ANATOMY OF TWO WHEELER

1
ANATOMY OF TWO WHEELER

• PREESNTED BY
• AJAY K. JAIN

2
ANATOMY OF TWO WHEELER
3
Handle bar
Fuel tank
Pillion graprail
Tail light
Seat
Visor
Meter
Head light
Rear mudguard
Shocker rods
Shocker outer
Spring suspension
Wheel
Disk brakes
Alloy wheels
Exhaust pipe
Engine
Frame
Main stand
4
CHASSIS
5
SHOCKER ROD OUTER
SPRING BOOT
FORK HOLDER UNDER
SHOCKER ROD
6
FUEL TANK
REAR COWL
SIDE COWL
7
SILENCERTAIL PIPE ASSY
8
SEAT
9
SWING ARM
10
STAND
11
HANDLE BAR
12
METER COVER
TACHOMETER
METER PLATE
SPEEDO METER
