Title: Airmux-200%20%20Version%201.750%20GA


1
Airmux-200 Version 1.750 GA
  •

2
Airmux-200 in Brief
  • Airmux-200 is a point-to-point
    multi point-to-point radio solution for combined
    TDM and Ethernet traffic over license free
    frequencies

3
Agenda
  • Benefits, Product Highlights and Configurations
  • Version 1.750 New Products and Features
  • Product Architecture
  • Applications
  • Sales Tools

4
Airmux-200 Benefits
  • Excellent price/performance in the industry -
    Fast ROI
  • Combination of up to 4 x E1/T1 plus Ethernet,
    with high traffic throughput
  • High link availability with carrier-class
    performance
  • Service stability avoiding interferences with
    adaptive modulation
  • Reduction of deployment time and expenses as part
    of a complete interoperable solution with other
    RAD devices (e.g. Megaplex Multiservice Access
    Multiplexers)?
  • Enhanced Air Interface security using Advanced
    Encryption System (AES) with a 128-bit encryption
    key

5
Airmux-200 Benefits (contd)?
  • Radio density increase by supporting various
    channel bandwidth (5,10,20 MHz)?
  • Management of hundreds of links and access
    devices from
  • a single SNMP fault management application
  • Easy deployment via installation and alignment
    tools

6
AirMux-200 Highlights
  • Combination of E1 or T1 and Ethernet
  • Up to 4 x E1 or 4 x T1 Ethernet (IDU E)?
  • Up to 48Mbps air throughput - Function of
    distance, net payload is 18.3 Mbps FDX
  • Range up to 80km/50 miles for Ethernet services
    only
  • RADview SNMP network fault management
  • Robust and reliable Telco-Grade
  • Easy and fast installation
  • Compliant with FCC, ETSI, CSA
  • OFDM based air-interface, enabling N-LOS
    deployments

7
AirMux-200 Highlights (Contd)?
  • Solutions in Various Frequency Bands
  • 2.300 2.400 GHz
  • 2.400 - 2.4835 GHz
  • 2.500 - 2.690 GHz
  • 4.940 - 4.990 GHz
  • 5.250 - 5.350 GHz
  • 5.470 - 5.725 GHz
  • 5.725 - 5.850 GHz
  • 5.850 - 5.950 GHz

8
Airmux-200Various Products Configurations (1/2)?
  • Airmux 200 AIND (All-indoor Configuration)?
  • Combines the IDU and ODU in a single enclosure.
  • Supports 4T1 ETH with 5.8GHz FCC, designed for
    the US market
  • Airmux-200 L
  • Low price POE link for Ethernet services only,
    enables improved position versus low end
    competitors.
  • Frequencies 2.4 FCC, 2.4 High Power, 5.8 FCC
  • Throughput 2 Mbps full duplex
  • Max Range 20 Km
  • Channel BW 5 MHz
  • Transmit Power 18dBm max

9
Airmux-200Various Products Configurations (2/2)?
  • Airmux-200 LC (Collocation)?
  • Airmux 200 L with hardware-ready Collocation
    capabilities
  • Enables Airmux 200 L collocations at a central
    site, using burst synchronization pulses, thus
    reducing mutual interference
  • The burst synchronization feature is managed by
    the Hub Site Synchronization Unit (HSSU)?

10
Version 1.750 Products and Features
11
Version 1.750 New ProductsHub Site
Synchronization (HSS)?
  • All ODU High End (ODU-HE), All-Indoor (AIND) and
    Airmux 200L products are supported
  • HSS enables collocation of radios by eliminating
    interference
  • HSS ensures simultaneous data transmission for
    all collocated radios, thus eliminating the
    possible interference which occurs if different
    ODUs at the same site transmit and receive
  • A mix of channel BW, frequencies and services is
    allowed
  • Supports up to 16 collocated units
  • Requires HSS Unit and Sync cables

Hub Site
Ethernet and Power over CAT 5 from ODU to PoE
Cable for Hub Site Synchronization
OD Units
12
Version 1.750 New ProductsIDU-R
  • IDU-R provides a backup link for E1/T1
    connections
  • Maintains continuous link operation link
  • Upon failure of the primary connection, IDU-R
    switches automatically to backup
  • The air-interface can be defined as primary or
    backup link
  • Operates with all Airmux-200 outdoor units
    portfolio

