Title: Advanced Ethernet Features


1
Local Area Networks
  • Advanced Ethernet Features

2
IEEE 802.3 Family of LAN Protocols Advanced
Features
  • Introduction
  • Along with order-of-magnitude increases in speed
    and the application of switching to Ethernet,
    there are a number of advanced features that have
    been developed
  • Full-duplex operation
  • Jumbo Frames
  • Flow Control
  • Link Aggregation
  • Virtual LANs (VLANs)
  • Priority Transport
  • Port Authentication
  • There are other networking technologies that can
    take advantage of these features we are only
    discussing these in the context of Ethernet

3
Advanced Ethernet Features Full-Duplex Operation
  • Introduction
  • Traditional Ethernet is half-duplex a station
    cannot send and receive data simultaneously
  • While upgrading from shared to switched LANs
    increases network capacity, it does not
    completely eliminate CSMA/CD from network
    operation
  • The collision domain shrinks, but there are still
    two stations competing for the medium
  • Full-duplex operation allows nodes to transmit
    and receive simultaneously
  • Effectively no collision domain because there is
    only one transmitter and one receiver on a
    switched LAN leading to direct transmission
    without CSMA/CD.
  • 100 link utilization with well-designed LAN
    switches
  • 100BASE-TX, and 100BASE-FX support full duplex as
    transmit and receive signal paths can be
    simultaneously active.

4
Advanced Ethernet Features Full-Duplex Operation
  • Collision Domains
  • Lets take a moment to explore the impact of
    switching full-duplex operation on the
    collision domains found in a network
  • Half-duplex shared
  • Half-duplex switched
  • Full-duplex switched
  • A tangent switch backplane capacity
    full-duplex operation

5
Advanced Ethernet Features Full-Duplex Operation
  • IEEE 802.3x
  • The IEEE 802.x Working Group developed a standard
    that enhanced switched mode operation by defining
    full-duplex data transfer operation
  • IEEE 802.3x finalized in 1997
  • Allow independent (and simultaneous) transmission
    and reception of data by an Ethernet node
  • Though mistakenly associated with Fast Ethernet,
    IEEE 802.3x is applicable to all flavors of
    Ethernet
  • Also included specifications for flow control
    across full-duplex links
  • Requires backwards compatibility (though manual
    configuration of mixed half and full-duplex
    equipment requires care!

6
Advanced Ethernet Features Full-Duplex Operation
  • Requirements
  • Requires the use of a star topology with a
    central wiring closet
  • The Ethernet PHY must have independent transmit
    receive paths
  • Baseband coax -gt NO!
  • Fiber and UTP -gt YES
  • There must be only two nodes on a dedicated
    point-to-point link
  • Both nodes must be configured for full-duplex
    operation
  • Requires switches beware of full-duplex
    Ethernet hubs!

7
Advanced Ethernet Features Full-Duplex Operation
  • Operational Considerations
  • While full-duplex ports are CSMA/CD capable, the
    MAC algorithm is disabled in full-duplex
    operation
  • Frames are transmitted as soon as possible with
    only the IFG (Inter-frame Gap) between frames
  • While CSMA/CD distance (delay) requirements no
    longer apply, the noise attenuation
    characteristics of the physical media still
    impose distance limits
  • For UTP, half and full-duplex limits are the same
  • For fiber, full-duplex links can span great
    distances (up to 40km with single-mode fiber and
    expensive optical components)

8
Advanced Ethernet Features Full-Duplex Operation
  • Flow Control across full-duplex links
  • While great for efficiency, care is needed to
    prevent full-duplex nodes from being overwhelmed
    with traffic
  • The committee incorporated MAC-layer flow control
    into 802.3x to help prevent buffer overflow at
    nodes
  • Without CSMA/CD the methods used for flow control
    in a half-duplex environment disappeared (e.g.-
    backpressure)
  • The 802.3x MAC Control Protocol
  • The standard defined new MAC control frames to
    use between nodes in a full-duplex connection
  • These control frames are special Ethernet frames
    of type 0x8808 hex that contain opcodes for
    various functions

