IP Spoofing

1
IP Spoofing

•

  BY
• ASHISH KUMAR

• BT
  IT
• UNDER GUIDANCE
  OF
• MRS.ASHA
  JYOTI
•


2
IP SPOOFING ?

• IP Spoofing is a technique used to gain
  unauthorized access to computers.
• IP Internet Protocol
• Spoofing using somebody elses information
• Exploits the trust relationships
• Intruder sends messages to a computer with an IP
  address of a trusted host.

3
IP SPOOFING
4
WHY IP SPOOFING IS EASY ?

• Problem with the Routers.
• Routers look at Destination addresses only.
• Authentication based on Source addresses only.
• To change source address field in IP header field
  is easy

5
IP SPOOFING STEPS

• Selecting a target host (the victim)
• Identify a host that the target trust
• Disable the trusted host, sampled the targets
  TCP sequence
• The trusted host is impersonated and the ISN
  forged.
• Connection attempt to a service that only
  requires address-based authentication.
• If successfully connected, executes a simple
  command to leave a backdoor.

6
Spoofing Attacks

• Spoofing is classified into -
• 1. Non-blind spoofing
• This attack takes place when the attacker is
  on the same subnet as the target that could see
  sequence and acknowledgement of packets.

7
CONTD

• 2. Blind spoofing
• This attack may take place from outside where
  sequence and acknowledgement numbers are
  unreachable. Attackers usually send several
  packets to the target machine in order to sample
  sequence numbers, which is doable in older days .

8
COTND

• 3. Denial of Service Attack
• IP spoofing is almost always used in denial
• of service attacks (DoS), in which attackers
• are concerned with consuming bandwidth
• and resources by flooding the target with as
• many packets as possible in a short amount
• of time.

9
CONTD

• 4. SMURF ATTACK
• Send ICMP ping packet with spoofed IP source
  address to a LAN which will broadcast to all
  hosts on the LAN
• Each host will send a reply packet to the spoofed
  IP address leading to denial of service

10
CONTD

• 5. Man - in - the middle
• Packet sniffs on link between the two
• endpoints, and therefore can pretend to
• be one end of the connection.

11
Detection of IP Spoofing

• 1. If you monitor packets using
  network-monitoring software such as netlog, look
  for a packet on your external interface that has
  both its source and destination IP addresses in
  your local domain. If you find one, you are
  currently under attack.

12
Detection of IP Spoofing

• 2. Another way to detect IP spoofing is to
  compare the process accounting logs between
  systems on your internal network. If the IP
  spoofing attack has succeeded on one of your
  systems, you may get a log entry on the victim
  machine showing a remote access on the apparent
  source machine, there will be no corresponding
  entry for initiating that remote access .

13
IP-Spoofing Counter-measures

• No insecure authenticated services
• Disable commands like ping
• Use encryption
• Strengthen TCP/IP protocol
• Firewall
• IP trace back

14
IP Trace-back

• To trace back as close to the attackers location
  as possible
• Limited in reliability and efficiency
• Require cooperation of many other network
  operators along the routing path
• Generally does not receive much attention from
  network operators

15
Misconception of IP Spoofing

• A common misconception is that "IP Spoofing" can
• be used to hide your IP address while surfing the
• Internet, chatting on-line, sending e-mail, and
  so
• forth.
• This is generally not true. Forging the source IP
• address causes the responses to be misdirected,
• meaning you cannot create a normal network
• connection. However, IP spoofing is an integral
  part of
• many networks that do not need to see responses.

16
IP-Spoofing Facts

• IP protocol is inherently weak
• Makes no assumption about sender/recipient
• Nodes on path do not check senders identity
• There is no way to completely eliminate IP
  spoofing
• Can only reduce the possibility of attack

17
Applications

• Asymmetric routing (Splitting routing)
• SAT DSL
• NAT
• IP Masquerade

18
ADVANTAGES

• Multiple Servers
• Sometimes you want to change where packets
  heading into your network will go. Frequently
  this is because you have only one IP address, but
  you want people to be able to get into the boxes
  behind the one with the real' IP address.

19
ADVANTAGES

• Transparent Proxying
• Sometimes you want to pretend that each packet
  which passes through your Linux box is destined
  for a program on the Linux box itself. This is
  used to make transparent proxies a proxy is a
  program which stands between your network and the
  outside world, shuffling communication between
  the two. The transparent part is because your
  network won't even know it's talking to a proxy,
  unless of course, the proxy doesn't work.

20
DISADVANTAGES

• Blind to Replies
• A drawback to ip source address spoofing is
  that reply packet will go back to the spoofed ip
  address rather than to the attacker. This is fine
  for many type of attack packet. However in the
  scanning attack as we will see next the attacker
  may need to see replies .in such cases ,the
  attacker can not use ip address spoofing .

21
DISADVANTAGE

• Serial attack platforms
• However, the attacker can still maintain
  anonymity by taking over a chain of attack hosts.
  The attacker attacks the target victim using a
  point host-the last host in the attack chain
  .Even if authorities learn the point hosts
  identity .They might not be able to track the
  attack through the chain of attack hosts all the
  way back to the attackers base host.

22
CONCLUSION

• IP spoofing attacks is unavoidable.
• Understanding how and why spoofing attacks are
  used, combined with a few simple prevention
  methods, can help protect your network from these
  malicious cloaking and cracking techniques.

23
References

• IP-spoofing Demystified (Trust-Relationship
  Exploitation), www.networkcommand.com/docs/ipspoof
  .txt
• Introduction to IP Spoofing, Victor Velasco,
  www.sans.org/rr/threats/intro_spoofing.php
• Internet Vulnerabilities Related to TCP/IP and
  T/TCP, ACM SIGCOMM, Computer Communication Review
• IP Spoofing, www.linuxgazette.com/issue63/sharma.h
  tml
• FreeBSD IP Spoofing, www.securityfocus.com/advisor
  ies/2703
• IP Spoofing Attacks and Hijacked Terminal
  Connections, www.cert.org/advisories/CA-1995-01.ht
  ml
• Network support for IP trace-back
• Web Spoofing. An Internet Con Game,
  http//bau2.uibk.ac.at/matic/spoofing.htm

24

• THANK YOU !