Airmux-200
Airmux-200
E1/T1
E1/T1
Leased Line
IDU-R
IDU-R
13
Version 1.750 New ProductsPOE-8 ODU-High
End
  • POE-8
  • Feeds up to 8 ODUs from a single indoor unit
    instead of using 8 separate indoor PoE devices
  • Supports both AC and DC (-20 to -60V)?
  • ODU High End (HE)?
  • The ODU-HE
  • Supports Hub Site Synchronization (HSS)?
  • Transmits higher Tx Power for some frequencies
  • Operates with IDU and PoE devices

14
Airmux-200Version 1.750 - Features
  • Management
  • Service pricing flexibility enabled by Ethernet
    throughput configuration in steps of 1Kbps
  • Telnet CLI (Command Line Interface) supported for
    the entire portfolio - supports local ODU
    configuration monitoring
  • New Frequency
  • 2.5 GHz BRS
  • Limitation
  • The SW version at both ends of a link must be the
    same

15
System Basic Architecture
Up to 48 Mb/s Up to 80 Km
ODU
ODU
100Mb/s Up to 100m CAT5e Cable
100Mb/s Up to 100m CAT5e Cable
IDU
IDU-E
16
Airmux-200 System Components-IDUs
  • IDU Standard indoor unit
  • Ethernet
  • Ethernet E1 or T1
  • Ethernet 2 x E1 or 2 x T1
  • IDU E Carrier-class indoor unit
  • 2 x Ethernet 4 x E1 or 4 x T1

17
IDU Performance
  • Jitter and wander according to G.823.4
  • Clock recovery (lt0.05 PPM)?
  • E1 typical delay is 8 msec
  • TDM circuit BER lt 10e-11 _at_ sensitivity threshold
  • Ethernet delay less then 3 msec
  • Lossless Ethernet traffic Even in 10 Air
    interface loss still there will be no ETH packet
    loss
  • Lossless TDM traffic future (2Q 2007)?
  • Unit size One U

18
Typical Application
HQ
Remote Site
Packet
Up to 80 km/ 50 miles
Switch
Switch
Server
LAN
LAN
V24
PBX
Megaplex
AirMux-200
AirMux-200
n x E1
n x E1
n x FXS
V.35
PSTN
Router
  • Main Drivers
  • Fast ROI versus leased lines
  • Fast deployment and equipment reuse
  • Broadband infrastructure enabler
  • Backup for terrestrial lines

19
Cellular Backhaul Applications
Temporary Backhaul
Rural Area Deployment
Urban Area Deployment
NLOS Backhauling
Intermediate Backhaul
Access Service
Backhaul to Low ARPU Areas
Backup to Wired Backhaul
20
Cellular Backhaul Applications
  • Alternative to Leased Lines
  • Complementing existing networks in Rural Areas
  • Remote communities locations
  • Low ARPU communities
  • Hard to reach locations and NLOS scenarios
  • Overlay to network coverage in Urban Areas
  • Enhance coverage and capacity
  • Providing service to low-ARPU locations in the
    city
  • Hard to reach locations Problematic trenching
    or N-LOS scenarios
  • NLOS scenarios
  • Addressing peak hours requirements and temporary
    events
  • 3G ramp-up (More base stations More capacity per
    site Street-level locations)?
  • Intermediate backhaul
  • Backup

21
Fixed Access by Cellular Operators
  • Leverage existing cellular infrastructure to
    deliver fixed access services
  • Connectivity from the BTS to the customer site
  • Additional revenue stream for the carrier

22
Broadband Access
  • Expand broadband data and voice to rural and
    underserved markets
  • Eliminate costly rollout investments and speed
    time to market
  • Telco grade Long range High capacity (x 10
    more than leased line)?