9
Advanced Ethernet Features Full-Duplex Operation
  • The PAUSE MAC Control Frame
  • The only defined MAC Control Command assigned
    opcode 0x0001 hex
  • Sent to the reserved destination multicast
    address 01-80-c2-00-00-01
  • Included in the frame is the Pause time
  • Can be a value between 0 and 65,535
  • This value is a multiplier receiver multiplies
    value by 512 bit times to determine the Pause
    time
  • During that interval Receiver (of the PAUSE
    frame) should transmit no frames

10
Advanced Ethernet Features Jumbo Frames
  • Introduction
  • The effect of frame size on efficiency
  • Current maximum ethernet frame size is 1518 bytes
    (1522 with VLAN tagging)
  • Compare this with other technologies like Token
    Ring and FDDI
  • Not efficient for certain applications
  • File transfers
  • Compute clusters
  • Storage Area Networks
  • Jumbo frames nominally refer to any ethernet
    equipment that can transport frames larger than
    the standard frame size

11
Advanced Ethernet Features Jumbo Frames
  • Implementation
  • While Jumbo frames are implemented by many
    manufacturers, there is no current standard
  • This means you must be careful with network
    design and interoperability
  • Even in a vendors product line there can be
    differences!
  • A variety of sizes has been proposed a very
    common size is around 9000 bytes
  • Large enough to allow a complete NFS message to
    ride in a single Ethernet frame
  • Another common size is around 4470 bytes (to be
    compatible with other protocols like FDDI)
  • See http//darkwing.uoregon.edu/joe/jumbo-clean-g
    ear.html for a list of equipment frame sizes

12
Example (TCP packet transfer)
  • Due to overhead caused by TCP relaibility, the
    TCP throughput lt 0.7 MSS / (rtt
    sqrt(packet_loss)), where MSS is maximum segment
    size (MTU minus TCP/IP headers), rtt is round
    trip time, and packet_loss is probability of
    frame loss.
  • Suppose rtt is about 40 msec, and let's say
    packet_loss is 0.1. With an frame size of 1500
    bytes (MSS of 1460). Evaluate the TCP throughput.
  • Answer TCP throughput 0.7x1460x8/(0.04x0.033)6.
    5 Mbps based on TCP's ability to detect and
    recover from congestion (loss).
  • Assume Jumbo Frame of 9000 byte. Evaluate the TCP
    throughput.
  • AnswerTCP throughput 0.7x(9000-40)x8/(0.04x0.033
    ) 40 Mbps.
  • Evaluate the packet loss rate to achieve a
    throughput of 500 Mbps with 1500 bytes and 9000
    byte frames.
  • Answer packet_loss (0.7 x MSS/(rtt x
    TCP_throughput))2.
  • We would need a packet loss rate of no more than
    1x10-5 when frame size is 9KBytes.
  • However, with 1500 byte frames, the required
    packet loss rate is down to 2.8x10-7!
  • While the jumbo frame is only 6 times larger, it
    allows us the same throughput in the face of 36
    times more packet loss.

13
Example (Continue)
  • A 9000 byte GE packet takes the same amount of
    time to transmit as a 900 byte F-Ethernet packet
    or a 90 byte 10 Mbps Ethernet packet.
  • Jumbo frames on GE at worse add less delay
    variation than 1500 byte frames do on slower
    Ethernets.
  • No one is suggesting that slower Ethernets use
    9000 byte frames.
  • As for queueing delay concerns, that could happen
    whether packets are large or small. If delivery
    QoS is required, then the routers need to
    implement some kind of priority or expedited
    forwarding, regardless of the packet sizes.
  • Tiny frames (including 53 byte ATM cells) may be
    helpful when multiplexing lower bit rate streams,
    but they become increasingly inefficient on
    gigabit and beyond links.
  • Conclusion leaving the local area network at
    high speed, the dynamics of TCP will require to
    use large frame sizes. Without them, the packet
    loss rate over a high bandwidth-delay product
    path would have to be extraordinarily low. Core
    internet infrastructure, from campus backbones to
    Network Access Points (NAPs), should be
    particularly careful not to limit the permitted
    MTU to 1500 bytes. In the long run there is no
    reason to stop at 9000 byte frames, but given the
    current ethernet CRC limitation it is a good
    evolutionary step for gigabit data rates.

