An Embedded Software Primer

1
An Embedded Software Primer

• David E. Simon

2
Chapter 5 Survey of Software Architectures

1. Round-Robin
2. Round-Robin with Interrupts
3. Function-Queue-Scheduling Architecture
4. Real-Time Operating System Architecture
5. Selecting an Architecture

3
Round-Robin

• The following code (Fig. 5.1 Simon) illustrates a
  round-robin where the code checks each I/O device
  in turn and services them as needed.

4
Round-Robin (contd.)

• This is the simplest architecture devoid of
  interrupts or shared-data concerns.
• A digital multimeter illustrates this.
• A pseudo-code written for it would consist of a
  switch-case loop that performs functions based on
  the position of the rotary switch.
• However several problems offset its simplicity
  advantage-
• If a device has a lower response time this
  architecture wont work.
• e.g. if in Fig. 5.1 device Z has a deadline of
  15 ms and A and B take 10 ms each.
• If any one of the cases for the multimeter could
  at the worst take 5 seconds, the system would
  have a max. response time of 5 seconds, which
  would make it less appealing.
• Architecture is not robust. Addition of a single
  device might cause all deadlines to be missed.

5
Round-Robin with Interrupts

• Fig. 5.4 shows a round-robin with interrupts.

6
Round-Robin with Interrupts (contd.)

• ISRs called by each device set flags. These are
  in turn polled by the main program that then does
  the required follow-up processing.
• ISRs can be assigned priorities as per the
  requirements giving better response especially
  for devices with hard deadlines.
• The disadvantage is the complexity of having to
  work with the shared-data variables.
• Examples
• A Simple Bridge
• A communication bridge is a simple example that
  passes data between 2 ports.
• Assume the bridge encrypts data at one port and
  decrypts it at the other (Fig. 5.6).

7
Round-Robin with Interrupts (contd.)
8
Round-Robin with Interrupts (contd.)

• A character received at one of the bridge links
  causes an interrupt that must be serviced before
  the next character arrives.
• The link will be busy while sending a character
  after which it will interrupt the microprocessor
  to indicate it is ready for the next character.
• Routines read and write characters to queues and
  check whether the queues is empty or not.
• Encryption and decryption is handled by routines.
• Fig. 5.7 shows the code.
• Transmitting and receiving characters on links A
  and B are handled by separate ISRs.
• vEncrypt and vDecrypt in main read the data
  queues and pass the processed data to
  qDataToLinkA and qDataToLinkB.
• fLinkAReadyToSend and fLinkBReadyToSend track
  whether I/O is ready to send characters.
• Note that shared-data sections are made atomic.
• As reading and writing is done in ISRs, these
  have higher priority than the encryption or
  decryption, so a sudden character burst will not
  cause system overruns.

9
Round-Robin with Interrupts (contd.)
10
Round-Robin with Interrupts (contd.)

• Characteristics of the Round-Robin with
  Interrupts
• The main shortcoming of this architecture is that
  all the task code executes with the same
  priority.
• If devices A,B and C in fig. 5.4 take 200 ms, C
  will have to wait 400 ms.
• This can be avoided by moving Cs task code to
  the ISR at the expense of increased interrupt
  latency of lower priority devices.
• Another solution is to check Cs flag more often
  like A,C,B,C,D,C.......
• The worst-case response for a device task-code
  occurs when the its interrupt occurs immediately
  after main passes its task code.
• Examples where this architecture does not work
  are -
• A laser printer. Calculating locations for the
  black dots is time consuming so only ISRs will
  get good response. If task codes are moved into
  ISRs low priority interrupts will not be serviced
  fast enough.
• Underground tank monitoring system. The code that
  calculates the gasoline amount hogs the
  processor.

11
Function-Queue-Scheduling Architecture

• Fig. 5.8 shows an implementation of this
  architecture.

12
Function-Queue-Scheduling Architecture (contd.)

• The ISRs add function pointers to a queue for
  main to call.
• Main can call the functions based on a preset
  priority providing better response times for
  higher priority tasks
• The worst-case response (WCR) for the highest
  priority task is equal to the longest task code
  function assuming that it started just before the
  ISR put the function pointer for the highest
  priority task in the queue.
• This is much better than the round-robin-with-inte
  rrupts which has a WCR equal to the sum of all
  the task codes for the other devices.
• A disadvantage of the architecture apart from the
  complexity involved is that a high priority task
  might hog the processor, and a lower priority
  task might never get to execute.

13
Real-Time Operating System Architecture

• Fig. 5.9 shows the operation.

14
Real-Time Operating System Architecture (contd.)

• Again ISRs handle important sections.
• Some differences from previous architectures are
  -
• The real-time operating system (RTOS) handles
  communications between ISRs and task codes.
• The RTOS will decide which task code to run based
  on urgency (priority)
• RTOS can suspend a task to run another (usually
  higher priority) one.
• If an ISR sets a flag for a higher priority task
  the RTOS runs the task immediately on return even
  if it is in the middle of another lower priority
  one.
• Hence the worst-case response is zero.
• Response is basically independent of task code
  length unlike previous architectures. Changes to
  code lengths of low priority tasks dont affect
  higher priority tasks.
• One disadvantage might be the added RTOS
  processing time.

15
Selecting an Architecture

• Select the simplest architecture meeting response
  requirements.
• RTOSs should be used where response requirements
  demand them.
• Hybrid architectures can be used if required.
  e.g. you can use an RTOS with a low-priority task
  polling the relatively slower hardware.