23
AirMux-200 Applications with RAD Products
  • AirMux-200 provides a high ROI in a variety of
    campus, enterprise and service provider
    applications.
  • These include
  • Lossless Hot Spot Backhauling
  • Telephone Service Extension to Remote/Rural
    Locations
  • Multiple Services in Daisy Chain Topology
  • Multiple Services with Unique E1/T1 Ring
    Protection
  • Emergency Services and Temporary Deployment
  • Wireless Backup
  • Interconnecting Multiple Legacy Services over
    Packet Networks
  • Cellular Backhaul
  • Voice Traffic Extension over Wireless

24
1 .Lossless Hot Spot Backhauling
ISP
Hot Spot
5.8 GHz
Ethernet
Ethernet
Packet
Access Point
AirMux-200
AirMux-200
Router
  • Supports full 5.8 GHz for lossless hot spot
    backhauling including band and channel separation
  • Transparent Ethernet forwarding
  • Ethernet and power over Ethernet ODU/IDU
    connection

25
2. Telephone Service Extension to Remote/Rural
Locations
Remote/Rural Location
Central Site
5.8 GHz
CPE
MP-104/204
E1
AirMux-200
E1
AirMux-200
MP-2104/2100
Remote/Rural Location
PSTN
5.8 GHz
E1
CPE
MP-104/204
AirMux-200
E1
AirMux-200
  • Extends telephony services to remote or rural
    areas
  • Megaplex units serve as channel banks at the
    remote end, and as aggregation devices at the
    center

26
3. Multiple Services in Daisy Chain Topology
AirMux-200
AirMux-200
AirMux-200
AirMux-200
MP-2104
FCD-IP
MP-2104
FCD-IP
V.52
  • Drop-and-insert topology saves cost of lease
    lines or infrastructure investment
  • Drop of any service
  • Optimized solution for specific node requirements
  • Target markets utilities, cellular,
    transportation

27
4. Multiple Services with Unique E1/T1 Ring
Protection
Fire Alarm
FCD-IP
MP-2104
4 x E1/T1 Ring
  • Typical users
  • Campus
  • Cellular
  • Utilities
  • Unique ring protection
  • Optimized solution for specific node requirements
  • Any service

28
5.Emergency Services and Temporary Deployment
Central Site
AirMux-200
Remote Site
n x links
Switch
Switch
Megaplex
AirMux-200
AirMux-200
n x E1
DXC
  • Enables mobility and fast deployment
  • Typical users military, emergency services,
    broadcast, etc.

29
6. Wireless Backup
Site B
Site A
AirMux
AirMux
CPE
CPE
DXC
DXC
G.703
G.703
Copper
RADview NMS
  • Automatic switch-over with DXC
  • Typical users financial organizations,
    government, military

30
7.Interconnecting Multiple Legacy Services over
Packet Networks
Router
AirMux-200
V.35
IPmux-14
AirMux-200
Ethernet
LAN
Gmux 2000
Ethernet Services
Ethernet
E1/T1
PBX
n x E1/T1
Ethernet over Fiber Cable PLC
IPmux-14
Ethernet
LAN
NMS
  • End-to-end transmission of multiple user services
    over IP, with central demarcation and aggregation
    IPmux units
  • Adds Ethernet traffic engineering tools such as
    rate limiting and VLAN stacking
  • End-to-end service provisioning with
    RADview-SC/TDMoIP

31
8. Cellular Backhaul
BTS Site
BTS
BSC Site
AirMux-200
n x E1
Switch
10/100BT
AirMux-200
Packet
BSC
n x links
BTS Site
TDM
Optimux 34
BTS
E3
n x E1
AirMux-200
Ethernet
AirMux-200
  • Integration of cellular, monitoring and
    management traffic
  • Future migration to IP 3G BTS
  • Cost-effective alternative to Microwaves
  • High link availability
  • 0.05 ppm clock recovery
  • 8 msec E1 or T1 delay
  • 3 msec Ethernet delay

32
9. Voice Traffic Extension over Wireless
Branch 1
PBX
Up to 80 km/ 50 miles
E1/T1
Vmux-110
AirMux-200
AirMux-200
Headquarters
Vmux-2100
Branch 2
PBX
E1/T1
Vmux-110
IP or E1/T1
Router
E1/T1
IP / TDM Network
PBX
E1/T1
PSTN
  • High link utilization with up to 161 compression
    ratio
  • Enables extending E1 or T1 over IP for up to 80
    km/50 miles

33
Airmux 200 Sales Tools
  • Marketing
  • Presentation
  • Airmux Brochure
  • Airmux 200 Product Profile
  • Airmux POE Product Profile
  • Datasheet
  • 3 Case Studies
  • 6 Application Notes
  • Technical
  • A total of 25 certificates and safety declarations

34
Thank You
For your attention
www.rad.com
Write a Comment
User Comments (0)
About PowerShow.com