14
Advanced Ethernet FeaturesLink Aggregation
  • Introduction
  • Allows an increase in network capacity
    availability without changing the underlying
    network technology
  • Another alternative to use when upgrading to a
    higher speed is neither feasible or possible
  • Sometimes called inverse multiplexing
  • Benefits
  • Increased bandwidth capacity
  • Granular capacity increase
  • Higher link availability
  • Uses existing hardware

15
Advanced Ethernet FeaturesLink Aggregation
  • Disadvantages
  • Like any technology there is always disadvantages
    -- these have kept link aggregation a niche
    solution
  • More space network interfaces necessary
  • More complexity
  • More maintenance overhead
  • Harder to troubleshoot aggregated links
  • Performance improvements depend on traffic flow

16
Advanced Ethernet FeaturesLink Aggregation
  • Application Scenarios
  • Switch-to-Switch
  • Switch-to-Station (possibly a server or router)
  • Station-to-Station (very rare)

17
Advanced Ethernet FeaturesLink Aggregation
  • Issues Considerations
  • Addressing Interfaces
  • Need to assign logical MAC across all aggregated
    NICs
  • Traffic Distribution Algorithm
  • How to allocate traffic among aggregated links
  • Want efficiency, but have to worry about other
    factors
  • Transparency to upper layers
  • Non-duplication
  • Ordering
  • Performance

18
Advanced Ethernet FeaturesLink Aggregation
  • Other Considerations
  • Mixing aggregate-able technologies
  • Mixing speeds (versions) of aggregate-able
    technologies
  • Using aggregation with shared LAN technologies
  • Must worry about the operation of the MAC
    algorithm
  • Really not recommended for use with shared LANs

19
Advanced Ethernet FeaturesLink Aggregation
  • The IEEE 802.3ad Link Aggregation Standard
  • Work on the standard began in 1998 with final
    approval in 2000
  • Standard applies to Ethernet only
  • All links in an aggregation must be the same
    speed
  • Other restrictions
  • Only full-duplex links
  • Only one aggregation group per pair of devices
    (there can be other individual links between
    these devices)
  • Many technical details taken from Etherchannel
    an earlier proprietary link aggregation protocol
    developed by Cisco

20
Advanced Ethernet FeaturesLink Aggregation
  • The IEEE 802.3ad Goals
  • Incremental bandwidth across logical channels
  • Linearly incremental bandwidth
  • Increased link availability
  • Automatic configuration fault tolerance via
    rapid link reconfiguration
  • Maintenance of link invariants
  • Transparency to upper layers/applications
  • Backwards compatibility with non-802.3ad
    equipment
  • No change to Ethernet frame
  • Network Management support

21
Advanced Ethernet FeaturesLink Aggregation
Operation
22
Advanced Ethernet FeaturesLink Aggregation
  • The IEEE 802.3ad Control Protocols
  • To maintain control of the aggregated links and
    traffic between devices, two control protocols
    are used
  • Marker Protocol
  • Link Aggregation Control Protocol (LACP)
  • Marker Protocol
  • Used to move data flows from one aggregated
    link to another
  • Uses fixed and link-constrained 128 byte Ethernet
    frames
  • Uses request/response operational commands

23
Advanced Ethernet FeaturesLink Aggregation
  • Link Aggregation Control Protocol (LACP)
  • Used to automatically configure maintain
    aggregated links between cooperating systems
  • Protocol is generally passive, operating in the
    following manner
  • Devices advertise their configuration capability
    via LACP messages
  • There are no response messages devices are
    supposed to read incoming messages and configure
    themselves appropriately (usually the best common
    configuration)
  • If device status or capability changes the
    change is to be advertised via LACP
  • LACP messages can be overridden by manual
    configuration

