Title: Panasonic KX-TA624 Advanced Hybrid PBX System


1
Panasonic KX-TA624Advanced Hybrid PBX System
  • OVERVIEW

2
System Outline
  • Initial configuration is 3 CO X 8 Stations
  • KX-TA62460 Doorphone / Door Opener Card
  • KX-TA62470 Card adds 8 Stations
  • KX-TA62477 Card adds 3 CO X 8 Stations
  • KX-TA62491 DISA / Fax Detection Card
  • KX-TA62493 Caller ID Card for 3 CO lines

3
KX-TA624
  • Initially configured with 3 CO X 8 Station
  • ExternalMusic Source
  • External Paging Jack
  • RS-232 for SMDR
  • Ground Screw
  • Power On/Off Switch
  • Vertical / Horizontal Mounting

4
KX-TA624 System Connections
  • 1 External Paging Jack (Radio Shack Cat. No.
    42-2420)
  • 1 External Music On Hold Input Jack (Radio
    Shack Cat. No. 42-2420)
  • 1 Station Message Detail Recording RS-232
  • Reset Switch
  • System Clear Switch
  • Vertical / Horizontal Mounting

5
KX-TA624 System Connections
  • Central Office Lines RJ-14 CO Lines
  • Extensions RJ-14 Extensions Extensions 101,
    105, 109, 113, 117 121 all ring at the same
    time Extensions 102, 106, 110, 114, 118 122
    all ring at the same time Extensions 103, 107,
    111, 115, 119 123 all ring at the same time
    Extensions 104, 108, 112, 116, 120 124 all
    ring at the same time
  • Paging Jack 3.55 mm
  • Music On Hold Jack 3.55 mm
  • SMDR 9 pin Male RS-232

6
KX-TA62460
  • Card for 4 door phones (KX-T30865)
  • 2 door phone speech paths - 1 2, 3 4
  • Card for 4 Door Openers (not provided)
  • Door phone connections RJ-14. 4 conductor line
    cord to jack. (red/green to DP 1, black/yellow to
    DP 2)

7
Up to Four Doorphones
  • Requires the KX-62460 DP Card
  • Optional Doorphones - KX-T30865
  • Day/Night/Lunch Ring Assignments
  • Flexible Ring Tone Pattern (three)
  • Flexible Ring Length (15 or 30 Seconds)
  • Flexible Door Opener Assignment and Times (for
    Day/Night/Lunch
  • Adjustable Door Opener Time

8
KX-T30865
  • Door phone unit
  • Ring- Day, Night, Lunch
  • Door Opener Day, Night, Lunch

9
KX-TA62470
  • 8 Extension Expansion Card
  • This card can be installed directly to the system
    for a 3 CO X 16 station, or connected on
    the KX-TA62477 for jacks 17 through 24.

10
KX-TA62477
  • 3 CO and 8 Ext Expansion Card
  • Lines 4 through 6
  • Jacks 9 through 16

11
KX-TA62491
  • DISA (Direct Inward Station Access)
  • Day / Night message
  • Fax Detection
  • One Touch Access to stations or ring groups
  • One per system

12
DISA (Direct Inward Station Access)
  • Caller hears a pre-recorded Outgoing Message
    (requires a KX-TA62491 card).
  • Operator records max of two messages (Day/Night)
    up to 30 seconds each.
  • Fax Detection (Requires the KX-TA62491 to answer
    the incoming call)
  • One Touch Dialing- to an extension, operator or
    Ring Group. Up to 10 codes.
  • Programmable Security Codes

13
DISA (continued)
  • Calling an External Party- Security Codes, CO
    Security, 3 time and youre out.
  • Can answer 1 - 6 lines
  • DISA Busy Mode- Call Wait, Disconnect or hear
    DISA 2 message
  • Intercept on busy stations to another
    programmable station

14
KX-TA62493 CID
  • Provides Name or Number to a Proprietary
    Telephone
  • KX-T7130 or KX-T7030
  • 2 cards maximum
  • card for lines 1-3, and lines 4-6

15
Caller ID
  • Requires the KX-TA62493 card. Max 2 cards.
    Handles three COs each
  • Log up to 20 numbers.
  • Must use a KX-T7030 or KX-T7130
  • Will not display CID on a SLT
  • Prog a CID Indication Button for Logging
  • Prog a CID Selection Button to scroll info

16
KX-T Proprietary Devices
  • KX-T7130
  • KX-T7030
  • KX-T7020
  • KX-T7050
  • KX-T7055
  • KX-T7040
  • KX-T7880
  • KX-T7885

