance FM modulation might result
    in large reduction of the carrier therefore, the
    reference level is measured by choosing a
    receiver bandwidth that covers the whole signal.
  • Another problem is how to specify x for different
    classes of emission usually adopted values are
    x20 dB and x26 dB.
  • In the case of CDMA or OFDM, where there is a
    large band of relatively flat PSD, x-dB method
    might give incorrect results.

77
x-dB method
  • the ITU-R recommends that "until occupied
    bandwidth measurement methods have been developed
    making full allowance for the specific character
    of the activities of monitoring stations, these
    stations should continue to use the x-dB method
    as specified to perform the measurement at -26 dB
    and apply a correction factor for the appropriate
    class of emission, to determine the occupied
    bandwidth". Also, "administrations and other
    entities of the ITU-R should be encouraged to
    study, including by testing, the extension of the
    x-dB method to other classes of emission and
    development of appropriate correction factors for
    x-26dB".

78
Effects of interference
  • The ratio of the total power of a signal to the
    total power of interfering emissions is W/U.
  • The ratio of the power of the interfering
    emissions remaining outside the occupied
    bandwidth to the total power of interfering
    emissions is k.

79
Effects of interference
  • If k is equal to the ratio of the out-of-band
    radiated power of the emission to be measured to
    its total power, the interference does not affect
    the measured value.
  • When k0, the interfering emissions are entirely
    within the band and the apparent bandwidth
    becomes narrower.
  • When k1, the interfering emissions are entirely
    outside the band, and the apparent bandwidth
    becomes wider.
  • In practice, the effects of interference are
    complicated. In the actual measurement, it is
    sufficient to consider k1.
  • A value of the ratio W/U gt30 dB restricts the
    measuring error of the power ratio to lt0.1 of
    the total power.

80
Effects of noise
  • The effects of random noise on the measured value
    of bandwidth are the same as those of
    interference, replacing k by kn (Wb/WBO), W/U by
    S/N (Pt/PN). Cases kn0 or kn1 do not exist
    with random noise.
  • As signal to noise ratio S/N becomes smaller,
    the apparent out-of-band radiated power increases
    and the apparent occupied bandwidth extends.
  • To confine the measuring error of the power ratio
    to less than 0.1, the value of S/N for the
    emission to be measured should be greater than
    about 25 dB, for values of k less than about 1/3,
    which is considered appropriate for monitoring.

81
Effects of noise
82
Requirements for equipment
  • The frequency characteristic of the passband
    should be flat within K0.5dB over the range of
    the spectrum of the emission to be measured, and
    the loss in stop-band should be at least 30 dB,
    with a steep slope in the transition band.
  • The frequency selectivity should be such as to
    discriminate against out-of-band noise and
    interference whilst not introducing a loss of
    more than 2 dB at the edges of the passband
    relative to the level at the middle of passband.
  • The equipment should exhibit good linearity for
    an input variation of at least 60 dB, in order to
    cope with possible variations of the field
    intensity of the emission.

83
Conclusion
  • Digital modulation is becoming predominant
    modulation, such as OFDM for audio and video
    broadcasting (DAB, DVB-T), GMSK and spread
    spectrum for mobile systems, spread spectrum and
    OFDM for WLAN.
  • Digital modulations require measurements of a
    number of new parameters, compared to analog
    modulation.
  • Modern receivers use A/D converters and modern
    DSP techniques for signal analysis and
    demodulation.
  • It is necessary for the monitoring personnel to
    be trained to perform measurements on the newly
    introduced digital modulation techniques, using
    modern DSP receivers.

84
Literature
  • Communications Systems Engineering, J. G. Proakis
    and M. Salehi, Prentice Hall, 2002.
  • The Mobile Communications Handbook, J. D. Gibson,
    editor, CRC Press, 1996.
  • Digital Signal Analysis, S. D. Stearns and D. R.
    Hush, Prentice Hall, 1990.
  • International Telecommunication Union Spectrum
    Monitoring Handbook, ITU, 2002.
  • Swept and FFT Analysis, Product Note, Agilent
    Technologies.
Write a Comment
User Comments (0)
About PowerShow.com