24
Advanced Ethernet FeaturesLink Aggregation
  • Link Aggregation Control Protocol (LACP)
  • What is exchanged in LACP messages
  • System ID used to ensure all aggregated links
    belong to the same (far-end) device
  • Port Numbers Priority uniquely identifies
    links optionally assigns an aggregation
    priority to a link
  • Aggregation Link Characteristics not all links
    between devices are aggregation candidates a key
    (unique value) shared by all links that can be
    aggregated
  • Operational Mode LACP can operate in either
    Active (send LACP messages without prompt) or
    Passive mode
  • LACP Message Transmission Frequency the
    configurable time interval between generation of
    LACP messages

25
Advanced Ethernet FeaturesVirtual LANs (VLANs)
  • Introduction
  • With LANs as discussed so far, there is no
    difference between the physical logical network
    layout
  • With VLANs the physical topology can be different
    than the logical topology
  • In other words, the set of stations that can
    communicate as if they are part of the same LAN
    (via direct MAC layer frames) can now be
    physically separated
  • Requires the use of VLAN-aware switches
  • VLAN applications
  • Moves, Adds, Changes
  • LAN Security (traffic isolation)
  • User Mobility
  • Bandwidth Efficiency

26
Advanced Ethernet FeaturesVirtual LANs (VLANs)
  • The old way

27
Advanced Ethernet FeaturesVirtual LANs (VLANs)
  • The new way

28
Advanced Ethernet FeaturesVirtual LANs (VLANs)
  • Requirements for VLAN Operation
  • Frame tags
  • VLAN awareness
  • VLAN association rules
  • Frame distribution
  • How do switches know the logical (virtual)
    groupings?
  • First, frames belong to VLANs
  • Two methods of associating frames with VLANs
  • Implicit tagging
  • Each switch examines the frame and based on its
    characteristics associates
  • Explicit tagging
  • Fields in the frame carry VLAN information

29
Advanced Ethernet FeaturesVirtual LANs (VLANs)
  • Varieties of VLAN Associations
  • Switch port-number based VLAN membership
  • MAC-address (48 bit) based VLAN membership
  • Protocol-based
  • IP-based
  • Application-based

30
Advanced Ethernet FeaturesVirtual LANs (VLANs)
  • The IEEE 802.1Q Standard
  • Due to demand, development of 802.1Q began in
    1995
  • Final approval in December 1998
  • Does not replace IEEE 802.1D (MAC-layer Bridges)
    but compliments it
  • Extends it for VLAN-aware switches
  • Maintains backward compatibility for non-VLAN
    operation and use in mixed environments
  • Defined VLAN use with Ethernet, Token Ring, and
    FDDI
  • What the standard covers
  • Frame tagging
  • Forwarding/Filtering Database
  • Priority Operation
  • Encapsulation of Token Ring/FDDI frames
  • Automatic distribution of VLAN information
  • Management of VLAN-aware switches

31
Advanced Ethernet FeaturesVirtual LANs (VLANs)
  • IEEE 802.1Q VLAN Tags Frame Format
  • Required modification of the basic Ethernet frame
  • Designed to fit in allow operation with
    non-tagged frames
  • Required extensive testing to ensure expanded
    frame (1522 bytes) caused no problems in existing
    equipment
  • Maximum Frame size changed in IEEE 802.3ac (1998)

32
Advanced Ethernet FeaturesVirtual LANs (VLANs)
  • IEEE 802.1Q VLAN Tag Fields
  • VLAN Protocol ID (16 bits) set to 0x8100 hex in
    all tagged frames
  • Priority (3 bits) used for the Priority
    function described later
  • Canonical Format Indicator (1 bit) only
    important when using 802.1Q to bridge between
    technologies
  • VLAN Identifier (12 bits) allows a maximum of
    4094 VLANs in a network
  • The value 0xFFF hex is reserved
  • The value 0x000 hex denotes a priority tag only
    frame has no VLAN association
  • E-RIF optional field used with Token Ring
    FDDI LANs employing native source routing

