Chlorine Disinfection of Drinking Water

1
Chlorine Disinfection of Drinking Water

• California Unified Program 8th Annual Training
  Conference
• February 8, 2006
• Presented by Paul G. Beswick
• Metropolitan Water District of Southern
  California
• Environmental Support Services
• [phone] pbeswick_at_mwdh2o.com

2
(No Transcript)
3
The Chlorine Disinfection Process

• Public Health benefits of chlorination
• Process flow
• Process components

4
Chlorination Public Health Benefit

• A critical role protecting US drinking water
  supply from waterborne infectious diseases for
  over 90 years
• Cholera, typhoid, dysentery, hepatitis A
  virtually eliminated
• In over 98 of disinfection systems
• Germicidal potency, residual disinfection
  properties, efficiency, economy

5
Chlorination Public Health Benefit
6
All Uses of Chlorine
7
The Chlorination Process
8
Chlorine Rail Car Unloading

• 90 Ton rail cars

9
Chlorine Trailer Unloading

• 17/19 Ton Trailers

10
Stationary Chlorine Tank

• 25 ton stationary tank

11
Chlorine Cylinder Storage

• 1 ton cylinders

12
Chlorine Evaporators
13
Chlorinators
14
Ejectors
15
Treatment Chemical Storage
Chemical Qty Capacity
Chlorine 3 90 ton rail cars
Caustic (25) 8 127,000/ 50,000 gal.
Aqueous Ammonia (19) 4 13,000/10,000 gal.
16
Chlorine System Safety - What we are doing

• 24 hour monitoring and access control
• Detailed operating procedures
• Highly trained staff
• Leak sensors and alarms
• Automatic supply shut-off valves
• Chlorine containment and neutralization
• On-site emergency response capability strong
  relationship with fire dept responders

17
Control Room

• Operator on duty 24 hours a day.
• Chlorine alarms are received in the Control Room.
• Chlorine facilities are visually inspected twice
  a shift.

18
(No Transcript)
19
Chlorine Trailer Manway

• Remote emergency shut-off capability
• Highly sensitive chlorine gas detector

20
Multiple Emergency Shut-off Locations

• Controlled from several strategic locations
• Shut-off is immediate

21
Monel Flex Hose Connection

• Durable/flexible connection
• Inspected/replaced regularly

22
Chlorine Gas Monitoring

• Continuous monitoring, alarms locally and in
  Control Room
• Sensors strategically placed throughout plant
• Calibrated regularly

23
Chlorine leak alarms

• Audio/Visual chlorine gas leak alarms -
  immediate notification to all plant personnel.

24
Vacuum Operation

• Chlorine piped to points of use throughout plant
  under vacuum
• Safest method of transmission

25
New chlorine containment facilities
26
Chlorine Cargo Trailers Inside Containment
Chlorine Storage Bay
27
Caustic Neutralization System
Two 3.5-Ton Chlorine Scrubbers
28
Chlorine Rail Car Containment
29
Chlorine Rail Car Containment
30
Chlorine Rail Car Scrubbers
31
Good Relations With Fire Dept. Responders
32
LAFD Visits Jensen Plant
33
LAFD Visits Jensen Plant
34
Where Is The Real Chlorine Release Threat?!
35
Rural Bexar County, Texas June 28, 20043 dead,
50 hospitalized
36
Graniteville, South CarolinaJanuary 6, 20059
killed, 554 hospitalized, 5,400 evacuated
37
Graniteville, South CarolinaJanuary 6, 20059
killed, 554 hospitalized, 5,400 evacuated
38
Graniteville, South CarolinaJanuary 6, 20059
killed, 554 hospitalized, 5,400 evacuated
39
Graniteville, South CarolinaJanuary 6, 20059
killed, 554 hospitalized, 5,400 evacuated
40
Where Is The Real Chlorine Release Threat?!

• Two train wrecks in 6 months
• resulted in significant chlorine releases
• 12 dead
• over 600 taken to hospital
• over 5,000 evacuated.

41
Chlorine Rail Transportation Issues

• Rail freight cost cutting, lack of re-investment,
  explosive growth, stretched resources
• Security
• In transit
• Storage while in transit
• Identifying hazmat derailment
• Warning local first responders
• Mobilizing specialist response team