17
KX-T7130
  • Large Display Speaker phone.
  • 12 Flex CO Buttons
  • 12 Flex Func Buttons
  • Handset/Headset
  • White or Black

18
KX-T7030
  • Display Speakerphone
  • 12 Flex CO Buttons
  • 4 Flex Function Buttons

19
KX-T7020
  • Speakerphone
  • 12 Flex CO Buttons
  • 4 Flex Function Buttons

20
KX-T7050
  • Monitor Telephone
  • 12 Flex CO Lines
  • 4 Flex Monitor Buttons

21
KX-T7055
  • Monitor Telephone
  • 3 Flex CO Buttons
  • 3 Flex Monitor Buttons
  • White Only

22
KX-T7040
  • Direct Station Selector/ Busy Lamp Field Console
    DSS/BLF
  • 32 Programmable DSS/BLF buttons
  • 16 Programmable One-Touch feature buttons

23
KX-T7880
  • Multi-Line Cordless
  • 3 Flex CO Buttons
  • 1 Intercom Button
  • Conference, Hold
  • Up to 30 on a system

24
KX-T7885
  • 900 MHz Multi-Line Wireless Telephone with LCD
  • 3 Line Multi-Function LCD
  • Top line for call activity and phone status
    symbols
  • Middle line for normal display phone
    alpha-numeric text
  • Bottom line for flexible button identification
    text
  • 4 Programmable buttons for up to 12 functions
  • 6 Ringer Modes including Vibrator Mode
  • Headset Jack (2.5mm jack)
  • High Capacity, Quick Charging NiMH battery
  • Includes one battery
  • Additional KX-A276 batteries can be purchased
    separately

25
New Enhanced Capabilities
  • Account Codes
  • Call Transfer to CO
  • Conference Call, Unattended
  • Room Monitor
  • Station Message Detail Recording (SMDR)
  • TAM - Telephone Answer Machine Support
  • Time (Day, Night, Lunch) Service
  • Voice Mail Integration
  • Additional Features

26
Account Codes
  • SMDR can be used for Accounting / Billing
  • 24 Separate Codes Available
  • Incoming Calls to SMDR is Optional
  • Outgoing Calls have four choices Verify- All
    Mode, Verify- Toll Mode Forced Mode, Option
    Mode
  • Four Digits (0 - 9)
  • Emergency Numbers override Acct. Entry

27
Call Transfer CO / Unattended Conference
  • Allows an APT to Transfer an incoming CO or
    Intercom call to an outside CO
  • Disabled by default (prog 606)
  • Timer Adjustment 1 - 32 Minutes
  • Unattended Conference- Leave the conference by
    Pressing CONF. Return by Pressing CONF. Max
    time 32 minutes

28
Room Monitor
  • Monitor APT or Door phone w/o a tone
  • Must be assigned (prog 612)
  • Activate at phone (7351)
  • Can Not Use a KX-T7050 or 7055
  • SLT with MUTE button can be used for monitoring

29
SMDR
  • Print details to a computer or serial printer on
    outside calls
  • Requires a DB9-DB9 Null Modem Cable. Cable will
    be a female 9 pin to female 9 pin.
  • Shows Date, Time, Ext. making the call, CO line
    the call was made on, dialed number, duration of
    call. Incoming will display callers number (with
    CID from Telco and a KX-TA62493 card.

30
TAM Extension
  • Assign a jack for TAM (Sys 611)
  • TAM answers CO, dial station connected to TAM,
    hear busy, dial 4.
  • All stations can be assigned as TAM
  • Disconnects TAM Station

31
Time (Day, Night, Lunch) Service
  • Automatic or Manual Mode - (006)
  • Flexible Ringing- (408-410)
  • Delayed Ringing- (411-413)
  • Incoming Ring Service- (414-416) Choice of DIL,
    DISA1, DISA2
  • Flexible Out Dial (405-407)

32
Voice Mail Integration
  • Supports In-Band Signaling (follow on ID)
  • Up to four ports
  • Works with the KX-TVS75/100/200
  • Activates the MW Light on 7000 Series
  • Supports immediate answer, delayed answer and
    DISA Intercept Routing
  • Flexible MW Button on 7000 Series

33
Additional Features
  • Additional Timers (prog 200-211)
  • KX-T7040 DSS Console- Max two, uses station port
  • System Password, 4 digit, adjustable
  • 12/24 Hour Clock
  • CO Line Indicator Assignment (prog 109) Assigns
    capability of answering calls not assigned to
    ring.
  • Flash Key Mode (prog 110) allows EFA