33
Advanced Ethernet FeaturesVirtual LANs (VLANs)
  • IEEE 802.1Q VLAN Switch Operation
  • Normal switches examine the destination MAC
    address in frames to determine what ports to
    transmit it on
  • The filtering/forwarding database matches
    destination MAC address to a port (unicast)
  • Unknown MAC addresses are flooded until learned
  • Broadcast MAC addresses transmitted out all port
    except the one it was received on
  • VLAN-aware switches add a second variable into
    the filtering/forwarding database corresponding
    decision
  • VLAN association for the frame
  • The switch needs a way to determine which
    physical ports to associate with a VLAN
  • Static (manual) mapping
  • Dynamic mapping

34
Advanced Ethernet FeaturesVirtual LANs (VLANs)
  • Automatic VLAN configuration
  • To allow easier administration of VLAN-based
    networks, a control protocol was developed for
    communicating VLAN information between switches
  • The protocol, call GVRP (GARP VLAN Registration
    Protocol), is part of a family of switch-related
    control protocols
  • GVRP allows the switch at one end of a link to
    advertise the VLANs associations for the physical
    port to the far-end device
  • Uses a reserved destination MAC address
    01-80-c2-00-00-21
  • Similar definitions and operation to LACP

35
Advanced Ethernet FeaturesTraffic Classes
Quality of Service
  • Introduction
  • While priorities are included in several of the
    802 protocols and the IEEE 802.1D specification
    outlines how bridges should map priorities
    between different protocols, the original
    specifications do not define a true set of
    traffic classes
  • Ethernet as defined has no traffic classes
  • Bridges are not told how to prioritize frames for
    transmission)
  • To provide better MAC layer support for
    time-critical data an update to the 802.1D
    specification defines and outlines the use of
    traffic classes
  • This work is sometimes called 802.1p because it
    was the committee that developed the priority
    mechanisms

36
Advanced Ethernet Features Traffic Classes
Quality of Service
  • The Use of Traffic Classes in IEEE 802.1D
  • The updated standard relies on three concepts
  • User Priority the priority found in the
    priority field of the MAC frame usually carried
    end-to-end unless it needs to be modified to fit
    the rules of a transit MAC protocol
  • Access Priority the priority with which a
    bridge accesses the outbound LAN to transmit a
    frame it must relay
  • Traffic Class if bridge has multiple queues for
    outbound traffic, the traffic class is used to
    determine the relative priority of the queues
  • The Traffic Class is assigned by the bridge on
    the basis of incoming user priority
  • Traffic classes help reduce the queuing delay
    seen by high priority frames, though there is
    still an access delay for transmission (based on
    the outbound MAC protocol)

37
Advanced Ethernet Features Traffic Classes
Quality of Service
  • The Use of Traffic Classes in 802.1D (continued)
  • Eight traffic classes are defined usable for
    each outbound port, corresponding to eight
    distinct outbound queues
  • Within a queue a FIFO discipline is typically
    used strict ordering in the traffic class
  • Output scheduling
  • There are two basic choices for determining how
    to pull data out of the queues for transmission
  • Obviously, strict round robin is not one of the
    choices!
  • Strict Priority transmit any waiting frames out
    of the highest priority queues exclusively
  • Weighted Fair Queuing (WFQ)
  • Uses round robin but is modified by a weight
  • Higher weights assigned to higher priority queues

38
Advanced Ethernet Features Traffic Classes
Quality of Service
  • The Use of Traffic Classes in 802.1D (continued)
  • Bridge Queue Diagram

39
Advanced Ethernet Features Traffic Classes
Quality of Service
  • Weighted Fair Queuing

40
Advanced Ethernet Features Traffic Classes
Quality of Service
  • Mapping of User Priority to Traffic Class
  • The recommended 802.1D mapping of incoming user
    priority to traffic class is shown in Table 12.4
  • If the 802.1Q (virtual LAN) specification is in
    use the priority field in the tag header can be
    used to determine the traffic class if necessary
  • How this is done was already discussed
  • Even protocols like 802.3 and 802.11 that support
    only one access priority can support multiple
    traffic classes (queues) but how the queues are
    filled are determined by other parameters (e.g.
    protocol type)

