VMware Infrastructure

• Alex Dementsov
• Tao Yang

Clarkson University Feb 28, 2007
2
Vmware Infrastructure 3

• ESX server
• Platform for virtualizing servers,storage and
  networking
• VMFS
• High-performance cluster file system for storage
  virtualizatio
• Virtual SMP
• Multi-processor support for virtual machines
• VirtualCenter Server
• Centralized management automation and
  optimization for IT infrastructure
• High Availability (HA)
• Cost effective high availability for virtual
  machines
• DRS (Distributed Resource Scheduler )
• Dynamic balancing and allocation of resources
  for virtual machines
• VMotion
• Live migration of virtual machines without
  service interruption
• Consolidated Backup
• Centralized backup software for virtual machines

3
Before installation

• Hardware Requirement
• 1 At least two processors of one of the
  following types
• 1500MHz Intel Xeon and later, or AMD
  Opteron (32-bit mode)
• 1500MHz Intel Viiv or AMD A64 x2
  dual-core processors
• 2 1GB RAM minimum
• 3 One or more Ethernet controllers
• 4 A SCSI disk, Fibre Channel LUN, or RAID
  LUN with unpartitioned space
• Do not support IDE and SATA disk, though Esx
  can install on PC, you can get the support from
  the pcs disk storage.

4
Glance at Vmware Infrastructure3

• Windows-oriented system

5
Installation

• Install on the raw hardware
• rooted from the IDE device such as
• cd- rom, IDE hard disk.
• graphic interface /text interface
• if (graphic interface)
• like windows os

6
Client Installation

• Required windows operation system,
• .NET framework 1.1, and for more reliability
  install the service pack 1 for .NET framework 1.1

7
ESX Server Configuration

• Permission for install Guest os
• connect
• two general kinds of group and person

8
Guest OS Installation
9
ESX Server Features

• Bare-metal architecture
• CPU virtualization
• Virtualization for storage
• Virtualization for Networking
• Security

10
Networking
11
Network services

• Virtual machines
• VMkernel
• Service console

12
Storage
Storage devices

• Local
• Fibre Channel
• iSCSI (hardware initiated)
• iSCSI (software initiated)
• Network file system (NFS)

13
Security
14
VMware HA

• Failure management

HA - High Availability
15
VMware DRS

• Workload distribution

DRS - Distributed Resource Scheduler
16
VMware VMotion

• Live migration of VMs

17
Screenshots NetWare 6.5
18
Screenshots Solaris 10