41
Advanced Ethernet Features Traffic Classes
Quality of Service
  • Internet Traffic Quality of Service
  • Many higher layer protocols have QoS mechanisms
    there should be some way to map higher level QoS
    levels to 802.1D traffic classes
  • There are a couple of difficulties with this
  • Internet traffic usually traverses a set of
    diverse networks making mapping between layers
    difficult
  • Lower layers typically cannot see the QoS
    mechanisms used in higher layers
  • In IP and ATM networks this would allow higher
    layer QoS (like the IP TOS bits or ATM service
    class) to be used to set the priorities of frames
    wherever possible
  • Though important for the construction of
    internets with end-to-end QoS support, this is an
    area of ongoing research that currently lacks
    approved standards

42
Advanced Ethernet Features Traffic Classes
Quality of Service
  • The Final Word on Traffic Classes
  • Remember there is a difference between Quality
    of Service and Class(es) of Service
  • Quality of Service provides or tries to guarantee
    the system/network will provide certain agreed
    upon service levels
  • Minimum bandwidth
  • Maximum Delay
  • With Classes of Services there are not
    guarantees per say

43
Advanced Ethernet Features Port Authentication
  • Introduction
  • Once upon a time the Internet was a friendly
    place
  • There was not much worry about security nowadays
    that is obviously not the case
  • The IEEE saw the need to secure the edge of the
    network as a key security weakness
  • Main targets
  • Wireless networks (IEEE 802.11)
  • Edge Ethernet ports

44
Advanced Ethernet Features Port Authentication
  • IEEE 802.1x
  • A working group was established to address edge
    security and develop a standard solution (Sum
    2001)
  • Solution is not Ethernet-specific, but it has
    been adopted mainly for securing 802.3 802.11
    (WLANs)
  • General Operation
  • IEEE 802.1x allows a network device (switch) to
    query and authenticate a node before allowing
    network access
  • Supported on Win XP and CE nodes third-party
    add-ins for other operating systems
  • If the 802.1x-capable device does not hold
    authentication information, it must have some
    back-end access to an authentication server
    (via another authentication protocol such as
    RADIUS or TACACs)

45
Advanced Ethernet Features Port Authentication
  • IEEE 802.1x Operation
  • Allows authentication via username/password or
    some other user-based credentials
  • Uses EAPOL (Extensible Authentication Protocol
    over LAN) for the node (802.1x Supplicant) to
    exchange authentication data with the switch
    (802.1x Authenticator)
  • EAPOL adapted from earlier authentication
    protocols developed for PPP (Point-to-Point
    Protocol)
  • Port remains locked until successful
    authentication occurs
  • Some vendors support more advanced features based
    on 802.1x (VLAN selection), but this is not part
    of the standard

46
Advanced Ethernet Features Port Authentication
  • IEEE 802.1x Operation

47
Advanced Ethernet Features Port Authentication
  • IEEE 802.1x Operation (2)

48
Advanced Ethernet Features Port Authentication
  • IEEE 802.1x Operation (3)

49
IEEE 802.3 Family of LAN ProtocolsHomework
Reading
  • Homework 3 - Due at Class 6 in two weeks
  • Chapter 7 7.2, 7.7
  • Additional Question (5 points) download
    Ethereal (www.ethereal.com) or an equivalent
    sniffer program and install on a PC you have
    access to and permission to use. Capture a web
    session in a file (at least getting a couple of
    different pages) and explain what traffic you
    see. If any frames appear that are not part of
    the web session explain why they are there.
  • Complete Lab1 in the OPNet Lab Manual, submit
    your answers to the questions at the end of the
    Lab
  • Reading
  • This weeks material Stallings chapters 7 and
    12.5
  • Next week Chapter 8, 9, and 10
Write a Comment
User Comments (0)
About PowerShow.com
